Philips SA159/02 Bedienungsanleitung

16/18

user manual

manuel d’utilisation | benutzerhandbuch | manual del usuario

gebruikershandleiding | manuale per l'utente | manual do usuário

användar-handbok

Digital Audio Player

Lecteur audio numérique | Digitaler Audio-Player | Reproductor de audio digital

Digitale audiospeler | Lettore audio digitale | Leitor Áudio Digital

Digital ljudspelare

sa150 COVER 1 8/23/05 10:25 AM Page 1

We hope you enjoy your product

Please visit www.philips.com/support and enter your product name to view:

- FAQ, Frequently Asked Questions

- Latest user manuals

- Latest PC software downloads

- Firmware upgrade files

Since it is possible for you to upgrade your product,

we recommend that you register your product on

www.philips.com/register

so we can inform you as soon as new free upgrades become available.

The model and production numbers can be found on the label close to the USB connector.

About your new product

With your newly purchased product, you can enjoy MP3 and WMA music playback

(see MUSIC MODE section)

Included accessories

-Headphones

-USB adaptor

-Neck-strap

-CDROM with user manual, drivers,

FAQ, music management softwares

SA150_ENG.qxd 8/24/05 10:40 AM Page 1

16/18

Overview of controls and connections

1pHeadphones jack

2+ / - Volume control

3EQ Select Equalizer; Repeat or loop a sequence

MENU For menu options

J( / )K Rewind / Fast forward; Up / Down to 1 level

2; Power on / off and Play / Pause; confirms a menu setting

4Display Dynamically displays menu, options and track information

5USB USB cable connector

6HOLD Disable key press

7Battery door Open to insert battery

SA150_ENG.qxd 8/24/05 10:40 AM Page 2

Preparations

Install software

1Insert the supplied CD into your computer's CD-ROM drive.

If the CD does not autorun, please click the .exe file from the root directory of the CD.

2Select your language and follow screen instructions to complete installation of

MusicmatchRJukebox and Firmware Manager.

Organize and transfer your music

Your player will appear as a new USB mass storage in Windows Explorer.

You can organize files and transfer music to your device during USB connection.

1Click and highlight one or more music track to transfer between your player and your computer.

2Use drag and drop actions to complete your transfer.

3You can also transfer your digital music collection from your computer to your device through

MusicmatchRJukebox.

Safely disconnect your device

Exit any active application working with your player. Safely remove your device by clicking

from your task tray.

WINDOWS98SE USERS:There is no icon.

Simply disconnect your device after file transfer completes.

(File transfer completes when stops animating.)

ATTENTION!

WINDOWS 98SE USERS:

To avoid installation problems, DO NOT CONNECT your device to the computer

until AFTER installation completes.

SA150_ENG.qxd 8/24/05 10:40 AM Page 3

About Batteries

You can use the following batteries with your device:

- normal batteries type LR03, UM4 or AAA (preferably Philips); or

- alkaline batteries type LR03, UM4 or AAA (preferably Philips); or

- rechargeable batteries type LR03, UM4 or AAA (preferably Philips)

Note: Remove batteries if they are empty or if the player is not going to be used for a long time.

Inserting batteries

Open the battery compartment. Insert batteries with correct polarity.

Powering on / off

Power on: Press and hold 2; until the PHILIPS splash screen appears.

Power off: Press and hold 2; again until there is no display on the screen.

TIP

Your device automatically powers down if there is no operation and no music played for

the duration defined in SETTINGS > TIME OUT.

✔

Indication of power level

You can see the approximate power level of your batteries on the display.

Battery full Battery two-thirds full

Battery half full Battery low

Battery empty

TIP

When the batteries are nearly empty, the battery low screen blinks.

Your device will power down in less than 60 seconds.

Your device will save all settings and un-finished recordings before it powers down.

✔

SA150_ENG.qxd 8/24/05 10:40 AM Page 4

MUSIC mode: Playback

Turn on the digital audio player and enter the Music library.

Your device will play all your music alphabetically in the music library as you press 2;.

Go to next track Press )K

Go to previous track Press J(

Pause music Press 2; during playback

Forward search Press and hold )K

Backward search Press and hold J(

Volume control + / -

Basic Operation Controls to press

SA150_ENG.qxd 8/24/05 10:40 AM Page 5

A-B REPEAT

To repeat or loop a sequence in a track:

1During playback mode, press EQ at your chosen starting point;

➔appears on the screen.

2Press EQ again at your chosen end point;

➔appears on the screen, and the repeat sequence begins.

Advanced features in playback

PLAY MODES

Changing play modes

1Press MENU . Select Playmodes.

2Use scroll controls to select the following options.

Off Normal playback

Repeat once Play one track repeatedly

Repeat all Play all tracks repeatedly

Shuffle Play all tracks randomly

Shuffle repeat Play all tracks randomly and repeatedly

Icon Meaning

Playmodes Off / Repeat once / Repeat all / Shuffle / Shuffle repeat

Scroll speed Low / Off / High / Medium

Delete

General settings Time out / Sleep timer / Resume / Backlight / Contrast /

Language / Information / Factory settings

Setting Options

EQUALIZERS

You can set your device to play music tracks with different EQ (equalizers).

Changing equalizers

1During playback mode, press EQ.

2Toggle to select Rock,Funk,Jazz,Classic,Hip-Hop, Dance or Off.

You can hear different music effect when toggling.

Press MENU. Use scroll controls to select the following options:

SA150_ENG.qxd 8/24/05 10:40 AM Page 6

Customizing settings

1 Press MENU for settings options. Select "General settings"

2Press J( to scroll up or )K to scroll down for your option.

3Press 2; to confirm your selection.

4Press MENU or J( to exit the existing settings screens.

Time out 3 min / 5 min / 10 min / 30 min / Off

Sleep timer Off / 15 min / 30 min / 45 min / 60 min

Resume Off / On

Backlight 10 sec / 30 sec / 60 sec / Always on / Off

Contrast Levels 1-6

Language English / Français / Deutsch / Español / Italiano / Português

Nederlands / Svenska / Polski

Information FW version / Memory available

Factory settings Restore Factory settings

Setting Options

TIP

- Options for each setting are shown on the device display.

- Available settings vary with selected mode.

✔

SA150_ENG.qxd 8/24/05 10:40 AM Page 7

About Firmware Manager

Your device is controlled by an internal program called firmware. With Firmware Manager, you can

update and restore your device with a few simple clicks.

Install Firmware Manager

1Insert the supplied CD into your computer’s CD-ROM drive.

2Follow screen instructions to begin and complete installation.

Update and restore firmware

1Insert the supplied CD into your computer’s CD-ROM drive.

2Install Firmware Manager from the supplied CD to your computer.

3Connect to the Internet. Launch Firmware Manager.

4Follow on screen instructions to complete firmware restore.

SA150_ENG.qxd 8/24/05 10:40 AM Page 8

Cannot power up Insert new batteries. Press 2; and power up the device.

In case of device error, connect your device to the

computer. Use Firmware Manager to restore your device.

Device shows "Memory Full" Connect your device to the computer. Delete unwanted files.

Unplug safely. Record again.

Symptom Solution

Troubleshooting

If a fault occurs, first check the points listed in the following pages. For further help and other

troubleshooting tips, please also check out FAQs at www.philips.com/support.

If you are unable to find a solution by following these hints, consult your dealer or service center.

WARNING:

Under no circumstances should you try to repair the set yourself, as this will invalidate

the warranty.

SA150_ENG.qxd 8/24/05 10:40 AM Page 9
