Philips SA4MIN02RF/97 Bedienungsanleitung

SA4MIN02

SA4MIN04

www.philips.com/welcome GoGEAR

www.philips.com/welcome

User manual

3EN

Contents

1 Important safety information 4

General maintenance 4

2 Your new player 6

What's in the box 6

PC software loaded on the player 6

Files loaded on the player 6

Overview 6

Controls 6

Home screen 7

Screen on/off 7

3 Get started 8

Charge power 8

Switch the player on or off 8

4 Music 9

Transfer your PC music library to the

player 9

      

Find music on the player 9

Find music by song information 9

     

Play music 9

Select play options 10

5 FM radio 11

Tune in to radio stations 11

Store preset stations 11

6 Recordings 12

Record audio/voices 12

Record from the FM radio 12

Listen to recordings 12

7 Folder view 13

8 Settings 14

Backlight 14

Language 14

Version 14

Reset 14

    

Philips Device Manager 15

10 Troubleshooting 17

11 Technical data 18

PC requirements 18

Need help?

Please visit www.philips.com/welcome where

you can access a full set of supporting materials

such as user manual, the latest software updates

and answers to frequently asked questions.

4EN

1 Important safety

information

General maintenance

The translation of this document is for

reference only.

In the event of any inconsistency between the

English version and the translated version, the

English version shall prevail.

Caution

 To avoid damage or malfunction:

 Do not expose the product to excessive heat caused

by heating equipment or direct sunlight.

 Do not drop the product or allow objects to fall on

your player.

 Do not allow the product to be submerged in

water. Do not expose headphone socket or battery

compartment to water, as water entering the set may

cause major damage.

 Active mobile phones in the vicinity may cause

interference.

          

         

responsible for any loss of data if the product becomes

damaged or not readable / legible.

         

the supplied music software to avoid problems.

 Do not use any cleaning agents containing alcohol,

ammonia, benzene, or abrasives as these may harm the

product.

About operating and storage temperatures

 Operate in a place where temperature is

always between 0 and 35ºC (32 to 95ºF)

 Store in a place where temperature is

always between 20 and 45ºC ( 4 to

113ºF).

 Battery life may be shortened in low

temperature conditions.

Replacement parts/accessories:

Visit www.philips.com/support to order

replacement parts/accessories.

Hearing Safety

The maximum output voltage of the player is

not greater than 150 mV.

Listen at a moderate volume:

Using headphones at a high volume can impair

your hearing.This product can produce sounds

in decibel ranges that may cause hearing loss for

a normal person, even for exposure less than

a minute.The higher decibel ranges are offered

for those that may have already experienced

some hearing loss.

Sound can be deceiving. Over time your hearing

'comfort level' adapts to higher volumes of

sound. So after prolonged listening, what sounds

'normal' can actually be loud and harmful to

your hearing.To guard against this, set your

volume to a safe level before your hearing

adapts and leave it there.

To establish a safe volume level:

Set your volume control at a low setting.

Slowly increase the sound until you can hear it

comfortably and clearly, without distortion.

Listen for reasonable periods of time:

Prolonged exposure to sound, even at normally

'safe' levels, can also cause hearing loss.

Be sure to use your equipment reasonably and

take appropriate breaks.

Be sure to observe the following guidelines

when using your headphones.

Listen at reasonable volumes for reasonable

periods of time.

Be careful not to adjust the volume as your

hearing adapts.

Do not turn up the volume so high that you

can’t hear what’s around you.

You should use caution or temporarily

discontinue use in potentially hazardous

situations.

5EN

Do not use headphones while operating a

motorized vehicle, cycling, skateboarding, etc.; it

         

areas.



    

manufacturer may void user's authority to

operate the product.

All other brands and product names are

trademarks of their respective companies or

organizations.

Unauthorized duplication of any recordings

whether downloaded from the Internet or

made from audio CDs is a violation of copyright

laws and international treaties.

The making of unauthorized copies of copy

protected material, including computer

    

recordings, may be an infringement of

copyrights and constitute a criminal offense.

This equipment should not be used for such

purposes.

The Windows Media and the Windows logo are

registered trademarks of Microsoft Corporation

in the United States and/or other countries.

Be responsible! Respect copyrights.

Philips respects the intellectual property of

others, and we ask our users to do the same.

Multimedia content on the internet may have

been created and/or distributed without the

original copyright owner's authorization.

Copying or distributing unauthorized content

may violate copyright laws in various countries

including yours.

Compliance with copyright laws remains your

responsibility.

The recording and transfer to the portable

player of video streams downloaded to your

computer is intended only for use with public

domain or properly licensed content.You

may only use such content for your private,

non commercial use and shall respect eventual

owner of the work. Such instruction may

state that no further copies shall be made.

Video streams may include copy protection

technology that prohibits further copying. For

such situations the recording function will not

        

Data logging

Philips is committed to improving the quality

of your product and enhancing the Philips user

     

this device, this device logs some info / data to

the non volatile memory region of the device.

These data are used to identify and detect

any failures or problems you as a user may

experience while using the device.The data

stored, for example, will be the duration of

playback in music mode, duration of playback

in turner mode, how many times battery low

was encountered, etc.The data stored do not

reveal the content or media used on the device

or the source of downloads.The data stored on

the device are retrieved and used ONLY if the

user returns the device to the Philips service

center and ONLY to simplify error detection

and prevention.The data stored shall be made

      

6EN

2 Your new player

What's in the box

Make sure that you have received the following

items:

Player

Earphones

Quick start guide

Safety and Warranty sheet

Note

 The images serve as reference only. Philips reserves the

right to change color/design without notice.

Ph ips GoGear a dio p ay r

Quick start guide

Safety andWarranty

Be o e u i g our set

Che k o t det i s ns de th s book et

PC software loaded on the player

MINI comes with the following PC software:

 Philips Device Manager (helps you get

   

To getPhilips Device Manageronline,

 On your PC, go to www.philips.com/

support.

Files loaded on the player

      MINI:

 User manual

 Frequently asked questions

Overview

Controls

 Press and hold: Switch the player on

or off

 Press: Go back one level, or exit

b /

 Press: Increase/decrease the volume

 Press and hold: Increase/decrease the

volume quickly

7EN

c /

on the list of options:

Press: Skip to the previous/next option

on the play screen:

Press: Skip to the next/previous option

Press and hold: Fast forward/rewind

  

 Press: Select options, or start/pause/

resume play

Press and hold: Show the options

d Display

e USB connector for power charging and

data transfer

f RESET

 Press the hole by using the tip of a

ball pen when the screen does not

respond to the pressing of keys

g MIC

 Microphone

 3.5 mm headphone connector

Home screen

Mode To

  

make voice recordings

tune in to the FM radio;

record from the FM radio

   

customize the settings of MINI

Navigate from the Home screen

 From the Home screen, you can access

functional menus by pressing the navigation

buttons / and .

 Press to go back one level or exit.

Screen on/off

To save power, the screen switches off

     

duration if

 no new action is taken on MINI.

To select the time duration

 Go to [Settings] > [Backlight].

To exit the power saving mode

 Press any key.

8EN

3 Get started

Charge power

MINI has a built in battery that can be charged

through the USB port of a computer.

1 Slide out the USB connector:

a Press the button to unlock the USB

connector.

b Slide out the USB connector.

2 Connect MINI to a PC

» You enter the transfer mode.

Switch the player on or off

Press and hold until the player is switched on

or off.

9EN

4 Music

Transfer your PC music

library to the player

You can transfer music from your PC media

library to MINI in the following way:

       

Explorer.

By doing so, you can organize your

    

       

Explorer,

1 Connect MINI to a PC.

» You enter the transfer mode.

2 On the PC, under My Computer or

Computer,

 Find MINI;

     

3        

folders to MINI.

     

     "

       

        

by the song information on MINI.

Launch media management software to check

      

Windows Media Player 11.

     "

       

folders as needed.

Find music on the player

Find music by song information

From the Home screen, go to   

by song title (meta data or ID3 tag) in different

folders.

#    "

 From the Home screen, go to  

   

 In , press and hold . Press /

and to select [Local folder].

Play music

1 Press or     

2 Press to start play.

» Play starts from current song.

» On the play screen, you can see the

    

3 During playback,

 Press to pause and resume play.

        

 Repeatedly press or .

To rewind or fast forward within current song

 On the play screen, press and hold

or .

10 EN

Select play options

During music play, press and hold to select

play options.

[Repeat]

[Normal]: Plays all the songs in

sequence.

[Repeat One]: Repeats current song.

[Repeat All]: Repeats all songs.

$%"&(: Plays all songs in random

order.

[Intro]: Plays each song in current

folder for 10 seconds.

[Equalizer]

     

11EN

5 FM radio

Note

 Plug in the supplied earphones when you tune in to

radio stations.The earphones double as antenna. For

better reception, move the earphone cable in different

directions.

Tune in to radio stations

Auto tune

         

Auto search to search for stations.

1 In , press and hold .Then, press

/ and to select [Auto Search].

» Available stations are stored as presets.

2 Press repeatedly to select a preset

station.

Tip

 When you move to a new place (such as a new city or

country), restart auto tune for better reception.

Manual tune

Use Manual tune to search for a frequency or

station.

 On the play screen, press and hold

or .

» You tune in to the next station from

current frequency.

     or

repeatedly.

Store preset stations

1 Tune in to a radio station.

2 On the radio play screen, press and hold

.Then, press / and to

select[Save].

» Current station is stored as a preset.

To remove current preset station

 On the radio play screen, press and

hold .Then, press / and

to select[Delete].

To remove all preset stations

 On the radio play screen, press and

hold .Then, press / and

to select[Delete all].

Andere Handbücher für SA4MIN02RF/97

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips MP3-Player Handbücher

Philips

Philips GoGear SA178 Bedienungsanleitung

Philips

Philips GoGear SA1ARA04K Bedienungsanleitung

Philips

Philips RUSH SA230 Bedienungsanleitung

Philips

Philips HDD6320/05 Bedienungsanleitung

Philips

Philips SA1200 - 512 MB Digital Player Bedienungsanleitung

Philips

Philips GoGear ViBE SA1VBE04P Bedienungsanleitung

Philips

Philips RUSH SA238 Bedienungsanleitung

Philips

Philips GO GEAR SA3RGA02 Bedienungsanleitung

Philips

Philips GoGear RaGa SA1926 Bedienungsanleitung

Philips

Philips GoGEAR SA4RGA02VN/97 Bedienungsanleitung

Philips

Philips GoGear SA2625 Bedienungsanleitung

Philips

Philips GoGear SA2CAM08K Bedienungsanleitung

Philips

Philips SA238/00 Bedienungsanleitung

Philips

Philips AZ1316/00C Betriebsanleitung

Philips

Philips SA4111 Bedienungsanleitung

Philips

Philips SA167/00 Bedienungsanleitung

Philips

Philips GoGear LUXE SA2422BT Bedienungsanleitung

Philips

Philips SA3020 - GoGear 2 GB Bedienungsanleitung

Philips

Philips GoGear SA1ARA16 16GB Bedienungsanleitung

Philips

Philips Nike MP3RUN Psa260 Bedienungsanleitung

Philips

Philips GoGEAR SA4VBE08 Bedienungsanleitung

Philips

Philips GoGear SA5285 Bedienungsanleitung

Philips

Philips AZ1816/55 Betriebsanleitung

Philips

Philips GOGEAR VIBE SA2VBE04RC Bedienungsanleitung

Beliebte MP3-Player Handbücher anderer Marken

Blaupunkt

Blaupunkt Compact Drive MP3 Bedienungsanleitung

Memorex

Memorex MMP9008 - 8GB USB 2.0 Bedienungsanleitung

Meizu Electronic Technology

Meizu Electronic Technology E5 Bedienungsanleitung

Naxa

Naxa NMV-173NX Bedienungsanleitung

Zipy

Zipy go! Waving Bedienungsanleitung

Sylvania

Sylvania SMPK4068 Bedienungsanleitung

Sony

Sony NW-MS7 - Memory Stick Walkman Bedienungsanleitung

Irradio

Irradio RF-42UC Bedienungsanleitung

NABAIJI

NABAIJI SWIM MUSIC 100 Bedienungsanleitung

Laser

Laser MP3-A9-4GB Bedienungsanleitung

Samsung

Samsung YP-T7F Bedienungsanleitung

Savant

Savant SMS-1001-00 Kurzanleitung

Trevi

Trevi XP 71 BT Bedienungsanleitung

AGPtek

AGPtek C2 Bedienungsanleitung

MobiBlu

MobiBlu DAH-1500i Bedienungsanleitung

Denver

Denver MPS-201 Bedienungsanleitung

Steren

Steren MP3-002 Bedienungsanleitung

Kenwood

Kenwood M1GD50 Bedienungsanleitung
