Philips BClever SV1 Bedienungsanleitung

multimedia projector

bCool SV1

Philips

User guide

English

Packaging contents 4

Optional accessories 5

Service accessories 5

6-9

Controls 6-7

Remote control 8

Connections 9

10-12

Positioning the projector and screen 10

Turning on the projector 10

Adjusting the focus and size of the image 11

Adjusting the vertical and horizontal angle of the projector 11

To raise the projector 11

To lower the projector 11

Keystone correction 11

Moving/transporting the projector 11

Preparation 11

Moving/transporting the projector 11

Inserting the batteries in the remote control 12

13-16

General information 13

Computer input 13

USB connection (Universal Serial Bus) 13

Video input 13

Connecting to a computer 14

Connecting to video equipment 15-16

CVBS (Video) 15

S-VHS (S-Video) 15

Scart connection 15

Component/HDTV (YPbPr/ YCbCr) 16

1. Introduction

2. Functional overview

3. Set up

4. Installation

Philips Multimedia Projector 2English User guide bCool SV1

Index

17-30

Preparation 17

General 17

Messages 17

General explanation 17

Feedback messages 17

Some examples 17

On Screen Display Menu 18-23

Menu tree 18-19

General explanation 20

Computer adjustments 21

Picture adjustments 21

Video series adjustments 21

Picture adjustments 21

General adjustments 22-23

'Features' adjustments 22

Setup adjustments 23

Theft deterrence - SecurityMax 24-30

What to do if... 24

Introduction 24

Setting up SecurityMax 25

Setting a Security code 25

Changing your Security code 26

Entering your personal start-up text 27

Setting the Shutdown timer 27

Unlocking the projector after shutdown 28

Update the shutdown timer 28

Disable the shutdown timer 29

Removing SecurityMax protection 30

Exit SecurityMax 30

31-33

Cleaning 31

Cleaning the cabinet 31

Cleaning the lens 31

Lamp 32

Lamp replacement 32

Resetting the lamplife time 33

34-36

End of life directives

Philips is paying a lot of attention to producing environmentally-friendly in green focal areas.

Your new product contains materials which can be recycled and reused. At the end of its life

specialised companies can dismantle the discarded product to concentrate the reusable

materials and to minimise the amount of materials to be disposed of.

Please ensure you dispose of your old product according to local regulations.

5. Operation

6. Maintenance

7.Troubleshooting

Philips Multimedia Projector 3English User guide bCool SV1

Index

Congratulations on your purchase.You have selected one of the most sophisticated and reliable

products on the market today. We are sure that when used properly, it will bring you years of

enjoyment.You will want to keep this manual available, as it is a convenient source of information

about your projector. For your own protection and prolonged operation of your projector, please

read the enclosed Safety Sheet. Make sure the following statement is on the Safety Sheet:

Please confirm that the following items are packed in the projector box.They are provided to

help you use or set up your projector.

Projector - Lens cap Remote control + batteries Mains Lead

Two AAA batteries

S-Video cable Composite Video cable VGA cable

USB cable Softbag Cable pouch

Quick set up Card and Cd-rom (with Projection

Safety Sheet Assistant, Warranty card,

SecurityMax, User Guide,

Spec. sheet and more.)

When moving this projector, you must prevent small metallic objects from entering

inside of the projector.This projector is not intended to be routinely carried.

This product may contain lead and mercury. Disposal of these materials may be

regulated due to environmental considerations. For disposal or recycling information,

please contact your local authorities or the Electronic Industries Alliance:

www.eiae.org

Packaging contents

WARNING

Philips Multimedia Projector 4English User guide bCool SV1

1. Introduction

VOolume

OKMenu

A/V Mute

Mute

D-ZoomD-FreezeSource

Mouse RIGHTLEFT RIightLeft

Standby

The following accessories are available from your dealer:

• LCA3126/00 - 180W replacement lamp - 8670 931 26009

• LCA2218/00 - Ceiling mount - 8670 922 18009

• LCA5311/00 - RCA/VGA component video adaptor cable - 8670 953 11009

The following accessories are available from our Service Organization:

• Laser pointer remote Control - 3139 228 62631

• Compact remote control - 3139 228 62641

• User Guide (Cd- rom) - 3122 435 96321

Optional accessories

Service accessories

Philips Multimedia Projector 5English User guide bCool SV1

1. Introduction <

To activate and deactivate the menu.

To confirm actions in the menu when the menu is on screen.

When the menu is active, use the Cursor to navigate through the OSD menu.The Cursor

works with up/down and left/right button operation.

To automatically adjust frequency, tracking, horizontal and vertical position.

With most signal sources, Auto Image provides the best results.

To turn the projector on or off.

The Standby indicator (text on button/ring around button):

In Power on mode:

– the light blinks green when the projector is warming up;

– light is green when the projector is on.;

In Power off mode:

– light is red when the projector is off. (Standby);

– the light blinks red when the projector is cooling down.

Light turns red when there is a temperature problem.

– Fast blinks red (0.5 sec On, 0.5 sec Off) when lamp start has failed.

– Fast blinks red (1 sec On, 1 sec Off) in case of fan error.

To select the current projection source (Computer,YPbPr,YCbCr, RGBS, S-Video or Video).The

button toggles between the six signals.

To adjust the size of the image.

To adjust the focus of the image.

Menu 1

OK 2

Cursor Control 3

Auto Image 4

Standby/

Standby indicator 5

Temperature indicator 6

Lamp indicator 7

Source 8

Zoom Ring 9

Focus Ring 0

Philips Multimedia Projector 6English User guide bCool SV1

2. Functional overview

Temp.

Source Auto Image

Lamp Temp.

Source Auto Image

Lamp

Controls

To connect the projector to the mains.

To release the elevator foot.

To adjust the vertical angle of the projector.

To adjust a possible oblique displayed picture.

To correct picture distortion of the vertical keystone type by internal scaling.

Mains inlet socket !

Elevator button @

Elevator foot #

Lamp compartment $

Horizontal adjuster %

Keystone correction

keys ^

Philips Multimedia Projector 7English User guide bCool SV1

2. Functional overview Controls

Temp.

Source Auto Image

Lamp Temp.

Source Auto Image

Lamp

2. Functional overview

To turn the projector on or off in the Power/Standby mode.

Function as the Left and Right mouse buttons of your pc when USB connection has been made.

To adjust the volume.This model does not support this function.

To activate and de-activate the menu.

To mute the sound of the projector.This model does not support this function.

To select the current projection source (Computer,YPbPr,YCbCr, RGBS, S-Video or Video).

The button toggles between the six signals.

To capture a (moving) picture.The button toggles between the Freeze mode and the display

situation.

To magnify the size of the projected image. Use Cursor control to select the zoom center and

press D(igital)-Zoom to select the required zoom factor:

The button toggles between the various zoom factors.

To mute the sound of the projector and the picture.This model only supports Video Mute.

To manipulate the mouse cursor on the connected computer as long as the menu is not active.

When the menu is active use the Cursor to navigate through the OSD menu.The Cursor

works with up/down and left/right button operation.

The Cursor Control can only function as a mouse cursor when projector and computer are connected

via the USB connectors. Windows 98

, Windows ME

, Windows 2000

or Windows XP

should be

installed on the computer when you make the USB connection.

To confirm actions in the menu when the menu is on screen.

The maximum range of the remote control is approximately 7 m (± 25 feet).

x 1 x 4 x 9 x 16

Stand by On 1

Mouse Left/Right 2

– Volume + 3

Menu 4

Mute 5

Source 6

D(igital)-Freeze 7

D(igital)-Zoom 8

A(udio)/V(ideo) Mute 9

Cursor Control 0

Note

OK !

Note

Philips Multimedia Projector 8English User guide bCool SV1

<Remote control

VOLUME

OKMENU

A/V Mute

MOUSE

D-ZOOMD-FREEZESOURCE

Standby

RightLeft

Mute

Data source connections

–Input socket to connect to the Data out terminal of a computer.

–Input socket to connect to DVD- and HDTV-video equipment

This socket can be connected to the following output sockets:YCbCr,YPbPr, RGBS

(Composite sync), RGBHV.

In-/Output socket to connect a PC or Apple Macintosh computer equipped with a USB

downlink connection.When USB connection is used, the mouse cursor on the connected

computer can be controlled through the projector remote control. Make sure Windows 98

Windows ME

, Windows 2000

or Windows XP

is installed on the computer.

Video source connections

Input socket to connect to the S-Video out socket of a S-VHS video recorder, a VCR,

Laser Disc player, DVD player, video camera or TV with AV output socket.

This socket can be connected to a S-Video/S-VHS (Y/C) output socket.

Input socket to connect to the Video out socket of a video recorder, Laser Disc player, video

camera, DVD player, or TV with AV output socket.

This socket can be connected to CVBS output sockets.

Other connections

To receive the signals from the remote control.

To insert an optional locking device (Kensington lock).

Data in 1

USB 2

S-Video 3

Video 4

IR sensor 5

Lock slit 6

Philips Multimedia Projector 9English User guide bCool SV1

2. Functional overview

Data in S-Video Video

USB

54321 6

<Connections

3. Set up >

•Place the projector on a stable, level surface out of direct sunlight and away from sources of

excessive dust, dirt, heat, water, moisture, vibration and strong magnetic fields.

•Allow sufficient cooling of the product by keeping all air inlets and outlets clear from

obstructions.

•Position the projector in such way that the viewers cannot watch into the projector light beam.

•Choose a screen size suitable for the number of viewers and the size of the room.

•Picture quality is best when you sit directly in front of the projector screen.

•The projector can be used for front projection, rear projection and ceiling projection

applications. As default factory setting, the projector has been set up for front projection.

You can change to rear or ceiling projection via the ‘Mirror’function in the ‘Setup’menu.

•For more information, check the Projection Assistance application on the Cd-rom.

1Insert the mains lead into the projector's Mains inlet socket and connect it to the wall socket.

–The Standby indicator light is red indicating the projector is now in the Standby mode.

2Remove the lens cap.

3Press the Standby button on the projector or remote control to turn on the projector.

–The Standby indicator light blinks green indicating the projector is now warming up.

–When the projection lamp is on, the Standby indicator light turns green after the start-up

screen has appeared for several seconds.

4Press the Standby button twice to switch the projector back into the Standby mode.

–The Standby Warning screen will appear for 20 seconds.

–The projector will now go into Standby mode.

5To switch off the mains supply completely, disconnect the mains lead.

– Save energy! Please put the projector in the Standby position if you are not going to use the

projector for more than 15 minutes.

–When no signal inputs are detected for 15 minutes, the projector automatically returns to

Standby (‘Auto Standby’).

–Before disconnecting the mains lead, make sure that the cooling fan has stopped

(about 2 minutes after the projector returned to Standby).

Positioning the projector and

screen

Turning on the projector

Notes

Philips Multimedia Projector 10 English User guide bCool SV1

SCREEN

Front projection Ceiling front projection

Rear projection Ceiling rear projection

Temp.

Source Auto Image

Lamp Temp.

Source Auto Image

Lamp

Andere Handbücher für bClever SV1

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Projektor Handbücher

Philips

Philips NeoPix Prime NPX540/INT Bedienungsanleitung

Philips

Philips Screeneo U5 Bedienungsanleitung

Philips

Philips LC4433 Bedienungsanleitung

Philips

Philips PICOPIX PPX1020 Bedienungsanleitung

Philips

Philips PicoPix PPX 4010 Bedienungsanleitung

Philips

Philips LC6131/05 Bedienungsanleitung

Philips

Philips NeoPix Easy Bedienungsanleitung

Philips

Philips LC4650G Bedienungsanleitung

Philips

Philips NeoPix Start Bedienungsanleitung

Philips

Philips LC3132 - bSure SV2 SVGA LCD Projector Bedienungsanleitung

Philips

Philips LC4043 Bedienungsanleitung

Philips

Philips LC718199 Bedienungsanleitung

Philips

Philips PICOPIX PPX1230 Bedienungsanleitung

Philips

Philips ProScreen PXG30 Series Bedienungsanleitung

Philips

Philips HDP1690TV Bedienungsanleitung

Philips

Philips PPX 3407 Bedienungsanleitung

Philips

Philips Screeneo HDP2510 Bedienungsanleitung

Philips

Philips Screeneo 3.0 Bedienungsanleitung

Philips

Philips NeoPix Prime One Bedienungsanleitung

Philips

Philips NeoPix Ultra 2 Bedienungsanleitung

Philips

Philips PicoPix PPX2340 Bedienungsanleitung

Philips

Philips PPX4010/INT Bedienungsanleitung

Philips

Philips NeoPix ACE Bedienungsanleitung

Philips

Philips 730 Bedienungsanleitung

Beliebte Projektor Handbücher anderer Marken

iEmmet

iEmmet MP-312 Bedienungsanleitung

Epson

Epson VS400 Bedienungsanleitung

Sony

Sony VPL-HS10 Marketing Specifications & Features Bedienungsanleitung

Sony

Sony VPL-HW65ES Service-Handbuch

Toshiba

Toshiba TLP-791U Bedienungsanleitung

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Bedienungsanleitung

NEC

NEC NP600S EDU Bedienungsanleitung

BenQ

BenQ SH753P Bedienungsanleitung

Eiki

Eiki EK-623U series Bedienungsanleitung

Epson

Epson PowerLite Pro Cinema 6020UB Bedienungsanleitung

Epson

Epson PowerLite Home Cinema 705HD Bedienungsanleitung

Christie

Christie LHD700 Bedienungsanleitung

Navitar

Navitar FX Bedienungsanleitung

InFocus

InFocus LitePro 560 Bedienungsanleitung

Sony

Sony SRX-R815P Bedienungsanleitung

Vivitar

Vivitar DP1500 X Bedienungsanleitung

Acer

Acer C20 Series Bedienungsanleitung

Asus

Asus ZenBeam Latte Bedienungsanleitung

Philips bClever SV1 Bedienungsanleitung

Beliebte Projektor Handbücher anderer Marken
