Philips Elite SRP4219G/07 Bedienungsanleitung

Remote

control

user manual

v2 9/21

SRP4219G/07

SRP4229B/07

Universal

Universelle

Audio/Video

Élite

SRP4229B_07 ENG Manual v2.indd 1SRP4229B_07 ENG Manual v2.indd 1 9/2/21 5:03 PM9/2/21 5:03 PM

Setup ................................................................................3

Button functions............................................................4

Programming your remote..........................................6

Direct Code Entry.....................................................6

Auto Code Search....................................................8

Controlling combo devices....................................9

Using your remote .......................................................10

Primary audio control...........................................10

Code identication.................................................11

Reset to factory settings.......................................11

Troubleshooting .......................................................... 12

90-day Limited Warranty.......................................... 12

FCC statement ............................................................. 13

Table of contents

For assistance with this

remote, scan here or visit:

byjasco.com/47597i

SRP4229B_07 ENG Manual v2.indd 2SRP4229B_07 ENG Manual v2.indd 2 9/2/21 5:03 PM9/2/21 5:03 PM

Your universal remote requires two (2) AAA

batteries (not included). Alkaline batteries are

recommended.

Battery installation

1. On the back of the remote, pull down on

the textured surface and slide battery cover

downward to remove.

2. Match the (+) and (-) marks on the batteries

to the (+) and (-) marks inside the battery

compartment, then insert two (2) AAA

batteries. Be sure to use fresh batteries.

3. Position battery cover slightly below opening

and push upward to lock into place.

NOTE:If your remote stops operating properly,

replace the batteries with new ones.

Battery precautions

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc), or

rechargeable (Ni-Cd, Ni-MH, etc.) batteries.

• Always remove old, weak or worn-out

batteries promptly and recycle or dispose of

them in accordance with local and national

regulations.

Battery saver

Your remote automatically turns o if the buttons

are held down for more than 8 seconds. This will

save your batteries should your remote get stuck

in a place where the buttons remain depressed

(e.g., between sofa cushions).

Code saver

You have up to 10 minutes to change the batteries

in your remote without losing the codes you have

programmed.

Setup

SRP4229B_07 ENG Manual v2.indd 3SRP4229B_07 ENG Manual v2.indd 3 9/2/21 5:03 PM9/2/21 5:03 PM

SETUP

INPUT

DVD

STR

AUD

ENTER

112233

445566

778899

ABCD

VOL

LAST

STREAM

EXIT 7

9 9

11 11

Button functions

SRP4229B_07 ENG Manual v2.indd 4SRP4229B_07 ENG Manual v2.indd 4 9/2/21 5:03 PM9/2/21 5:03 PM

1. Power - Turns devices ON/OFF

2. TV, STR, DVD, AUD - Selects the device

to control

3. Up/down/left/right menu navigation

4. Last channel - Returns to the previously

selected channel

5. Setup - Used to program the remote

6. Channel up/down

7. Home/Guide - Easily access features on

streaming devices, or Guide on cable/satellite

receivers

8. Info/Options - Displays on-screen show/

content information

9. Menu - Displays the on-screen menu

10. Record, play, stop, rewind, fast forward, pause

11. Numbers - Enter numbers for direct channel

selection

12. Dash (-) - Use to select digital channels,

e.g., 4.1

13. Enter - Some devices require enter to be

pressed after channel selection

14. ABCD - Access additional features for DVRs,

cable and satellite receivers

15. DVD/Blu-ray™open/close - Open/close a

player, or List features on cable/satellite

receivers

16. Exit -Exit on-screen menus

17. Streaming app hotkey - Access top apps like

Netix®, Amazon®Prime, Hulu®and more

18. Volume up/down

19. Mute - Mutes sound

20. Ok - Selects menu items for the controlled

device

21. Input - Selects video inputs

Button functions

SRP4229B_07 ENG Manual v2.indd 5SRP4229B_07 ENG Manual v2.indd 5 9/2/21 5:03 PM9/2/21 5:03 PM

Programming your remote

Your remote is designed to control multiple audio/

video devices. To use, you will need to program the

remote for your devices. There are two dierent

methods you can use to program the remote,

Direct Code Entry or Auto Code Search.

• The Direct Code Entry method is the

recommended method, as it is the simplest

and quickest method in most cases.

• The Auto Code Search method searches

through all the codes in the remote to nd a

code for your device.

NOTE:This remote comes preprogrammed for

Roku®boxes and Samsung TVs. Press TV for

Samsung TVs and STR for Roku boxes.

Direct Code Entry (recommended)

1. Locate the Code List included with

your remote. Find the section for the

type of device you wish to control,

(e.g., TV, STR, DVD, AUD). Locate the

brand of your device and circle all the

remote codes for the brand.

2. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns on.

Release the SETUP button. The red

light will remain on.

NOTE:The red light will either be a

small light at the top of the remote or

the power ON/OFF button.

3. Press and release the device button

on the remote for the type of device

you wish to control, (e.g., TV, STR,

DVD, AUD). The red light will blink

once and remain on.

NOTE:Any of the device buttons on the

remote can be programmed to control

any of your devices. For example, you

can use the AUX device button on the

remote to control a satellite receiver,

digital converter box, streaming media

player or any device category in the

Code List.

SETUP

SRP4229B_07 ENG Manual v2.indd 6SRP4229B_07 ENG Manual v2.indd 6 9/2/21 5:03 PM9/2/21 5:03 PM

Programming your remote

4. Use the number buttons on the

remote to enter the rst 4-digit

remote code you circled in the

Code List in Step 1. The red light

will turn o after entering the

fourth digit

5. Point the remote at the device.

Test the buttons on the remote to

see if the device responds as you

would expect. If the buttons do not

operate the device, return to Step 2

above and use the next code that

you circled for that device.

6. Repeat steps 1 – 5 for each device you wish

to control.

Programming notes:

• Some codes may operate only a few functions

of your device. There may be another code in

the Code List that controls more functions.

Test other codes in the Code List for more

functionality.

• If you do not nd a remote code that works

your device or there are no codes in the

Code List for your device, use the Auto Code

Search method in the next section to program

your remote.

• For combination devices such as a TV/DVD

combo or TV/VCR combo, you may have to

enter a code for each device.

• Write down the remote codes used to

program the remote for future reference.

112233

445566

778899

SRP4229B_07 ENG Manual v2.indd 7SRP4229B_07 ENG Manual v2.indd 7 9/2/21 5:03 PM9/2/21 5:03 PM

Programming your remote

1. Manually turn on the device you

wish to control.

NOTE:The Auto Code Search process

cannot be used for devices without

power ON/OFF capability. Use Direct

Code Entry in these cases.

2. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns on.

Release the SETUP button. The red

light will remain on.

NOTE:The red light will either be a

small light at the top of the remote or

the power ON/OFF button.

3. Press and release the device button

on the remote for the type of device

you wish to control, (e.g., TV, DVD,

STR, AUX). The red light will blink

once and remain on.

4. With the remote pointed at the

device, press and release the POWER

button on the remote. The remote

will send 10 dierent codes to the

device. The red light will blink once

for each code and remain on after

sending the 10 codes.

Did the device turn o?

• If YES, go to Step 5.

• If NO, repeat Step 4 to test the

next 10 codes.

5. Manually turn the device back on.

6. With the remote pointed at the

device, press and release the

VOL button. The remote will

re-send the rst code of the 10 codes

from Step 4. The red light will blink

once and remain on.

SETUP

VOL

Auto Code Search

Auto Code Search is a process where you can

search through all the codes stored in the remote

to nd a code for your device. It is recommended

that you read through all the steps below to

familiarize yourself with Auto Code Search before

starting the process.

SRP4229B_07 ENG Manual v2.indd 8SRP4229B_07 ENG Manual v2.indd 8 9/2/21 5:03 PM9/2/21 5:03 PM

Programming your remote

Did the device turn o?

• If YES, you have found a code for

the device. Press and release the

same device button you pressed

in Step 3. This will store the code

in the remote. Go to Step 7.

• If NO, continue to press and

release the VOL button until

the device turns o to test the

other 9 codes from Step 4. Be sure

to wait approximately 3 seconds

after each VOL button press to

allow the device time to respond

to the code. When the device

turns o, you have found a code

for your device. Press and release

the same device button pressed in

Step 3. This will store the code in

the remote. Go to Step 7.

NOTE:

• The VOL button can be used to

go backwards through each batch

of 10 codes.

• The red indicator light will ash 2

times after testing the rst or last

code in each batch of 10.

7. Use the remote to turn the device

back on. Test the buttons on the

remote to see if the device responds

as you would expect. If the buttons

do not operate the device, return

to Step 2 and repeat this process to

search for a better code to operate

the device.

8. Repeat this process for each device you wish

to control.

Controlling combo devices

Some combo devices (e.g., TV/VCR, TV/DVD, DVD/

VCR, etc.) will require you to set up two dierent

device buttons to control both parts of the combo

device. For example, if you have a TV/DVD combo,

you may need to set up one code under the TV

button to control the TV and a separate code

under the DVD button to control the DVD.

VOL

SRP4229B_07 ENG Manual v2.indd 9SRP4229B_07 ENG Manual v2.indd 9 9/2/21 5:03 PM9/2/21 5:03 PM

Using your remote

Primary Audio Control

The Primary Audio Control feature allows you to

select a single device that the volume buttons

always control. For example, the remote can be

in TV mode while the volume buttons control

the volume on your audio receiver or sound bar

instead of your TV.

Enabling Primary Audio Control

1. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns on.

Release the SETUP button. The red

light will remain on.

2. Press and release the device button

(TV, AUD, etc.) on the remote for the

device you wish to control

the volume.

3. Press and release the MUTE button.

4. Press and release the VOL button.

The red light will blink twice and

turn o.

Disabling Primary Audio Control

1. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns on.

Release the SETUP button. The red

light will remain on.

2. Press and release the device button

(TV, AUD, etc.) programmed to control

the Primary Audio Control feature.

3. Press and release the MUTE button.

4. Press and release the VOL button.

The red light will blink twice and

turn o.

SETUP

VOL

SRP4229B_07 ENG Manual v2.indd 10SRP4229B_07 ENG Manual v2.indd 10 9/2/21 5:03 PM9/2/21 5:03 PM

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Philips Fernbedienung Handbücher

Philips

Philips SBCRU641/00 Bedienungsanleitung

Philips

Philips 22AV1106B Bedienungsanleitung

Philips

Philips Perfect replacement SRC3036WM Bedienungsanleitung

Philips

Philips SRU 5120/87 Bedienungsanleitung

Philips

Philips SRP2018/27 Bedienungsanleitung

Philips

Philips SRU7060/10 Bedienungsanleitung

Philips

Philips Perfect replacement SRU5108/27 Administratorhandbuch

Philips

Philips SBC RU 520 Bedienungsanleitung

Philips

Philips KWR101803/01B Bedienungsanleitung

Philips

Philips Perfect replacement SRC3036WM/17 Bedienungsanleitung

Philips

Philips SBCRU530/88 Bedienungsanleitung

Philips

Philips TSU500 Bedienungsanleitung

Philips

Philips SRP8121G/27 Bedienungsanleitung

Philips

Philips SRP1101/10 Bedienungsanleitung

Philips

Philips ipronto TSi6400 Bedienungsanleitung

Philips

Philips SpaceWise Bedienungsanleitung

Philips

Philips SRP4004/86 Bedienungsanleitung

Philips

Philips Perfect replacement SRP5107WM/17 Bedienungsanleitung

Philips

Philips City line Bedienungsanleitung

Philips

Philips SRP5002 Bedienungsanleitung

Philips

Philips Pronto TSU9300 Sicherheitsleitfaden

Philips

Philips Pronto TSU 2000 Bedienungsanleitung

Philips

Philips SRU 5040/10 Bedienungsanleitung

Philips

Philips Pronto SBC RU 950 Systemhandbuch

Beliebte Fernbedienung Handbücher anderer Marken

Panasonic

Panasonic EUR7622KB0 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen Beo4 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Bedienungsanleitung

Multiplex

Multiplex PROFI TX 9 Bedienungsanleitung

One Remote

One Remote RMB4 Bedienungsanleitung

FUTABA

FUTABA 9ZAP - PART2 Bedienungsanleitung

HR Matic

HR Matic HR MULTI 3 Bedienungsanleitung

Yamaha

Yamaha ACC-GNRST-30-20 Bedienungsanleitung

EisSound

EisSound KBSOUND Bedienungsanleitung

Marantz

Marantz RC101 Bedienungsanleitung

Conrad

Conrad FS20 TC6 Bedienungsanleitung

Anritsu

Anritsu MP1777A Bedienungsanleitung

Niles

Niles WVC100 Fehlerbehebungshandbuch

RCA

RCA RCU1300 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen BEO6 Bedienungsanleitung

GE 94901 Bedienungsanleitung

Onbon

Onbon YQ1-75 Bedienungsanleitung

FUTABA

FUTABA R7108SB Montageanleitung
