Phonak CROS Bedienungsanleitung

Behind-the-Ear and In-the-Ear

Phonak CROS transmitter

User Guide

Manufacturer:

Phonak AG

Laubisrütistrasse 28

CH-8712 Stäfa

Switzerland

EU Representative:

Phonak GmbH

D-70736 Fellbach-Oefﬁngen

Germany

www.phonak.com

029-1016-03/V2.00/2011-01/A+W Printed in Switzerland

0459

1. Welcome 5

2. Important safety information:

Please read before operating your Phonak CROS

system for the ﬁrst time 6

Hazard warnings 6

Information on product safety 8

3. Phonak CROS system description 10

4. Step-by-step instructions for using

the Phonak CROS system 14

Step 1. Getting to know your

Phonak CROS transmitter 14

Step 2. Battery preparation 17

Step 3. Inserting the battery 18

Step 4. Turning on the Phonak CROS

transmitter 19

Step 5. Placing the Phonak CROS transmitter 21

Step 6. Adjusting the volume 26

Step 7. Selecting the hearing program 28

Contents

Step 8. Removing the Phonak CROS

transmitter 29

Step 9. Turning off the Phonak CROS

transmitter 31

Step 10. Changing the battery 32

5. Care and maintenance 33

6. Troubleshooting 35

7. Wireless Accessories and FM systems 37

Wireless Accessories 37

FM systems 37

8. Service and warranty 39

9. Compliance information 40

10. Information and explanation of symbols 43

11. For the US market only, complies with the

FDA regulations 46

1. Welcome

Your new Phonak CROS system is a premium Swiss

quality product. It was developed by Phonak, one of

the world‘s leading companies in hearing technology.

Your Phonak CROS system offers the most modern

digital hearing technology currently available on the

market.

Please read these user instructions thoroughly in order

to beneﬁt from all the possibilities your new Phonak

CROS system has to offer. With proper use and care, you

will be able enjoy your Phonak CROS system for many

years to come.

If you have any questions, please consult your hearing

care professional.

Phonak - life is on www.phonak.com

0459

Please read the information on the following pages

before using your Phonak CROS system

A Phonak CROS system will not restore normal hearing

and will not prevent or improve a hearing impairment

resulting from organic conditions. Infrequent use of a

Phonak CROS system does not permit a user to attain

full beneﬁt from it. The use of a Phonak CROS system is

only part of hearing habilitation and may need to be

supplemented by auditory training and instruction in

lipreading.

2.1Hazard warnings

Use only Phonak CROS systems that have been

specially programmed for you by your hearing care

professional. Other systems may be ineffective

and may, in certain cases, damage your hearing.

Changes or modiﬁcations to the Phonak CROS system

that were not explicitly approved by Phonak are

not permitted. Such changes may damage your ear

or the hearing system.

2. Important safety information

Phonak CROS system batteries are toxic if they are

swallowed! Keep out of reach of children and pets. If

batteries are swallowed, consult your physician

immediately!

If you feel pain in or behind your ear, if it is inﬂammed

or if skin irritation and accelerated accumulations

of ear wax occur, please check with your hearing care

professional or physician.

Hearing programs in the directional microphone mode

reduce background noises. Please be aware that

warning signals or noises coming from behind, e. g.

cars, are partially or entirely suppressed.

The Phonak CROS system contains small parts

which can be swallowed by children.

External devices may only be connected if they have

been tested in accordance with corresponding

IECXXXXX standards. Only use accessories approved

by Phonak AG.

2.2 Information on product safety

Never immerse your Phonak CROS system in water!

Protect it from excessive moisture. Always remove

your hearing system before showering, bathing,

or swimming.

Protect your Phonak CROS system from heat

(never leave near a window or in the car.) Never

use a microwave or other heating devices to

dry your hearing system. Ask your hearing care

professional about suitable drying methods.

When you are not using your Phonak CROS system,

leave the battery compartment open so that any

moisture can evaporate. Make sure that you always

completely dry your Phonak CROS system after use.

Store the Phonak CROS system in a safe, dry and

clean place.

Do not drop your Phonak CROS system! Dropping

onto a hard surface can damage your Phonak CROS

system.

Always use new batteries for your Phonak CROS

system. You can return used batteries to your hearing

care professional.

Remove the battery if you are not using your

Phonak CROS system for a long period of time.

X-ray radiation (e. g. CT scans, MRI scans) may

adversely affect the correct functioning of your

Phonak CROS systems. We recommend that you

remove them before undergoing X-ray procedures

and keep them outside the room.

Do not use your Phonak CROS system in areas

where electronic equipment is prohibited.

In the event that Phonak CROS accidentally falls

off the ear, an acoustical alert ( ) will indicate

that the connection between the Phonak CROS and

the hearing instrument is broken.

2. Important safety information

The Phonak CROS system is a hearing application for

unilateral hearing loss to compensate the head shadow

effect for sounds originating on the unaidable side.

The Phonak CROS transmitter is placed on the unaidable

ear and transmitts sounds to the Phonak hearing aid

on the other ear. The sound is transmitted wireless and

can be heard clearly and directly on the hearing ear.

Phonak CROS transmitter + Phonak hearing aid =

Phonak CROS system

The following user instructions describe Behind-the-Ear

(BTE) and In-the-Ear (ITE) CROS transmitter models.

The BTE CROS transmitter can be adapted with a variety

of retention systems.

The ITE CROS transmitter are available as a HS-model

that are situated in the ear canal and a FS-model that

are situated only in the bowl of the ear.

On the following pages use the labeled drawings to

identify the model and the retention that you use.

3. Phonak CROS system description

Your hearing care professional will tell you what size

of battery you need for your Phonak CROS system.

BTE

Option A: with Phonak CROS retention

aPhonak CROS retention

bBattery compartment with ON / OFF switch

cSwitch

dMicrophone input with microphone protector

Option B: with Phonak CROS Tip

aEarpiece: Phonak CROS Tip

bBattery compartment with ON/OFF switch

cSwitch

dMicrophone input with microphone protector

eRetention

fRemoval handle

3. Phonak CROS system description

ITE

Option A: HS-model Option B: FS-model

aCustom made shell

bWax protection system

cBattery compartment with ON/OFF switch

dProtected microphone inlet

eSwitch

f Right or left indicator (right=red, left=blue)

gVent

f f

The following chapter provides step-by-step instructions

on how to use your Phonak CROS system. Please

follow these steps carefully. In the drawings, the parts

that are particularly important for each step are

shown in green.

Step 1. Getting to know your Phonak CROS transmitter

The Phonak CROS transmitter only works in

conjunction with a Phonak hearing aid as the

receiver.

Take the Phonak CROS transmitter in your hand and try

out the system controls. This will make it easier for

you to feel for and operate the controls later on when

wearing the Phonak CROS system.

4. Step-by-step instructions for using

the Phonak CROS system Your hearing care professional can configure your

Phonak CROS transmitter (push) switch as either a

volume control or a program selector.

To increase the volume, press the switch on your right

instrument*. To decrease the volume, press the switch

on your left instrument* (Fig. 1a/1b).

Option A: BTE

Left Right

* Phonak CROS transmitter or hearing aid

Fig. 1a

Decrease

volume

Increase

volume

Option B: ITE

Left Right

Fig. 1b

4. Using your Phonak CROS system

Decrease

volume

Increase

volume

In order to change a hearing program, press the

switch displayed (Fig. 1c/1d).

Option A: BTE Option B: ITE

Step 2. Battery preparation

Remove the protective foil from the new battery (Fig. 2).

Wait for two minutes before inserting to activate the

battery.

Fig. 1c Fig. 1d

Fig. 2

Step 3. Inserting the battery

Take the Phonak CROS transmitter in your hand

(Fig. 3a/3c) and open the battery door. Insert the

battery so that you see the + symbol on the battery

(Fig. 3b/3d).

Option A: BTE

Option B: ITE

Fig. 3a Fig. 3b

Fig. 3c Fig. 3d

4. Using your Phonak CROS system

Step 4. Turning on the Phonak CROS transmitter

The Phonak CROS transmitter is switched on by closing

the battery compartment (Fig. 4a/4b).

Option A: BTE Option B: ITE

Fig. 4a Fig. 4b
