SECTION 1 - TECHNICAL SPECIFICATION

Page 1.1

pickering

HIGH VOLTAGE AMPLIFIER MODULE 41-650

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI High Voltage Programmable Ampliﬁer 41-650

ISSUE 7.7 MAY 2022

yUp to 5 Ampliﬁer Channels

yProgrammable Gain

yDC to 120 kHz Large Signal Bandwidth (-1 dB)

yPowered by the Chassis

yShort Circuit and Thermal Protection

yUp to ±30 Vpk Output

(±33 Vpk for -S1 Version)

ySingle Slot Width, 3U

yVISA Drivers Supplied for Windows

Plus Soft Front Panel

ySupported in PXI or LXI Chassis

y3 Year Warranty

Simpliﬁed Functional Diagram Showing One (of the Five)

Ampliﬁer Channels

Pxi Interface

PSU Monitor

Thermal Monitor

+5V PXI Supply

Variable Input Attenuator Variable Gain Amplifier

Channel 1

Output

Other

Channels

Channel 1

Input

High Voltage

Power Supply

PXI Interface

+ -

Supplied Soft Front Panel for the 41-650 Voltage Ampliﬁer

Model

No. Channels Max. Signal

Output

Large

Signal 1dB

Bandwidth

Small

Signal 1dB

Bandwidth

Gain

Settings

41-650 5

±30 Vpk

(±33 Vpk

-S1 version)

120 kHz 1.5 MHz

x1, x2,

5x, x7,

x10, x14,

x20

The 41-650 is a 5 channel voltage ampliﬁer that is ideal

for increasing the output voltage from other PXI modules,

enabling users to easily generate the signal voltages

commonly required in applications such as automotive test.

Each channel can be independently programmed to a

gain of 1, 2, 5, 7, 10, 14 or 20, enabling it to be used with

modules with low output voltage capability. Input and

output connections can be speciﬁed as either via a single

D-type or separate SMB connectors to suit the user’s

wiring system.

The 41-650 includes automatic thermal and short circuit

protection on all outputs and is capable of supplying load

currents up to 50 mA peak from each channel.

The module requires no external power supply, all power

for the ampliﬁer system is drawn from the PXI chassis.

The module includes monitoring of the thermal protection

system for detection of fault conditions in the DUT and

protection of the internal power supplies.

A DC offset facility allows the user to null out the small

DC offset generated by the module, or to null out small

external DC offsets from the driving source. A monitor

facility via a separate connector can be used for a DMM to

monitor the output of each ampliﬁer to aid the nulling of

each channel without external multiplexing.

Page 1.2

SECTION 1 - TECHNICAL SPECIFICATION

HIGH VOLTAGE AMPLIFIER MODULE 41-650

pickering

High Voltage Programmable Ampliﬁer, 41-650

pickeringtest.com

Speciﬁcations

Output Amplitude Volts

0.17

0.55

1.7

5.5

17.4

41-650 High Voltage Ampliﬁer - Typical Bandwidth Plot

41-650 High Voltage Ampliﬁer - SINAD Plot

Solid line: Input = 5.5 V peak to peak

Large dashed line: Input = 0.55 V peak to peak

Small dotted line: Input = 0.055 V peak to peak

SECTION 1 - TECHNICAL SPECIFICATION

Page 1.3

pickering

HIGH VOLTAGE AMPLIFIER MODULE 41-650

High Voltage Programmable Ampliﬁer, 41-650

pickeringtest.com

Speciﬁcations

General Speciﬁcation

General

Number of Channels:

Channel Crosstalk:

Output Range:

Up to 5

Typically 50 dB at 100 kHz

±30 Vpk (±33 Vpk -S1 version)

Inputs

Input Impedance:

Max Input Voltage:

Input Offset Tolerance:

DC Offset:

Single ended 600 Ω or 10 kΩ

according to model

10 V

±20 mV

Adjustable control for offsetting

the input voltage by ±25 mV,

8-bit resolution. Monitor output

allows the use of a DMM to null

any channel.

Outputs

Output Impedance:

Gain:

Gain Accuracy:

Output Slew Rate:

Group Delay:

Noise Floor:

Output Current:

Output Protection:

50 Ω

Adjustable to 1, 2, 5, 7, 10, 14, 20

<1.5 % at DC (typically <1 %),

excluding DC offset.

23 V/µs typical

Less than 1 µs from 100 Hz to

100 kHz

Typically 1 mV AC rms from

100 Hz to 300 kHz

±50 mA each channel (full power

into 600 Ω).

Short circuit proof, thermal

protection on each channel.

Operation of thermal protection

detected over the PXI interface.

Power Requirements

+3.3 V +5 V +12 V -12 V

0 1.2 A Idle

3.5 A at Max. Load

0.05 A 0.05 A

Operating/Storage Conditions

Operating Conditions

Operating Temperature:

Humidity:

Altitude:

0 °C to +55 °C

Up to 90 % non-condensing

5000 m

Storage and Transport Conditions

Storage Temperature:

Humidity:

Altitude:

-20 °C to +75 °C

Up to 90 % non-condensing

15000 m

PXI & CompactPCI Compliance

The module is compliant with the PXI Speciﬁcation

2.2. Local Bus, Trigger Bus and Star Trigger are not

implemented.

Uses a 33 MHz 32-bit backplane interface.

Safety & CE Compliance

All modules are fully CE compliant and meet applicable

EU directives: Low-voltage safety EN61010-1:2010,

EMC Immunity EN61326-1:2013,

Emissions EN55011:2009+A1:2010.*

Mechanical Characteristics

Single slot 3U PXI (CompactPCI card).

3D models for all versions in a variety of popular ﬁle

formats are available on request.

Connectors

PXI bus via 32-bit P1/J1 backplane connector.

Signals via front panel connectors:

• 25-pin male D-type (41-650-001, 41-650-011, 41-650-001-S1)

• 10 x 50 Ω SMB coaxial (41-650-002, 41-650-012)

Page 1.4

SECTION 1 - TECHNICAL SPECIFICATION

HIGH VOLTAGE AMPLIFIER MODULE 41-650

pickering

High Voltage Programmable Ampliﬁer, 41-650

pickeringtest.com

Ordering Information

Mating Connectors & Cabling

For connection accessories for the 41-650 module please

refer to the 90-008D 25-pin D-type and 90-011D RF

Cable Assemblies data sheets where a complete list and

documentation can be found for accessories, or refer to

the Connection Solutions catalog.

Product Order Codes

Voltage Ampliﬁer, 600 Ω, D-Type

Voltage Ampliﬁer, 600 Ω, SMB

41-650-001

41-650-002

Voltage Ampliﬁer, 10 kΩ, D-Type

Voltage Ampliﬁer, 10 kΩ, SMB

41-650-011

41-650-012

Voltage Ampliﬁer, ±33 Vpk output, D-Type 41-650-001-S1

Other versions of this product can be supplied. with

variations in input impedance, connector type and voltage

rating. Please contact your local Pickering sales ofﬁce.

Product Customization

Pickering modules are designed and manufactured on our

own ﬂexible manufacturing lines, giving complete product

control and enabling simple customization to meet very

speciﬁc requirements.

All customized products are given a unique part number,

fully documented and may be ordered at any time in the

future. Please contact your local sales ofﬁce to discuss.

Inhaltsverzeichnis

Andere Pickering Computerhardware Handbücher

Pickering

Pickering 40-755A-9 Series Bedienungsanleitung

Pickering

Pickering 50-295A Bedienungsanleitung

Pickering

Pickering 40-588-222 Bedienungsanleitung

Pickering

Pickering 50-296A Bedienungsanleitung

Pickering

Pickering 40-738 Bedienungsanleitung

Pickering

Pickering 50-510A Bedienungsanleitung

Pickering

Pickering 50-510 Bedienungsanleitung

Pickering

Pickering 50-297 Bedienungsanleitung

Pickering

Pickering 60-901 Bedienungsanleitung

Pickering

Pickering PXI 40-923 Bedienungsanleitung

Pickering

Pickering PXI 40-419 Bedienungsanleitung

Pickering

Pickering 40-575A Bedienungsanleitung

Pickering

Pickering 50-110 Bedienungsanleitung

Pickering

Pickering Pxi 40-922 Bedienungsanleitung

Pickering

Pickering 45-720A Bedienungsanleitung

Pickering

Pickering 50-671A Bedienungsanleitung

Pickering

Pickering LXI 60-891-045 Bedienungsanleitung

Pickering

Pickering 65-218 Bedienungsanleitung

Pickering

Pickering 50-200 Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
