Page 1.1

20A FAULT INSERTION SWITCH 40-193/194

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI 20 A Fault Insertion Switch Modules 40-193

ISSUE 5.1 DEC 2019

y7 Fault Insertion Channels

ySimulation of Various Types of Electrical Fault,

Enabling Rigorous Fault Testing

yChoice of 1 or 2 Fault Insertion Buses

y20 A Hot or Cold Switching

ySwitch up to 16 VDC

yVISA, IVI & Kernel Drivers Supplied for

Windows

ySupported by PXI or LXI Chassis

y3 Year Warranty

Stimulus/Measurement Connections

UUT Connections

Fault Insertion Bus 2

Fault Insertion Bus 1

Fault Connections

COM1

COM2

40-193-002 Fault Insertion Switch Schematic

Diagram. This version has 2 fault buses,

the 40-193-001 has 1 fault bus

Pickering’s Range of PXI Fault Insertion Switches

Model

No. Signal Channels Fault

Buses

Fault

Inputs

Max

Voltage

Max Current

or Bus Type

40-190B 74, 64 or 32 1 or 2 4 or 8 165 V 2 A

40-191A 6 2 2 40 V 30 A

40-192 6 2 2 200 V 10 A

40-193 7 1 or 2 1 or 2 16 V 20 A, 1 A min

40-194 7 1 or 2 1 or 2 16 V 20 A, no min

40-195 22 or 11 pairs — 8 or 4 150 V 1 A

40-196 10 or 5 pairs — 10 or 5 110 V 5 A

40-197A 34 or 16 4 8 300 V 2 A

40-198 20 1 or 2 3 or 6 250 V 5 A

40-199 10 1 or 2 2 250 V 10 A

40-200 4 or 8 differential 4 8 100 V CAN, FlexRay

40-201 4 or 8 differential 2 4 100 V

Ethernet/

AFDX/

BroadR-Reach

40-202 22 or 11 pairs — 22 or 11 150 V 1 A

The 40-193 is a 7-Channel Fault Insertion switch designed

for the simulation of fault conditions in automotive systems.

It is able to insert 3 different fault conditions between the

test ﬁxture and the equipment under test:

• Open-Circuit

• Short-Circuit between UUT connections

• Short-Circuit to other signals such as Power, Ignition &

Ground via Fault Insertion Bus

Through relays on each channel enable signals to the UUT

to be held open-circuit. Fault Insertion Buses allow any

channel to be shorted to any other channel and enable

any channel to be connected to an external signal such as

Power, Ignition or Ground to simulate fault conditions.

Range Description:

• 40-193-001 7 Channels, One Fault bus.

• 40-193-002 7 Channels, Two Fault buses.

The 40-193 uses miniature automotive relays with 20 A hot

or cold switching current. All relays are normally open.

Page 1.2 20A FAULT INSERTION SWITCH 40-193/194

pickering

SECTION 1 - TECHNICAL SPECIFICATION

20 A Fault Insertion Switch, 40-193

pickeringtest.com

Speciﬁcations

Power Requirements

+3.3 V +5 V +12 V -12 V

0 160 mA 450 mA

(9 relays energised) 0

Operating/Storage Conditions

Operating Conditions

Operating Temperature:

Humidity:

Altitude:

0 °C to +55 °C

Up to 90 % non-condensing

5000 m

Storage and Transport Conditions

Storage Temperature:

Humidity:

Altitude:

-20 °C to +75 °C

Up to 90 % non-condensing

15000 m

PXI & CompactPCI Compliance

The module is compliant with the PXI Speciﬁcation 2.2.

Local Bus, Trigger Bus & Star Trigger are not implemented.

Uses a 33 MHz 32-bit backplane interface.

Safety & CE Compliance

All modules are fully CE compliant and meet applicable

EU directives: Low-voltage safety EN61010-1:2010,

EMC Immunity EN61326-1:2013, Emissions

EN55011:2009+A1:2010.

Mechanical Characteristics

Double slot 3U PXI (CompactPCI card).

3D models for all versions in a variety of popular ﬁle

formats are available on request.

Connectors

PXI bus via 32-bit P1/J1 backplane connector.

Signals via 2 front panel 8-pin male power D-Type

connectors, for pin outs please refer to the operating

manual.

Relay Type

The 40-193 is ﬁtted with miniature automotive relays with

silver alloy contacts. A spare relay is built onto the circuit

board to allow easy maintenance with minimum downtime.

Switching Speciﬁcation

Switch Type: Electro-mechanical

Contact Type: Silver alloy

Cold Switching Capacity

Maximum Current:

Maximum Voltage:

20 A

16 VDC*

Hot Switching Capacity

Maximum Current:

Maximum Voltage:

Maximum Power:

Min. Switching Capacity:

20 A

16 VDC*

280 W

1 A, 12 VDC

Max Total Fault Bus Current:

Overall Module Current:

20 A

20 A simultaneously on

each stimulus connection

Initial On Path Resistance:

Off Path Resistance:

<15 mΩ

>108 Ω

Operate Time:

Max Operating Speed at

nominal load:

10 ms typical

6 cpm

Expected Life - resistive load

Mechanical Life:

At Max. Switch Capacity:

>1x107 operations

>1x105 operations

* For full voltage rating, signal sources to be switched

must be fully isolated from mains supply and safety earth.

DC Resisve

40-193 Current/Voltage Curve

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Pickering Schalten Handbücher

Pickering

Pickering 40-191 Bedienungsanleitung

Pickering

Pickering PXIe 42-880B Bedienungsanleitung

Pickering

Pickering 40/42-87 A Series Bedienungsanleitung

Pickering

Pickering 40-183B Bedienungsanleitung

Pickering

Pickering 40-191A Bedienungsanleitung

Pickering

Pickering 40-201 Bedienungsanleitung

Pickering

Pickering 40-202 Bedienungsanleitung

Pickering

Pickering 60-200 Bedienungsanleitung

Pickering

Pickering 4 782B Series Bedienungsanleitung

Pickering

Pickering LXI 60-102C Bedienungsanleitung

Pickering

Pickering PXI 40-618 Bedienungsanleitung

Pickering

Pickering 60-890-005 Bedienungsanleitung

Pickering

Pickering SIM SIMRC-1000 Series Bedienungsanleitung

Pickering

Pickering 40-738 Bedienungsanleitung

Pickering

Pickering 40-754 Bedienungsanleitung

Pickering

Pickering 10-780A Bedienungsanleitung

Pickering

Pickering LXI 60-890-022 Bedienungsanleitung

Pickering

Pickering PXI 40-197 Bedienungsanleitung

Pickering

Pickering LXI 60-770 Bedienungsanleitung

Pickering

Pickering PXI 40-192A Bedienungsanleitung

Pickering

Pickering 40-200 Bedienungsanleitung

Pickering

Pickering 40-860 Bedienungsanleitung

Pickering

Pickering PXI 40-830 Bedienungsanleitung

Pickering

Pickering 40-190B Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
