INSTRUCTIONS AND WARRANTY

MODEL NO. PHH03

PINEWARE QUARTZ HEATER

Thank you for purchasing our Pineware Quartz Heater. Please read the

instructions carefully before using and keep safe for future reference.

The following instructions will allow you to use this product to its

maximum performance.

IMPORTANT SAFEGUARDS:

When using any electrical heaters, basic safety precautions should always be

followed including the following:

1. Please read the instructions carefully before using any heater.

2. Always ensure that the voltage on the rating label corresponds to the

mains voltage in your home.

3. Incorrect operation and improper use can damage the heater and

cause injury to the user.

4. The heater is intended for domestic use only. Commercial use

invalidates the warranty and the supplier cannot be held responsible

for injury or damage caused when using the heater for any other

purpose than that intended.

5. Avoid any contact with moving parts.

6. This heater is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their

safety.

7. Children should be supervised to ensure that they do not play with

the heater.

8. Check the power cord and plug regularly for any damage. If the cord or

the plug is damaged, it must be replaced by the manufacturer or a

qualified person in order to avoid an electrical hazard. Do not operate

the heater if the cord is damaged.

9. Do not use the heater if it has been dropped or damaged in any way.

In case of damage, take the unit in for examination and/or repair by an

authorised service agent.

10.To reduce the risk of electric shock, do not immerse or expose the

heater, plug or the power cord to water or any other liquid.

11.Never immerse the full heater in water or any other liquid for

cleaning purposes.

12.Remove the plug from the socket by gripping the plug. Do not pull on

the cord to disconnect the heater from the socket. Always unplug the

heater when not in use, before cleaning or when adding or

removing parts.

13.The use of accessory attachments that are not recommended

or supplied by the manufacturer may result in injuries, fire or

electric shock.

14.A short cord is provided to reduce the hazards resulting from becoming

entangled in or tripping over a longer cord.

15.Do not let the cord hang over the edge of a table or counter. Ensure

that the cord is not in a position where it can be pulled on inadvertently.

16.Do not allow the cord to touch hot surfaces and do not place on or near

a hot gas or electric burner or in a heated oven.

17.Do not place the heater on a gas or electric cooking top nor over or

near an open flame.

18.Place the power cable away from areas where people walk so that it

cannot be stepped on or tripped over.

19.Use of an extension cord with this heater is not recommended.

However, if it is necessary to use an extension lead, ensure that the

lead uses the same power consumption as the appliance to avoid

overheating of the extension cord, appliance or plug point. Do not

place the extension cord in a position where it can be pulled on by

children or animals or tripped over.

20.This heater is not suitable for outdoor use. Do not use this heater for

anything other than its intended use.

21.DO NOT carry the heater by the power cord.

22.Do not leave this heater unattended during use. Always unplug the unit

when not in use or before cleaning.

23.Always operate the heater on a smooth, even, stable surface.

Do not place the unit on a hot surface.

24.Ensure that the switch is in the “OFF” position after each use.

25.The manufacturer does not accept responsibility for any damage or

injury caused by improper or incorrect use, or for repairs carried out by

unauthorized personnel.

26.In case of technical problems, switch off the heater and do not attempt

to repair it yourself. Return the heater to an authorised service facility

for examination, adjustment or repair. Always insist on the use of

original spare parts. Failure to comply with the above-mentioned

precautions and instructions, could affect the safe operation of this

heater.

27.Do not place the heater on windowsills or other places where it may be

exposed to dripping or splashing water; do not place vases or similar

objects filled with liquids near the heater.

28.Never touch the heater with wet or damp hands or feet.

29.Do not use the heater in bathrooms or in areas with high damp and

humidity or close to water.

30.Never expose the heater to atmospheric conditions such as rain, sun,

wind etc.

31.To avoid the risk of overheating, ensure the cable is completely

unwound when in use.

32.Only plug in and switch on the heater when it is in use. When not in

use, switch the heater off and unplug it.

33.Ensure the heater is kept a minimum distance of 50 cm from walls or

any objects and ensure the airflow is not directed to the wall or objects

to prevent and avoid damage.

34.Do not leave the heater unattended when it is on.

35.Ensure that the cord is not in front of warm air outlet grill when in use.

36.Only use the heater in its natural, vertical position.

37.Ensure the grills are always kept clean.

38.Never install and use the heater immediately below a fixed

power outlet.

39.Do not use the heater near liquids or flammable gasses

or materials.

40.Do not cover the heater.

41.Do not use the heater in rooms that are smaller than 4m2.

42.Do not use this heater with a programmer; timer, separate control

system or any other device that switches the heater on automatically.

IMPORTANT: ENSURE THE HEATER IS USED IN THE UPRIGHT POSITION

AT ALL TIMES.

CAUTION: DO NOT ALLOW THE HEATER TO TIP OVER.

SPECIFICATIONS:

Supply Voltage:

220-240V ~ 50-60Hz

Maximum Output:

1200W

PARTS DIAGRAM:

IMPORTANT:

When the heater is in use, it should always be kept vertical (handle should be at

the top). Putting the heater in any other position could be dangerous and cause a

potential fire hazard.

ASSEMBLY:

You will need to assemble the body frame and base plate together.

•Remove both the butterfly nuts (3) from the base plate.

•Insert the power cord through the hole in the middle of the base plate.

•Secure the base plate to the body frame.

•Secure with the 2 butterfly nuts (previously removed).

•Fix the power cord in place by slotting it into the designated clips.

1- Body frame

2- Base plate

3- Butterfly nut (2pcs)

4- Tip-over safety switch rod

5- Power cord

OPERATING INSTRUCTIONS:

1. Insert the plug into a suitable power socket ensuring the lead is neither near

the heat source nor a tripping hazard.

2. Select the number of elements required, 1, 2 or 3 by pressing the buttons

located at the top of the heater.

3. The buttons operate the top, middle and lower elements.

4. To make the heater oscillate press the turn button.

5. To make the heater stop oscillating press the turn button again.

CLEANING AND MAINTAINANCE:

•Ensure the unit is switched off and unplugged.

•Ensure the unit has cooled down.

•Clean the grilles frequently. This can be done with a damp cloth

or a duster.

•Never use abrasive powders or solvents.

•Do not stick any objects into the grills to try and clean them.

STORING THE HEATER:

1. Unplug the heater from the wall outlet and clean all the parts as

instructed above. Ensure that all parts are dry before storing.

2. Store the heater in its box or in a clean, dry place.

3. Never store the heater while it is still wet or dirty.

4. Storing the heater in a damp environment could cause the heater to

rust and/or will affect the mechanics in the heater which is not

covered by your guarantee.

SERVICING THE HEATER:

There are no user serviceable parts in this heater. If the unit is not operating

correctly, please check the following:

Problem

Possible Cause

Solution

The heater does not work.

1. Not properly plugged

into the mains

wall socket.

2. No electricity in the

mains wall socket.

1. Plug firmly into

the mains.

2. Check fuse or breaker.

The room is too cold.

1. The chosen power

setting is too low.

2. There’s a draft from a

window or door.

1. Increase the

power setting.

2. Block up any drafts

or close any

open windows.

The room is too hot.

1. The chosen power

setting is too high.

1. Choose a lower

power setting.

If the heater still does not work after checking the above:

- Consult the retailer for possible repair or replacement. If the retailer fails to

resolve the problem and you need to return the heater, make sure that:

•The unit is packed carefully into its original packaging.

•Proof of purchase is attached.

•A reason is provided for why it is being returned.

If the supply cord is damaged, it must be replaced by the manufacturer or an

authorised service agent in order to avoid any hazard. If service becomes

necessary within the warranty period, the heater should be returned to an

approved Home of Living Brands (Pty) Ltd service centre. Servicing outside the

warranty period is still available, but will, however, be chargeable.

CHANGING THE PLUG:

Should the need arise to change the fitted plug, follow the instructions below.

This unit is designed to operate on the stated current only. Connecting to

other power sources may damage the heater.

PLEASE AFFIX YOUR PROOF OF PURCHASE/RECEIPT HERE

IN THE EVENT OF A CLAIM UNDER WARRANTY THIS RECEIPT MUST BE PRODUCED.

W A R R A N T Y

1. Home of Living Brands (Pty) Limited ("Home of Living Brands") warrants to the original purchaser of

this product ("the customer") that this product will be free of defects in quality and workmanship

which under normal personal, family or household use and purpose may manifest within a period of

1 (one) year from the date of purchase ("warranty period").

2. Where the customer has purchased a product and it breaks, is defective or does not work properly

for the intended purpose, the customer must notify the supplier from whom the customer bought the

product ("the supplier") thereof within the warranty period. Any claim in terms of this warranty must

be supported by a proof of purchase. If proof of purchase is not available, then repair, and/or

service charges may be payable by the customer to the supplier.

3. The faulty product must be taken to the supplier's service centre to exercise the warranty.

4. The supplier will refund, repair or exchange the product in terms of this warranty subject to

legislative requirements. This warranty shall be valid only where (a) the customer is not the cause

of the product breaking, and (b) the product has been used for the intended purpose stipulated in

the product manual. The warranty does not include and will not be construed to cover products

damaged as a result of disaster, misuse, tamper, abuse or any unauthorised modification or repair

of the product.

5. This warranty will extend only to the product provided at the date of the purchase and not to any

expendables attached or installed by the customer.

6. If the customer requests that the supplier repairs the product and the product breaks or fails to work

properly within 3 (three) months of the repair and not as a result of misuse, tampering or

modification by or on behalf of the customer, then the supplier may replace the product or pay a

refund to the customer, subject to the supplier’s discretion.

7. The customer may be responsible for certain costs where products returned are not in the original

packaging, or if the packaging is damaged. This will be deducted from any refund paid to the

customer.

HOME OF LIVING BRANDS (PTY) LTD (JOHANNESBURG)

NATIONAL CONTACT TEL NO. (087) 245-0029

JOHANNESBURG TEL NO. (011) 490-9600

CAPE TOWN TEL NO. (021) 552-5161

DURBAN TEL NO. (031) 303-1163

www.homeoflivingbrands.com

www.pineware.co.za

Inhaltsverzeichnis

Andere Pineware Heizung Handbücher

Pineware

Pineware PQH02 Bedienungsanleitung

Pineware

Pineware PFH11 Installationsanleitung

Beliebte Heizung Handbücher anderer Marken

oventrop

oventrop Regucor Series Bedienungsanleitung

Blaze King

Blaze King CLARITY CL2118.IPI.1 Bedienungsanleitung

ELMEKO

ELMEKO ML 150 Bedienungsanleitung

BN Thermic

BN Thermic 830T Bedienungsanleitung

KING

KING K Series Leitfaden

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Kurzanleitung

Well Straler

Well Straler RC-16B Bedienungsanleitung

EUROM

EUROM 333299 Bedienungsanleitung

Heylo

Heylo K 170 Bedienungsanleitung

Eterna

Eterna TR70W Bedienungsanleitung

Clarke

Clarke GRH15 Bedienungsanleitung

IRSAP

IRSAP The Radiator Company Ovali Bedienungsanleitung

Empire Heating Systems

Empire Heating Systems WCC65 Bedienungsanleitung

Wetekom

Wetekom 92 86 43 Bedienungsanleitung

Desa

Desa SPC170-F Bedienungsanleitung

Watlow

Watlow Watrod Electric Tubular Heaters Bedienungsanleitung

Haverland

Haverland ECO-DRY GPS Series Stücklistenhandbuch

Stelpro

Stelpro ASILVC2060 Series Bedienungsanleitung
