PIONEERPOS StealthTouch M5 Bedienungsanleitung

Specifications

Display 15" LCD, Active matrix TFT, 1024x768

Touchscreen Option Resistive, Intellitouch SAW, InfraRed

Processor Intel Celeron-M 1GHz, upto Pentium-M 2GHz

Memory 512MB, upto 2GB DDR2

Video Memory upto 128MB (shared)

Storage Hard Drive, Solid-state Disk, or Compact Flash

CD/DVD Internal (optional)

Operating System XP Prof, WePOS, XP embedded, CE.NET, Linux

Network/Ethernet 10/100/1000 BaseT

WiFi (wireless) RF 802.11 (optional)

Serial Port 4

USB 2.0 6 : 4 Standard, 2 powered +12V, 1 powered +24V

Parallel Port 1

Cashdrawer Port 2 (Epson emulation, 24V)

CF Slot 1 (optional)

Speakers 2 Watts, Stereo (optional)

Mounting Options Wall or Pole mount, VESA 75mm

Security Lock Bolted (4mm screw), or Kensington MicroSaver

Bezel Color Dark grey

Dimensions (with Base) Width: 14.63" (380mm)

Height: 14.37" (373mm)

Depth: 10.37" (269mm), Wallmount: 3.3" (85mm)

Weight 22 lbs / 10 kgs (Wallmount: 10 lbs / 4.6 kgs)

Operating Temperature 0oC to 40oC

Operating Humidity 20% to 80%

Power Supply External, 120W, AC 100-240V

Agency Approvals FCC A, CE, UL

Add-ons Magnetic stripe or Barcode slot reader

Fingerprint /Biometric reader (DigitalPersona)

Rear customer display or 10" LCD

Barcode scanner (omni-directional)

Proximity RFID reader

StealthTouch-M5 Touchcomputer

compact, fanless, and versatile

StealthTouch-M5 is a 15" All-in-one touchcomputer powered by Intel

Pentium-M technology. Its versatile design allows you to customize the M5

to meet your application requirements and budget. The M5's versatility

makes it an ideal choice for applications in food service, retail,

manufacturing, healthcare, and self-service kiosk.

When configured as fanless and diskless thin client, the M5 will reduce

grease and dust intakes. It also has the power to run demanding

applications in Windows XP or Vista.

M5's benefits:

+ Rugged and slim design.

+ Choice of Resistive touch, Intellitouch, or InfraRed.

+ Blazing network, 10/100/1000BaseT. Wireless (WiFi) optional.

+ 4 Serial, 6 USB ports.

+ PoweredUSB to power up receipt printer, credit card terminal.

+ Integrated magnetic stripe reader and biometric fingerprint reader.

+ 2nd display port for advertisement on LCD or Plasma display.

Rear display

Dual view

VESA mount

Barcode scanner
