Planar Helium PCT2785 Bedienungsanleitung

www.planar.com

USER'S GUIDE

Touch LED LCD Monitor

PCT2785

Content

Operation Instructions...................................................................................................................................................1

Unpacking Instructions .................................................................................................................................................2

Safety Precautions...........................................................................................................................................................2

Package Overview ...........................................................................................................................................................3

Front View of the Product ............................................................................................................................................4

Rear View of the Product ..............................................................................................................................................4

Quick Installation .............................................................................................................................................................5

Webcam Installation.......................................................................................................................................................6

Basic Operation and Calibration/Reset Instructions...........................................................................................8

Advanced Operation—OSD Menu......................................................................................................................... 10

Supporting Timing Modes ........................................................................................................................................ 13

Technical Information................................................................................................................................................. 14

Wall-Mount Installation Instructions..................................................................................................................... 15

Troubleshooting............................................................................................................................................................ 16

Planar Support ............................................................................................................................................................... 17

Operation Instructions

Thank you for purchasing the PCT2785 multi-touch, edge-lit LED LCD monitor. Please read this

guide thoroughly before installation.

FCC RADIO FREQUENCY INTERFERENCE STATEMENT

WARNING: (FOR FCC CERTIFIED MODELS)

This LED Monitor has been tested and found compliant with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide proper protection

against harmful interference to a residential installation. This Touch LED LCD Monitor generates,

uses, and can radiate radio frequency energy. Harmful interference to radio communication may

be the result if it‘s not properly installed and used. However, there is no guarantee that

interference will not occur in a particular installation. If this Touch LED LCD Monitor does cause

serious interference to radio or television reception, resetting may correct it. Moreover, users are

encouraged to reduce interference by doing one or more of the following:

 Reorient or relocate the receiving antenna.

 Move the Touch LED LCD Monitor and the receiver further away from each other.

 Connect the Touch LED LCD Monitor into an outlet on a circuit different from that to which

the receiver is connected.

 Consult your local dealer or a qualified technician.

FCC Warning:

To assure a continued FCC compliance, a user must use a grounded power supply cord and the

provided shielded video interface cable with bonded ferrite cores. Also, any unauthorized

changes or modifications to this Touch LED LCD Monitor would void the user‘s authority to

operate this device.

Note: If necessary, shielded interface cables and AC power cord must be used to meet the

emission level limits.

According to WEEE regulation, this Touch LED LCD Monitor can't be handled as normal trash in Europe when

it is out of usage. Please refer to the recycle information on Planar’s website to handle it.

For more information on how to recycle your product, please visit http://www.planar.com/about/green/

Unpacking Instructions



Remove the Touch LED LCD Monitor out of the package and take off the plastic bag and

Polystyrene Foam.



Pull the base from Parallel versus Panel to Vertical.



Adjust the Panel between 15° leaning forward and 70° leaning backward.

Safety Precautions

Follow all warnings, precautions and maintenance as recommended in this user’s manual to

maximize the life of your unit.

Do:

 Turn off the product before cleaning.

 Touch screen surface may be cleaned using a soft clean cloth moistened with mild window

glass commercial cleaners or 50/50 mixture of water and isopropyl alcohol.

 Use a soft cloth moistened with mild detergent to clean the display housing.

 Disconnect the power plug from AC outlet if the product is not going to be used for an

extended period of time.

Don’t:

 Do not touch the LED Display screen surface with sharp or hard objects.

 Do not use abrasive cleaners, waxes or solvents for your cleaning.

 Do not operate the product under the following conditions:

o Extremely hot, cold or humid environment.

o Areas susceptible to excessive dust and dirt.

o Near any appliance generating a strong magnetic field.

o In direct sunlight.

 If smoke, abnormal noise or odor emits from your Touch LED LCD Monitor, remove the power

cord immediately and call your service center.

 Never remove the rear cover of your Touch LED LCD Monitor. The display unit inside contains

high-voltage parts and may cause electric shock.



Never try to repair your Touch LED LCD Monitor yourself. Always call your service center or a

qualified technician to fix it.



Due to safety concerns, if the VESA mounting kit is purchased separately, please

make sure the mounting kit is UL-listed, and replaceable only by service personnel.

Package Overview

Touch LED LCD Monitor Power Cord

VGA Signal Cable Audio-in Cable

USB Cable (A to B) HDMI Cable

Touch Pen Cable Wrap

User’s Guide Cleaning Cloth

Front View of the Product

①②③④⑤⑥⑦⑧

①Webcam LED indicator

②Webcam

③Microphone

④OSD Turn On/ Off

⑤Scroll Down/ Adjust Decrease/ Audio Adjust/ Auto *

⑥Scroll UP/ Adjust Increase/ Audio Adjust/ Mute *

⑦Input select/ Confirm Selection

⑧Power On/ Off/ LED Indicator

* Hot keys Instructions please see “Using the OSD Menu”on page 8.

Rear View of the Product

①②③④⑤⑥⑦⑧⑨

①Power Input

②Up-stream USB port (to PC)

③USB port-A (support USB 3.0 plug play device)

④USB port-B (support USB 3.0 plug play device)

⑤Audio Input

⑥Headphone Jack

⑦DisplayPort Input (DisplayPort 20 pin)

⑧VGA Input (D-Sub 15 pin)

⑨HDMI input (HDMI 19 pin)

Quick Installation

1. Connect either VGA, HDMI or DisplayPort Video Source from the monitor to the computer.

Make sure both monitor and computer are powered OFF. Please note. The monitor ships

with only VGA and HDMI cables. DisplayPort cable may be sourced separately from a cable

supplier.

2. Connect the audio cable from audio output of computer to the audio input of the monitor.

3. Connect the USB cable from the computer to the monitor.

4. Connect power cord to a properly grounded AC outlet, and then to the monitor.

5. Power-ON computer and then POWER-ON the monitor.

6. Set the timing mode on your computer. Recommended resolution and refresh rate is 1920 x

1080 @ 60Hz.

Figure 1:

Power cable

VGA cable

HDMI cable

Audio cable

USB 3.0 cable

DisplayPort cable

(not supplied)

Webcam Installation

1. Download the free“Instant messaging software” such as Yahoo Messenger, or Skype from

the Internet. Complete the installation.

2. Use the USB 3.0 cable (included with the monitor) to connect the monitor to one of the USB

3.0 ports of the computer.

3. Windows will automatically search for the camera, and proceed with the installation of the

driver.

4. Connect one end of the Microphone cable to the“Microphone in” port of the computer, and

connect the other end to the “MIC” port.

5. Start the Messenger software, and enjoy the pleasure of video chat.

Basic System Requirements

‧ Microsoft Windows 7, 8

‧ Pentium or compatible processor, 400 GHz

‧ USB Port

‧ Messenger Software (supporting video chat function), Video Software, or Video

Conferencing System

Hardware Installation

Connect your webcam’s USB cable to an available USB 3.0 port on your computer. Windows

automatically detects the device.

USB 3.0 cable

Microphone cable

Basic Operation and Calibration/Reset Instructions

Before using the Touch LED LCD Monitor:

 Connect external equipment properly.

 Insert the power plug, and the power LED indicator will light orange.

Power On/Off

To turn the Touch LED LCD Monitor on/off:

Press button on the front. The power LED indicator light will be blue when the Touch LED

LCD Monitor is on.

Using the OSD Menu

Use OSD menus to adjust settings by using the menu button on the front of the Touch LED LCD

Monitor.

Displays main menu

1 Exits from OSD menu

2 Selects between VGA, HDMI, DisplayPort or Auto mode

Select the desired item when in OSD menu

▼When not in OSD menu, directly enters Picture Mode, press 3 seconds

enters Auto Image Adjust.

Select the desired item when in OSD menu

▲When not in OSD menu, directly enters Audio Adjust menu, press 3

seconds enters Mute mode.

▼+ ▲Recalls both Contrast and Brightness (when not in OSD menu)

OSD Lock Out Function

When Touch LED LCD Monitor is in normal mode, the “OSD Lock Out” function can be enabled.

Option 1: OSD lock – all 4 buttons are locked except the “POWER” button.

Press and hold the 1button and the ▲button for 10 seconds to lock the OSD buttons.

The Touch LED LCD Monitor will show an “OSD LOCKED” message for 3 seconds and the

message will disappear automatically.

Repeat this step to unlock.
