PLANAR LCD MONITOR PE150MANUAL www.planar.com

Table of Contents

Preface ...............................................................................................................................2

Chapter 1 Installation........................................................................................................4

Unpacking ............................................................................................................................................. 4

Connecting the LCD Monitor and Base ................................................................................................ 4

Viewing Angle Adjustment................................................................................................................... 4

Detaching LCD Monitor from Its Stand................................................................................................ 5

Interface for Arm Applications.............................................................................................................. 5

Connecting the Display to your Computer ............................................................................................ 5

Connecting the AC Power..................................................................................................................... 5

Setting Up the LCD Monitor................................................................................................................. 5

Power Management System .................................................................................................................. 6

Chapter 2 Display Controls ...............................................................................................6

User Controls ........................................................................................................................................ 6

Adjusting the Monitor's Display............................................................................................................ 6

Function Description ............................................................................................................................. 7

Chapter 3 Technical Information .....................................................................................8

Specifications ........................................................................................................................................ 8

Standard Timing Table.......................................................................................................................... 9

Troubleshooting .................................................................................................................................. 10

Preface

This manual is designed to assist users in setting up and using the LCD Monitor. Information

in this document has been carefully checked for accuracy; however, no guarantee is given to

the correctness of the contents. The information in this document is subject to change without

notice. This document contains proprietary information protected by copyright. All rights are

reserved. No part of this manual may be reproduced by any mechanical, electronic or other

means, in any form, without prior written permission of the manufacturer.

FCC Statement Warning

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy, and if not installed and used in accordance with

the instruction, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications not expressly approved by the manufacturers may void the

user's authority to operate this equipment.

NOTE

A shielded-type signal cord is required in order to meet the FCC emission limits and also to prevent interference to

the radio and television reception. It is essential that only the supplied signal cord be used.

Canadian DOC Notice

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numérique de la classe B repecte toutes les exigences du Règlement sur le matériel

brouilleur du Canada.

Important Safety Instructions

Please read the following instructions carefully. This manual should be retained for future

use.

1. To clean LCD Monitor screen;

-- Power off LCD Monitor and unplug the AC Cord.

-- Spray a non-solvent cleaning solution onto a rag.

-- Gently clean the screen with dampened rag.

2. Do not place the LCD Monitor near a window. Exposing the monitor to rain water,

moisture or sunlight can severely damage it.

3. Do not apply pressure to the LCD screen. Excess pressure may cause permanent damage to

the display.

4. Do not remove the cover or attempt to service this unit by yourself. Servicing of any nature

should be performed by an authorized technician.

5. Store LCD Monitor in a room with a room temperature of -20° ~ 60°C (or -4° ~ 140°F).

Storing the LCD Monitor outside this range could result in permanent damage.

6. If any of the following occurs, immediately unplug your monitor and call an authorized

technician.

* Monitor to PC signal cable is frayed or damaged.

* Liquid spilled into LCD Monitor or the monitor has been exposed to rain.

* LCD Monitor or the case is damaged.

7. A certified line is required to connect this device to a power outlet. For a nominal current

up to 6A and a device weight above 3 kg, a line not lighter than H05VV-F, 3G, 0.75 mm2

must be used.

Chapter 1 Installation

Unpacking

Before unpacking the LCD Monitor, prepare a suitable workspace for your Monitor and

computer. You need a stable and clean surface near a wall power outlet. Make sure that LCD

Monitor has enough space around it for sufficient airflow. Though the LCD Monitor uses

very little power, some ventilation is needed to ensure that the Monitor does not become too

hot.

After you unpack the LCD Monitor, make sure that the following items were included in the

box:

* LCD Monitor * User's Manual on CD

* 1.5m Monitor-to-PC signal Cable * 1.8m Power Cord

* Base

If you find that any of these items is missing or appears damaged, contact your dealer

immediately.

Connecting the LCD Monitor and Base

When you open the box to take the base and put on the

desk first. Then connect the LCD Monitor and base

please.(See fig.1-1 )

Figure 1-1

Viewing Angle Adjustment

The LCD Monitor is designed to allow users to have a

comfortable viewing angle. The viewing angle can be

adjusted from -5°to +30°.(See fig. 1-2)

Figure 1-2

Warning

Do not force the LCD Monitor over its maximum viewing angle settings as stated above. Attempting this

will result in damaging the Monitor and Monitor stand.

Detaching LCD Monitor from Its Stand

1. Unscrew screws of the hinge bracket

2. Remove the stand from LCD monitor (See fig. 1-3)

Figure 1-3

Interface for Arm Applications

Before installing to mounting device, please refer to Fig.1-3.

The rear of this LCD display has four integrated 4 mm, 0.7

pitches threaded nuts, as well as four 5 mm access holes in

the plastic covering as illustrated in Figure 1-4. These

specifications meet the VESA Flat Panel Monitor Physical

Mounting Interface Standard (paragraphs 2.1 and 2.1.3,

version 1, dated 13 November 1997).

Figure 1-4

Connecting the Display to your Computer

1. Power off your computer.

2. Connect the signal cable to the VGA port on your PC.

3. Make sure connection are secure.

Figure 1-5

Attention

This device must be connected to an off-the-shelf video cable in order to comply with FCC regulations.

A ferrite-core interface cable is included in the LCD Monitor package.

This device will not be in compliance with FCC regulations when a non-ferrite-core video cable is used.

Connecting the AC Power

1. Connect the power cord to the Monitor AC socket.

(See Fig. 1-6)

2. Connect the plug Pin of power cord to an AC power

source.

Figure 1-6

Setting Up the LCD Monitor

1. Make sure the AC power cord is connected to the LCD Monitor.

2. Turn on the LCD Monitor's power switch, located on the bezel of the monitor.

Power Management System

This LCD Monitor complies with the VESA DPMS (version 1.0) Power Management guidelines. The

VESA DPMS provides four power saving modes through detecting a horizontal or vertical sync. signal.

When the LCD Monitor is in power saving mode, the monitor screen will be blank and the power LED

indicator will light yellow.

Chapter 2 Display Controls

User Controls

A brief description and the location of all LCD Monitor function controls and indicators:

Figure 2-1

1 DC Power Switch Press the power switch to switch the monitor ON/OFF.

2 DC Power-On

Indicator

LED lights Green color --- Power is ON.

LED lights Yellow --- Monitor is in "Power Saving Mode".

LED is off --- Power is OFF.

3 Function Select

Buttons

Press either left or right control button for OSD (On Screen Display)

menu selection.

4 Adjustment Control

Buttons

Press the left button to decrease the OSD setting and press the right

button to increase the OSD setting.

Adjusting the Monitor's Display

The monitor has four function control buttons to select among functions shown on OSD

menu, designed for easy user-viewing environments.

OSD Function Menu

To access OSD Main menu, simply press one of the

Function Select control buttons, and the menu

diagram will pop up on the screen as shown on Fig.

2-2:

Continue pressing the Function Select buttons to

scroll through the entire menu items ,then press

Adjustment Control buttons to adjust content of

selected item.

Figure 2-2

Attention

Firmware revision may have been updated into a latest version while the version number shown on all

OSD menus in this manual will stay as Ver. 1.00.

Function Description

Icon Function Function Description

Brightness This function increases or decreases the brightness of the image.

Contrast This function increases or decreases the difference between the dark and light

color.

H-Position This function shifts the entire display image left or right.

V-Position This function shifts the entire display image up or down.

Phase A total of 32 scales (0 to 31) are available to adjust the focus and clarity of the

display.

Clock

This function carries a frequency tracking feature that offers the user to have

better stability and clarity. Increasing Clock value can be up to +50 scales. The

number of decreasing Clock (minus) is depend on the input timing.

Auto Adjustment This function will adjust the display size automatically to fit full screen.

OSD H-Position This function moves the OSD menu window left or right.

OSD V-Position This function moves the OSD menu window up or down.

Graph Text

This function is to choose a display that allows maximum graphics text

quality. The resolution selection can either be 640 x 400 or

720 x 400. Please refer to Chapter 3 “ Standard Timing” Table for of different

timing modes.

Recall The recall function will return all adjusted parameters to factory preset values.

Language

Five OSD language options are available:

English, German, French, Spanish and Italian.

Press the left or right Adjustment Control button to select other language.

Color

Temperature

Color Temp.: Push the (+ -) button to select a different color temperature.

Please see the diagram below for function and description.

Save Exit Saves the values of this setting and exits the OSD menu function.

Icon Function Description

9300 CIE coordinated Color Temperature of

9300°K

Sets the CIE coordinate color temperature to

9300°K

6500 CIE coordinated Color Temperature of

6500°K

Sets the CIE coordinate color temperature to

6500°K

User Three colors (Red, Green, Blue) can be

adjusted from the OSD menu

Sets the settings to a by user defined CIE

Temperature.

Chapter 3 Technical Information

Specifications

LCD Panel

Size 15.0" (38 cm)

Display Type Active matrix color TFT LCD

Resolution 1024 x 768

Display Area (mm) 304 x 228 (H x V)

Brightness 200 cd/m2(typical)

Contrast Ratio 400:1 (typical)

Response Time 35 ms (typical)

Viewing Angle

Vertical: -55° ~ +45°

Horizontal: -65° ~ +65°

Display Colors 16.7M with FRC or Dithering

Video

Input Signal

Input Impedance

Polarity

Amplitude

Multi-mode Supported

Analog RGB 0.7Vp-p

75 Ohm ± 2%

Positive, Negative

0 - 0.7 ± 0.05 Vp

Horizontal Frequency: 24 ~ 61 KHz

Vertical Frequency: 56 ~ 75 Hz

Control

Power On/Off switch with LED indicator

Power Management

Mode Power AC Input LED Color

On 25W maximum 240 VAC Green

Standby 5W maximum 240 VAC Yellow

Suspend 5W maximum 240 VAC Yellow

Off 5W maximum 240 VAC Yellow

DC Power Off 5W maximum 240 VAC Dark

Disconnected 5W maximum 240 VAC Yellow: Standby, Suspend, Off

Dark: DC Power off

* Meeting VESA DPMS requirements measured from AC Input end of AC adapter.

Inhaltsverzeichnis

Andere Planar Monitor Handbücher

Planar

Planar UltraRes X RS232 Series Bedienungsanleitung

Planar

Planar m70L Bedienungsanleitung

Planar

Planar UltraRes W Series Bedienungsanleitung

Planar

Planar PL1910W Bedienungsanleitung

Planar

Planar PL1500M Bedienungsanleitung

Planar

Planar PT1945RW Bedienungsanleitung

Planar

Planar PLL2210MW Bedienungsanleitung

Planar

Planar Bobcat X SN-4045-WX Bedienungsanleitung

Planar

Planar c50RP Bedienungsanleitung

Planar

Planar PXN2480MW Bedienungsanleitung

Planar

Planar VitalScreen S VSS17SX Bedienungsanleitung

Planar

Planar PX1710M Bedienungsanleitung

Planar

Planar UltraLux Series Bedienungsanleitung

Planar

Planar CM17.4SXAD Bedienungsanleitung

Planar

Planar PL1700 Bedienungsanleitung

Planar

Planar PE1500 Bedienungsanleitung

Planar

Planar PS5562 Bedienungsanleitung

Planar

Planar Clarity Matrix MX55HDU Bedienungsanleitung

Planar

Planar Dome Q2 Bedienungsanleitung

Planar

Planar ICEBrite EL VGA Displays EL640.480-AM Bedienungsanleitung

Planar

Planar WS231 Bedienungsanleitung

Planar

Planar PL1920M Bedienungsanleitung

Planar

Planar PL2010 Bedienungsanleitung

Planar

Planar PT1545R Bedienungsanleitung

Beliebte Monitor Handbücher anderer Marken

Linear Acoustic

Linear Acoustic LQ-1000 Bedienungsanleitung

AOC

AOC I2579V Bedienungsanleitung

Gateway

Gateway FPD1520 Bedienungsanleitung

Furuno

Furuno Mu 120c Bedienungsanleitung

Asus

Asus VB171D - 17" LCD Monitor Bedienungsanleitung

Dell

Dell S2230MX Gebrauchsanweisung

Philips

Philips 107C64 Bedienungsanleitung

Dell

Dell S2409WFP Bedienungsanleitung

EverFocus

EverFocus EN-7517E Bedienungsanleitung

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Bedienungsanleitung

Dell

Dell Precision 7680 Bedienungsanleitung

LG 50PM1M - - 50" Plasma Panel Bedienungsanleitung

Bosch

Bosch DDU 9 Bedienungsanleitung

Acer

Acer A231HL Bedienungsanleitung

Philips

Philips 86BDL4152T Bedienungsanleitung

NEC

NEC AccuSync LCD5V Bedienungsanleitung

Emay

Emay SleepO2 Bedienungsanleitung

IBM

IBM 6360 Montageanleitung
