Planar PT1785P Bedienungsanleitung

PT1700MX / PT1710MX /

PT1775S / PT1785P

Touch Screen LCD Monitors

USER’S GUIDE

www.planartouch.com

The information contained in this document is subject to change without notice.

This document contains proprietary information that is protected by copyright. All rights

are reserved. No part of this document may be reproduced, translated to another lan-

guage or stored in a retrieval system, or transmitted by any means, electronic,

mechanical, photocopying, recording, or otherwise, without prior written permission.

Windows is a registered trademark of Microsoft, Inc.

Other brand or product names are trademarks of their respective holders.

Important Recycle Instructions:

Lamp(s) inside this product contains mercury. This product may contain other

electronic waste that can be hazardous if not disposed of properly. Recycle or dispose in

accordance with local, state, or federal Laws. For more information, contact the Electronic

Industries Alliance at WWW.EIAE.ORG. For lamp specific disposal information check

WWW.LAMPRECYCLE.ORG.

For more information on how to recycle your product, please visit

WWW.PLANARSYSTEMS.COM/GREEN.

Precautions .....................................................................................................3

Table of Contents

Usage Notice ...........................................................................3

Introduction .............................................................................4

About PT1700MX / PT1701MX / PT1775S ....................................................4

Touch Screen for PT1700MX ..................................................................5

Touch Screen for PT1701MX ..................................................................5

Touch Screen for PT1775S .....................................................................5

Touch Screen for PT1785P .....................................................................6

Package Overview ..........................................................................................7

Installation ...............................................................................8

Product Overview............................................................................................8

Front View .................................................................................................8

PT1700MX / PT1701MX / PT1775S Bottom View ....................................8

PT1785P Bottom View ..............................................................................8

Start Your Installation......................................................................................9

Connecting the Display (Figure 12.1) ...........................................................11

(Figure 12.1) ..........................................................................................12

Kensington Security Slot...............................................................................13

VESA Mount your monitor ............................................................................14

Remove the Deskstand .........................................................................15

User Controls .........................................................................16

Side Panel Controls ......................................................................................16

How to Use the OSD Menus.........................................................................17

On-Screen

Display

Menus

.........................................................................19

Appendix................................................................................20

Troubleshooting ...........................................................................................20

Warning Signal.............................................................................................21

No Signal................................................................................................21

Going to Sleep.........................................................................................21

Out of Range ...........................................................................................21

Product Dimensions.....................................................................................22

Compatibility Modes.....................................................................................24

Touch Screen Driver Installation..................................................................25

Product Registration and Technical Support ...............................................31

Usage Notice

Warning-To prevent the risk of fire or shock hazards, do not expose

this product to rain or moisture.

Warning-Please do not open or disassemble the product as this may

cause electric shock.

Precautions

Follow all warnings, precautions and maintenance as recommended in this

user’s manual to maximize the life of your unit.

Do:

Turn off the product before cleaning.

Touch screen surface may be cleaned using a soft clean cloth

moistened with mild window glass commercial cleaners or 50/50

mixture of water and isopropyl alcohol.

Use a soft cloth moistened with mild detergent to clean the display

housing.

Use only high quality and safety approved AC/DC adapter.

Disconnect the power plug from AC outlet if the product is not going

to be used for an extended period of time.

Don’t:

Do not touch the LCD Display screen surface with sharp or hard

objects.

Do not use abrasive cleaners, waxes or solvents for your cleaning.

Do not operate the product under the following conditions:

- Extremely hot, cold or humid environment.

- Areas susceptible to excessive dust and dirt.

- Near any appliance generating a strong magnetic field.

- In direct sunlight.

Introduction

About PT1700MX / PT1701MX / PT1775S /

PT1785P

The PT1700MX / PT1701MX / PT1775S / PT1785P is a 17” flat panel

screen with an active matrix, thin-film transistor (TFT) liquid crystal

display (LCD).

Features include:

Direct Analog signal input

Active matrix TFT LCD technology

1280x1024 SXGA resolution

17” viewable display area

31.47 ~ 80 kHz horizontal scan

56 ~ 75 Hz high refresh rate

0.264mm x 0.264mm Pixel pitch

Auto adjustment function

Multilingual OSD user controls

VESA DPMS power saving

Kensington security slot

75 mm / 100 mm VESA mount

Removable base for flexible mounting solutions.

PT1700MX – 5-wire resistive touch screen with dual RS-232 Serial/USB

controller

PT1701MX – Capacitive touch screen with dual RS-232 Serial/USB

controller

PT1775S – SAW touch screen with dual RS-232 Serial/USB controller

PT1785P – Projected capacitive touch screen with USB controller

Built-in speakers-1W X 2

Touch Screen for PT1700MX

5-wire resistive touch screen for finger and stylus input

Surface: Anti-glare treatment

Interface: Dual RS-232 Serial/USB controller

Durability: 35 million touches at a single point

Hardness of surface: 3H Typical

Operating force: 40g~200g when using a silicon rubber tipped pen with a

1 mm diameter minimum and a hardness of 60 degree.

Transmittance: 82%±5%

Driver: Windows®7, VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded,

Linux, Apple®Mac OS

Touch Screen for PT1701MX

Capacitive touch screen for finger input

Surface: Anti-glare treatment

Interface: Dual RS-232 Serial/USB controller

Durability: 225 million touches at a single point

Hardness of surface: Mohs’ Hardness rating of 7

Transmittance: 85%±5%

Driver: Windows®7, VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded,

Linux, Apple®Mac OS

Touch Screen for PT1775S

Surface Acoustic Wave (SAW) touch screen for finger and stylus input

Surface: Anti-glare treatment

Interface: Dual RS-232 Serial/USB controller

Durability: 50 million touches at a single point

Hardness of surface: Mohs’ Hardness rating of 7

Operating force: Typically less than 85 g

Transmittance: 92%±5%

Driver: Windows®7, VISTA, XP, 2000, ME, 98, NT4.0, CE, XP Embedded,

Linux, Apple®Mac OS

Touch Screen for PT1785P

Project capacitive touch screen for finger input only

Surface: Glare treatment

Interface: USB controller

Transmittance: 90%±5%

Driver: Windows®7, VISTA 64/32 bits, XP, 2000, XP Embedded Express,

Linux, Apple®Mac OS

Package Overview

LCD Display Power Cord VGA Signal Cable

USB Cable - Type A to B Audio-in Cable RS-232 Cable

(PT1700MX/PT1701MX/PT1775S only)

User’s Manual

Landing Strip Touch Screen Driver

Installation CD-ROM

User’s Guide

DC Power Supply

(sold separately) Cable Cover Screw

Installation

Product Overview

 Front View

PT1700MX/PT1701MX/PT1775S PT1785P

 PT1700MX/PT1701MX/PT1775S Bottom View (Without Stand)

 PT1785P Bottom View (Without Stand)
