Planet Networking & Communication GS-4210-16P4C Bedienungsanleitung

8-/16-/24-/48-Port 10/100/1000T +

2-/4-Port 100/1000X SFP Managed Switch

GS-4210 Series

Quick Installation Guide

Table of Contents

1. Package Contents ....................................................................................... 3

2. Requirements ............................................................................................. 5

3. Terminal Setup ........................................................................................... 6

3.1 Logging on to the Console.................................................................... 7

 3.2 ConguringIPAddressviatheConsole ................................................. 7

 3.3 StoringCurrentSwitchConguration..................................................... 9

4. Starting Web Management .........................................................................10

 4.1 LoggingintotheManagedSwitch .......................................................10

 4.2 SavingCongurationviatheWeb ........................................................12

5. RecoveringBacktoDefaultConguration.....................................................13

6. Customer Support .....................................................................................16

1. Package Contents

Thank you for purchasing PLANET GS-4210 Managed Switch series. The

descriptionsofthisseriesareshownbelow:

Model Description PoEBudget

GS-4210-8T2S 8-Port10/100/1000T+2-Port100/1000XSFP

ManagedSwitch ---

GS-4210-8P2S 8-Port10/100/1000T802.3atPoE+2-Port

100/1000XSFPManagedSwitch 140W

GS-4210-8P2C

8-Port10/100/1000T802.3atPoE+2-Port

10/100/1000T+2-Port100/1000XSFPManaged

Switch

120W

GS-4210-16T2S 16-PortLayer2ManagedGigabitEthernetSwitch

w/2SFPInterfaces ---

GS-4210-16P2S 16-Port10/100/1000T802.3atPoE+2-Port

100/1000XSFPManagedSwitch 220W

GS-4210-16P4C 16-Port10/100/1000T802.3atPoE+4-Port

GigabitTP/SFPComboManagedSwitch 240W

GS-4210-24T2S 24-PortLayer2ManagedGigabitEthernetSwitch

w/2SFPInterfaces ---

GS-4210-24P2S 24-Port10/100/1000T802.3atPoE+2-Port

100/1000XSFPManagedSwitch 300W

GS-4210-24P4C 24-Port10/100/1000T802.3atPoE+4-Port

GigabitTP/SFPComboManagedSwitch 280W

GS-4210-24PL4C 24-Port10/100/1000T802.3atPoE+4-Port

GigabitTP/SFPComboManagedSwitch 430W

GS-4210-24T4S 24-Port10/100/1000T+4-Port100/1000XSFP

ManagedGigabitSwitch ---

GS-4210-24T4SR

24-Port10/100/1000T+4-Port100/1000X

SFPManagedGigabitSwitchwith36-72VDC

RedundantPower

---

GS-4210-48T4S 48-PortLayer2ManagedGigabitEthernetSwitch

w/4SFPInterfaces ---

“Managed Switch” is used as an alternative name in this Quick Installation

Guide.

Open the box of the Managed Switch and carefully unpack it. The box should

containthefollowingitems:

zTheManagedSwitchx1

zQuickInstallationGuidex1

zRS232 to RJ45 Cable x 1

zRubberFeetx4

zTwoRack-mountingBracketswithAttachmentScrewsx1

zPowerCordx1

zSFPDust-proofCap

Models SFPDust-proofCaps

GS-4210-8P2C

GS-4210-8T2S

GS-4210-8P2S

GS-4210-16T2S

GS-4210-16P2S 2

GS-4210-24T2S

GS-4210-24P2S 2

GS-4210-16P4C

GS-4210-24P4C

GS-4210-24PL4C

GS-4210-24T4S

GS-4210-24T4SR

GS-4210-48T4S

If any item is found missing or damaged, please contact your local reseller for

replacement.

2. Requirements

zWorkstations running Windows XP/2003/2008/2012/Vista/7/8/10/11, MAC OS X

orlater,Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.

zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard).

zSerial Port Connection(Terminal)

The above Workstations come with COM Port (DB9) or USB-to-RS-232

converter.

The above Workstations have been installed with terminal emulator, such as

TeraTerm,PuTTYorHyperTerminalincludedinWindowsXP/2003.

Serial cable -- one end is attached to the RS-232 serial port, while the other

endtotheconsoleportoftheManagedSwitch.

zEthernet Port Connection

 Networkcables--Usestandardnetwork(UTP)cableswithRJ45connectors.

 TheabovePCisinstalledwithWebbrowser.

Note

It is recommended to use Chrome 98.0.xxx or above to access the

ManagedSwitch. Ifthe Web interface ofthe ManagedSwitch isnot

accessible, please turn off the anti-virus software or firewall and

then try it again.

3. Terminal Setup

To congure the system, connect a serial cable to a COM port on a PC or

notebook computer while the other end to RJ45 console port of the Managed

Switch.

Managed Switch

PC / Workstation

with

Terminal Emulation Software

Serial Port

RS232 to RJ45 Cable

Console Port

RJ45

Figure 3-1: Managed Switch Console Connectivity

A terminal program is required to make the software connection to the Managed

Switch.

1. Run terminal program on the OS.

2.When the following screen appears, make sure that the COM port should be

conguredas:

Baud:115200

Databits:8

Parity:None

Stopbits:1

Flowcontrol:None

Figure 3-2: COM Port Conguration

3.1 Logging on to the Console

Once the terminal is connected to the device, power on the Managed Switch and

the terminal will run self testing procedures. Then, the following message asks to

log in user name and password. The factory default user name and password are

shownasfollowsandtheloginscreeninFigure3-3appears.

Username:admin

Password:admin

Note

The following console screen based on the GS-4210-24T4S is the

sameasthoseoftheGS-4210series.

Figure 3-3: Managed Switch Console Login Screen

The user can now enter commands to manage the Managed Switch. For a detailed

descriptionofthecommands,pleaserefertothefollowingchapters.

Note

1.For security reason, please change and memorize the new pass-

wordafterthisfirstsetup.

2.Only accept command in lowercase letter under console inter-

face.

3.2 ConguringIPAddressviatheConsole

TheManagedSwitchisshippedwithdefaultIPaddressasshownbelow:

IPAddress:192.168.0.100

SubnetMask:255.255.255.0

To check the current IP address or modify a new IP address for the Managed

Switch,pleaseusetheproceduresasfollows:

 DisplayofthecurrentIPaddress

1. On “GS-4210-24T4S#”prompt,enter“show ip”.

2.The screen displays the current IP address, subnet mask and gateway shown in

Figure3-4.

Figure 3-4: IP Information Screen

 CongurationoftheIPaddress

3. On “GS-4210-24T4S#”prompt,enter“congure”.

4. On “GS-4210-24T4S (cong)#” prompt, enter the following command and

press<Enter>asshowninFigure3-5.

GS-4210-24T4S(cong)# ip address 192.168.1.100 mask 255.255.255.0

GS-4210-24T4S(cong)#ip default-gateway 192.168.1.254

ThepreviouscommandwouldapplythefollowingsettingsfortheManagedSwitch.

IP Address: 192.168.1.100

Subnet Mask: 255.255.255.0

Gateway: 192.168.1.254

Figure 3-5: Setting IP Address Screen

5.RepeatStep1tocheckiftheIPaddresshaschanged.

If the IP is successfully congured, the Managed Switch will apply the new IP

address setting immediately. You can access the Web interface of Managed Switch

throughthenewIPaddress.

Note

Ifyouarenotfamiliarwithconsolecommandortherelatedparam-

eter,enter“?”anytimeinconsoletogetthehelpdescription.

3.3 StoringCurrentSwitchConguration

In switches, the running conguration le is stored in the RAM. In the current

version, the running conguration sequence can be saved from the RAM to FLASH

by saving command or copying running-cong startup-cong command, so

that the running conguration sequence becomes the startup conguration le,

whichiscalledcongurationsave.

1. On “GS-4210-24T4S #”prompt,enter“copy running-cong startup-cong”

asshowninFigure3-6.

Figure 3-6: Saving the Conguration Screen

4. Starting Web Management

The following shows how to start up the Web Management of the Managed

Switch. Note the Managed Switch is congured through an Ethernet connection.

Please make sure the manager PC must be set to the same IP subnet address.

For example, the default IP address of the Managed Switch is 192.168.0.100;

then the manager PC should be set to 192.168.0.x (where x is a number

between1and254,except100)andthedefaultsubnetmaskis255.255.255.0.

PC / Workstation

with Web Browser

192.168.0.x

Managed Switch

RJ45/UTP Cable

IP Address: 192.168.0.100

Figure 4-1: IP Management Diagram

4.1 Logging in to the Managed Switch

1.Use Chrome 98.0.xxx or above Web browser and enter IP address

https://192.168.0.100toaccesstheWebinterface.

2.When the following dialog box appears, please enter the default user name and

password“admin”.TheloginscreeninFigure4-2appears.

DefaultIPaddress:192.168.0.100

DefaultUsername:admin

DefaultPassword:admin

Figure 4-2: Web Login Screen
