Planet NOVA100 Series Bedienungsanleitung

NOVA100 series

FN-500

FN-800

Palm Top

Fast Ethernet Stackable Hub

EMFN5/800

Trademarks

Contents subject to revision without prior notice.

PLANET is a registered trademark of PLANET

Technology Corp. The information in this manual is

subject to change without notice. All other trademarks

belong to their respective owners.

FCC Warning

This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is operated

in a commercial environment. This equipment

generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance

with the Instruction manual, may cause harmful

interference to radio communications. Operation of

this equipment in a residential area is likely to cause

harmful interference in which case the user will be

required to correct the interference at his own

expense.

Table of Contents

1Unpacking Information

Check List 5

Product Features 6

2General Description

About FN-500/FN-800 7

Front Panel of FN-500/FN-800 7

Rear Panel of FN-500/FN-800 9

3Installation

Hardware Installation 11

General Rules 11

Connecting End Nodes 12

Stacking two Hubs 13

Hub to Hub Connection, through Uplink port 14

Connecting the Hub to AC Power 15

4Troubleshooting 17

Appendix

Product Specification 19

FN-500/FN-800 User’s Manual 5

1. Unpacking Information

Check List

Carefully unpack the package and check its contents against

the checklist given below.

Checklist of 5/8-port 100Base-TX Fast Ethernet Hub

•NOVA100 5/8-port Palm-Top Fast Ethernet hub

•User’s manual

•AC Power Adapter and Power Cord

•RS-232 Stackable cable

•Accessories

Please inform your dealer immediately for any wrong, missing,

or damaged part if possible, retain the carton including the

original packing materials, and use them against to repack

the product in case there is a need to return it to us for repair.

PLANET NOVA100 Series

Product Features

•Conforms to IEEE 802.3U 100Base-TX standard

•Provides LED indicators for monitoring overall hub

condition and individual port status

•Automatic bad port partitioning to protect the network

•Two expansion connectors for stacking up to 5 hubs

together, and confirming Class II specification

•For desktop or wall-mounted installation

FN-500/FN-800 User’s Manual 7

2. General Description

About FN-500/ FN-800

This section describes the important parts of NOVA 100 5/8-

port Fast Ethernet hub. It presents front panel and rear panel

drawings of the product showing the LEDs, connectors, and

switches.

FN-500: 5-port Palm-Top Fast Ethernet Stackable Hub

FN-800: 8-port Palm-Top Fast Ethernet Stackable Hub

Front Panel of FN-500/ FN-800

The following figure shows the front panel of FN-500/FN-

800 100Base-TX Fast Ethernet hub.

1 2 3 4 5UpLink

Networking & Comm unic ation

FN-500

PWR

COL

1 2 3 4 5

LINKTX/RX

Figure 1. Front Panel of FN-500

1 2 3 4 5 6 7 8

UpLink

Networking&Communication

FN-800

PWR

COL

1 2 3 4 5 6 7 8

LINKTX/RX

Figure 2. Front Panel of FN-800

There are 5/8 (five/eight) RJ-45 ports and one “Uplink”port

on the front panel. Each port is labeled with a port number.

One special port labeled with “Uplink”is converted from

PLANET NOVA100 Series

port#1. You can either use Port#1 or “Uplink”port. The

“Uplink”port is used for connecting another hub through an

ordinary straight-wired twisted-pair cable by running one end

of straight cable to “Uplink”port and the other end to another

hub’s station port.

On the front panel, there are several LED indicators for

monitoring the device itself, and the network status. At a

quick glance of the front panel, the user would be able to tell

if the product is receiving power; if it is monitoring another

hub or concentrator; or if a problem exists on the network.

LED Indications

The following describes the function of each LED indicator.

LEDs Status Descriptions

PWR

(Power LED) Steady

Green This LED light is located at the left

side on the front panel. It will light

up(ON) to show that the product is

receiving power. Conversely, no light

(OFF) means the product is not

receiving power.

COL

(Collision

LED)

Blink

Red A “collision”in Ethernet, is when

two end nodes transmit at the same

time. The indicator lights up

whenever there is a collision between

a directly attached end node and any

other node

FN-500/FN-800 User’s Manual 9

LEDs Status Descriptions

LNK

(Link LEDs) Steady

Green Each RJ45 station port on the hub is

assigned an LED light for monitoring

port "Good Link and Activity". Each

LED is normally OFF after the power

on operation, but will light up

steadily to show “Good Link”.

TX/RX

(Activities

LEDs)

Blink

Green Each LED is normally OFF after the

power on operation and flash to show

that transmit and receive signals are

passing in and out the hub. The

flashing rapidly increases with the

network traffic.

Rear Panel

On the rear panel there are power DC jack, ID switch and two

expansion connectors. The following describes the function of

each connector and switch.

Figure 3 Rear panel of FN-500

Figure 4 Rear panel of FN-800

PLANET NOVA100 Series

DC Power Jack

The power cord should be plug into this socket. The DC jack

accept DC power equal to 5 Volt , 2 Amp, minimum for FN-

500 and 4 Amp. minimum for FN-800.

ID Switch

This switch is for setting the address of each hub when stack

two or more hubs together. Each hub should have one unique

number. The switch has four positions (No.1 to 4), therefore,

there are 16 possible combinations, except the setting of all

positions at OFF is not allowed;i.e. 15 combinations only is

accepted. For example, the settings from position No.1 to 4

are “off off on on”, the corresponding ID number is “3”.

Expansion Connectors

For FN-500/FN-800, there are two DB25 female connectors at

rear panel . These two connectors have the same function then

user can stack another hub by choosing any one of them.

Therefore, if one is used for “stack up”, then the other is for

“stack down”. Any combination of 5/8 port hub is allowed

only within the limitation of 5 hubs in one stack.
