Page1

Model APS-997C

Owner’sManual

IMPORTANT! In order to provide you with the highest level of security to your

vehicle, this system is equipped with selectable manual override circuitry. It is

possible that you will need to override you security system if the transmitter

becomes lost, or inoperative due to battery failure. Reading the sections on

"Manually Overriding Your System" is necessary to fully understand the procedure

required to enable your vehicle in such situations. In addition, the chart on page

23 of this manual has a section for the particular features and options installed in

your vehicle as well as the override method selected. Although the default mode

is "Valet Switch" operation, the system can be configured for "Custom Code"

operation for enhanced security. Confirm the override mode selected on page 23

of this manual, and familiarize yourself with the section on it's operation.

FEATURES :

1 Two Way 5 Button Remote Control And 1 One Way 5 Button Remote Control

Six Channel Code Learning Programmable Receiver

External Superheterodyne Transceiver Antenna w/PushButton Switch & LED

Single Or Two User Programmable W/Separate Control Outputs

Single Button Lock/Unlock or Separate Button Lock/Unlock or Both

Remote Keyless Entry With Optional Access Guard (must have power door

locks)

Selectable Manual Override Mode

New Enhanced Panic Feature (Any button other than unlock stops siren, no

change to the units state)

Smart Disarm (If triggered, elect to shut off siren, or disarm entire unit )

Adjustable Shock Sensor Via The Transmitter (Pre-Detect Off, Pre & Full Detect

Off,CityMode)

Safe Start Output Controlled From Channel 3 (Option Channel 3 ForTrunk, Or

For Remote Start)

24 Hour Time Start Mode

Cold Temperature Start Mode

2 or 4 Hour Automatic Start Mode

Parking Meter Count Down Timer On LCD Remote

Additional Count Down Timer Mode

Remote Panic InAll Modes (Press & Hold Lock /Unlock Button For 3 Seconds

To Engage)

Improved Custom Code Override, User Selectable and Programmable

Protected Push Button Valet/Override Switch In Windshield Receiver

5 Button Remote Start Security System With

Plug-In Shock Sensor & Starter Disable

128-8774

2 of 24

Page2

7-Function LED-Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming

Intrusion Alert With Memory

Instant Siren Activation

Starter Disable Output

Additional Engine Immobilizer Output, (Optional Relay Required)

True Last Door Arming (Hardwire Only)

Defective Zone By-Pass

Defective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared)

6 Tone Mini Siren

Car Horn Output ForAdditionalAlarm Response (Improved Timing To Minimize

RF Interference.)

Additional Negative Trigger Input (Hood and Trunk)

RF Inhibit With Ignition On

Parking Light Flasher (Relay On Board)

Plug In Dual Stage Shock Sensor (Pre-detect, Full Trigger and “City Mode”)

Audible Arm, Disarm, Defect, and Tamper Chirp Indications

Headlight Control Output

Illuminated Entry Control Output

Active or Passive Arming Selectable

Programmable Auto Lock On / Off

Programmable Auto Unlock On / Off/Drivers Door/All Doors

Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec

L/ Dbl. U/L

Programmable Active or Passive Door Locks

User Programmable Permanent Chirp Delete

On Command RF Chirp Delete from Transmitter Or Selectable Through

Software

Dome Delay Learn Circuitry (Patent Pending)

OPTIONS :

Remote Trunk Release (must have electric trunk release)

Remote Keyless Entry (must have power door locks)

Multiple Vehicle Capable

Remote Power Window Roll Up

Remote Garage Door Interface

WARNING! Be certain that the vehicle is outdoors before using this or any remote

vehicle starting device. A running engine produces dangerous car-

bon monoxide fumes which can be harmful or fatal if prolonged expo-

sure occurs. DO NOT remote start the vehicle if it is garaged.

YOUR“CODEHOPPING“TRANSMITTERS

The transmitters included with your new security system use the most advanced

and secure form of radio frequency transmission available on any current auto-

motive security system. Some of today’s sophisticated auto thieves use a device

known as a code grabber, which will receive and store the signal from your

128-8774

3 of 24

Page3

keychain transmitter and re-transmit at a later time to disarm your system.

Your Keeloq Code Hopping transmitters will change their signal every time the

button is pressed, so when a thief grabs then re-transmits your signal, the alarm

system will not respond.

If your transmitter button is pressed more than fifty times while it is out of range of

the vehicle (children playing with your keys), the transmitter will not operate when

you return to the vehicle, and will need to be re-aligned to the receiver. To do this,

simply press button 1, (lock), two times within a one second time period. The

system will now respond to that transmitter each time a button is pressed.

NOTE:This system is custom configurable and can be set up to

operate with a number of options controlled from any transmit-

ter button or button combination. For reference, we will de-

scribe operation assuming that your system is programmed

for separate lock and unlock buttons. Also reference will be

made to the icons as shown on the buttons left.

NOTE: The LCD based remote will be explained in detail fur-

ther in this manual See "System Status" described later in this

manual. Consult your installation center if your system has

been configured differently.

NOTE: Your system has the option of using a siren, the vehicle

horn, or both for the sounding device. Where the siren is refer-

enced below, the horn or both may in fact chirp, or beep.

ARMINGTHE SYSTEM-ACTIVE

1. Turn off the engine, exit the vehicle, and close all doors, hood lid and trunk lid.

2. Press and release Lock/Arm button on the keychain transmitter.

The dash mounted LED begins to flash slowly.

Parking Lights flash one time.

Siren sounds one chirp.

If the siren/horn sounds 3 chirps, then you have left a door, trunk, or

hood lid ajar. Simply close the opened entry point to provide full protec-

tion. If the siren "chirped" three times, sometime after arming, the

exclusive delayed dome light learn circuit has been programmed and

the system detected a open entry point after the learned delay expired.

Again, closing the hood, trunk, or doors will correct the problem and you

do not need to disarm the system to make the correction. If the siren/

horn did not sound when arming, then the chirps have been turned off

and you should refer to the section titled "ELIMINATING THE ARM/DIS-

ARM CHIRPS" in this manual.

Doors Lock - Optional

NOTE: If the optional Headlamp illumination feature has been added, and has

been selected for operation when arming, as an added convenience, the

system will turn on the headlights when the system is armed.

SILENT ARMING - ACTIVE (Must be activated during programming)

1. Turn off the engine, exit the vehicle and close all doors, hood lid and trunk lid.

2. Press and hold the Lock/Arm button on the keychain transmitter for 2

seconds.

The dash mounted LED begins to flash slowly.

Parking Lights flash one time.

128-8774

4 of 24

Page4

Siren will not sound.

If the siren "chirped" three times, sometime after arming, the exclusive delayed

dome light learn circuit has been programmed and the system detected a open

entry point after the learned delay expired. Closing the hood, trunk, or doors will

correct the problem and you do not need to disarm the system to make the

correction.

Doors Lock - Optional

NOTE: If the optional Headlamp illumination feature has been added, and has

been selected for operation when arming, as an added convenience, the sys-

tem will turn on the headlights when the system is armed.

The LCD Remote has the following response:

ARMINGTHE SYSTEM-PASSIVE(AUTOMATIC)

(Must be activated during programming)

1. Turn off the engine, exit the vehicle and close and lock all doors, hood lid and

trunk lid.

The dash mounted LED begins to flash rapidly, indicating 30 second passive

arming has begun.

2. Opening any protected entry point during the 30 second passive arming cycle

will immediately suspend automatic arming and the 30 second passive arm-

ing cycle will restart when all doors are closed. At the end of the passive

arming cycle;

The dash mounted LED begins to flash slowly.

Parking Lights flash one time.

Siren sounds one chirp

If the siren did not sound when arming, then the chirps have been turned off and

youshouldrefer to the section titled “ELIMINATINGTHEARM/ DISARM CHIRPS“

in this manual.

Doors Lock - Optional

Door locking during passive arming is a selectable feature. The alarm can be

programmed to allow the doors to lock only when arming using the keychain

transmitter and they will not automatically lock during passive arming.

PROTECTIONWHILE THESYSTEMISARMED

Opening any protected door, hood or trunk lid will cause the alarm to imme-

diately sound. The alarm will continue to sound for 30 seconds, then stop and

continue to monitor all protected entry points. If the thief left a door opened, the

alarm will sound for six 30 second cycles, remain armed and ignore that trig-

gered zone.\

Whenever the system is armed, the dash mounted LED indicator will slowly

flash. This serves as a visual deterrent to the potential thief. The LED is a very

low current bulb and will not cause the vehicle’s battery to drain, even when left

unattended for extended periods.

Whenever the system is triggered, the vehicle’s parking lights will flash for the

full 30 second alarm cycle, attracting visual attention to the vehicle.

Optional - Whenever the system is armed, the vehicle’s starting circuit will be

bypassed. If the thief should choose to ignore the siren, the vehicle can not be

started.

Any mild impact to the vehicle’s glass will cause the alarm to sound a short

series of warning tones.

128-8774

5 of 24

Page5

Any strong impact to the vehicle’s glass will cause the alarm to trigger for the full

30 second alarm cycle.

NOTE: If the optional interior illumination circuit was installed, the interior light will

flash as well for the full 30 second alarm cycle.

DISARMINGTHESYSTEM

NOTE: If the optional 2 step door unlock circuit is installed, when the unlock

transmitter button is activated, the drivers door only will unlock, pressing the

unlock button a second time will cause all doors to unlock.

NOTE: If your transmitter has been configured with single button Lock/Unlock, to

activate the all door unlock feature operate the Lock/Unlock button a second

time within 3 seconds of the first unlock command.

1. As you approach the vehicle, press and release the Unlock/Disarm button on

the keychain transmitter.

The dash mounted LED turns off.

The LED will start flashing rapidly, indicating that the system is re-arming

automatically. Open any door to suspend the automatic arming.

Parking Lights flash two times.

If the parking lights flashed three times, then the alarm was triggered in your

absence. Before turning the key on, examine the LED to identify which zone was

triggered.

Siren sounds two chirps.

If the siren sounds 4 chirps, then the alarm was triggered in your absence. Before

turning the key on, examine the LED and refer to the INTRUSION WARNING

SIGNALS section of this manual to identify which zone was triggered.

If the siren did not sound when disarming, then the chirps have been turned off

and you should refer to the section titled “ELIMINATING THEARM / DISARM

CHIRPS“ in this manual.

Doors Unlock - Optional

2 Step Doors Unlock - Optional

NOTE: If the optional Headlamp illumination feature has been added and has

been selected for operation when disarming, as an added convenience, the

system will turn on the headlights when the system is disarmed.

SILENT DISARMING (Must be activated during programming)

NOTE: If the optional 2 step door unlock circuit is installed, when the unlock

transmitter button is activated, the drivers door only will unlock, pressing the

unlock button a second time will cause all doors to unlock.

NOTE: If your transmitter has been configured with single button Lock/Unlock as

shown, to activate the all door unlock feature operate the Lock/Unlock button a

second time within 3 seconds of the first unlock command.

1. Press and hold button the Unlock/Disarm button on the keychain transmitter for

2 seconds.

The dash mounted LED turns off.

The LED will start flashing rapidly, indicating that the system is re-arming

automatically. Open any door to suspend the automatic arming.

Parking Lights flash two times.

128-8774

6 of 24

Page6

If the parking lights flashed three times, then the alarm was triggered in your

absence. Before turning the key on, examine the LED to identify which zone was

triggered.

Siren will not sound.

If the siren sounds 4 chirps, then the alarm was triggered in your absence.

Before turning the key on, examine the LED and refer to the INTRUSION

WARNING SIGNALS section of this manual to identify which zone was triggered.

Doors Unlock - Optional

2 Step Doors Unlock - Optional

NOTE: If the optional Headlamp illumination feature has been added and has

been selected for operation when disarming, as an added convenience, the

system will turn on the headlights when the system is disarmed.

WHILETHE SYSTEMIS SOUNDING

If during a triggered state, you wish to shut off the siren without disarming your

security system, simply press and release any transmitter button other than the

Unlock/Disarm button. This action will turn off the siren yet leave the vehicle fully

armed and protected. This feature is particularly useful if you are aware of children

playing near your vehicle that may accidently trigger your security system. In this

case you can cancel the siren sounding without disarming your alarm.

INTRUSIONWARNINGSIGNALS

This system will inform you if an intrusion attempt has occurred while you were

away from the vehicle. If an intrusion attempt has occurred, the siren will

chirp 4 times and the parking lights will flash 3 times when disarming the

system. Enter the vehicle and observe the red dash mounted LED to identify

which zone was triggered.

If the LED is flashing one time...pause...one time...pause...etc., then an

intrusion attempt was made to the shock sensor, or an accessory trigger-

ing device that may have been added to the system.

If the LED is flashing two times...pause...two times...pause...etc., then

an intrusion attempt was made to a hood or trunk pin switch that was

added to the system or to a light activated entry point if the alarm was

installed using the voltage sensing feature.

If the LED is flashing three times...pause...three times...pause...etc.,

then an intrusion attempt was made through one of the vehicle’s doors.

These intrusion warning indicators are stored in the system’s memory and will

only be erased when the ignition key is turned on.

PUSH-BUTTONLED RECEIVERVALET/OVERRIDE/SAFETYCONTROLSWITCH

ThePush-ButtonLEDswitch located in thereceiverallowsyouto temporarily bypass all

alarm functions, eliminating the need to hand your transmitter to parking attendants or

garagemechanics.Whenthe system is invaletmode,allalarm functions are bypassed,

howeverthe remotepanicfeatureandremotedoorlockswillremainoperational.Tousethe

valetmode, thesystemmust firstbe disarmedeitherby usingyour keychaintransmitter,or

byactivatingyour personalizedmanualoverride code.

1. Enterthevehicle, andturnthe ignitionkeyto the onposition.

2. Press and hold the Push-Button switch until the LED turns on solid. The system will

remainin thevalet mode.

3. To returntonormaloperation, press and releasethePush-Buttonswitch any time the

ignitionis on.

128-8774

7 of 24

Page7

NOTE: Alwaysrememberto returnthevehicle tothevaletoff position.Thiswill ensurethat

thevehicleremainsprotectedat alltimes.

MANUALLYOVERRIDINGYOURSYSTEM:

Using The Receivers Push-Button Override Switch

YourSecurity System canbedisarmed without the useofthe keychain transmitter.This is

necessary,sinceyou will needtheabilityto operate yourvehicleifthe transmitter islostor

its battery fails. If your system has been selected for Valet Switch manual override as

indicatedonthe lastpageofthis manual,tobypass the alarmsystem;

1. Open the vehicledoor. The alarmwillsound.

2. Turntheignition keytothe onposition.

3. Within5seconds,pressand release the push-button overrideswitch.

The alarm system will stop sounding and enter the (bypassed) mode. You can now start

andoperate thevehiclenormally.

Typically this overridemodeis usedonlyif thetransmitterhasbecome inoperative.

Programming Your Custom Override Code:

Unlikeoverrideswitcheseasilyfound, and defeated, this security systemallowsthecon-

sumer to program a personal override code, offering a higher level of security. To take

advantageof thisoption,programmablefeature#10must beselected forthe CustomCode

Option. Consultyourinstallation centerforprogrammingdetails. Thesystem comesfrom

the factory with a pre-programmed override code of 11. To change this default override

code,dothefollowing:

1. Disarm the system by use of the transmitter, or by use of the emergency override

sequence.Turn theignitionswitchto theonposition.

2. Within10seconds, press and releasetheReceiverspush-button switch, 3times.

3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.

(Thesirenorhorn will beep andthelightswill flash one time.)

4. Within10seconds, beginto enteryourchosen 10thsdigitbypressingand releasingthe

Receiverspush-buttonswitchfrom 1 up to9times.

5. Within10secondsof the last entered10thsdigit,turn the ignition switch offthenon.

6. Within10seconds, begintoenter yourchosenunits digit bypressingand releasingthe

Receiverspush-buttonswitchfrom 1 up to9times.

7. Finishbyturning the ignition switchtotheoff position.

Ifthenew code wasaccepted,the unit willreportback the newlyenteredcode, by flashing

theLED, firstindicatingthe10thsdigit, pauseandthentheunits digit.The unitwillreportthe

new code three times with a one second pause between each code, then the system will

beginarming. IftheLED flashpatternreportsthepreviously storedcode,thenewcode was

notenteredcorrectly. Pleaserepeatsteps1through7 above consideringthefollowing.

NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0

(Zero),ornodigit entered in anyplace,unitsor tenths.

NOTE: If15secondsofinactivityexpire, or if the ignition switch is turnedoffformorethen

5 seconds during any of the above steps, the unit will revert back to the last

successfully stored code.

Custom Code Programming Example:

To Change the code from the factory pre-assigned code of 11 to “52” you would do the

following:

1. Disarm the system by use of the transmitter, or by use of the emergency override

sequence.

2. Turntheignition switch totheon position.

128-8774

8 of 24

Page8

3. Within10seconds, press and releasetheReceiverspush-button switch, 3times.

4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.

(Thesirenorhorn will beep andthelightswill flash one time.)

5. Within10seconds, begintopress andreleasethe Receiverspush-buttonswitch toset

thetenthsdigit. (Asper theexample,press andrelease5 timestoset thetenthsdigit to

6. Within10seconds ofthe lastpress ofthe pushbutton,turn theignition switchoff thenon.

7. Within10seconds, begintopress andrelease theReceiversPush-button switchtoset

theunitsdigit.

(Aspertheexample, press and release2timesto set the unitsdigitto2).

8. Turn theignitionswitch to theoffposition. Immediately observetheLED flash pattern.

YouwillnotetheLEDflashingfivetimes,pause,andthenflashtwotimes,pause.Thispatternwill

berepeatedthreetimesindicatingthenewcode(52)hasbeenacceptedandstoredinmemory.

NOTE: If after step 7, the LED flashes a code other than what was just entered, this

indicates that the code has not been changed. You will have to repeat steps 1

through7above being certaintonotethe following:

Acceptabledigits 10thsorunits are1through9.The unitwillnot recognizea0(Zero),or no

digitenteredin any place,unitsor tenths.

NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then 5

seconds during any of the above steps, the unit will revert back to the last successfully

storedcode.

MANUALLYOVERRIDINGYOURSYSTEM:

USINGTHECUSTOMCODEOVERRIDE

Assumingtheoverride codeprogrammedhas not beenchanged,and thedefaultoverride

codeof11 isinthesystem's memory.

1) Enterthe vehicle andturntheignition switchtotheon position.

NOTE:Thesirenwill sound.

2) Within5 seconds, press andreleasetheReceivers push-button switch1time.

3) Within5 seconds, turn the ignitionswitchoffthenon.

4) Within5 seconds, press andreleasetheReceivers push-button switch1time.

5) Turnthe ignition switch off then onandstartthevehicle.

NOTE: Ifyouhave changed theprogrammedoverride codethensubstituteyour newcode

tenths for step 2 above, and units for step 5 above.

ELIMINATINGTHENORMAL ARM/DISARM CHIRPS

You can selectively eliminate the normal arm & disarm chirps by holding the transmitter

buttonslightlylongerwhen arming or disarming. This willpreventthesiren chirps for one

arm or disarm cycle. If you find this inconvenient and wish to eliminate these chirps

permanently,

1.Turntheignitionswitch 'on" then 'off".

2. Within 10 seconds of turning off the ignition, press and release the Receivers push-

buttonswitch3times.

3.Ifthechirps were on beforeyoustarted,thesiren will emit 2shortchirpsindicating that

thechirpsarenowoff. Ifthe chirps were off before you started,thesirenwillemitone

shortchirpindicatingthatthe chirps are now on.

NOTE: If the vehicle battery is disconnected then reconnected, the unit will return to the

defaultsetting ofchirps on. Repeatthe aboveprocedure toeliminatethearm/disarm

chirps.

128-8774

9 of 24

Page9

NOTE: Your system must be programmed by the installation center to en-

able this feature.

NOTE: Whenever the chirps are bypassed, the 4-chirp intrusion indicator

and 3 chirp defective zone indicator will always operate. Since these are

important warnings to you that something has happened, they cannot be

eliminated.

NOTE: Your system must be programmed by the installation center to en-

able this feature.

REMOTEPANICOPERATION

The Lock or Unlock button on your keychain transmitter also functions as a panic

switch for use in emergency situations. To use remote panic,

1. Press and hold the Lock or Unlock button on the keychain transmitter for 3 or

more seconds. The alarm will immediately sound.

2. To stop the alarm, press and hold the Lock or Unlock button on the transmitter

again for 3 seconds. If the button is not pressed, the alarm will automatically

stop after 30 seconds. Also if any transmitter button other than the Lock or

Unlock button is pressed and released, the Panic mode will be turned off

immediately. The normal function of this transmitter button will be suspended

during the Panic sounding period.

3. During the panic mode, the Lock and Unlock buttons can be used to lock and

unlock the doors, (if the option is installed), however once the unlock/disarm

button is pressed, the vehicle's starter inhibit device, (where installed) will be

disabled allowing the vehicle to start.

NOTE: While in the Panic mode, pressing and releasing the Lock or Un-

lock buttons will, if the option is installed, lock and unlock the doors respectively.

While in the panic mode, anytime the Unlock button is pressed, the panic feature

will continue for the allotted 30 seconds, however, the security system will be

disarmed allowing the vehicle to start.

RFSHOCKSENSORMODESELECTION

The way in which your alarm system reacts to threatening vibrations, created by

attempts to enter the vehicle by breaking a window, is adjustable by the transmitter

immediately after arming. There are 4 modes of operation that can be selected

by the operator:

1. Normal Operation (default mode)

In this mode, any strong vibrations will cause the siren to sound (full

detect) for 30 seconds. Any lesser vibration will cause the siren to emit

about 6 short warn away chirps, (pre-detect).

2. Stage 1 (Omit pre-detect)

In this mode, the warn away chirps created by the lesser vibration will be

deleted. If strong vibration occurs, the siren will sound.

3. Stage 2 (Omit pre & full detect)

In this mode, both the pre-detect stage and the full trigger stage of the sensor

are defeated. The unit will not react to vibration of any magnitude.

NOTE: Shock Sensor Icon Is Displayed On The LCD Panel.

4. Stage 3 (City Mode)

In this mode, the pre-detect chirps will change from six pre-warning tones to

a full 10 seconds of warning chirps.

The full detect trigger duration will be reduced from 30 seconds to 15 seconds.

128-8774

10 of 24

Page10

NOTE: Setting the stage of the shock sensor will be effective for one arming cycle

only. Once the system has been disarmed, the very next arming cycle will

cause the sensor to default to the normal operation stage.

To change or adjust the shock sensor, press and release the ARM button of you

keychain transmitter.

1.Within 2 seconds of arming, press and release the ARM button 1 time, to

defeat the pre-detect stage of the shock sensor. (The lights will flash and the

siren will chirp once.)

2.Within 2 seconds of step 1, press and release the ARM button 2 times, to

defeat the pre and full detect stages of the shock sensor. (The lights will

flash and the siren will chirp twice.)

3.Within 2 seconds of step 1, press and release the ARM button 3 times to

enter the "City Mode" of operation. (The lights will flash and the siren will chirp

three times.)

While under control of the remote start the system can be programmed to allow

you to shunt the shock sensor from the transmitter. If the system has been such

programmed, simply press the lock button of your keychain transmitter anytime

during the remote start cycle. The shock sensor will be shunted for the entire run

cycle and will resume normal operation after the remote start unit shuts off.

Check with your installation center to determine if this feature has been pro-

grammed into your system.

Push-Button LED Receiver Safety Control Switch

The Push-Button LED control switch allows you to temporarily disable the remote

starting function of the system. This recommended whenever the vehicle is being

serviced. To place the system in the service mode:

1) With the system disarmed/unlocked, and the ignition switch off Press and

Hold the Push-Button, found on the windsheild receiver, in.

2) Turn the ignition switch on, off, on, off, on, off.

3) The LED begins to flash two short flashes followed by one long flashes and

continues this pattern until returned to normal mode of operation.

This puts the unit into the R/S Override mode indicating that the remote start is

in the service mode and will not start from RF or any other input Posse or

otherwise.

To Exit R/S Override Mode

1) With the system disarmed, Press and Hold the Push-Button, found on the

windsheild receiver, in.

2) Turn the ignition switch on, off, on, off, on, off.

3) The LED turns off indicating that the R/S unit is fully functional one again.

REMOTESTARTINGTHEVEHICLE

The system WILL NOT start the vehicle if any one of the following conditions

exists:

1. The Vehicle Hood Is Opened.

2. The Gear Selector Is InAny Gear Other Then Park.

3. The Brake Is Depressed.

4. The Safety Control Switch Is In The Off Position.

WARNING! Be certain that the vehicle is outdoors before using this or any remote

vehicle starting device. A running engine produces dangerous carbon

monoxide fumes which can be harmful or fatal if prolonged exposure

occurs. DO NOT remote start the vehicle if it is garaged.

Andere Handbücher für APS-997C

Inhaltsverzeichnis

Andere Platinum Sicherheitssystem Handbücher

Platinum

Platinum APS-596C Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
