POCKetec Datastor Mini Bedienungsanleitung

THE DATA STORED ON THIS HARD DRIVE IS NOT

GUARANTEED BY POCKETEC.

POCKETEC IS NOT RESPONSIBLE FOR ANY LOSS OF DATA.

ALWAYS BACK UP ALL DATA REGULARLY.

USB 2.0 ULTRA-Portable Portable Hard

Drive

’l

Table of Contents

Introduction 03

Features and Benefits 04

The POCKETEC Package 04

Minimum System Requirements 05

Care and Handling 05

Hardware Installation 06

Software Installation for Windows® 07

Software Installation for Macintosh® 10

Installing the DataStor for Use with LINUX 11

Installing the DataStor for Use with DOS 11

Removing the DataStor After Use 12

Frequently Asked Questions 13

How To… 17

Warranty Information 18

Contact Information 19

Introduction

Pocketec proudly introduces the DataStor Mini™, the miniature version of

the award winning DataStor™ USB 2.0 Drive. The ultra-portable Mini is

smaller than your wallet but it packs enough storage space for 5,000 MP3

songs, 29 CDs worth of data, or 8.5 hours of digital video (20GB version).

Best of all, the Mini is totally bus powered by the host computer so you

don’t have to lug around an AC adapter or worry about batteries. Just plug

the Mini into the USB port of your computer and you instantly have access

to 20GB of extra storage space.

The DataStor Mini™ works with laptops and desktops and is compatible

with Windows®, MAC, DOS and Linux, so cross-platform file sharing is a

breeze. The Mini is USB 2.0 certified, offering the fastest transfer rates.

Plug-N-Play, hot-swappable, and hot-pluggable features make the Mini

convenient and easy to use. The Mini is the perfect way to back up your

critical data or to take your data with you wherever you go.

*To achieve USB 2.0 speeds, your computer must be USB 2.0 enabled.

Features and Benefits

•USB 2.0 certified with transfer rates up to 480Mbps (40x faster than USB 1.1)

•Backwards compatible with USB 1.1

•Tiny footprint offers maximum portability

•Massive storage capacity

•Stackable (multiple DataStor minis can be attached to your computer)

•No additional power source required (no batteries or AC adapter required)

•Cross-platform compatible (Windows®, MAC OS, LINUX and DOS)

•Plug-N-Play (drivers not required for Windows® XP/2000/ME and MAC OS 10.1+)

•DOS Level Support

•Average sustained write speed of 16MB/s and read speed of 18MB/s*

The POCKETEC Package

Your POCKETEC™ package contains the following:

•DataStor mini Ultra-Portable Hard Drive

•Standard DataStor mini USB connection cable

•Quick Start Guide

•CD-ROM Installation mini-CD with E-Manual

•Mini Carrying Case

•One-Year Limited Warranty

* The speed may vary depending on the host computer. The average sustained speed is the average

transfer rates of the drive on various computers using performance-testing software.

Minimum System Requirements

•400MHz or equivalent processor

•Minimum required RAM for your OS

•Windows® 98/98SE/ME/2000/XP, MAC OS 8.6 or higher

•Available USB port (Note: to achieve USB 2.0 speeds you must use the DataStor

mini with a USB 2.0 port)

•CD-ROM drive for driver installation or Internet connection for driver download.

Note: Driver not required for Windows® ME/2000/XP and MAC OS 10.1 +.

Driver required for Windows® 98/98SE and MAC OS 8.6-10.0.x.

Note: For Macintosh® computers with a front-loading CD-ROM, please download the

drivers from www.pocketec.net and install the downloaded drivers. (Front-loading CD-

ROM drives cannot read mini-CDs). Only use the mini-CD for CD-ROM drives with a

slide-out tray.

Care and Handling

•Please keep the DataStor mini in the protective carrying case when it is not in use,

so as to minimize risk of damage. Always handle your DataStor mini drive carefully.

•Do not move or disconnect the DataStor mini from your computer while the DataStor

mini drive is writing or reading data to or from the drive. This may cause loss of data

or damage to the hard drive.

•Before unplugging the DataStor mini or turning off the DataStor mini, click on the

“Stop Storage Device” icon on the task bar (or for the MAC, drag the DataStor mini

drive to the trash can), then turn the DataStor mini drive’s power switch to the “OFF”

position. Failure to do so may cause loss of data or corruption of the partition. Note:

this is not required for LINUX or DOS. Failure to do so may cause loss of data.

•No formatting is necessary. The DataStor mini is already formatted. DO NOT leave

the DataStor mini connected and on while reformatting other drives.

Care and Handling

•DO NOT open the outer case. Opening the case may damage the DataStor mini, its

components or the hard drive and will VOID THE WARRANTY.

•DO NOT expose the DataStor mini to extreme temperatures or humidity. Either may

cause serious damage to the hard drive.

•DO NOT put on or near electromagnetic equipment such as amplifiers, speakers,

source units, magnets or any other magnetized devices.

•DO NOT shock the drive. Static shock can cause the drive to lose data.

Hardware Installation

First, make sure you have all the package contents. You should have one USB cable,

one DataStor mini drive, one installation mini-CD w/E-Manual, one Quick Start Guide

and one carrying case. If you are missing any of the above contact POCKETEC

immediately. If you are running MAC OS 8.6 – 10.0.x you must first install the drivers.

1. Take the USB cable and locate an available

USB port on your computer.

2. Connect the USB connector to your USB port

on the computer or powered USB hub. Note:

Only USB ports located directly on the

computer or a powered USB hub will provide

sufficient power. USB ports on keyboards or

non-powered USB hubs will not work.

3. Connect the mini-USB connector to your

DataStor mini drive.

4. Make sure all connections are secure.

5. Turn the power switch to the “USB” position.

(DO NOT TURN THE POWER SWITCH TO THE

EXT POSITION).

That completes the Hardware Installation Process

Driver Installation For Windows®

Software drivers are not required for computers running the following operating systems:

Windows®ME/2000/XP

Software drivers must be installed for Windows®98 and 98SE. For driver installation

from the mini-CD, follow steps 1 - 7 below after the hardware installation.

1. Insert the POCKETEC Drivers CD into your CD-ROM.

2. Select Next at the new hardware wizard.

3. Select “Search for the best driver for your

device (recommended)” and select Next.

4. Check the CD-ROM drive only and select Next.

5. When the wizard finds the JLIX00.INF driver

select Next.

6. Select Finish to complete the driver installation

process.

For driver installation of the downloaded drivers,

please view the next page.

Downloaded Driver Installation For Windows®

Software drivers are not required for computers running the following operating systems:

Windows®ME/2000/XP

Software drivers must be installed for Windows®98 and 98SE. For driver installation

from the downloaded file, follow steps 1 - 19 below.

1. Go to www.pocketec.net

2. Go to the DOWNLOADS section and click drivers for Windows.

3. Select the “DataStor mini” link to download the drivers.

4. Download the files to your desktop.

5. Open the DataStor-mini-drivers.zip

file.

6. Select Extract to unzip the files to a

location on your computer.

7. Select to extract the files to a directory (in this

example we are using the desktop).

8. After the drivers are successfully extracted,

close the extraction program.

9. Next, plug in your DataStor mini drive.

10. Turn it on to the “USB” position.

11. Wait for the “Add New Hardware Wizard” to start.

12. Select “Next” when the wizard starts.

13. At the next window. Select “Search for the

best driver for your device.

(Recommended).”

14. Select “Next” to continue.

15. Check the box next to “Specific Location”

16. Select Browse, and browse to the

DataStor-mini-drivers folder (in this example

it was extracted to the desktop). And select

OK.

17. Select Next to continue the installation.

18. After the wizard picks up the drivers,

select Next to continue.

19. Select Finish to complete the driver

installation.
