Polar Electro DL893-A Bedienungsanleitung

Model:

DL893-A/DL894-A/DL895-A/DL896-A/DL897-A/

DL898-A/DL899-A /CK480-A

Cabinet Refrigerators/

Freezers

Instruction manual

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 1 2019/5/13 15:58

AU Telephone Helpline: 1300225960

Safety Tips

• Position on a flat, stable surface.

• A service agent/qualified technician should carry out

installation and any repairs if required. Do not remove any

components or service panels on this product.

• Consult Local and National Standards to comply with the

following:

- Health and Safety at Work Legislation

- Fire Precautions

- Wiring Regulations

- Building Regulations

• DO NOT use jet/pressure washers to clean the appliance.

• DO NOT use the appliance outside.

• DO NOT use this appliance to store medical supplies.

• DO NOT use electrical appliances inside the appliance (e.g.

heaters, ice cream makers etc.)

• DO NOT stand or support yourself on the base, drawers or

doors.

• DO NOT allow oil or fat to come into contact with the plastic

components or door seal. Clean immediately if contact occurs.

• Bottles that contain a high percentage of alcohol must be

sealed and placed vertically in the refrigerator.

• Always carry, store and handle the appliance in a vertical

position and move by holding the base of the appliance.

• Always switch off and disconnect the power supply to the unit

before cleaning.

• Keep all packaging away from children. Dispose of the

packaging in accordance with the regulations of local

authorities.

• If the power cord is damaged, it must be replaced by a POLAR

agent or a recommended qualified technician in order to avoid

a hazard.

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 2 2019/5/13 15:58

AUAU

Telephone Helpline: 1300225960

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• Polar recommend that this appliance is PAT tested on an

annual basis to ensure the product remains safe.

Caution Risk of Fire

• Do not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

Warning: Keep all ventilation openings clear of

obstruction. Unit should not be boxed in without

adequate ventilation.

• Warning: Do not use mechanical devices or other means

to accelerate the defrosting process, other than those

recommended by the manufacturer.

• Warning: Do not damage the refrigerant circuit.

• Warning: Do not use electrical appliances inside the food

storage compartments of the appliance, unless they are the

type recommended by the manufacturer.

Product Description

DL893-A - 600 litre Single Door Stainless Steel Refrigerator

DL894-A - 600 litre Single Door Stainless Steel Freezer

DL895-A - 1200 litre Double Door Stainless Steel Refrigerator

DL896-A - 1200 litre Double Door Stainless Steel Freezer

DL897-A - 1200 litre Double Door White Freezer

DL898-A - 1200 litre Double Door White Refrigerator

DL899-A - 600 litre Single Door White Refrigerator

CK480-A - 600 litre Single Door White Freezer

Introduction

Please take a few moments to carefully read through this manual. Correct maintenance and operation of

this machine will provide the best possible performance from your POLAR product.

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 3 2019/5/13 15:58

AU Telephone Helpline: 1300225960

Pack Contents

The following is included:

• POLAR Refrigerator or Freezer

• Keys x 2

• Shelf guides x 6 (Single) / x 12 (Double)

• Shelves x 3 (Single)/x 6 (Double)

• Instruction manual

POLAR prides itself on quality and service, ensuring

that at the time of packaging the contents are

supplied fully functional and free of damage.

Should you find any damage as a result of transit,

please contact your POLAR dealer immediately.

Installation

Note: If the unit has not been

stored or moved in an upright

position, let it stand upright for

approximately 12 hours before

operation. If in doubt allow to

stand.

1. Remove the appliance from the packaging.

Make sure that all protective plastic film and

coatings are thoroughly removed from all

surfaces.

2. Maintain a distance of 20cm (7 inches)

between the unit and walls or other objects for

ventilation. NEVER LOCATE NEXT TO OR

NEAR A HEAT SOURCE.

Note: Before using the appliance

for the first time, clean the

shelves and interior with soapy

water.

3. Set the brakes on the castors to keep the

appliance in position

Level the appliance by adjusting the screw

feet.

Removing the Compressor Safety

Band

• The compressor is located on the top of the

appliance, and sits on rubber washers. Under

normal operating conditions the compressor is

allowed to vibrate.

• To avoid damage through excessive motion

during transit, a stainless steel safety band is

placed over the compressor and screwed into

the top of the appliance.

• This safety band and the two screws fixing it

to the appliance must be removed before the

appliance is turned on.

Compressor

Safety Band

Compressor

Screws

Lock/Unlock the Doors

A lock is fitted to the doors to ensure foodstuffs

are kept secure within your POLAR appliance.

Use the keys provided to lock/unlock the doors.

Fitting the Shelves

1. Place one set of shelf guides on either side of

the cabinet at the desired height.

2. Slide the shelf into place.

3. Repeat for the remaining shelves.

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 4 2019/5/13 15:58

AUAU

Telephone Helpline: 1300225960

Operation

Storing Food

To get the best results from your POLAR appliance,

follow these instructions:

• Only store foodstuffs in the appliance when it

has reached the correct operating temperature.

• Do not place uncovered hot food or liquid

inside the appliance.

• Wrap or cover food where possible.

• Do not obstruct the fans inside the appliance.

• Avoid opening the doors for prolonged periods

of time.

Turn On

1. Close the door(s) of the appliance.

2. Ensure the power switch is set to [O] and turn

on at the socket.

3. Switch on the Power [I]. The current

temperature within the appliance is displayed.

Control Panel

To See the Setpoint

Push and immediately release the SET key: the

display will show the Setpoint value.

Changing the Setpoint

1. Push the SET key for more than 2 seconds to

change the Setpoint value.

2. The value of the set point will be displayed and

the COMPRESSOR LED starts blinking.

3. To change the Set value push and

buttons within 10 seconds.

4. To store the new Setpoint push the SET key or

wait 10 seconds.

Manual Defrost

The appliance will automatically run a defrost cycle

every six hours.

Note: The cycle starts from the

time the appliance is initially

powered up.

To manually defrost the appliance:

1. Press and hold the aux button for more then 2

seconds.

2. The defrost cycle will start immediately and the

Defrost LED illuminates.

Note: Starting a manual defrost

also resets the automatic

defrost timer.

3. The next automatic defrost will start six hours

after the manual defrost has finished.

Cleaning, Care &

Maintenance

Defrost appliance at least

every 3 months, more often if

required.

Switch off and disconnect

from the power supply before

cleaning.

• Clean the interior of the appliance as often as

possible.

• Do not use abrasive cleaning agents. These

can leave harmful residues.

• Clean the door seal with warm soapy water.

• Always wipe dry after cleaning.

• Do not allow water used in cleaning to run

through the drain hole into the evaporation

pan.

• Take care when cleaning the rear of the

appliance. Sharp edges can cut.

• A POLAR agent or qualified technician must

carry out repairs if required.

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 5 2019/5/13 15:58

AU Telephone Helpline: 1300225960

Stainless Steel Care

To maintain the stainless steel exterior of your Polar item, please consider the following information:

Never:

• Use abrasive Scourers or scrubbing pads, etc.

• Use Chlorinated or acidic detergents.

• Allow anything e.g. food, dirt, cleaning chemicals to remain on the surface for longer than necessary,

clean them off right away.

• Allow the surface to remain wet.

Do:

• Clean often.

• Use soft Cloths or plastic Scourers.

• Rub with the grain of the metal, rather than across it.

• Use detergents and polish designed for cleaning Stainless Steel.

• Ensure that the cleaning products are washed off fully and that the steel is left dry.

Cleaning the Condenser

• The condenser is part of the refrigeration

system. The condenser requires monthly

cleaning.

• Always disconnect power supply before carrying

out Routine Maintenance.

• Failure to clean the condenser will reduce the

performance and life of your Polar unit and may

invalidate your warranty.

• The condenser is located above the refrigeration

cabinet. These models have a removable filter

which can be cleaned with a vacuum cleaner.

Troubleshooting

If your POLAR appliance develops a fault, please check the following table before making a call to the

Helpline or your POLAR dealer.

Fault Probable Cause Solution

The appliance is not

working

The unit is not switched on Check the unit is plugged in correctly and

switched on

Plug and lead are damaged Call POLAR agent or qualified Technician

Fuse in the plug has blown Replace the fuse

Power supply Check power supply

Internal wiring fault Call POLAR agent or qualified Technician

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 6 2019/5/13 15:58

AUAU

Telephone Helpline: 1300225960

Fault Probable Cause Solution

The appliance turns on,

but the temperature is

too high/low

Too much ice on the evaporator Defrost the appliance

Condenser blocked with dust Clean condenser with hose attachment of

vacuum

Doors are not shut properly Check doors are shut and seals are not

damaged

Appliance is located near a

heat source or air flow to the

condenser is being interrupted

Move the refrigerator to a more suitable

location

Ambient temperature is too high Increase ventilation or move appliance to a

cooler position

Unsuitable foodstuffs are being

stored in the appliance

Remove any excessive hot foodstuffs or

blockages to the fan

Appliance is overloaded Reduce the amount of food stored in the

appliance

The appliance is

leaking water

The appliance is not properly

levelled

Adjust the screw feet to level the appliance

(if applicable)

The discharge outlet is blocked Clear the discharge outlet

Movement of water to the drain is

obstructed

Clear the floor of the appliance

(if applicable)

The water container is damaged Call POLAR agent or qualified Technician

The drip tray is overflowing Empty the drip tray (if applicable)

The appliance is

unusually loud

The safety band has not been

removed

Remove the safety band

Loose nut/screw Check and tighten all nuts and screws

The appliance has not been

installed in a level or stable

position

Check installation position and change if

necessary

Technical Specifications

Model Voltage Power Current Temperature

Range

Capacity

(litres)

DL893-A 220-240V 50Hz 255 2.0A -2°C to 8°C 376

DL894-A 220-240V 50Hz 565 4.9A -22°C to -18°C 376

DL895-A 220-240V 50Hz 400 3.0A -2°C to 8°C 681

DL896-A 220-240V 50Hz 800 4.8A -22°C to -18°C 681

DL897-A 220-240V 50Hz 800 4.8A -22°C to -18°C 681

DL898-A 220-240V 50Hz 400 3.0A -2°C to 8°C 681

DL899-A 220-240V 50Hz 255 2.0A -2°C to 8°C 376

CK480-A 220-240V 50Hz 565 4.9A -22°C to -18°C 376

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 7 2019/5/13 15:58

AU Telephone Helpline: 1300225960

Model Refrigerant Dimensions

H x W x D mm

Weight

(kg)

DL893-A R290 95g 2000 x 680 x 858 145

DL894-A R290 100g 2000 x 680 x 858 148

DL895-A R290 110g 2000 x 1340 x 858 195

DL896-A R290 130g 2000 x 1340 x 858 198

DL897-A R290 130g 2000 x 1340 x 858 198

DL898-A R290 130g 2000 x 1340 x 858 195

DL899-A R290 90g 2000 x 680 x 858 145

CK480-A R290 90g 2000 x 680 x 858 138

Electrical Wiring

The plug is to be connected to a suitable mains socket.

POLAR appliances are wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.

Compliance

The product must not be disposed of as household waste. To help prevent possible harm to human

health and/or the environment, the product must be disposed of in an approved and environmentally safe

recycling process. For further information on how to dispose of this product correctly, contact the product

supplier, or the local authority responsible for waste disposal in your area.

POLAR parts have undergone strict product testing in order to comply with regulatory

standards and specifications set by international, independent, and federal authorities.

POLAR products have been approved to carry the following symbol:

mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.

Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to

change specifications without notice.

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 8 2019/5/13 15:58

DECLARATION OF CONFORMITY

Equipment Type

Gastro Refrigerator Single Door Upright - 600Ltr Ventilated

Gastro Freezer Single Door Upright - 600Ltr Ventilated

Gastro Refrigerator 2 Door Upright - 1200LVentilated

Gastro Freezer 2 Door Upright - 1200L Ventilated

Solid Double Door Freezer White Exterior - 1200Ltr Ventilated

Solid Double Door Refrigerator White Exterior - 1200Ltr Ventilated

Gastro Refrigerator Single Door Upright- 600Ltr Ventilated

Cabinet Freezer 600ltr White Exterior

Model

DL893-A

DL894-A

DL895-A

DL896-A

DL897-A

DL898-A

DL899-A

CK480-A

Legislation

Electrical Safety

Electromagnetic Compatibility

Standards

AS/NZS 60335.1:2011 +A1:2012 +A2:2014 +A3:2015 +A4:2017

AS/NZS 60335.2.89:2010 +A1:2013+A2:2016

EN55014-1:2006 +A1:2009 +A2:2011

EN55014-2:2015

EN61000-3-2:2014

EN61000-3-3:2013

Producer Name

Polar

Producer Address

15 Badgally Road,

Campbelltown,

NSW 2560

I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and Standard(s).

Date

26th April 2019

Signature

Full Name

Ashley Hooper

Position

Technical & Quality Manager/ Responsible Supplier

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 9 2019/5/13 15:58

DL893-A-899-A_CK480-A_A5_v7_20190513.indb 10 2019/5/13 15:58

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Polar Electro Kühlschrank Handbücher

Polar Electro

Polar Electro CM287 Bedienungsanleitung

Polar Electro

Polar Electro G596-A Bedienungsanleitung

Polar Electro

Polar Electro CG841 Bedienungsanleitung

Polar Electro

Polar Electro G Series Bedienungsanleitung

Polar Electro

Polar Electro GH261 Bedienungsanleitung

Polar Electro

Polar Electro Tapas Bedienungsanleitung

Polar Electro

Polar Electro UA005-A Bedienungsanleitung

Polar Electro

Polar Electro GH215-A Bedienungsanleitung

Polar Electro

Polar Electro GC870-A Bedienungsanleitung

Polar Electro

Polar Electro Deli CG841-A Bedienungsanleitung

Polar Electro

Polar Electro GE579 Bedienungsanleitung

Polar Electro

Polar Electro CD239 Bedienungsanleitung

Polar Electro

Polar Electro G Series Bedienungsanleitung

Polar Electro

Polar Electro CD610 Bedienungsanleitung

Polar Electro

Polar Electro CD080-A Bedienungsanleitung

Polar Electro

Polar Electro UA001-A Bedienungsanleitung

Polar Electro

Polar Electro GJ447 Bedienungsanleitung

Polar Electro

Polar Electro U636-A Bedienungsanleitung

Polar Electro

Polar Electro UA001 Bedienungsanleitung

Polar Electro

Polar Electro CD080-A Bedienungsanleitung

Polar Electro

Polar Electro FA854 Bedienungsanleitung

Polar Electro

Polar Electro G608 Bedienungsanleitung

Polar Electro

Polar Electro CS102 Bedienungsanleitung

Polar Electro

Polar Electro FA854-A Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
