Polaroid Pixie CSA-00301S Bedienungsanleitung

FCC Compliance Statement:

This device complies with Part 15 of the FCC Rules. Operation is subjected to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

This equipment has been tested and found to comply with limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in residential installations.

This equipment generates, uses, and can radiate radio frequency energy, and

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause interference to radio or television

equipment reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the

following measures:

-Reorient or relocate the receiving antenna.

-Move the equipment away from the receiver.

-Plug the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/television technician for additional

suggestions.

You are cautioned that any change or modications to the equipment not expressly

approved by the party responsible for compliance could void Your authority to

operate such equipment.

* Environment:

Do not throw the appliance away with the normal household waste at the end of its

life. Bring it to an ofcial collection point for recycling.

By doing this you will help to preserve the environment.

Welcome:

Thanks for purchasing this product. Much time and effort has gone

into this product’s development, and our hope is it will give you many

years of trouble-free service.

Safety Notice:

1. Do not disassemble the camera; otherwise the warranty will be

voided.

2. Avoid all contact with water, and dry hands before using.

3. Do not expose the camera to high temperature or leave it in direct

sunlight. Doing so may damage the camera.

4. Use the camera with care. Avoid pressing hard on the camera

body.

5. For your own safety, avoid using the camera when there is a storm

or lightning.

6. Do not use batteries of different types. Doing so may lead to the

potential for serious damage.

7. Remove the batteries during long periods of non-use, as a

deteriorated battery may affect the functionality of the camera.

8. Remove the battery if it shows signs of leaking or distortion.

9. Use only the accessories supplied by the manufacturer.

10. Keep the camera out of the reach of small children.

Parts of the video camera - 1

1Microphone

2Power Button ( )

3LCD Panel

4Record Button ( )

5Up Button (Zoom in)

6Down Button (Zoom out)

7OK Button

8Mode/ Button

9USB Port

10 TV-out Connector

Need help with your digital video camera?

Call our toll-free customer service number. Look for the insert with this icon:

Or visit www.polaroid.com.

11 Shutter Button ( )

12 Strap Holder

13 Speaker

14 Battery / Memory Card Slot

15 Lens

16 Flash Strobe

17 Tripod Port

Parts of the video camera - 2

Parts of the video camera - 1

1Microphone

2Power Button ( )

3LCD Panel

4Record Button ( )

5Up Button (Zoom in)

6Down Button (Zoom out)

7OK Button

8Mode/ Button

9USB Port

10 TV-out Connector

Need help with your digital video camera?

Call our toll-free customer service number. Look for the insert with this icon:

Or visit www.polaroid.com.

11 Shutter Button ( )

12 Strap Holder

13 Speaker

14 Battery / Memory Card Slot

15 Lens

16 Flash Strobe

17 Tripod Port

Parts of the video camera - 2

13 15

1. Loosen the screws and remove

the battery/card compartment

cover.

2. Insert the card as indicated in the

illustration until it reaches the end

of the slot.

3. When using a SD card, the built-in

memory will become inaccessible.

4. To remove the SD card, gently

push the card until it pops up.

5. Re-install the cover.

Please use two AA batteries.

1. Loosen the screws and

remove the battery/card

compartment cover as

indicated.

2. Load the batteries into the

battery compartment with +

and - ends correctly installed.

3. Re-install the cover.

Loading the battery

Inserting the SD/MMC card (optional)

Turning on the video camera:

Open the LCD panel; or press and

hold down the Power button ( ) for

3 seconds.

Turning off the video camera:

Close the LCD panel; or press and

hold down the Power button ( ) for

3 seconds.

Turning on/off the video camera

Icon Description

Full battery life

Moderate battery life

Low battery life

Empty battery life

Battery life indicator

1. Loosen the screw and remove

the battery/card compartment

cover.

2. Insert the card as indicated in the

illustration until it reaches the end

of the slot.

3. When using a SD card, the built-in

memory will become inaccessible.

4. To remove the SD card, gently

push the card until it pops up.

5. Re-install the cover.

Please use two AA batteries.

1. Loosen the screw and remove

the battery/card compartment

cover as indicated.

2. Load the batteries into the

battery compartment with +

and - ends correctly installed.

3. Re-install the cover.

Loading the battery

Inserting the SD/MMC card (optional)

Turning on the video camera:

Open the LCD panel; or press and

hold down the Power button ( ) for

3 seconds.

Turning off the video camera:

Close the LCD panel; or press and

hold down the Power button ( ) for

3 seconds.

Turning on/off the video camera

Icon Description

Full battery life

Moderate battery life

Low battery life

Empty battery life

Battery life indicator

Reading LCD indicators - 1

Digital video camera mode:

Video REC mode:

1.1

Zoom ratio

SD card inserted

Battery life

Flash mode

Number of

recordings

Mode icon

1.1

Zoom ratio

SD card inserted

Battery life

Recording icon

Mode icon Recording time

Playback thumbnail mode:

Playback full mode:

Reading LCD indicators - 2

File type

Highlight box

Current/total

recordings

Mode icon

Playback

Button tip Battery life

Play Exit

Button tip

Mode icon

Battery life

Reading LCD indicators - 1

Digital video camera mode:

Video REC mode:

1.1

Zoom ratio

SD card inserted

Battery life

Flash mode

Number of

recordings

Mode icon

1.1

Zoom ratio

SD card inserted

Battery life

Recording icon

Mode icon Recording time

Playback thumbnail mode:

Playback full mode:

Reading LCD indicators - 2

File type

Highlight box

Current/total

recordings

Mode icon

Playback

Button tip Battery life

Play Exit

Button tip

Mode icon

Battery life

Need help with your digital video camera?

Call our toll-free customer service number. Look for the insert with this icon:

Or visit www.polaroid.com.

Connecting the video camera to a TV

NOTE : TV systems differ for different countries. You may need

to adjust the TV-out setting to display normally. (Taiwan: NTSC;

America: NTSC; Europe: PAL; China: PAL)

Connect your video camera and TV via the accessoryAV cable for

real-time display. You can display your video clips and still pictures

directly on your TV, sharing them with your friends and family.

1. Turn on your TV and switch to an appropriateAV input mode.

2. Connect the audio and video ends of the AV cable to the TV.

3. Turn on the video camera.

4. Connect the other end of the AV cable to your video camera.

1. Turn on the video camera.

2. Connect the video camera to your computer via the USB cable, and

the video camera will become a removable disk in your computer.

3. You can copy les from the video camera to your computer, and

vice versa.

Connecting the video camera to your PC

Recording a video clip

1. Press the Record button ( ) to start recording.

2. Use the Zoom buttons ( ) to zoom in or zoom out the screen.

3. Press the Record button ( ) again to stop recording.

Taking a still picture

Playing back your recordings

1. Use the Zoom buttons ( ) to zoom in or zoom out the screen.

2. Press the Shutter button ( ) on the top of the camera to take a

still picture.

1. Press the Mode button.

2. Use the Zoom buttons ( ) to select Playback mode.

3. Press the OK button to enter.

4. Use the Zoom buttons ( ) to shift between les.

5. Press the OK button to review/play the le.

To delete a picture

1. You must be in the Playback mode.

2. To delete a le, press the Shutter button ( ) and a prompt

window will show up. Select ( ) to conrm the deletion or select

( ) to cancel.
