Polycom COMMUNICATOR C100S Bedienungsanleitung

POLYCOM®

COMMUNICATOR

MODEL NO. C100S

USER GUIDE

POLYCOM

COMMUNICATOR

Polycom® Communicator User Guide - 1

Introduction

Thank you for choosing the

Polycom® Communicator C100S.

The Polycom® Communicator

C100S connects to your

computer’s USB port, giving you

full-duplex, two-way telephone

conversations over the Internet via

your Skype™ account.

This package contains everything

you need to get started. If you are

missing any of the items shown

on this page, please contact your

reseller immediately.

Polycom® Communicator User Guide

Setup Wizard CD

Carrying Case

Polycom® Communicator User Guide - 2

LED

Volume Up

Application

Launch

Volume Down

Call

Pickup/

Hangup

Mute

Features

Speaker

Stereo

Headphone

Jack (3.5mm)

Keypad (See

enlargement

below) Back Cover/

Stand

USB Cable

(attached)

Microphones

Polycom® Communicator User Guide - 3

Insert the Setup Wizard CD

included with your package and

follow the onscreen instructions.

When prompted, connect the

Polycom® Communicator C100S

to the port on your computer in the

following manner:

Flip open the back cover of the

Polycom® Communicator C100S

unit.

Unwind the USB cable.

Open up the back cover/stand

to its locked position. (For best

acoustic performance, the unit is

designed to stand at a 40º angle to

the surface it rests upon.)

Insert the USB cable of the unit

into a USB port on your computer.

When the unit has been connected,

complete the software and

hardware installation as per the

onscreen instructions.

Setup

Polycom® Communicator User Guide - 4

The Polycom® Communicator is

ready to use after completion of

software and hardware installation.

In order to use the Polycom®

Communicator C100S, you will

need to have Skype™ installed on

your computer. Go to www.skype.

com to download the latest version

of Skype™.

In order for the Polycom®

Communicator C100S to function

properly, the microphone and

speaker volume (in Windows

Sounds and Audio Devices)

settings must not be set to “mute”.

The controls on the keypad allow

you to have basic call control

functionality:

Launch the Skype™

application

Answer an incoming call

Hang up a completed call

Initiate a call with a selected

Skype™ Buddy

Volume Up

Volume Down

Mute

Getting Started

Polycom® Communicator User Guide - 5

With the Polycom® C100S

Manager, you can test for

microphone, speaker, and LED

functionality.

To launch the Polycom® C100S

Manager, double-click on the

Polycom® Communicator icon

on the desktop and click on the

Diagnostics Tools tab (see below).

Diagnostics

Polycom® Communicator User Guide - 6

In order to use this device, you

will need to have Microsoft®

Windows® XP installed on your

computer.

For best acoustic performance,

always use the device with its back

cover/stand opened to the locked

position.

For private conversations,

stereo headphones can be plugged

into the side of the Polycom®

Communicator C100S unit. If you

have a set of desktop PC speakers

you can plug them into the 3.5mm

headphone port on the side of the

Polycom Communicator for stereo

sound.

You can use the Windows®

Sounds and Audio Devices

screen to adjust the volume of the

microphones and speaker.

Please note that the Polycom

Communicator automatically becomes

your default Windows Audio Device

(Mic & Speaker) when it is plugged

into your computer. If you do not want

the Polycom Communicator to be

your default Windows Audio Device

you can change your audio settings by

doing the following: Select “Start”

→ “Settings” → “Control Panel”

→ “Sounds and Audio Devices” →

“Audio” → then select your embedded

sound card from the drop-down menu

for “Default Audio Device”.

Tips

Polycom® Communicator User Guide - 7

If you make this change you will then

need to go to the Skype Application

and make Polycom Communicator

the default sound device for Skype

by doing the following: Open the

Skype Application → Select “Tools”

→ “Options” → “Sound Devices”.

You can then change the “Audio In”,

“Audio Out” and “Ringing” settings to

the Polycom Communicator.

To check for new software

updates, run the Polycom® C100S

Manager and click the Help tab.

This will automatically take you to

the Polycom® Tech Support site.

The latest software is available for

download from this site.

For additional information about

the Polycom® Communicator

C100S or other Polycom® products,

please visit www.polycom.com.

Polycom® Communicator User Guide - 8

This device complies with part

15 of the FCC Rules. Operation

is subject to the following two

conditions:

(1) This device may not cause

harmful interference, and

(2) This device must accept any

interference received, including

interference that may cause

undesired operation.

U.S. and Canada Regulatory and

Compliance Information

Part 15 Rules

Class B Digital Device or Peripheral

NOTE: This equipment has been

tested and found to comply with

the limits for a Class B digital

device, pursuant to part 15 of

the FCC Rules. These limits are

designed to provide reasonable

protection against harmful interfer-

ence in a residential installation.

This equipment generates, uses and

can radiate radio frequency energy

and, if not installed and used in

accordance with the instructions,

may cause harmful interference to

radio communications. However,

there is no guarantee that interfer-

ence will not occur in a particular

installation. If this equipment does

cause harmful interference to radio

or television reception, which

can be determined by turning the

Polycom® Communicator User Guide - 9

equipment off and on, the user is

encouraged to try to correct the

interference by one or more of the

following measures:

Reorient or relocate the receiv-

ing antenna.

Increase the separation between

the equipment and receiver.

Connect the equipment into an

outlet on a circuit different from

that to which the receiver is con-

nected.

Consult the dealer or an experi-

enced radio/TV technician for help.

Modiﬁcations

In accordance with part 15 of the

FCC rules, the user is cautioned

that any changes or modiﬁcations

not expressly approved by Polycom

Inc. could void the user’s authority

to operate the equipment.

Canadian EMC Class B

This Class [B] digital apparatus

complies with Canadian ICES

-003.

Cet appareil numérique de la classe

[B] est conforme à la norme NMB-

003 du Canada.
