10. Appendices 10. Appendices
10.3 Factory parameter query
N° Description Range Default Remarks
H0* Accumulate heating operation time 30~120 45min Adjustable
H1 Defrosting maximum speed 1~25 12min Adjustable
H2 Stop defrosting temperature 1~25 12°C Adjustable
H3 Start defrosting temperature -20~20°C -1°C Adjustable
F0 Heating temperature dierence before start 0°C~18°C 5°C Adjustable
F1 Heating temperature dierence before stop 0°C~18°C 5°C Adjustable
F2 EEV adjust period 10~60 s 15s Adjustable
F3 Cooling temperature dierence before start 0°C~18°C 2°C Adjustable
F4 Cooling temperature dierence before stop 0°C~18°C 2°C Adjustable
P0 Compensate temperature -9~9°C 0°C Adjustable
P1 Reserve Adjustable
P2 Reserve Adjustable
P3 Minimum working temperature -19~15°C -15°C Adjustable
P4 Minimum ambient temperature dierence 2~18°C 2°C Adjustable
P5 Operation mode
Range: 0~3
0=Heating only
1=Cooling only
2=Cooling and heating
3=Cooling,heating and Auto
3Réglable
P6 Auxiliary heater On / O ON
P7 Temperature auxiliary heater start 2~15°C 5°C Adjustable
P8 Temperature dierence between inlet and outlet protection 2~60°C 10°C Adjustable
P9 Bottom plate heater temperature start -9~10°C 0°C Adjustable
P10 High fan speed
300~1500
83 Adjustable
P11 Mid fan speed 68 Adjustable
P12 Low fan speed 52 Adjustable
P13 Reserve
P14 Reserve
P15 Reserve
P16 Reserve
P17 EEV Maximum opening 50~480 480P Adjustable
P18 EEV Minimum opening 50~300 80P Adjustable
P19 Reserve
P20 Forced recycle refrigerant OF: OFF
ON: ON OF Adjustable
P22 Heating maximum setting temperature 35~60°C 40°C Adjustable
P23 Heating minimum setting temperature 15~25°C 20°C Adjustable
P24 Cooling maximum setting temperature 25~35°C 30°C Adjustable
P25 Cooling minimum setting temperature 2~10°C 7°C Adjustable
C0 Test mode On / O O
C1 Test mode compressor manually 10~120 50Hz
C2 Test mode EEV manually opening 60 ~ 480 350P
C3 Test mode fan speed
1 ~ 150
AC : 1:H, 2:M, 3:L
DC: value*10
Range : 300~1500
82
Step 1 : Keep pressing
SET IN NO ROOM VALUE
OUT
1
2
ON
OFF
TEMP
HUM
h
MIN
%
F
AUTOFAN
h
MIN
%
F
+
SET IN NO ROOM VALUE
OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
3 s until you enter the settings, then enter the password 1688.
