Posch SplitMaster 30 Bedienungsanleitung
Operating Instructions
SplitMaster 30
D1010419 - V001
*D1010419-V001*
English
Copyright by Posch Gesellschaft m.b.H., Made in Austria
Manufacturer
POSCH Gesellschaft m.b.H.
Paul-Anton-Keller-Strasse 40
A-8430 Leibnitz
Tel.: +43 (0) 3452/82954
Fax: +43 (0) 3452/82954-53
E-mail: [email protected]
http://www.posch.com
© Copyright by POSCH Gesellschaft m.b.H., Made in Austria
Please be sure to fill this in before starting. Then you can be sure that this document relates
to your machine, so if you have any queries you will be given the correct information.
Machine number:..............................................................................
Serial number:.....................................................................................
POSCH Austria:
8430 Leibnitz, Paul-Anton-Keller-Strasse 40, telephone: +43 (0) 3452/82954, fax: +43 (0) 3452/82954-53, e-mail: [email protected]
POSCH Germany:
84149 Velden/Vils, Preysingallee 19, telephone: +49 (0) 8742/2081, fax: +49 (0) 8742/2083, e-mail: [email protected]
Manufacturer
2
Contents
1Foreword 5
1.1 Copyright notice 5
1.2 Liability for defects 5
1.3 Reservations 5
1.4 Definitions 5
1.5 Operating instructions 6
2Safety information 7
2.1 Explanation of symbols 7
2.2 General safety information 8
2.3 Safety instructions for log splitter 8
2.4 Safety instructions for rope winches 9
2.5 Noise 9
2.6 Remaining risks 9
2.7 Proper use 10
2.8 Incorrect use 10
3General 11
3.1 Scope 11
3.2 Description 11
3.3 The most important components of the machine 12
3.4 Stickers and their meaning 13
3.5 Set-up 14
4Start-up 15
4.1 Driven by electric motor (type E) 15
4.2 Driven by tractor via cardan shaft (type Z) 17
4.3 Powered by diesel engine (Type D) 18
5Operation 19
5.1 "Autospeed" 19
5.2 Splitting blade - hydraulic height adjustment 20
5.3 Lifting device 20
5.4 Cylinder 22
5.5 Setting the splitting distance (stroke) 23
5.6 Timber support 24
5.7 Splitting process 24
5.8 Changing the splitting blade 26
6Put out of operation 28
6.1 Switching off the machine 28
Contents
3
7Transport 29
7.1 Transportation using the travel gear 29
8Checks 31
8.1 Protective guards 31
8.2 Screw fittings 31
8.3 Electrical equipment 31
8.4 Hydraulic lines 32
8.5 Tool guide 32
8.6 Two-hand controller 32
8.7 Oil level 32
9Maintenance 33
9.1 Tool guide 33
9.2 Oil changing 33
9.3 Diesel engine 35
9.4 Cleaning 35
10 Special equipment 36
10.1 Radio remote control 36
10.2 Rope winch 38
11 Additional equipment 43
11.1 Splitting blade variants 43
12 Troubleshooting 44
12.1 Disposal 45
13 Technical data 46
14 Service 48
EC Declaration of Conformity 49
Contents
4
Foreword
Thank you for buying our product.
This machine has been built in conformity with applicable European standards and
regulations.
These operating instructions explain how to operate the machine safely and efficiently and
how to maintain it.
Any person entrusted with the transport, installation, commissioning, operation or
maintenance of the machine must have read and understood:
▪ the operating instructions
▪ the safety instructions
▪ the safety information given in the individual chapters.
To avoid operator error and ensure problem-free operation, the operating instructions must
be available to the operating personnel at all times.
Copyright notice
All documents are protected by the law of copyright.
Documents including excerpts thereof may not be distributed or reproduced nor may their
content be communicated without express permission.
Liability for defects
Read these operating instructions through carefully before putting the machine into
operation.
We accept no liability for damage or disruptions caused by failure to observe the operating
instructions.
Claims for liability must be reported as soon as the defect is identified.
Claims are null and void for example in the following cases:
▪ improper use
▪ faulty attachments and drives not supplied with the machine
▪ failure to use original spare parts and accessories
▪ conversions or modifications, where not agreed with us in writing
We are not liable for defects of wearing parts.
Reservations
Technical data, dimensions, illustrations of the machine and safety standards are subject
to continual change and are therefore not in any circumstances binding in relation to the
supplied machine.
We accept no liability for printing and typesetting errors.
Definitions
Operator
The operator is the party which operates the machine and uses it for its intended purpose
or causes it to be operated by suitable, trained personnel.
Operating personnel
1
1.1
1.2
1.3
1.4
Foreword
5
The operating personnel (operators) are those entrusted by the operator to operate the
machine.
Technical personnel
Technical personnel are persons entrusted by the operator of the machine with special tasks
such as installation, set-up, maintenance and troubleshooting.
Electrician
An electrician is a person who, by virtue of his specialist training, has knowledge of electrical
systems, standards and regulations and is able to identify and prevent possible hazards.
Machine
The term machine replaces the commercial designation of the object to which these
operating instructions relate (see cover sheet).
Operating instructions
This manual is a "translation of the original operating manual"
1.5
Foreword
6
Safety information
Explanation of symbols
The following symbols and instructions in this manual provide warnings about possible
personal injury or property damage or give useful information about working with the
machine.
DANGER
Warning about danger zones
Instruction regarding safe working, where non-compliance entails the risk of serious or
fatal injury.
Always observe these instructions and ensure that you work with particular caution and
care.
DANGER
Warning of dangerous electrical voltage
Contact with live parts can result in immediate death.
Protective covers and enclosures marked with this sign may only be opened by qualified
electricians after the electricity supply has been turned off.
DANGER
Crushing hazard
Risk of injury through upper limbs getting trapped.
Z2001304
DANGER
Crushing hazard
Injury hazard entailing trapping of lower limbs.
NOTICE
Instruction
Symbol for proper use of the machine.
Non-observance can result in malfunctions by or damage to the machine.
Noise
Symbol for an area where noise levels can exceed 85 dB(A).
Non-observance can cause hearing problems or deafness.
2
2.1
Safety information
7
Further information
Symbol for further information relating to a bought-in part.
Information
Action-related information.
General safety information
The machine may only be operated by persons who are familiar with the machine’s
operation and hazards and with the user manual.
▪ It is the operator’s responsibility to provide appropriate staff training.
Persons under the influence of alcohol, drugs or pharmaceutical products that impair
responsiveness must not operate the machine or carry out maintenance work on it.
The machine may only be operated if it is in perfect working condition.
If faults occur on the machine, work must be stopped immediately.
Ensure the machine is stable before starting it.
Minimum age of operative: 18 years.
Only one person may operate the machine at a time.
Take regular breaks to ensure concentration.
Ensure that your workplace is adequately illuminated as poor lighting can significantly
increase the risk of injury.
Never work without the protective guards in place.
Only carry out repair, set-up, maintenance and cleaning work when the drive is switched off
and the tool is stationary.
▪ If the machine has a PTO drive, the universal joint shaft must be removed from the
tractor.
▪ The electric motor must be switched off and the power cable disconnected.
Never leave the machine running unattended.
Switch off the machine's drive unit before carrying out any adjustments.
Only use original - POSCH - spare parts.
Do not modify or tamper with the machine.
Work on electrical equipment must only be carried out by qualified electricians.
Never use damaged cables.
Machines with electric motors must not be used in the rain as this can lead to a malfunction
of the switch or the motor.
Machines with combustion engines:
DANGER
Carbon monoxide formation
Suffocation hazard
a) Never operate machines in confined spaces!
Safety instructions for log splitter
Prior to starting up the machine, the machine operator must agree the safety provisions with
the operator for wood manipulation (crane, forklift, front-end loader, etc.) and must observe
these safety provisions and the safety instructions from the wood manipulation operator.
2.2
2.3
Safety information
8
▪ This may mean that the machine operator is required to leave the place of operation
while the wood feed is loaded, in order to comply with the necessary safety distances.
Do not hold the log with your hand while splitting.
Do not reach into the splitting area.
Wear safety shoes and close-fitting clothes when working with this device.
Only use the machine outdoors.
Wear protective gloves.
Never split angle-cut wood.
Keep the work area free of chips and wood residues.
Shut the drive down before removing any jammed pieces of wood.
Max. log length 50 - 125 cm
Always retract the splitting tool when the machine is being transported or is not in operation.
The working pressure of the hydraulic system must not exceed 260 bar.
Safety instructions for rope winches
The rope winch may only be used when the machine is connected to the three-point linkage
of the tractor!
Ensure that the rope is not pulled over sharp edges!
Never guide the rope by hand whilst reeling it in!
Noise
The workplace-related, A-rated emission sound pressure level is 70 dB(A), measured at the
operative's ear.
In machines with an internal combustion engine an A-rated emission sound pressure level
of 90 dB(A), measured at the operative's ear, should be expected.
In the case of machines with a PTO drive, the noise level depends on the noise of the tractor.
Ear protection is therefore necessary.
The stated values are emissions values, and thus do not necessarily represent reliable
values for the work area. Although there is a correlation between emission and pollutant
levels, it is not possible to deduce reliably from that whether or not additional precautionary
measures are necessary. Factors that influence the level of pollutants present in the work
area include the individual nature of the work area, other sources of noise, e.g. the number
of machines and other work operations being carried out in the vicinity. Equally, permissible
values for a work area may vary between different countries. However, this information
should enable the user to estimate the dangers and risks more accurately.
Remaining risks
Even if all safety precautions are observed and the machine is used in accordance with the
instructions, some risks still remain:
▪ Touching of revolving parts or tools.
▪ Injury caused by flying logs or log pieces.
▪ Risk of burns if the engine is not properly ventilated.
2.4
2.5
2.6
Safety information
9
▪ Hearing loss if ear protection is not worn when working.
▪ Human error (e.g. due to excessive physical exertion, mental strain, etc.)
With every machine, some risks still remain. Therefore you should always be very careful
when working. It is up to the operating personnel to ensure that work is carried out safely.
Proper use
The machine - SplitMaster 30 - is designed exclusively for splitting logs with a diameter of
10 - 80 cm and a length of 50 - 125 cm.
The machine may only be used to process firewood.
Incorrect use
Any incorrect use or use other than that specified under "Proper use" is expressly forbidden.
2.7
2.8
Safety information
10
