Thank you for selecting the Power Inspired iPower-DC2to protect your equipment. The

iPower-DC2is an Uninterruptible Power System (UPS) providing battery back up power

for DC products under 30W and operating from USB (10W max) or 9, 12 or 24Vdc. Ideal

for small DC powered devices including but not limited to, network termination units,

routers, hubs, IP cameras etc. It is intended to be installed between the equipment

supplied DC power supply and the equipment.

Please read this manual before using the iPower-DC2.

⚠ Safety

⚠Never expose the iPower-DC2 to direct sunlight or sources of heat.

⚠The iPower-DC2 should only be used and stored in a dry indoor environment.

⚠Ensure that the connected equipment is within the rating of the iPower-DC2.

⚠There are no user serviceable parts inside the iPower-DC2 – do not open.

⚠Do not use the product if the case is damaged.

⚠The iPower-DC2contains batteries that must be processed according to local

regulations.

☛Precautions:

☛Ensure that any AC/DC adapter used is regulated to within the voltage input

specification of the iPower-DC2, and an allowance of an additional 6W (0.67A@9V,

0.5A@12V, 0.25A@24V) is provided to cover the internal power consumption of

the iPower-DC2.

☛ The iPower-DC2 will start up automatically when input power is applied.

☛The input DC power source must match the setting on the voltage selector

switch.

☛In order to preserve battery longevity the iPower-DC2should be recharged as

soon as possible following a power outage.

1. Package Contents:

▪The iPower-DC2UPS

▪User Manual

▪2x 5.5*2.1/2.5mm sprung connector DC male cables

Other optional accessories may be provided such as:

▪DIN mounting kit

▪AC/DC Power Adapter

▪Lead adapter set

▪Additional Leads (‘Y’-Cables or DC-DC leads)

iPower-DC2

User Manual

2. Layout

ⒶDC Input Socket

ⒹVoltage Selector Switch

ⒼWarning / Fault

ⒷUSB Output

ⒺSecondary DC Outputs

ⒽBattery Status Indicators

ⒸPrimary DC Output

ⒻSet Voltage Indicator

ⒿOn/Off Switch

3. Installation & Operation

▪The iPower-DC2connects between the equipment DC supply and the equipment

itself.

▪Choose a suitable location out of direct sunlight and sources of heat with suitable

access to the DC power supply and the connected equipment.

▪Set the Voltage Selector Switch Ⓓto match the required voltage.

▪Note the polarity of both input and output DC jacks is centre pin positive

▪Plug in the DC adapter or DC source into input socket Ⓐand apply power.

▪The iPower-DC2will automatically start up.

▪Ensure the voltage indicator LED Ⓕis indicating the correct voltage:

24V: RED

12V: BLUE

9V: PURPLE (RED & BLUE)

▪If the Voltage Indicator LED Ⓕis flashing and the Fault LED Ⓖis illuminated the

input voltage does not match the voltage selector switch Ⓓsetting. Switch the unit

OFF by disconnecting the input DC power source from Ⓐand pressing and holding

the Power Off button Ⓙuntil all the LEDs extinguish (around 3 seconds). Set the

selection switch to the correct voltage and repeat.

▪Plug the equipment into the USB Ⓑand/or DC output jacks ⒸⒺas required using

the DC male cables provided. For best performance the primary DC equipment

should be connected to port Ⓒ. You can use USB and DC jack outlets at the same

time provided the unit rating is not exceeded.

3.1. Battery Operation

▪The iPower-DC2will immediately transfer to battery power if the input DC voltage is

lost. There is no loss of power to connected equipment.

▪When running on battery power the Voltage Indicator LED Ⓕwill flash and the green

battery status indicator LEDs Ⓗwill show battery status:

⦿⦿⦿⦿

⦾⦿⦿⦿

⦾⦾⦿⦿

⦾⦾⦾⦿

⦾⦾⦾

75% →100%

50% →75%

25% →50%

10% →25%

< 10%

▪NOTE: Due to the inherent discharge characteristics of Lithium batteries under varying

load conditions, the battery status indicators are approximate. The unit is calibrated so

that the reduction under same-load conditions from 25% to zero takes the longest time.

At high loads, the battery status may drop from 100% to 75% quickly. This is normal.

3.2. Cold Starting (Powerbank operation)

▪The iPower-DC2can be started up without DC input power by pressing and holding

the ON/OFF switch Ⓙuntil only the green battery LEDS Ⓗilluminate (around 1-2

seconds). The Voltage Indicator LED Ⓕwill start to flash.

▪NOTE: The output voltage when cold starting will be as per the voltage selector

switch Ⓓ. Ensure this is correct before connecting any equipment.

3.3. Charging

▪Following battery use, the iPower-DC2will start to recharge the internal battery as

soon as DC input power is restored.

▪The battery status indicator will flash when charging. Once full charge has been

reached the LED indicators will be steady.

⦾⦾⦾

⦾⦾ ⦿

⦾⦿⦿

⦿⦿⦿

⦿⦿⦿⦿

<25% charge

<50% charge

<75% charge

<100% charge

Charged

3.4. Switching Off

▪The iPower-DC2can only be switched off in battery mode.

▪Disconnect the input DC source and press and hold the ON/OFF button Ⓙuntil all

LEDs are off (around 3-5 seconds).

3.5. Other

▪If there is a voltage mismatch between input voltage (not including no-voltage) and

the voltage setting on Ⓓ, then the fault LED Ⓖwill illuminate and the output power

will be disconnected. This may occur when the voltage source is out of tolerance with

the input specification of the iPower-DC2. Ensure the supply is regulated and within

the power requirements of the equipment and the iPower-DC2.

▪If the voltage setting switch Ⓓis changed whilst the unit is in operation the output

will immediately be shut down and the fault LED Ⓖwill illuminate.

▪In the event of an overload the fault LED Ⓖwill illuminate and the output will be shut

off if the unit is operating from DC power. If the input voltage source allows for it, the

iPower-DC2will start up once the fault has been removed. In battery mode the unit

will shut off completely and will need to be restarted once the fault is removed.

4. Service

▪Ensure the iPower-DC2is kept within normal operating and storage temperatures as

specified in the specifications.

▪Ensure the iPower-DC2is switched off when disconnected.

▪Do not allow the iPower-DC2to remain for long periods with a discharged battery.

Always recharge following battery use.

▪The iPower-DC2will provide typically 5 years life in normal operating environments

and does not require any ongoing maintenance.

▪At end of life dispose of according to local battery and electronic equipment

regulations.

5. Specifications

Model IPOWER-DC2

Voltage Input 9V / 12V / 24Vdc

9V : 8.7~9.7Vdc

12V: 11.6 ~ 13.1Vdc

24V: 23.2 ~ 25.4Vdc

Maximum Input Capacity 36W

Max Power

[Total - USB+Jacks]

Interface USB Type A

Voltage 5V ±5%

Power Capacity 2.0A / 10W

Power Capacity 30W

Voltage 9Vdc / 12Vdc / 24Vdc (as per selector switch)

9V : 8.5~9.5Vdc

12V: 11.4 ~ 12.6Vdc

24V: 22.8 ~ 25.2Vdc

Type 18650 Lithium Ion

Capacity 4x 2500mAh (2S2P)

Total Capacity 37.0Wh / 10,000mAh (7.4V)

4x Green LED indicating 25, 50, 75 & 100% charge

Flashing - Charging, @<10% discharging 25% LED flashes rapidly

9V - Purple [Red/Blue], 12V - Blue, 24V - Red

Flashing indicates on battery power

Red Fault LED Overload / Voltage mismatch / Fault.

Overvoltage, overcharge, deep discharge, overload, short circuit,

over-temperature

Battery Over Charge, Over Discharge, Overload, short circuit

Input Connection 5.5x2.1mm DC Jack

USB Type A

5x 5.5x2.1mm DC Jack

Dimensions (WxDxH mm) 160x29x107mm

Weight (Gross / Net ) 435/375g

Temperature

Operating 0-40C

Storage -10 - 45C

Humidity 0-90% Non Condensing

Altitude To 2000m

BS EN61204-1, BS EN62477-1

RoHS, EMC to BS EN61204-3,

Enclosure ABS 94V0

NOTES

4. Product is exempt from Low Voltage Directive but designed in principle with safetyand performance standards given.

APPROVALS 4

UKCA / CE

1. Aregulated DC power supply must be provided at the required output voltage and rated at 36W for full load rating.

2. The output voltage on the DC jacks is set by the selector switch and should match the nominal input voltage.

3. Applicable at primary jack port.

Voltage

PROTECTION

MCU

PHYSICAL & ENVIRONMENTAL

Output

DC Output Jacks 2,3

Range

BATTERY

INDICATOR LEDS

Battery Status

INPUT 1

Range

OUTPUT

30W

USB Port

iPower-DC2 User Manual. Rev 1.2

Ⓒ

2022 Power Inspired Ltd

www.powerinspired.com
