PRECISION DIGITAL PROVU PD6210 Bedienungsanleitung

PROVUPD6210 Analog Input Batch Controller

Instruction Manual

PRECISION DIGITAL CORPORATION

233South Street • Hopkinton MA 01748 USA

Tel (800) 343-1001 • Fax (508) 655-8990 www.predig.com

Batch Controller

0-20 mA, 4-20 mA, 0-5 V, 1-5 V, and ±10 V Inputs

Isolated 24 VDC @ 200 mA Transmitter Power Supply

Start, batch, pause, & stop with front panel buttons

Display batch total + rate, grand total, batch count or preset

Single or multi-stage batching with up to 8 relays

Automatic overflow protection

Manual control or automatic batching

Dual-Line Display

NEMA 4X and IP65 Rated Front Panel

UL Listed & CE Marked

Display Features 0.6" & 0.46" Digits

Six Full Digits on Each Line

Optional Superluminous Sunlight Readable Display

Free USB Programming Software & Cable

2 or 4 Relays + Isolated 4-20 mA Output Options

External 4-Relay & Digital I/O Expansion Modules

Universal 85-265 VAC, or 12-24 VDC Input Power Models

Isolated 24 VDC @ 200 mA Transmitter Power Supply

Modbus® RTU Communication Protocol Standard

USB Install

Order from:

C A Briggs Company

622 Mary Street; Suite 101

Warminster, PA 18974

Phone: 267-673-8117 - 800-352-6265

Fax: 267-673-8118

Sales@cabriggs.com - www.cabriggs.com

PROVUPD6210 Analog Input Batch Controller Instruction Manual

Disclaimer

The information contained in this document is subject to change without notice. Precision

Digital makes no representations or warranties with respect to the contents hereof; and

specifically disclaims any implied warranties of merchantability or fitness for a particular

purpose.

CAUTION: Read complete

instructions prior to installation

and operation of the controller.

WARNING: Risk of

electric shock or

personal injury.

Warning

This product is not recommended for life support

applications or applications where malfunctioning could

result in personal injury or property loss. Anyone using

this product for such applications does so at his/her own

risk. Precision Digital Corporation shall not be held liable

for damages resulting from such improper use.

Limited Warranty

Precision Digital Corporation warrants this product against defects in material or

workmanship for the specified period under “Specifications” from the date of shipment from

the factory. Precision Digital’s liability under this limited warranty shall not exceed the

purchase value, repair, or replacement of the defective unit.

Registered Trademarks

PROVU®and MeterView®Pro are registered trademarks of Precision Digital Corporation.

Modbus®is a Registered Trademark of Schneider Automation Inc. All other trademarks

mentioned in this document are the property of their respective owners.

www.predig.com

PROVUPD6210 Analog Input Batch Controller Instruction Manual



3

Table of Contents
Table of Contents-----------------------------------------3
Table of Figures-------------------------------------------3
Introduction-------------------------------------------------4
Ordering Information ------------------------------------5
Specifications----------------------------------------------6
General------------------------------------------------------------6
Process Input---------------------------------------------------6
Batch Controller Rate/Totalizer Display ---------------7
Relays -------------------------------------------------------------7
Isolated 4-20 mA Transmitter Output -------------------8
Modbus®RTU Serial Communications-----------------8
PDA1044 Digital Input & Output Expansion
Module ------------------------------------------------------------8
MeterView Pro --------------------------------------------------8
Compliance Information--------------------------------9
Safety--------------------------------------------------------------9
Electromagnetic Compatibility----------------------------9
Safety Information-------------------------------------- 10
Installation ------------------------------------------------ 10
Unpacking------------------------------------------------------10
Panel Mounting Instructions-----------------------------10
Mounting Dimensions ------------------------------------11
Transmitter Supply Voltage Selection (P+, P-) ----11
Connections---------------------------------------------------12
Connectors Labeling--------------------------------------12
Power Connections ---------------------------------------12
Signal Connections ---------------------------------------13
Modbus RTU Serial Communications----------------14
Relay Connections ----------------------------------------14
Switching Inductive Loads-------------------------------14
F4 Digital Input Connections----------------------------15
4-20 mA Output Connections---------------------------15
Analog Output Transmitter Power Supply-----------15
External Relay & Digital I/O Connections -----------16
Interlock Relay Feature ----------------------------------16
Basic Operation and Programming--------------- 17
Front Panel Buttons and Status LED Indicators--17
Controller Operation----------------------------------------18
Batch Control Operation Example---------------------19
MeterView®Pro Software ---------------------------------21
MeterView Pro Installation ------------------------------21
Display Functions and Messages----------------------22
Setting Numeric Values -----------------------------------24
Setting Up the Batch Controller (setup) -------------25
Scaling and Calibration ----------------------------------26
Setting the Input Signal (Input) -----------------------26
Setting the Totalizer and Batching Features
(total)-------------------------------------------------------26
Setting the Input Units or Custom Tags (units)---26
Setting the Decimal Point (dEc pt)-------------------26
Programming the Batch Controller (prog)-----------27
Batch Start Mode (mode)------------------------------29
Setting the Display Parameter & Intensity
(dsplay) -----------------------------------------------------30
Setting the Relay Operation (relay) ------------------31
Relay Assignment (Assign) ---------------------------- 32
Setting the Relay Action--------------------------------- 32
Setting Batch Control Relays--------------------------- 32
Programming Alarm Set and Reset Points --------- 33
Setting Fail-Safe Operation----------------------------- 33
Programming Time Delay------------------------------- 33
Relay Action for Loss of 4-20 mA Input (Loop
Break) -------------------------------------------------------- 33
Relay Operation Details----------------------------------- 34
Overview----------------------------------------------------- 34
Relays Initialization --------------------------------------- 34
Fail-Safe Operation--------------------------------------- 34
Front Panel LEDs ----------------------------------------- 34
Automatic Reset (Auto)---------------------------------- 35
Pump Alternation Control-------------------------------- 35
Setting Up the Interlock Relay (Force On) Feature35
Sample Relay Operation -------------------------------- 36
Relay and Alarm Operation Diagrams---------------- 36
High Alarm Operation (Set > Reset)------------------ 36
Low Alarm Operation (Set < Reset) ------------------ 36
High Alarm with Fail-Safe Operation (Set >
Reset) -------------------------------------------------------- 36
Low Alarm with Fail-Safe Operation (Set < Reset)36
Rate Relay Sampling Operation----------------------- 37
Total Relay Sampling Operation----------------------- 37
Signal Loss or Loop Break Relay Operation ------- 37
Time Delay Operation------------------------------------ 38
Scaling the 4-20 mA Analog Output (Aout)--------- 38
Reset Menu (reset)----------------------------------------- 39
Control Menu (Contrl)------------------------------------- 39
Setting Up the Password (pass)------------------------ 39
Protecting or Locking the Controller ------------------ 39
Grand Total Reset Password & Non-Resettable
Total ---------------------------------------------------------- 40
Making Changes to a Password Protected
Controller---------------------------------------------------- 40
Disabling Password Protection ------------------------ 40
Advanced Operation and Programming---------41
Advanced Features Menu & Display Messages--- 42
Function Keys Operation-------------------------------- 44
F4 Operation------------------------------------------------ 44
Advanced Setup and Calibration---------------------- 44
Maximum/Minimum Readings-------------------------- 44
Noise Filter (filter) ------------------------------------- 45
Noise Filter Bypass (bypass)--------------------------- 45
Rounding Feature (round)------------------------------ 45
Modbus RTU Serial Communications (serial)--- 45
Select Menu (SElEct)------------------------------------ 46
Programmable Function Keys User Menu (user)- 48
Internal Source Calibration (ICAL) -------------------- 49
Troubleshooting-----------------------------------------50
Diagnostics Menu (diag)-------------------------------- 50
Determining Software Version ------------------------- 50
Reset Controller to Factory Defaults ----------------- 50
Factory Defaults & User Settings---------------------- 51
Troubleshooting Tips-------------------------------------- 53
EU Declaration of Conformity-----------------------55


PROVUPD6210 Analog Input Batch Controller Instruction Manual




4

Table of Figures
Figure 1: 1/8 DIN Panel Mounting......................10
Figure 2: Controller Dimensions - Side View ...11
Figure 3: Controller Dimensions - Top View ....11
Figure 4: Transmitter Supply Voltage Selection
.......................................................................11
Figure 5: Connector Labeling for Fully Loaded
PD6210..........................................................12
Figure 6: Power Connections ............................12
Figure 7: Transmitters Powered by Internal
Supply...........................................................13
Figure 8: Transmitter Powered by Ext. Supply or
Self-Powered ................................................13
Figure 9: Voltage Input Connections................13
Figure 10: Relay Connections ...........................14
Figure 11: AC and DC Loads Protection ..........14
Figure 12: Low Voltage DC Loads Protection..14
Figure 13: F4 Digital Input Connections...........15
Figure 14: 4-20 mA Output Connections..........15
Figure 15: Expansion Modules & DIN Rail
Mounting Kit.................................................16
Figure 16: External Relays Module Connections
.......................................................................16
Figure 17: Digital I/O Module Connections ......16
Figure 18: Interlock Connection........................16
Introduction
The PROVU®PD6210 is an easy-to-use batch controller ideal for simplifying independent batch
control operations where local control is preferred to expensive and expansive plant operation
systems. Its superluminous LED digits make it easily readable in smoke, dust, fog, and, with the
optional SunBright® display, even direct sunlight.
The controller comes programmed for easy front panel start, pause, stop, and batch size (preset)
changes. The bottom display can be programmed to display rate, grand total, batch count, or
preset by cycling the Stop (F3) button. A digital input is standard.
Single and multi-stage batching is possible with up to four (4) on-board relays and four (4) external
relays with the external relay module. Each batch control relay may have a unique preclose
amount when used for multi-stage batching.
Manual start batching is default, but automatic batching with a restart after a programmed time
delay from the completion of the last batch, is also possible.
Overrun correction adjusts the closing of the batch control relays to adjust for inaccuracies from
batch to batch. This increases accuracy over time as systems wear out. The overrun correction
feature is capable of compensating for inaccuracies of up to 10% of the programmed preset value.
At least two SPDT relays are included for use in batch control or rate alarms.
The batch controller also shares all common PROVUSeries features, including an isolated 24
VDC transmitter power supply and Modbus RTU Serial communications.


PROVUPD6210 Analog Input Batch Controller Instruction Manual

Ordering Information

Standard Models

85-265 VAC Model

12-24 VDC Model

Options Installed

PD6210-6R2

PD6210-7R2

2 relays (PD1102*)

PD6210-6R4

PD6210-7R4

4 relays (PD1104*)

PD6210-6R5

PD6210-7R5

2 relays & 4-20 mA output (PD1105*)

PD6210-6R7

PD6210-7R7

4 relays & 4-20 mA output (PD1107*)

*Model number for replacement option card.

SunBright Display Models

85-265 VAC Model

12-24 VDC Model

Options Installed

PD6210-6H2

PD6210-7H2

2 relays (PD1102*)

PD6210-6H4

PD6210-7H4

4 relays (PD1104*)

PD6210-6H5

PD6210-7H5

2 relays & 4-20 mA output (PD1105*)

PD6210-6H7

PD6210-7H7

4 relays & 4-20 mA output (PD1107*)

*Model number for replacement option card.

Accessories

Model

Description

PDA1002

DIN rail mounting kit for two expansion modules

PDA1004

4 SPST (Form A) relays

PDA1044

4 digital inputs & 4 digital outputs (2 may be connected)

PDA1232

RS-232 serial adapter

PDA1485

RS-485 serial adapter

PDA7485-I

RS-232 to RS-422/485 isolated converter

PDA8232-N

USB to RS-232 non-isolated converter

PDA8485-I

USB to RS-422/485 isolated converter

PDA2811

1 Meter Plastic NEMA 4X Enclosure

PDA2812

2 Meter Plastic NEMA 4X Enclosure

PDX6901

Suppressor (snubber): 0.01 µF/470 , 250 VAC

PROVUPD6210 Analog Input Batch Controller Instruction Manual

Specifications

Except where noted all specifications apply to operation at +25°C.

General

Display

Line 1: 0.6" (15 mm) high, red LEDs

Line 2: 0.46" (12 mm) high, red LEDs

6 digits: each (-99999 to 999999), with lead

zero blanking.

Default

Display

Assignment

The Upper display shows batch total. The

Lower display shows rate with alternating

units, and can be switched to show grand

total, batch count, or preset with the STOP

key.

Custom

Display

Assignment

The Upper and Lower displays may be

assigned to rate, total, grand total, batch

count, preset, set points, units (lower display

only), alternating R & T, R & GT, preset &

rate, max & min, or a Modbus display

may be programmed to alternate with a

custom unit or tag.

Alternating

Display

Displays alternate every 10 seconds when

display is selected or the batch is paused.

Display

Intensity

Eight user selectable intensity levels

Display

Update Rate

5/second (200 ms)

Overrange

Display flashes 999999

Underrange

Display flashes -99999

Front Panel

NEMA 4X, IP65

Programming

Methods

Four front panel buttons, digital inputs, or

PC and MeterView Pro software.

Noise Filter

Programmable from 2 to 199 (0 will disable

filter)

Filter Bypass

Programmable from 0.1 to 99.9% of

calibrated span

Recalibration

All ranges are calibrated at the factory.

Recalibration is recommended at least every

12 months.

Max/Min

Display

Max/min readings reached by the process

are stored until reset by the user or until

power to the controller is cycled.

Password

Three programmable passwords restrict

modification of programmed settings and

two prevent resetting the totals.

Pass 1: Allows use of function keys and

digital inputs

Pass 2: Allows use of function keys, digital

inputs and editing set/reset points

Pass 3: Restricts all programming, function

keys, and digital inputs.

Total Password: Prevents resetting the total

manually

Gtotal Password: Prevents resetting the

grand total manually

Non-Volatile

Memory

All programmed settings are stored in non-

volatile memory for a minimum of ten years

if power is lost.

Power

Options

85-265 VAC 50/60 Hz, 90-265 VDC, 20 W

max or 12-24 VDC 10%, 15 W max

Powered over USB for configuration only

Fuse

Required external fuse: UL Recognized, 5 A

max, slow blow; up to 6 controllers may

share one 5 A fuse

Isolated

Transmitter

Power Supply

TerminalsP+&P-: 24 VDC10%.12-24 VDC

poweredmodelsselectablefor24, 10, or5VDC

supply(internal jumperJ4).

85-265 VAC models rated @200 mA max,12-

24 VDC poweredmodelsrated@ 100mAmax,

@50mAmax for5or10VDC supply.

Normal Mode

Rejection

Greater than 60 dB at 50/60 Hz

Isolation

4 kV input/output-to-power line

500 V input-to-output or output-to-P+ supply

Overvoltage

Category

Installation Overvoltage Category II:

Local level with smaller transient

overvoltages than Installation Overvoltage

Category III.

Environmental

Operating temperature range: -40 to 65°C

Storage temperature range: -40 to 85°C

Relative humidity: 0 to 90% non-condensing

Connections

Removable screw terminal blocks accept 12

to 22 AWG wire, RJ45 for external relays,

digital I/O, and serial communication

adapters.

Enclosure

1/8 DIN, high impact plastic, UL 94V-0,

color: black

Mounting

1/8 DIN panel cutout required:

3.622" x 1.772" (92 mm x 45 mm)

Two panel mounting bracket assemblies are

provided.

Tightening

Torque

Screw terminal connectors: 5 lb-in (0.56 Nm)

Overall

Dimensions

4.68" x 2.45" x 5.64" (119 mm x 62 mm x

143 mm)

(W x H x D)

Weight

9.5 oz (269 g)

Warranty

3 years parts & labor

Process Input

Inputs

Field selectable:

0-20, 4-20 mA, 10 V (0-5, 1-5, 0-10 V),

Modbus PV (Slave)

Accuracy

±0.03% of calibrated span ±1 count,

square root & programmable exponent

accuracy range:

10-100% of calibrated span

Temperature

Drift

0.005% of calibrated span/C max from 0 to

65C ambient,

0.01% of calibrated span/C max from -40 to

0C ambient

Signal Input

Conditioning

Linear, square root, or programmable

exponent

Multi-Point

Linearization

2 to 32 points

PROVUPD6210 Analog Input Batch Controller Instruction Manual

Programmabl

e Exponent

1.0001 to 2.9999

Low-Flow

Cutoff

0-999999 (0 disables cutoff function)

Decimal Point

Up to five decimal places or none:

d.ddddd, d.dddd, d.ddd, d.dd, d.d,or

dddddd

Calibration

Range

Input Range

Minimum Span

Input 1 & Input 2

4-20 mA

0.15 mA

10 V

0.01 V

An error message will appear if the input 1

and input 2

signals are too close together.

Input

Impedance

Voltage ranges: greater than 500 k

Current ranges: 50 - 100 (depending on

resettable fuse impedance)

Input

Overload

Current input protected by resettable fuse,

30 VDC max.

Fuse resets automatically after fault is

removed.

F4 Digital

Input

Contacts

3.3 VDC on contact. Connect normally open

contacts across F4 to COM.

F4 Digital

Input

Logic Levels

Logic High: 3 to 5 VDC

Logic Low: 0 to 1.25 VDC

Batch Controller Rate/Totalizer Display

Rate Display

Indication

-99999 to 999999, lead zero blanking. “R”

LED illuminates while displaying rate.

Batch Total &

Grand Total

Display

0 to 999,999; automatic lead zero blanking.

“T” LED is illuminated while displaying batch

total. “GT” LEDs are illuminated while

displaying grand total. Up to 999,999 for

batch total/preset. Up to 999,999,999 with

grand total-overflow feature. “oF” is displayed

to the left of grand total overflow and ▲ LED

is illuminated.

Batch Total

Decimal Point

Up to five decimal places or none:

d.ddddd, d.dddd, d.ddd, d.dd, d.d,or

dddddd

Total decimal point is independent of rate

decimal point.

Totalizer

Calculates total based on rate and field

programmable multiplier to display total in

engineering units. Time base must be

selected according to the time units in which

the rate is displayed.

Grand

Totalizer

Rollover

Grand totalizer rolls over when display

exceeds 999,999,999. Relay status reflects

display.

Grand Total

Alarms

Up to seven, user selectable under setup

menu. Any set point can be assigned to

grand total and may be programmed

anywhere in the range of the controller for

grand total alarm indication. Relay 1 should

always be assigned to batch.

Programmabl

e Delay on

Release

0.1 and 999.9 seconds; applied to the first

relay assigned

to total or grand total.

If the controller is programmed to reset total

to zero automatically when the preset is

reached, then a delay will occur before the

total is reset.

Grand Total

Reset

Via front panel button, external contact

closure on digital inputs, automatically via

user selectable preset value and time delay,

or through serial communications.

Grand Total

Reset

Password

Grand total passwords may be entered to

prevent resetting the grand total from the

front panel.

Non-

Resettable

Grand Total

The grand total can be programmed as a

non-resettable total by entering the

password “050873”.

Caution!

Once the Grand Total has been

programmed as “non-resettable”

the feature cannot be disabled.

Relays

Rating

2 or 4 SPDT (Form C) internal and/or 4

SPST (Form A) external; rated 3 A @ 30

VDC and 125/250 VAC resistive load; 1/14

HP (≈50 W) @ 125/250 VAC for inductive

loads

Noise

Suppression

Noise suppression is recommended for each

relay contact switching inductive loads; see

page 14 for details.

Relay

Assignment

Relays may be assigned to batch control

total, sampling, rate, or grand total alarms.

Preclose

0-100% of batch size, individually user

programmable for each additional batch

control relay beyond the first.

Alarm

Deadband

0-100% of span, user programmable

High or Low

Alarm

User may program any alarm for high or low

trip point.

Unused alarm LEDs and relays may be

disabled (turn off).

Relay

Operation

Batch control

Automatic (non-latching)1

Sampling

Off (disable unused relays and enable

Interlock feature)

Manual on/off control mode

Secondary Functions2

Pump alternation control (2 to 8 relays)

Latching (requires manual acknowledge)

Relay Reset

User selectable via front panel buttons,

digital inputs, or PC

1. Automatic reset only (non-latching),

when the input passes the reset point

or total is reset to zero.

2. Automatic + manual reset at any time

(non-latching)

3. Manual reset only, at any time

(latching)

4. Manual reset only after alarm condition

has cleared (L)

Note: Digital inputs may be assigned to

acknowledge relays programmed for manual

reset. It is not recommended to change the

functions of front panel buttons to manual

reset.

Alarm Time

Delay

0 to 999.9 seconds, on & off relay time

delays

Programmable and independent for each

relay.

PROVUPD6210 Analog Input Batch Controller Instruction Manual

Fail-Safe

Operation

Programmable and independent for each

relay.

Note: Relay coil is energized in non-alarm

condition.

In case of power failure, relay will go

to alarm state.

Alarm Auto

Initialization

When power is applied to the controller,

relays will reflect the state of the input to the

controller.1

1. Alarms are active only when the batch is running.

2. These functions are not functional when the unit is being

used as a batch controller with total set to yes.

Isolated 4-20 mA Transmitter Output

Output

Source

Rate/process, total, grand total, max, min,

set points 1-8, Modbus register, or manual

control mode

Scaling

Range

1.000 to 23.000 mA for any display range.

Calibration

Factory calibrated: 4.000 to 20.000 = 4-20

mA output

Analog Out

Programming

23.000 mA maximum for all parameters:

Overrange, underrange, max, min, and

break

Accuracy

± 0.1% FS ± 0.004 mA

Temperature

Drift

0.4 µA/C max from 0 to 65C ambient,

0.8 µA/C max from -40 to 0C ambient

Note: Analog output drift is separate from input

drift.

Isolated

Transmitter

Power Supply

Terminals I+ & R: 24 VDC 10% . May be

used to power the 4-20 mA output or other

devices. Refer to Figure 6 on page 12 and

Figure 14 on page 15.

Allmodelsrated@40mAmax.

External

Loop Power

Supply

35 VDC maximum

Output Loop

Resistance

Power supply

Minimum

Maximum

24 VDC

10 

700 

35 VDC

(external)

100 

1200 

Modbus®RTU Serial Communications

Slave Id

1 –247 (Controller address)

Baud Rate

300 - 19,200 bps

Transmit

Time Delay

Programmable between 0 and 199 ms

Data

8 bit (1 start bit, 1 or 2 stop bits)

Parity

Even, Odd, or None with 1 or 2 stop bits

Byte-To-Byte

Timeout

0.01 –2.54 second

Turn Around

Delay

Less than 2 ms (fixed)

Note: Refer to the PROVU® Modbus Register Tables located

at www.predig.com for details.

PDA1044 Digital Input & Output Expansion

Module

Channels

4 digital inputs & 4 digital outputs per

module

System

Up to 2 modules for a total of 8 inputs & 8

outputs

Digital Input

Logic High

3 to 5 VDC

Digital Input

Logic Low

0 to 1.25 VDC

Digital Output

Logic High

3.1 to 3.3 VDC

Digital Output

Logic Low

0 to 0.4 VDC

Source

Current

10 mA maximum output current

Sink Current

1.5 mA minimum input current

+5 V Terminal

To be used as pull-up for digital inputs only

Connect normally open pushbuttons across

+5 V & DI 1-4.

MeterView Pro

System Re-

quirements

Microsoft®Windows®XP/Vista/7/8/10

Communica-

tions

USB 2.0 (Standard USB A to Micro USB

Configuration

Configure meters one at a time

PROVUPD6210 Analog Input Batch Controller Instruction Manual

Compliance Information

Safety

UL & c-UL Listed

USA & Canada

UL 508 Industrial Control Equipment

UL File Number

E160849

Front Panel

UL Type 4X, NEMA 4X, IP65; panel gasket provided

Low Voltage

Directive

EN 61010-1:2010

Safety requirements for measurement, control, and laboratory use

Electromagnetic Compatibility

Emissions

EN 55022:2010

Class A ITE emissions requirements

Radiated

Emissions

Class A

AC Mains

Conducted

Emissions

Class A

Immunity

EN 61326-1:2013

Measurement, control, and laboratory equipment

EN 61000-6-2:2005

EMC heavy industrial generic immunity standard

RFI - Amplitude

Modulated

80 -1000 MHz 10 V/m 80% AM (1 kHz)

1.4 - 2.0 GHz 3 V/m 80% AM (1 kHz)

2.0 - 2.7 GHz 1 V/m 80% AM (1 kHz)

Electrical Fast

Transients

±2kV AC mains, ±1kV other

Electrostatic

Discharge

±4kV contact, ±8kV air

RFI - Conducted

10V, 0.15-80 MHz, 1kHz 80% AM

AC Surge

±2kV Common, ±1kV Differential

Surge

1KV (CM)

Power-Frequency

Magnetic Field

30 A/m 70%V for 0.5 period

Voltage Dips

40%V for 5 & 50 periods

70%V for 25 periods

Voltage

Interruptions

<5%V for 250 periods

Note:

Testing was conducted on PD6200 and PD6300 series meters installed through the covers of

grounded metal enclosures with cable shields grounded at the point of entry representing installations

designed to optimize EMC performance. All hardware is identical to the PD6210 controllers.

Declaration of Conformity available at www.predig.com

PROVUPD6210 Analog Input Batch Controller Instruction Manual

Safety Information

CAUTION: Read complete

instructions prior to installation and

operation of the controller.

WARNING: Risk of electric shock

or personal injury.

Warning!

Hazardous voltages exist within enclosure.

Installation and service should be performed

only by trained service personnel.

Installation

There is no need to remove the controller from its case to complete the installation, wiring, and

setup of the controller for most applications. Instructions are provided for changing the transmitter

power supply to output 5 or 10 VDC instead of 24 VDC on page 11.

Unpacking

Remove the controller from box. Inspect the packaging and contents for damage. Report

damages, if any, to the carrier.

If any part is missing or the controller malfunctions, please contact your supplier or the factory for

assistance.

Panel Mounting Instructions

Prepare a standard 1/8 DIN panel cutout –3.622" x 1.772" (92 mm x 45 mm). Refer to Figure 1 for

more details.

Clearance: allow at least 6.0" (152 mm) behind the panel for wiring.

Panel thickness: 0.04" - 0.25" (1.0 mm - 6.4 mm).

Recommended minimum panel thickness to maintain Type 4X

rating: 0.06" (1.5 mm) steel panel, 0.16" (4.1 mm) plastic panel.

Remove the two mounting brackets provided with the controller (back-off the two screws so that there is

¼" (6.4 mm) or less through the bracket. Slide the bracket toward the front of the case and remove).

Insert controller into the panel cutout.

Install mounting brackets and tighten the screws against the panel. To achieve a proper seal, tighten

the mounting bracket screws evenly until

controller is snug to the panel along its short side. DO NOT OVER

TIGHTEN, as the rear of the panel may be damaged.

Figure 1: 1/8 DIN Panel Mounting

3.622" (92 mm)

1.772"

(45mm)

Panel Cutout

to DIN 43700

Square Corners to 0.060"

(1.5mm) Max Radius

Tolerances:

A: +0.032 (+0.8mm)

-0.000 (-0.0mm)

B: +0.024 (+0.6mm)

-0.000 (-0.0mm)
