Premio CT-DWL01 Bedienungsanleitung

USER’S

MANUAL

CT-DWL01

3.5" SBC Industrial Motherboard with 8th Gen. Intel®

Core™Processor i3/i5/i7 &

Intel® Celeron® Processor

CT-DWL01 l User’s Manual

Table of Contents

Prefaces …………………………………………………….…………………………………………….04

Revision …………………………………………………………………………………………..……………….………..04

Disclaimer ………………………………………………………..…….…….………………………….……………….. 04

Trademarks Acknowledgment …………..……………………………………………………….................. 04

Environmental Protection Announcement …………………………….………………….…………..….. 04

Safety Precautions ………………………………………….……………………………….…………….……….... 05

Technical Support and Assistance …………………………………….…………….…………….………….. 06

Conventions Used in this Manual ………………………………………………………………….….………. 06

Chapter 1 Product Introductions ………………………………………………………..…07

1.1 Product Description ……….………………………………..………….………………..………. 08

1.2 Specifications ………………..………………………….....…………….…………..…..………… 09

1.3 Available Models …………………..……………………..…………………………………..…... 10

Chapter 2 Mechanical Specifications ….…………………..………………………..…. 11

2.1 Switch and Connector Locations ..…………………………………..…….…..……..….... 12

2.2 Connector / Switch Definition …..………………………….……….…….………............ 14

2.3 I/O Interface Descriptions .………..…............................................................. 15

2.3.1 Clear CMOS……....…………….…………………………………………....……………… 15

2.3.2 Panel PWR setting …….…….…………………………………………....……………… 15

2.3.3 Backlight PWR setting ...……….……………………………………....……………… 16

2.3.4 Front Panel Header……………………………………....………………………………. 17

2.3.5 AT/ATX setting ……..…..……………………………………………....………………..… 18

2.3.6 Panel control ………..…………..……………………………………....…………………. 19

2.3.7 USB3 …………………………………………………………….……………....……………… 20

2.3.8 USB …………………………………………………………….……………………………..…. 21

2.3.9 eDP ………………………………………..………………………..……………………..….… 22

2.3.10 COM Port COM1 ………...………………..……………………………………………. 23

2.3.11 COM Port COM2 ……………………………………………………………………….. 24

2.3.12 COM Port COM3 …….……………………………………....……………………..…… 25

2.3.13 COM Port COM4 ………….…………………....………………………………….…… 26

2.3.14 GPIO ………………………………....……………………………………………………..… 27

2.3.15 SATA1 ………………………………....………………………………………………………. 28

2.3.16 SATA2 …………………………………………....………………………………………….… 29

2.3.17 SATA1_PWR1 …………………………………...………………………………………… 30

2.3.18 SATA2_PWR1 ………………………………………….………………………..……….. 31

2.3.19 USB2.0 ………………………………………………………………………………………… 32

2.3.20 DC12_IN …………………………………………...………………………...……….…… 33

2.3.21 FAN PWR ……………………….…………….…………………………………………….. 34

2.3.22 HDMI ………………………………………………………..……………...………………… 35

2.3.23 DP ……………………………………………………………………………..……………….. 36

2.3.24 RJ45 ……………………………………………………………………………….……..…… 37

2.3.25 LVDS ……………………………………………………………….………...………….…… 38

CT-DWL01 l User’s Manual

Chapter 3 Features & Interfaces ………………………………………………………..…39

3.1 Processor ……………………….………………………………..………….………………..………. 40

3.2 BIOS ……………………………..………………………….....…………….…………..…..………… 40

3.3 System Memory ……….…………..……………………..…………………………………..…... 40

3.4 Graphics ………………………………………..…………………………..………..……….………. 40

3.5 USB ……………………………….………………………………..………….………………..………. 40

3.6 Ethernet ……..………………..………………………….....…………….…………..…..………… 40

3.7 SATA ………………..……….…………..……………………..…………………………………..…... 40

3.8 Audio ………………………………..…………..…………………………..………..……….………. 40

3.9 Expansion ……………………..………………………….....…………….…………..…..………… 41

3.10 General Purpose Input Output ……………………..…………………………………..…... 41

3.10.1 GPIO Configuration ……………………..……….………………………………..…... 41

3.11 Watchdog Timer ………………..…………..…………………………..………..……….………. 42

3.11.1 Board Design ……………..………………..……….………………..……………..…... 42

3.11.2 Psuedo Code ……………..………………..……….……………………..………..…... 42

Chapter 4 Driver Installation ….…………………..………………..……………..…..…. 43

Chapter 5 System BIOS ….…………………………..………………..……………..…..…. 45

5.1 BIOS Introduction ………….….…………………………………..……...…….…..……..….... 46

5.2 Main Setup ………….….…………………………………..……...…….……………..……..….... 47

5.3 Advanced Setup ………….….…………………………………..……...…………..……..….... 48

5.3.1 CPU Configuration …………….…………………………………………....…………… 49

5.3.2 PCH-FW Configuration ………..…….………………..…………..…………………… 50

5.3.3 SATA and RST Configuration ...……………………………………....……………… 51

5.3.4 RST (UEFI RAID) Configuration ……..……….……………....………………..…… 52

5.3.5 Trusted Computing ……..……………………………………………....…………..…… 54

5.3.6 ACPI Settings ………..…………..……………………………………....……………….… 55

5.3.7 Super IO Configuration …………….………………………....……………….……… 56

5.3.8 Hardware Monitor ………..…….………………..………………………………….….. 61

5.3.9 Serial Port Console Redirection …..……….…………………....………………… 63

5.3.10 Network Stack Configuration .………………………….………....……………… 64

5.3.11 CSM Configuration .……..………………………..…………………....……………… 65

5.3.12 USB Configuration …………..…………………..……………….…....……………… 66

5.4 Chipset ………….………………………………........................................................... 67

5.4.1 System Agent (SA) Configuration ...……………………………....……………… 67

5.4.2 PCH-IO Configuration …………..……………………………....………………......… 70

5.5 Security …….……………………..……………........................................................... 75

5.6 Boot ……………..………………………………........................................................... 78

5.7 Save and Exit …………………………………........................................................... 79

Appendix WDT & GPIO .…………………………..………………..……………..…..…. 80

CT-DWL01 l User’s Manual

Revision

Disclaimer

All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio

Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The

information in this document is subject to change without notice and does not represent a commitment

on the part of Premio Inc.

Premio Inc. disclaims all warranties, express or implied, including, without limitation, those of

merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users

must take full responsibility for the application of the product.

electronic or mechanical, including photocopying, recording, or information storage and retrieval systems,

Trademarks Acknowledgment

Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.

Windows® is registered trademark of Microsoft Corporation.

AMI is trademark of American Megatrend Inc.

IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation

All other products and trademarks mentioned in this manual are trademarks of their respective owners.

EnvironmentalProtection Announcement

Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution

and ensure environment protection.

Prefaces

Revision Description Date

1.0 Initial release 2020/10/12

Preface

CT-DWL01 l User’s Manual

Safety Precautions

Before installing and using the equipment, please read the following precautions:

⚫Put this equipment on a reliable surface during installation. Dropping it or letting it fall could

cause damage.

⚫The power outlet shall be installed near the equipment and shall be easily accessible.

⚫Turn off the systempower and disconnect the power cord from its source before making any

installation. Be sure both the systemand the external devices are turned OFF. Sudden surge

⚫of power could ruin sensitive components. Make sure the equipment is properly grounded.

⚫When the power is connected, never open the equipment. The equipment should be opened

only by qualified service personnel.

⚫Make sure the voltage of the power source is correct before connecting the equipment to the

power outlet.

⚫Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use

liquid or spray detergents for cleaning.

⚫Avoid the dusty, humidity and temperature extremes.

⚫Do not place heavy objects on the equipment.

⚫If the equipment is not used for long time, disconnect it from the power to avoid being

damaged by transient over-voltage.

⚫The storage temperature shall be above -40°C and below 85°C.

⚫The computer is provided with a battery-powered real-time clock circuit. There is a danger of

explosion if incorrectly replaced. Replace only with the same or equivalent type

recommended by the manufacturer.

⚫If one of the following situation arises, get the equipment checked be service personnel:

•The power cord or plug is damaged.

•Liquid has penetrated into the equipment.

•The equipment has been exposed to moisture.

•The equipment does not work well or it cannot work according the user’s manual.

•The equipment has been dropped and damaged.

•The equipment has obvious signs of breakage.

Preface

CT-DWL01 l User’s Manual

Technical Support and Assistance

Contact your distributor, our technical support team or sales representative for technical support if you

need additional assistance. Please have following information ready before you call:

⚫Model name and serial number

⚫Description of your peripheral attachments

⚫Description of your software (operating system, version, application software, etc.)

⚫A complete description of the problem

⚫The exact wording of any error messages

Conventions Used in this Manual

Preface

This indication alerts operators to an operation that, if not strictly observed,

may result in severe injury.

WARNING

This indication alerts operators to an operation that, if not strictly observed,

may result in safety hazards to personnel or damage to equipment.

CAUTION

This indication provides additional information to complete a task easily.

NOTE

Chapter 1

Product Introductions

CT-DWL01 l User’s Manual

1.1 Product Description

The CT-DWL01 is a single board computer in 3.5" SBC Industrial Motherboard with 8th Gen. Intel®

Core™Processor i3/i5/i7 & Intel® Celeron® Processor

• 1x 260-pin DDR4 2400 SO-DIMM. Max. up to 32GB

• Triple independent display supported by:

1x DisplayPort support resolution 4096 x 1200

1x Dual-channel, up to 24-bit LVDS optional 1x eDP via internal connector

1x HDMI support resolution 1920 x 1200 (Optional)

• 1x Front Panel with Audio support by internal header

• 2x 4bit GPIO header

• 2x Mini PCI-e (Gen3) w/ SIM slot support

• 4x USB 3.2 Gen 2 (10Gbps), 4x RS-232/422/485 internal headers,

2x USB 2.0 internal header

• 2x SATA 6.0Gb/s

• Watchdog timer 1~225sec. system reset

• TPM 2.0 Supported

Chapter 1: Product Introductions

CT-DWL01 l User’s Manual

Chapter 1: Product Introductions

1.2 Specifications

System

Processor

Support 8th Gen. Intel® WL-UE Processor (15W TDP)

•Intel® Core™i7-8665UE Processor 8M Cache, up to

4.40 GHz

•Intel® Core™i5-8365UE Processor 6M Cache, up to

4.10 GHz

•Intel® Core™i3-8145UE Processor 4M Cache, up to

3.90 GHz

•Intel® Celeron® Processor 4305UE2M Cache, 2.00

GHz

System Memory : SoC

LAN Chipset :

•GbE1: Intel® I219LM (Support Wake-on-LAN and

PXE)

•GbE2: Intel® I210-IT (Support Wake-on-LAN and PXE)

Audio Codec : Realtek ALC888S HD Audio Codec

Memory : 1x 260-Pin DDR4 2400MHz SO-DIMM slot

Max. Size : 32GB

BIOS : AMI uEFI 256MB SPI flash

Watchdog : Software Programmable Supports 1~255

sec. System Reset

TPM : TPM 2.0 Through Infineon® SLB9665TT2.0 or

Equivalent

Display

Chipset :

•Intel® UHD Graphics 620 for Core series

•Intel® UHD Graphics 610 for Celeron series

Interface :

•1x DisplayPort support resolution 4096 x 1200

•1x LVDS & 1x EDP internal connector

•1x HDMI support resolution 1920 x 1200

(Optional)

Multiple Display : TripleDisplay (HDMI Optional)

Expansion

Mini PCI Express : 2x Mini PCI-e x1 (Gen3)

Rear I/O

LED : 1x Power LED, 1x HDD LED indicator

LAN : 2x RJ45

Display :

•1x HDMI 1.4, 4096x2160 @30/24Hz

•1x DisplayPort DP 1.2, 4096x2304 @60Hz

USB : 4x USB 3.2 Gen 2 (10 Gbps)

Internal I/O

Display :

•1x LVDS Dual -channel, up to 24-bit (1920x1200)

•1x eDP1.4 (4096x2306 @60Hz) (Optional )

COM : 4x RS-232/422/485 internal 2.0PH headers

USB : 2x USB 2.0 internal via a PH2.0 2x 10pin header

SATA : 2x SATA Gen3, w/2x 4pin SATA Power connector

Audio : 1x Front panel audio

DIO : 2x 4-bit DIO (4-in/4-out) via a PH2.0 2x 10pin

header, (PIN1_VCC, PIN2_GND)

Others :

1x Front panel

1x 4-pin PWM smart fan

1x Debug Port

1x RTC battery by cable

Operating System

Windows : Microsoft® Windows® 10 64-bit(RS5 or

above)

Linux : Linux Kernel 5.x (Fedora 30 or above / Ubuntu

19.04 or above)

Power

Power Connector : 4-pin CPU P4 connector

Power Input : AT/ATX 12V DC Input

Management : ACPI

Mechanical & Environment

Form Factor : 3.5" Embedded SBC

Dimension : 146 x 102mm

Operating Temp :

-40°C ~ 85°C, 95% (non-condensing), operating

Storage Temp :

-40°C ~ 85°C, 95% (non-condensing), Non-operating

Relative Humidity :

10% ~ 90% relativehumidity, non-condensing

ORDERING INFORMATION

Packing List

•1 x Heat Sink

•1 x SATA Power Cable

•1 x Driver DVD

Ordering Information

CT-DWL01-8365UE :

3.5" SBC with Intel® Core™i5-8365UE, DP, HDMI, 2x

LAN, 4x USB

CT-DWL01-4305UE :

3.5" SBC with Intel® Celeron® 4305UE, DP, HDMI, 2x

LAN, 4x USB

CT-DWL01-8665UE : (Optional)

CT-DWL01-8145UE : (Optional)

CT-DWL01 l User’s Manual

1.3 Available Models

Chapter 1: Product Introductions

Ordering Information Part Number

-DWL01-8365UE

3.5" SBC with Intel® Core

™i5-8365UE, DP, HDMI, 2x LAN, 4x USB

-DWL01-4305UE

3.5" SBC with Intel® Celeron® 4305UE, DP, HDMI, 2x LAN, 4x USB

-DWL01-8665UE

(Optional)

-DWL01-8145UE

(Optional)

Inhaltsverzeichnis

Andere Premio Einplatinencomputer Handbücher

Premio

Premio CT-DBT0x Bedienungsanleitung

Beliebte Einplatinencomputer Handbücher anderer Marken

WIN Enterprises

WIN Enterprises PL-80910 Bedienungsanleitung

AXIOMTEK

AXIOMTEK SBC81206 Series Bedienungsanleitung

Embest

Embest SOM-PH8800 Bedienungsanleitung

SeaLevel

SeaLevel SBC-R9 Bedienungsanleitung

SMART Embedded Computing

SMART Embedded Computing ATCA-8310 Bedienungsanleitung

WinSystems

WinSystems PPM-LX800-G Bedienungsanleitung

GIGAIPC

GIGAIPC QBiX-PPC Series Bedienungsanleitung

OLIMEX

OLIMEX A10S-OLinuXino-MICRO Bedienungsanleitung

Commell

Commell FS-978 Bedienungsanleitung

GIGAIPC

GIGAIPC QBiP-8665A/ Bedienungsanleitung

VersaLogic

VersaLogic Python EBX-11 Bedienungsanleitung

Micro Computer Specialists

Micro Computer Specialists IRV-3702 Bedienungsanleitung

CompuLab

CompuLab SB-A510 Bedienungsanleitung

Boser

Boser HS-7321 Bedienungsanleitung

Premier Farnell

Premier Farnell Embest SBC8530 Bedienungsanleitung

MicroSys Electronics

MicroSys Electronics miriac SBC-LS1043A2 Bedienungsanleitung

Aaeon

Aaeon UP Bedienungsanleitung

Portwell

Portwell WUX Series Bedienungsanleitung
