Prestigio PMP5580C_DUO Bedienungsanleitung

PMP5580C_DUO EN - 1

1. Packing List

1. Prestigio MultiPad 2. AC Adapter

3. Carrying Case 4. USB Cable

5. Quick Start Guide 6. Warranty Card

7. Legal and Safety Notices 8. OTG Cable

2. Device Overview

Quick Start Guide

Prestigio MultiPad

PMP5580C_DUO

2 1

106 8

EN – 2 PMP5580C_DUO

Power

urn on/off the device;

Suspend/Activate the device

Mini-HDMI video output

HDMI cable connection.

USB port USB connection.

DC Port

C adapte

connection.

Earphone Jack Earphones connection.

Built-in Microphone Record sounds.

Camera

ake photos.

Сharging indicator

urn to red during charging and turn to

green as finishing charging.

Vol +\ Vol - Button

djust the volume level.

Reset Reset the device if it fails to operate

correctly.

Micro SD Card Slot Insert Micro SD card.

Getting Started

3. Charging

zInsert the connector of adaptor to the DC port on the device and

connect the power adapter to the wall socket for charging.

zNormally it takes approximately 5 hours to fully charge the device.

Operating the device while charging with the AC adapter may extend

the time of full charging.

4. Power on/Power off

zTo turn on the device, press and hold the Power Button until you see

the start-up screen then release. It will automatically enter the Home

screen.

zPress the Power Button once to enter sleep mode and press it again

to awake the device.

zPress and hold the Power Button, and then tap on OK to power off

the device.

Quick Start Guide

Prestigio MultiPad

PMP5580C_DUO

PMP5580C_DUO EN - 3

5．Inserting a Memory Card

zThe device supports micro SD/SDHC cards.

zTo insert a Micro SD card, place the card connector towards the front

side of the device and the printing side of the card towards the rear

side of the device.

zTo remove the micro SD card, gently press the edge of the card to

release the safety lock and pull the card out of the slot.

zTo access the files on the memory card, select FireBrowser icon

and tap on SD Card.

Notice:

When you are reading the file from micro SD card, please don’t

remove it, or the device could fail to operate correctly.

6. Connecting to Wi-Fi

zIn the Home menu press the icon and select Settings icon to

access the list of options. Select Wireless & networks.

zIf the Wi-Fi is off, tap on the Wi-Fi line to turn it on.

zThe device will scan for available Wi-Fi networks and display them at

the right of the screen.

zTap on the network you want to connect to. Then tap inside the

Wireless password field to make the virtual keyboard appear. Enter

the required network information, tap on Enter, and then tap on

Connect.

zYour device will now attempt to establish a connection to the Wi-Fi

access point with the network parameters you entered.

7. Transferring content from PC

zConnect the device to your PC/Notebook via USB cable.

zSelect the content you want to transfer from your PC/Notebook.

zDrag the content from the PC/Notebook to the device.

zPlease do not disconnect the USB cable during loading. It may cause

malfunction of the device and files.

zLeft click on to disconnect the device and PC/Notebook safely.

Quick Start Guide

Prestigio MultiPad

PMP5580C_DUO

EN – 4 PMP5580C_DUO

Technical Specifications

Processor Dual Core ARM Cortex A9 up to 1.5 GHz

RAM 1GB DDR3

Display 8” TFT LCD, Capacitive multi-touch

Resolution 1024 x 768 pixels

Video: AVI,3GP, MP4, RM, RMVB, FLV, MOV

Audio:MP3/WMA/WAV/OGG/FLAC/APE/AAC

Supported File Formats

Picture: JPEG(Baseline), BMP, GIF（Static）,

PNG

Storage capacity 8 GB flash memory (about 6 GB are

accessible by user), Memory card slot

supports micro SDHC card up to 32 GB

Interfaces USB 2.0, Micro SD (micro SDHC

compatible), USB Host, HDMI

Communications WiFi (802.11 b/g/n)

Battery 4700 mAh Li-Pol battery

Dimensions 205*155*11（mm）(L x W x H) (appro.)

Weight 490 g (appro.)

Storage Temperature -20℃～+65℃

Operation

Temperature

0℃～+50℃

Operation Relative

Humidity 20% ～90%（40℃）

Storage Relative

Humidity 20% ～93%（40℃）

Disclaimer

As the Prestigio products are constantly updated and improved, your

device’s software may have a slightly different appearance or modified

functionality than presented in this Quick Start Guide.

Quick Start Guide

Prestigio MultiPad

PMP5580C_DUO
