Roadrunner 530A5GPS EN -1

Quick Start Guide

Prestigio Roadrunner 530A5GPS

1. Packing List

1. Prestigio car DVR

4. USB cable

7. CD ROM

2. Suction mount

5. Quick start guide

3. Car charger

6. Warranty Card

Note: The suction mount build in GPS receiver. Please connect

the car charge with the USB port of the GPS mount. When the

device connected GPS signal, the icon will become GREEN.

2. Device Overview

LED light

Mode Button

Lens

Reset button

Speaker

AV port

Power / Photo button

USB port

Bracket port

Mic

Record button

Micro SD card slot

Navigation button (5

directions –up, down, left,

right, center)

HDMI port

EN–2Roadrunner 530A5GPS

Quick Start Guide

Prestigio Roadrunner 530A5GPS

Note：

Beside USB port, the device can be supplied with power from another USB

port on the suction mount.

Getting started

3. Power on/Power off

Position the device in the vehicle using the suction mount and press

the Power button to turn it on. To power off the device press the

button again.

You can also connect the device to the car charger. It will

automatically turn on and start recording when the car engine starts.

When the engine stops, the device will automatically save the last file

and turn off.

4. Charging

Using the car changer: Connect the device to the car charger. The

device will start charging after the car engine is turned on. The device

will automatically turn on and start recording. When the engine stops,

the device will automatically save the last file and turn off.

Normally it takes approximately 2-3 hours to fully charge the device.

Note:

Before using the device for the first time, please, connect it to the PC

or notebook using the USB cable provided to fully charge the Li-ion

battery. The battery is completely charged in 2-3hours.

5. Inserting the Micro SD-card

Before starting video recording, please, insert a Micro SD card (not

included) into the Micro SD card slot in the device.

To extract the Micro SD card slightly push it inside the device, and

remove.

Note:

After inserting the Micro SD card the device will automatically

recognize it as default storage and all the data will be saved on this

card.

Roadrunner 530A5GPS EN -3

Quick Start Guide

Prestigio Roadrunner 530A5GPS

6. Recording

To start recording make sure the Video Mode is selected. Press the

Record button to start recording. The recorded files are saved on

Micro SD Card. To stop recording, press any button or stop the car

engine if the device is connected to the car charger.

7. Taking pictures

Press the Photo button to take a photo. Taken photos are saved on

Micro SD Card.

To take photos with a flash press the navigation button right.

Settings

8. Menu settings

Turn on the device and press Mode button twice to enter Settings. Press

the navigational button up/down to select the option and press OK to

enter the value selection.

The following options list is available in the Video menu:

Resolution: Select the video image size from 1920x1080 (30 fps),

1280x720 (60 fps), 1280x720(30 fps).

Record overwrite: Once there is no more free space left on the

Micro SD card the device will automatically erase the oldest files on

the card and continue recording new ones. Select one of the values to

set the video duration.

Power on delay: Select the time for device power on after the

engine started.

Power off delay: Select the time for device power off after the

engine started.

Motion detection: After enabling this function the device will start

recording automatically if it detects a moving object and stop

recording when there is no movement detected.

Volume: Select the playback volume and tone volume.

Language: Select the desired language from the list.

Date& Time setup: Install the current date and time.

EN–4Roadrunner 530A5GPS

Quick Start Guide

Prestigio Roadrunner 530A5GPS

Stamp: Select ON to add time and date indications to the images and

video.

Format: Select to format the Micro SD card.

TV type: Select NTSC / PAL.

Voice Recorder: Turn on / off the Mic.

Auto LCD Off: Select the time of LCD automatic off during recording.

Stamp Color: Select the display color of Stamp.

G-Sensor Set: Select the sensitivity of the G-Sensor.

GMT Setup: Select the local GMT.

Car Number Set: Set the plate number of your car.

Anti-flicker: Change frequency to remove the blinking effect when

recording under artificial lighting.

Default setting: Select to restore default system settings.

Version: Displays the current system version.

9. Playback mode

To enter playback mode press Mode button. The recorded file will be

displayed in thumbnails. Press the navigation button to view the file,

press OK to play the recorded files.

10. USB connection

To download registered files on your PC/notebook, please, connect the

device to the PC or notebook via USB-cable provided. After connecting

the device to the PC, the device will appear in “My computer” as the

removable disk. All registered files are stored in DCIM folder, videos are

stored in MOV format, and the pictures are stored in JPG format. You can

now download the files from the device.

11. Playback on TV

To playback the recorded files on TV connect the device to your TV with

the AV provided or HDMI cable (not included) and follow the TV

instructions or refer to your TV user manual.

Notes:

Please insert the Micro SD card before recording. Micro SD card is not

included in the package.

When the Micro SD card is out of memory, it will automatically erase

the oldest files and start recording from the beginning (only if the

Roadrunner 530A5GPS EN -5

Quick Start Guide

Prestigio Roadrunner 530A5GPS

Recycle option is activated).

12. Playback on GPS Video Player

To play the recorded files on GPS Video Player, please follow the steps

below:

Step 1 - Insert the Micro SD card into DVR and connect the DVR to PC.

You can find “player.exe” on Micro SD card. Or install the PLAYER

driver to your PC, the driver storage in the CD Rom provided.

Step 2 - Double click the “player.exe”, the videos will be listed on the

right top side.

Step 3 - Double click the file to start play the video

Step 4 - The position on the Google map and the trace can be seen on

the right middle side.

Step 5 - The red, green and white lines are the 3D G-sensor info. on

right bottom, there are the speed and direction info

EN–6Roadrunner 530A5GPS

Quick Start Guide

Prestigio Roadrunner 530A5GPS

Safety precautions

Please observe all safety precautions before using Prestigio Roadrunner

530A5GPS. Please follow all procedures outlined in this manual to

correctly operate the device.

Do not attempt to disassemble or alter any part of the device that is

not described in this guide.

Do not place the device in contact with water or any other liquids. The

device is NOT designed to be liquid proof of any sort.

In the event of liquid entry into interior of device, immediately

disconnect the device from the computer. Continuing use of the

device may result in fire or electrical shock. Please consult your

product distributor or the closest support center.

To avoid risk of electrical shock, do not connect or disconnect the

device with wet hands.

Do not place the device near a heat source or directly expose it to

flame or heat.

Never place the device in vicinity of equipments generating strong

electromagnetic fields. Exposure to strong magnetic fields may cause

malfunctions or data corruption and loss.

Technical Specifications

Recording

resolution

1920x1080 (30 fps), 1280x720 (60 fps),

1280x720(30 fps)

Video format

MOV

Picture format

JPG

Power source

Replaceable rechargeable battery

Interfaces

HDMI, USB, AV out, Micro SD card

(Supportsmax32GB, high-speed Micro SD card

recommended)

Microphone

Built-in

Operating

temperature

0 °~ 45°C

Roadrunner 530A5GPS EN -7

Quick Start Guide

Prestigio Roadrunner 530A5GPS

Video Storage Capacity

Storage

card(G)

H.264

1080P/ 30fps

H.264

720P / 60 fps

H.264

720P / 30 fps

2592 X 1944

(5M)

16G250min 290min 340min 21000 photos

8G120min 145min 170min 10500 photos

4G60min 72min 80min 5200 photos

2G30min 36min 40min 2600 photos

Disclaimer

If device has been damaged by liquid (for example, water, coffee or a

soft drink, etc.), the service for such liquid damage is not covered by the

Prestigio two (2) years limited warranty.

As the Prestigio products are constantly updated and

improved, your device’s software and hardware may have a

slightly different appearance or modified functionality than

presented in this Quick Start Guide.

Prestigio hereby states that this Roadrunner complies to basic

requirements and another relevant regulations given by the EU

directive1999/5/EC. Full version of the declaration of conformity is

available on http://www.prestigio.com/compliance.
