Prestigio MultiPad PMP3384B Bedienungsanleitung
PMP3384B EN - 1
1. Packing List
1. Prestigio MultiPad
2. AC Adapter
3. USB Cable
4. Carrying Case
5. Quick Start Guide
6. Warranty Card
7. Legal and Safety Notices
2. Device Overview
1
2
3
4
5
6
7
Quick Start Guide
Prestigio MultiPad
PMP3384B
EN
EN –2 PMP3384B
Page Jump
Buttons
Turn to the previous/next page in eBook
Reading Mode
Press and hold the Previous Page Button to
return to Home page. Press and hold the Next
Page Button to return to previous page.
SD Card Slot
Insert SD card
Reset Button
Reset the device to default settings
Mini USB Port
USB connection
Earphone Jack
Earphones connection
DC Port
AC adapter connection
Power Button
Turn on/off the device; Suspend/Activate the
device.
3. Charging
Insert the AC connector to the DC port on the device and connect the
power adapter to the wall socket for charging.
Normally it takes approximately 5 hours to fully charge the device.
Operating the device while charging with the AC adapter may extend
the time of full charging.
4. Power on/Power off
Press and hold the Power Button to turn on the device. It will
automatically enter the Home screen after the start-up screen.
Press the Power Button once to enter sleep mode and press it again
to awake the device.
Press and hold the Power Button, and then tap on Power
off/Standby to power off the device or to enter sleep mode.
5. Inserting a Memory Card
The device supports SD/SDHC cards.
To insert a SD card, place the card connector towards the device and
the card label towards the rear side of the device.
To remove the SD card, gently press the edge of the card to release
the safety lock and pull the card out of the slot.
To access the files on the memory card, select Explorer mode and
tap on SD Card.
7
5
6
4
3
2
1
EN
Quick Start Guide
Prestigio MultiPad
PMP3384B
PMP3384B EN - 3
6. Transferring Content to the device
1. Connect the device to your PC/Notebook using the USB cable.
2. Select the content you want to transfer from your PC/Notebook.
3. Drag the content from the PC/Notebook to the device.
4. Please do not disconnect the USB cable during loading. It may
cause malfunction of the device and files.
5. Left click on to disconnect the device and PC/Notebook safely.
NOTE:
Content can also be transferred to SD card on the device.
7. Connecting to Wi-Fi
Select Settings icon to access the list of options. Select Wireless &
networks.
If the Wi-Fi is off, tap on and switch it to . Then select the Wi-Fi
settings.
The device will scan for available Wi-Fi networks and display them at
the bottom of the screen.
Tap on the network you want to connect to. Then tap inside the
Wireless password field to make the virtual keyboard appear. Enter
the required network information, tap on Done, and then tap on
Connect.
Your device will now attempt to establish a connection to the Wi-Fi
access point with the network parameters you entered. After
connecting to a Wi-Fi network, the icon appears on the status bar
on the right side of the Home screen.
8. Automatic Upgr0061de
If there is a new system version, a system update dialog-box will pop
up.
Click “download”to download new firmware package. ( This process
will take a long time, please be patient)
When finishing to download the new firmware package, click
“installation”to upgrade your firmware.
Notice:
During automatic updates the charger should always be connected to
the device in order to avoid power shortage and as a result
interruption of the upgrade process.
New firmware package should be downloaded in a good WI-FI
network environment.
During upgrade some user data may be lost (installed applications).
Before upgrade please backup the important files.
Quick Start Guide
Prestigio MultiPad
PMP3384B
EN
EN –4 PMP3384B
Technical Specifications
Processor
High performance ARM Cortex A8 at 1GHz
RAM
512MB DDR3
OS
Android 2.3 (Gingerbread)
Display
8.4” TFT LCD, Resistive dual touch
Resolution
800 x 600 pixels
Storage
capacity
4 GB flash memory (2.8GB are accessible by user),
Memory card slot supports SDHC card up to 32 GB
Interfaces
USB 2.0, SD (SDHC compatible), USB Host
Communicati
ons
Wi-Fi (802.11 b/g/n)
Audio Format
MP3/WAV/OGG/FLAC/APE/AAC/WMA
Video Format
AVI/3GP/MP4/RM/RMVB/FLV/MKV/MOV/VOB/WMV/DAT
Photo Format
JPEG(Baseline) :96*32pixels to 8000*8000 pixels；BMP；
GIF（Static）； PNG
Battery
4000 mAh Li-Polymer battery
Dimensions
212.8x161.4x11（mm）
Weight
500 g
Disclaimer
As the Prestigio products are constantly updated and
improved, your device’s software may have a slightly
different appearance or modified functionality than
presented in this Quick Start Guide.
Prestigio hereby states that this Smartphone complies to basic
requirements and another relevant regulations given by the EU
directive1999/5/ES. Full version of the declaration of conformity is
available on http://www.prestigio.com/compliance.
EN
Quick Start Guide
Prestigio MultiPad
PMP3384B
