To press the TIMER ON button can set the auto-on
time of the unit. To press the TIMER OFF button
can set the auto-off time of the unit.
1. Press the TIMER ON button. The remote
controller shows TIMER ON, the last Auto-on
setting time and the signal "h" will be shown on
the LCD display area. Now it is ready to
reset the Auto-on time to START the operation.
2. Push the TIMER ON button again to set desired
Auto-on time. Each time you press the button,
the time increases by half an hour between 0
and 10 hours and by one hour between 10 and
24 hours.
3. After setting the TIMER ON ,there will be a one-
half second delay before the remote controller
transmits the signal to the air conditioner. Then,
after approximately another 2 seconds, the
signal "h" will disappear and the set temperature
will re-appear on the LCD display window.
To set the Auto-on time.
To set the Auto-off time.
1. Press the TIMER OFF button. The remote
controller shows TIMER OFF, the lastAuto-off
setting time and the signal "h" will be shown on
the LCD display area. Now it is ready to
reset the Auto-off time to START the operation.
2. Push the TIMER OFF button again to set desired
Auto-off time. Each time you press the button,
the time increases by half an hour between 0
and 10 hours and by one hour between 10 and
24 hours.
3. After setting the TIMER OFF ,there will be a one-
half second delay before the remote controller
transmits the signal to the air conditioner. Then,
after approximately another 2 seconds, the
signal "h" will disappear and the set temperature
will re-appear on the LCD display window.
The effective operation time set by the remote controller for the timer
function is limited to the following settings: 0.5, 1.0, 1.5, 2.0, 2.5, 3.0,
3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10, 11, 12, 13,
14, 15,16,17, 18, 19, 20, 21, 22, 23 and 24.
CAUTION
!
Example of timer setting
TIMER ON
Start
Off
6 hours later
(Auto-on Operation)
The TIMER ON feature is useful
when you want the unit to turn on
automatically when you return home.
The air conditioner will automatically
start operating at the set time.
To start the air conditioner in 6 hours.
1. Press the TIMER ON button, the
last setting of starting operation
time and the signal "h" will show
on the display area.
2. Press the TIMER ON button to
display "6.0h" on the TIMER ON
display of the remote controller.
3. Wait for about 3 seconds and the
digital display area will show the
temperature again. Now this
function is activated.
TIMER ON
Example:
h
Set
8
9
1
1
TIMER operation
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
FOLLOW
ME
RESET LOCK
SET TEMPERATURE( F)
SWING
LED
DISPLAY
TURBO
O
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
FOLLOW
ME
RESET LOCK
SET TEMPERATURE( F)
SWING
LED
DISPLAY
TURBO
O
