AMX78(3) Owner's Manual 0399

Important Information About Your

AMX78 System

Congratulations on your purchase of the AMX78 vehicle security system

manufactured by Prime Security. To fully benefit from the capabilities of your

AMX78 system, we encourage you to read the Owner’s Manual thoroughly. If

you have any problems or questions regarding your system, consult the dealer

from whom you purchased this product. To locate an authorized Prime dealer,

contact Prime Security directly at 1-800-253-0334 (toll-free within the U.S.) or

1-847-215-2233.

Lifetime Warranty

Prime guarantees the operation of your system control unit and remote

controls for as long as you own your car. (Please refer to your Lifetime Limited

Warranty Card for complete information.) Make sure that you receive your

warranty card from your dealer, complete the required information and mail

the registration portion to Prime Security. You should retain the top portion of

the warranty card for your records.

Remote Controls

Included with your system are two AviGlo™ 4-button/9-channel remote

controls. Once exposed to light, the AviGlo remote control buttons will glow,

making the buttons visible in the dark.

Each of the pair of remote controls is a miniature radio transmitter powered by

a +12 volt battery with a typical range of up to 100 feet. Obstructions,

electrical or radio interference, weather conditions, cellular transmissions,

window tint or a weak remote control battery may reduce the range or

interrupt transmission. (If the system does not immediately respond, release

and press the button again. This works better than holding the button down.)

The second remote can be used by a second driver, or kept as a spare.

Additional remote controls or batteries can be purchased from any authorized

Prime Dealer, or by calling Prime Security toll-free at 1-800-253-0334 (within

the U.S.) or 1-847-215-2233.

Electronic Scan Prevention (ESP)

Your system also includes ESP, which blocks electronic scanner codes

preventing unauthorized operation of your system.

AMX78(3) Owner's Manual 0399

Instant Remote Control Code Deletion

In the event of a lost or stolen remote control, all remote controls can be

erased from the system memory preventing unauthorized system operation.

(See the “Programming Table for Remote Controls” on page 9).

One-Step Remote Control Code Learning

The system allows you to add new remote controls in one step. (See the

“Programming Table for Remote Controls” on page 9).

Valet Switch

The valet switch is a small hidden toggle switch which allows you to control all

of the system programmable features. (See “User-Programmable Features” on

page 9). This switch can only be controlled with the use of your ignition key.

NOTE:Besuretohaveyourdealershowyouwherethevaletswitchislocated.

AMX78(3) Owner's Manual 0399

Operating Your System

To Arm The System

The alarm can be programmed for active or passive arming. Active arming

means the alarm can only be armed by the remote control. Passive arming

means if you forget to arm the alarm with the remote control, the alarm will

automatically arm itself 30 seconds after the doors have been closed and the

interior lights have turned off. (See the “Programming Table for System

Features” on page 9.)

Active Arming

Press the remote ARM/DISARM button for 1-2 seconds. The siren will chirp

twice, the parking lights will flash twice, the doors will lock,* the LED will

flash slowly and the starter will be disabled.

*If your system was installed with the door lock/unlock feature,

All other door lock/unlock related features will apply.

Passive Arming

Turn the ignition key “OFF,” exit the vehicle and close the doors. When the

interior lights turn off, the LED will begin flashing rapidly to indicate the alarm

is passive arming. After 30 seconds, the siren will chirp twice, the parking

lights will flash twice, the LED will flash slowly and the starter will be disabled

(at any time during passive arming, the alarm can be actively armed).

To Disarm the System

Press the remote ARM/DISARM button for 1-2 seconds. The siren will chirp

once, the parking lights will flash once, the doors will unlock, the interior

lights will turn on, the LED will turn off and the starter will be enabled.

Remote-Controlled Silent Arm/Disarm

Press the remote SILENT button for 1-2 seconds to arm or disarm your system

without the usual siren chirps.

Silent Arm Indications

The parking lights will flash twice, the doors will lock, the starter will be

disabled and the LED will flash slowly.

Silent Disarm Indications

The parking lights will flash once, the doors will unlock, the starter will be

enabled and the LED will turn off.

AMX78(3) Owner's Manual 0399

User-Programmable Long-Term Silent Arm/Disarm

This feature allows you to completely disable the arm/disarm siren chirps until

you decide to restore them. (See the "Programming Table for System Features"

on page 9.)

Remote Panic with Safety Locks

In a threatening situation, you can activate Remote Panic with Safety Locks.

When activated, the siren will sound and the parking lights will flash. If you

are inside your vehicle and the ignition key is “ON,” the doors will lock. If

you are outside the vehicle with the ignition key “OFF,” the doors will unlock.

To Activate

1.Press the remote control ARM/DISARM button for 3-4 seconds.

2. The siren will sound and the parking lights will flash.

3.If the ignition key is “OFF,” the doors will unlock. If the ignition key is

“ON,” the doors will lock.

To Deactivate

1.Press the remote control ARM/DISARM button for 1-2 seconds.

2. The siren will shut off and the parking lights will stop flashing.

Interior Light Illumination

When the alarm system is remotely disarmed, the vehicle interior light(s) will

turn on for 30 seconds or until the ignition key is turned on.

User-Programmable Passive Door Lock

Your system will notautomatically lock the doors when the alarm passively

arms to prevent the keys and remote from being locked in the vehicle. If you

prefer, you can easily program the alarm to automatically lock the doors every

time the alarm passive arms. (See the “Programming Table for System

Features” on page 9.)

User-Programmable Ignition-Controlled Door Lock/Unlock

For the ultimate in security and convenience, your system is programmed to

automatically lock your doors when the ignition key is turned “ON” or the

engine is started, and will unlock when the ignition key is turned “OFF.” This

feature can be programmed ON or OFF. (See the “Programming Table for

System Features” on page 9.)

AMX78(3) Owner's Manual 0399

Protected Valet Mode

You should place your system in Protected Valet Mode whenever your vehicle

is being serviced by mechanics, car wash personnel or driven by valet parking

attendants. While in the Protected Valet Mode, all alarm functions are

bypassed to prevent unauthorized or accidental arming. Remote-controlled

door lock/unlock, trunk release and all optional accessories will still operate.

To Turn on Protected Valet Mode

1.Turn the ignition key to the “ON” position or start the engine.

2.Flick the valet switch to the “ON” position.

3. The LED will turn on solid red to indicate the system is in the Protected

Valet Mode.

4.Turn the ignition key to the “OFF” position.

To Turn off Protected Valet Mode

1.Turn the ignition key to the “ON” position or start the engine.

2.Flick the valet switch to the “OFF” position.

3. The LED will turn off to indicate the system is no longer in the Protected

Valet Mode.

4.Turn the ignition key to the “OFF” position.

LED System Status Indicator

The LED on your vehicles dashboard or center console will inform you of the

system status.

LEDStatus

OffSystem is disarmed

On solidIn Protected Valet Mode

Slow flashSystem is armed

Flashing in cyclesSee “Specific Intrusion Identification” on page 6.

Rapid flashPassive arming

Remote-Controlled Trunk Release Capability

If you have the optional Trunk Release installed, simply press the remote

control TRUNK button for 1-2 seconds to activate your vehicle electronic

trunk release. The trunk will “pop” open (may require an optional relay).

AMX78(3) Owner's Manual 0399

Remote-Controlled Accessory Output

This output allows you to add an optional remote-controlled accessory to your

system such as a remote engine starter, window roll-up, garage door opener*

or fuel door release. To activate your optional accessory, press the OPTION

button on your remote control.*Requires additional module.

Zone2



Impact Sensor

The Zone2

Impact Sensor has two individual vibration/impact sensing zones.

Zone #1

If a less threatening vibration or impact is detected, the siren will issue 2

warn-away chirps. A second violation will also issue 2 warn-away chirps. A

third violation will, within 30 seconds, automatically activate the alarm. The

siren will sound and the lights will flash.

Zone #2

If a more threatening vibration or impact is detected at any time, the siren and

lights will activate instantly.

Previous Intrusion Alert

If the vehicle had been tampered with and the alarm had been triggered, the

siren will chirp 3 times upon remote disarm instead of the usual 1 chirp.

Specific Zone Intrusion Identification

If the alarm had been triggered in your absence, the siren will chirp 3 times

upon remote disarm (Previous Intrusion Alert). When you enter the vehicle

and turn the ignition “ON,” the LED will flash in cycles to specifically identify

which zone triggered the alarm.

LEDZone

1 flash...1 flash...Impact sensor

2 flashes...2 flashes...Hood/trunk trigger

3 flashes...3 flashes...Door trigger

AMX78(3) Owner's Manual 0399

Alarm State Memory

If your vehicle battery is disconnected and later reconnected, the system will

automatically return to its last state before power was removed, whether it was

armed, disarmed or in Protected Valet Mode. For example, if a mechanic

disconnects the battery while the alarm is disarmed or in Protected Valet

Mode, he won’t trigger the alarm when he reconnects the battery. Yet if a thief

removes power while the alarm is armed and reconnects it, the alarm will

instantly sound, the parking lights will flash and the starter will be disabled.

Automatic Malfunction Override

In the event of a faulty sensor or alarm input trigger zone, the alarm, when

remotely armed, will alert you by a series of chirps and parking light flashes.

How to Interpret the Chirps and Parking Light Flashes

When you press the remote control buttons, the system will respond with

chirps and flashes of the parking lights to indicate the system status. An

explanation of these chirp/flash acknowledgments is listed below.

Number of chirps and flashes Explanation

1 chirp, 1 flash Disarming of the alarm

2 chirps, 2 flashes Arming of the alarm

2 chirps and 2 flashes, then 4 chirps

and 4 flashesArmed and there is a sensor malfunction

(automatically bypassed)

3 chirps, 3 flashes Disarmed and there was an intrusion attempt

4 chirps, 4 flashes Armed and there was a trigger malfunction

(automatically bypassed)

AMX78(3) Owner's Manual 0399

User-Programmable Features

All system and remote control programmable features are accomplished by

turning the ignition key “ON” (or starting the engine) and flicking the valet

switch on and off a preset number of times.

Your system also allows you to add new remote controls in one step, delete

lost or stolen remote controls or rearrange the factory preset remote control

functions.

1.Remove the system from Protected Valet Mode. Programming cannot be

accessed while the system is in Protected Valet Mode indicated by the

LED on solid red.

2.Select the feature you wish to program from the “Programming Table for

System Features” or the “Programming Table for Remote Controls” on

page 9. Note the number of chirps associated with that feature.

3.Turn the ignition key to the “ON” position.

4.Within 10 seconds, begin flicking the valet switch on and off. The siren

will chirp once each time you flick the switch on then off.

5. Continue flicking the switch on and off, counting the number of chirps.

NOTE: Stop when you reach the number of chirps associated with your

chosen feature.

6.Follow the “Secondary Action.” You will hear a number of chirps to

confirm that you have changed the setting of that feature.

7.Turn the ignition key to the “OFF” position.

8.Repeat steps 1-7 for any other feature you wish to program.

AMX78(3) Owner's Manual 0399

Inhaltsverzeichnis

Andere Prime Security Sicherheitssystem Handbücher

Prime Security

Prime Security 68 Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
