Princess 01.182033.01.001 Bedienungsanleitung
EN
Instruction manual
NL
Gebruiksaanwijzing
FR
Mode d’emploi
DE Bedienungsanleitung
ES Manual de usuario
PT Manual de utilizador
IT Manuale utente
SV Bruksanvisning
CS Návod na použití
PL Instrukcja obsługi
SK Návod na použitie
Digital Aerofryer Deluxe
01.182033.01.001
RU Руководство по эксплуатации
2
3
4
1
5
PARTS DESCRIPTION / ONDERDELENBESCHRIJVING / DESCRIPTION DES PIÈCES
/ TEILEBESCHREIBUNG / DESCRIPCIÓN DE LAS PIEZAS / DESCRIÇÃO DOS
COMPONENTES / DESCRIZIONE DELLE PARTI / BESKRIVNING AV DELAR /
OPIS CZĘŚCI / POPIS SOUČÁSTÍ / POPIS SÚČASTÍ / ОПИСАНИЕ ЗАПЧАСТИ
6
Instruction manual
3
SAFETY
• By ignoring the safety instructions the
manufacturer cannot be held responsible for
the damage.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• Never move the appliance by pulling the
cord and make sure the cord cannot
become entangled.
• The appliance must be placed on a stable,
level surface.
• This appliance is only to be used for
household purposes and only for the
purpose it is made for. In worst case the
food can catch fire. (i.e. do not use more
than one tea spoon of oil, no meat that will
release to much grease or water intended
for boiling foods.
• This appliance shall not be used by children
aged less than 8 years. This appliance can
be used by children aged from 8 years and
above and persons with reduced physical,
sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Keep the
appliance and its cord out of reach of
children aged less than 8 years. Cleaning
and user maintenance shall not be made by
children unless older than 8 and supervised.
• To protect yourself against an electric shock,
do not immerse the cord, plug or appliance
in the water or any other liquid.
• The appliance is to be connected to a
socket-outlet having an earthed contact (for
class I appliances).
• WARNING: If the surface is cracked, switch
off the appliance to avoid the possibility of
an electric shock.
• Keep the appliance and its cord out of reach
of children less than 8 years.
• The temperature of accessible surfaces may
be high when the appliance is operating.
• The appliance is not intended to be operated
by means of an external timer or a separate
remote-control system.
EN
Instruction manual
4
• Surfaces indicated with this logo are
liable to get hot during use.
• In order to prevent disruptions of the airflow do
not put anything on top of the appliance and
make sure there is always 10 centimeter of free
space around the appliance.
• After the baking process the appliance needs to
cooldown, this cooling process will activate
automatically when the timer is done. Avoid to
unplug the appliance from the net socket before
the cooling process is finished because the
remaining hot air can damage the appliance.
• This appliance is intended to be used in
household and similar applications such as:
• Staff kitchen areas in shops, offices and other
working environments.
• By clients in hotels, motels and other residential
type environments.
• Bed and breakfast type environments.
• Farm houses.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
The universal recycling symbol, logo, or icon is an internationally
recognized symbol used to designate recyclable materials. The recycling
symbol is in the public domain and is not a trademark.
This product complies with conformity requirements of the
applicable European regulations or directives.
The Green Dot is the registered trademark of Der Grüne Punkt
– Duales System Deutschland GmbH and is protected as a trademark
worldwide. The logo may only be used by customers of DSD GmbH
holding a valid trademark usage contract or by engaged waste
management companies within the Federal Republic of Germany. This
also applies to reproduction of the logo by third parties in a dictionary, an
encyclopaedia or an electronic database containing a reference manual.
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with your
local Authority or local store for recycling advice.
The Eurasian Conformity mark (ЕАС) is a certification mark to
indicate products that conform to all technical regulations of the Eurasian
Customs Union.
Instruction manual
5
This symbol is used for marking materials intended to
come into contact with food in the European Union as defined in
regulation (EC) No 1935/2004.
Separate collection / Check your local municipal guidelines.
The product and packaging materials are recyclable,
subject to extended manufacturer responsibility. Dispose it
separately, following the illustrated packaging symbols, for better
waste treatment. The Triman logo is valid in France only.
Cleaning and maintenance
• Before cleaning, unplug the appliance and
wait for the appliance to cool down.
• Never immerse the device in water or any
other liquid. The device is not dishwasher
proof.
• Clean the pan and aeroplate (removable
grid) with hot water, some washing-up liquid
and a non-abrasive sponge. The pan and
aeroplate (removable grid) are not
dishwasher-proof.
• If dirt is stuck to the aeroplate (removable
grid) or the bottom of the pan, fill the pan
with hot water with some washing-up liquid.
Put the aeroplate (removable grid) in the
pan and let the pan and the grid soak for
about 10 minutes.
• Clean the appliance with a damp cloth.
Never use harsh and abrasive cleaners,
scouring pad or steel wool, which damages
the appliance.
PARTS DESCRIPTION
1. Fryer
2. Pan
3. Removable grid
4. Temperature/Time control knob (start/stop)
5. Display
6. Program select touch buttons
EN
Instruction manual
6
Display description 1 Aerofryer fries function 8 Meat function
2 Roast function 9 Toast function
3 Blinking when setting
temperature, on when
displaying program
temperature
10 Press to set temperature
4 Display (minutes and
temperature)
11 Chicken function
5 °C: On when display shows
temperature
12 Bake function
6 Fish function 13 Press to set time
7 Shellfish/Crustaceans function
BEFORE THE FIRST USE
• Remove all packaging material.
• Remove any stickers or labels from the appliance.
• Thoroughly clean the parts with hot water, some washing-up liquid and
a non-abrasive sponge.
• Wipe the inside and outside of the appliance with a moist cloth.
• Place the appliance on a stable, horizontal and level surface, do not
place the appliance on non-heat-resistant surfaces.
• Place the removable grid in the pan properly.
•This is an air fryer that works on hot air. Do not fill the pan with
oil or frying fat.
•In order to prevent disruptions of the airflow do not put anything
on top of the appliance and make sure there is always 10
centimeter of free space around the appliance.
Instruction manual
7
USE
• Put the mains plug in an earthed wall socket.
• Carefully pull the pan out of the air fryer.
• Put the ingredients in the basket.
• Slide the pan back into the air fryer.
• Do not touch the pan during and sometime after use, as it gets
very hot. Only hold the pan by the handle.
There are 8 frying programs included: Aerofryer fries, Roast, Fish,
Shellfish/Crustaceans, Chicken, Bake, Meat and Toast. Use the
corresponding function depending on the type of food you wish to
prepare.
Program Icon Default
temperature
(°C)/time(min)
Quantity Extra information
Aerofryer
Fries
200/15 800g Shake every 5
minutes
Homemade
Fries
Proposed time
120/10 min
200/20 min
800g Shake every 5
minutes
Roast 180/15 200g
Fish 180/20 200g
Shellfish/
Crustaceans
180/15 250g
Chicken 180/25 500g
Bake 160/40 1 pcs
Meat 180/15 200g
Toast 180/10 1 pcs
• Press the round control knob to turn on the Aerofryer. Select the
desired function by touching the icon touch button, the select
function is blinking. Press the start/stop round control knob to
start.
EN
Instruction manual
8
• When you select the function, the Aerofryer will start the
corresponding program. When you have chosen the wrong program,
you can cancel by pressing the start/stop round control knob. After this
you can select another function. It is also possible to adjust the chosen
program by changing the time and temperature.
• It is also possible to start the device without selecting a function. Set
the time and temperature with the timer and temperature knob, select
time or temperature pushing the time or temperature touch button on
display, then adjust by turning the start/stop round control knob. Press
the start/stop round control knob to start.
• The temperature can be set between 80 and 200 degrees, the time
can be set between 1 and 60 minutes.
• When you pull out the pan during the frying process, the device will
shut off automatically within 5 seconds. When you reinsert the device,
the program will resume.
• Excess oil from the ingredients is collected on the bottom of the pan.
• Some ingredients require shaking halfway through the preparation
time. To shake the ingredients, pull the pan out of the appliance by the
handle and shake it. Then slide the pan back into the air fryer.
• When you hear the timer beep 5 times, the set preparation time has
elapsed. The device will shut off after 20 seconds. Pull the pan out of
the appliance and place it on a heat resistant surface.
• Check if the ingredients are ready. If the ingredients are not ready yet,
simply slide the pan back into the appliance and set the timer to a few
extra minutes.
• Empty the basket into a bowl or onto a plate. When a batch of
ingredients is ready, the air fryer is instantly ready for preparing
another batch.
• The device can be switched off by pressing the round start/stop control
knob, it takes approximately 20 seconds to turn the device off.
Tips
• Shaking smaller ingredients halfway during the preparation time
optimizes the end result and can help prevent unevenly fried
ingredients.
• Add some oil to fresh potatoes for a crispy result. Fry your ingredients
in the air fryer within a few minutes after you've added the oil.
• Do not prepare extremely greasy ingredients such as sausages in the
air fryer.
• Place a baking tin or oven dish in the basket if you want to bake a
cake or quiche or if you want to fry fragile ingredients or filled
ingredients.
• You can also use the air fryer to reheat ingredients. To reheat
ingredients, set the temperature to 150°C for up to 10 minutes.
• Baking times may vary based on amount of fries, type of fries,
temperature and brand.
Instruction manual
9
PRODUCT SPECIFICATIONS
Item Detail
Volume 4.5 l
Preprogrammed baking programs 8
Control panel Digital
Touchscreen Yes
Material housing Stainless steel
High speed air convention Yes
Temperature range 80-200 °C
Timer function Yes
Non-slip feet Yes
Frying without oil Yes
Power 1500 Watt
ENVIRONMENT
This appliance should not be put into the domestic garbage at
the end of its durability, but must be offered at a central point for the
recycling of electric and electronic domestic appliances. This symbol
on the appliance, instruction manual and packaging puts your
attention to this important issue. The materials used in this appliance
can be recycled. By recycling of used domestic appliances you
contribute an important push to the protection of our environment.
Ask your local authorities for information regarding the point of
recollection.
Support
You can find all available information and spare parts at
www.princesshome.eu!
EN
Gebruiksaanwijzing
10
VEILIGHEID
• Als u de veiligheidsinstructies negeert, kan de
fabrikant niet verantwoordelijk worden
gehouden voor de mogelijke schade.
• Als het netsnoer beschadigd is, moet het
worden vervangen door de fabrikant, de
onderhoudsmonteur van de fabrikant of door
personen met een soortgelijke kwalificatie om
gevaar te voorkomen.
• Verplaats het apparaat nooit door aan het snoer
te trekken en zorg dat het snoer niet in de war
kan raken.
• Het apparaat moet op een stabiele, vlakke
ondergrond worden geplaatst.
• Dit apparaat is uitsluitend voor huishoudelijk
gebruik en voor het doel waar het voor bestemd
is. In het ergste geval kan het voedsel vlam
vatten. (Gebruik niet meer dan één theelepel
olie, geen vlees dat te veel vet vrijgeeft of water
dat bedoeld is om voedsel te koken.)
• Dit apparaat mag niet worden gebruikt door
kinderen jonger dan 8 jaar. Dit apparaat kan
worden gebruikt door kinderen vanaf 8 jaar en
door personen met verminderde lichamelijke,
zintuiglijke of geestelijke vermogens of gebrek
aan de benodigde ervaring en kennis indien ze
onder toezicht staan of instructies krijgen over
hoe het apparaat op een veilige manier kan
worden gebruikt alsook de gevaren begrijpen
die met het gebruik samenhangen. Kinderen
mogen niet met het apparaat spelen. Houd het
apparaat en het netsnoer buiten bereik van
kinderen jonger dan 8 jaar. Laat reiniging en
onderhoud niet door kinderen uitvoeren, tenzij
ze ouder zijn dan 8 jaar en onder toezicht staan.
• Dompel het snoer, de stekker of het apparaat
niet onder in water of andere vloeistoffen om
elektrische schokken te voorkomen.
• Het apparaat moet worden aangesloten op een
geaard stopcontact (voor klasse I-apparaten).
• WAARSCHUWING: Indien het oppervlak is
gebarsten, schakel dan het apparaat uit om
elektrische schokken te voorkomen.
• Houd het apparaat en het netsnoer buiten
bereik van kinderen jonger dan 8 jaar.
• De temperatuur van de toegankelijke
oppervlakken kan hoog zijn wanneer het
apparaat in gebruik is.
• Het apparaat is niet bedoeld om bediend te
worden met behulp van een externe timer of
een afzonderlijk afstandbedieningssysteem.
Inhaltsverzeichnis
Sprachen:
Andere Princess Fritteuse Handbücher
Princess
Princess 2618N Bedienungsanleitung
Princess
Princess 181000 Bedienungsanleitung
Princess
Princess Multi AeroCooker Bedienungsanleitung
Princess
Princess 01.182061.02.001 Bedienungsanleitung
Princess
Princess 01.182061.01.001 Bedienungsanleitung
Princess
Princess 01.183021.01.001 Bedienungsanleitung
Princess
Princess 01.182026.01.001 Bedienungsanleitung
Princess
Princess 01.182080.01.001 Bedienungsanleitung
Princess
Princess Deep fryer Pro Bedienungsanleitung
Princess
Princess 01.182037.01.001 Bedienungsanleitung
Princess
Princess 182024 Bedienungsanleitung
Princess
Princess 184000 Bedienungsanleitung
Princess
Princess 182727 Bedienungsanleitung
Princess
Princess 01.182080.01.001 Bedienungsanleitung
Princess
Princess Aerofryer XL Bedienungsanleitung
Princess
Princess 01.182016.01.650 Bedienungsanleitung
Princess
Princess 182613 Bedienungsanleitung
Princess
Princess Digital Family Aerofryer Bedienungsanleitung
Princess
Princess 01.182050.01.001 Bedienungsanleitung
Princess
Princess 01.183033.01.014 Bedienungsanleitung
