Instruction manual

SAFETY

• By ignoring the safety instructions the

manufacturer cannot be held responsible for

the damage.

• If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualified persons in order

to avoid a hazard.

• Never move the appliance by pulling the

cord and make sure the cord cannot

become entangled.

• The appliance must be placed on a stable,

level surface.

• The user must not leave the device

unattended while it is connected to the

supply.

• This appliance is only to be used for

household purposes and only for the

purpose it is made for.

• This appliance can be used by children aged

from 8 years and above and persons with

reduced physical, sensory or mental

capabilities or lack of experience and

knowledge if they have been given

supervision or instructions concerning use of

the appliance in a safe way and understand

the hazards involved.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be

made by children without supervision.

• Children of less than 3 years should be kept

away unless continuously supervised.

• Children aged from 3 years and less than 8

years shall only switch on/off the appliance

provided that it has been placed or installed

in its intended normal operating position and

they have been given supervision or

instruction concerning use of the appliance

in a safe way and understand the hazards

involved.

• Children aged from 3 years and less than 8

years shall not plug in, regulate and clean

the appliance or perform user maintenance.

• To protect yourself against an electric shock,

do not immerse the cord, plug or appliance

in the water or any other liquid.

• WARNING: Some parts of this product can

become very hot and cause burns.

Particular attention has to be given where

children and vulnerable people are present.

• Do not use this heater in the immediate

surroundings of a bath, a shower or a

swimming pool.

Instruction manual

• Joists, beams and rafters shall not be cut or

notched to install the appliance.

• Please do not install the appliance close to

curtains and other combustible materials.

This could cause a fire.

• The appliance shall, under no

circumstances, be covered with insulating

material or similar material.

• The heater must not be located immediately

below a socket-outlet.

• Do not use this heater if it has been dropped.

• WARNING: The heater must not be used if

the glass panels are damaged.

• Use this heater on a horizontal and stable

surface, or fix it to the wall, as applicable.

• WARNING: Do not use this heater in small

rooms when they are occupied by persons

not capable of leaving the room on their own,

unless constant supervision is provided.

• WARNING: To reduce the risk of fire, keep

textiles, curtain, or any other flammable

material a minimum distance of 1m from the

air outlet.

• The heater needs to be installed so that the

switches and other controls cannot be

touched by a person in the bath or shower.

• WARNING: In order to avoid

overheating, do not cover the heater.

This product complies with conformity requirements of the applicable

European regulations or directives.

Waste electrical products should not be disposed of with household

waste. Please recycle where facilities exist. Check with your local

Authority or local store for recycling advice.

PARTS DESCRIPTION

1. On / Off switch

2. Display

3. On/off button

4. WiFi button

5. + button

6. – button

7. Timer button

8. Heating indicator

Instruction manual

9. Wall bracket

10. Heater

11. Feet

INSTALLATION

Wall mounting

• Please note that the product must be installed at least 15 cm

from the floor and 50 cm from the ceiling.

• The heater must be mounted at 4 points, ensure there is a

300mm clearance on all sides of the heater.

• Measure the distance between the centre of each bracket both

horizontally and vertically to ensure drilling holes in the correct

place. Mark the positions of the 4 holes to be drilled on the wall

(1), use the supplied wall mount drawings for correct measures.

• Drill the holes in the wall (2), then insert the plastic expanded

plugs (3) and screw the 4 supplied screws into the plastic

expanded plugs (4).

• Attached the panel heater onto the screws and move the heater

to the left so that the screws drop into the securing slots (5).

Foot assembly

• If the heater is not mounted on the wall, the supplied feet must be

fitted to the unit.

• To fix the feet, remove the bottom screws from the heater

housing.

• Place the feet and secure them by putting the screws back into

the housing.

• Take care to ensure that the feet are located correctly on the

bottom end of the heater.

Instruction manual

BEFORE THE FIRST USE

• Putthepower cable intothe socket.(Note: Make surethe

voltagewhich is indicated on the devicematchesthe localvoltage

beforeconnecting the device.Voltage220V-240V 50-60Hz)

• When the device is turned on for the first time, a slight odour will

occur. This is normal, ensure adequate ventilation. This fragrance

is only temporary and will disappear soon.

• During heating up and cooling down there may be some noises

caused by the heater casing expanding and contracting, this is

normal and does not indicate any fault.

TOUCH BUTTON/DISPLAY FUNCTIONS

USE

• Push the on/off switch on the side of the heater to turn the heater

completely on or off.

Touch button functions

• Press the on/off touch button to turn the heater on, pressing it

again will set the device into stand-by mode.

• Wi-Fi button, when device is on or in stand-by mode:

– Press and hold for 6 seconds to put the heating into paring

mode (will beep 3 times).

– Follow the instructions on your phone.

• Press 'temperature up (+)' or 'temperature down (-)' buttons to

regulate the temperature you desired. The temperature can be

set between 0°C and 37°C. Holding the + or – button will increase

or decrease target temperature continuously.

• Timer button; when the device is on, press the timer button, the

time starts blinking “00:00”.

– Use the + and – buttons to set the hours.

– No button press for 5 seconds stops the time blinking.

– Setting time to 00:00 does not enable timer.

– Press timer button again -> time starts blinking and allows the

user to change timer duration.

– The remaining time is visible at the display.

– After the set time has expired the device will power off.

– Long-press while timer is running cancels the timer mode.

• Indicator lamp;

– On when heating element is on.

– Off when heating element is off.

Display

• When the red on/off switch is off, the display screen is also off.

• When power is on (on/off switch is on), and the machine is in

stand-by mode, the display screen is off, only when the device is

already connected to Wi-Fi, the display screen is off with only the

Wi-Fi icon visible.

Instruction manual

• Pressing the on/off touch button when the power is on will show

the Wi-Fi icon + current temperature + time (if set on the phone)

on the display screen with back ground light on.

• After 10 seconds without pressing one of the touch buttons, the

back ground light will go off. On screen you will still see: Wi-Fi

icon + current temperature + time (if set on the phone)

USING THE HEATER WITH PRINCESS HOME APP

• The heater can be used manually with its built-in controls or you

can use a smart phone or smart speaker to control it. Before you

begin, ensure the Princess Home app is downloaded. The

Princess Home app is available on Android and iOS.

• Download the correct version of the Princess Home app via our

website princesshome.eu/nl-nl/princess-home-app or use QR:

Pair your heater to Princess Home app

• Make sure your heater is powered.

• Open the Princess Home app.

• Select your country code, enter the cell phone number and tap

“Get” to get a message containing the verification code.

• Enter the verification code in the message and tap “Log in” to log

in to the App.

• Click "Add Device" to add a new device.

• Select the device you wanted to connect.

• Follow the instructions on the app to connect the heater.

How to set local time

• It is not possible to set time on the machine itself, it has to be set

in the app. Go to "My climate devices", choose the infrared

heater, then “Timezone”. On "Timezone" choose the right time

zone, then the machine will sync the same time as set on the

phone.

Technical Specification

Details 348035 348054 348070

Voltage 220-240V~ 220-240V~ 220-240V~

Frequency 50/60Hz 50/60Hz 50/60Hz

Power 350W 540W 700W

Wireless technology: Wi-Fi

Operating frequency: 2.4 GHz

Max. radio-frequency power: 20.5 dBm

CLEANING AND MAINTENANCE

• Before cleaning, unplug the appliance and wait for the appliance

to cool down.

• Clean the appliance with a damp cloth. Never use harsh and

abrasive cleaners, scouring pad or steel wool, which damages

the device.

Instruction manual

DECLARATION OF CONFORMITY

• Hereby, Smartwares Europe declares that the radio equipment

type 348035 / 348054 / 348070 are in compliance with Directive

2014/53/EU

• The full text of the EU declaration of conformity is available at the

following internet address: www.princesshome.eu/doc

ENVIRONMENT

This appliance should not be put into the domestic garbage at

the end of its durability, but must be offered at a central point for the

recycling of electric and electronic domestic appliances. This symbol

on the appliance, instruction manual and packaging puts your

attention to this important issue. The materials used in this appliance

can be recycled. By recycling of used domestic appliances you

contribute an important push to the protection of our environment. Ask

your local authorities for information regarding the point of

recollection.

Support

You can find all available information and spare parts at

www.princesshome.eu!

Gebruiksaanwijzing

VEILIGHEID

• Als u de veiligheidsinstructies negeert, kan

de fabrikant niet verantwoordelijk worden

gehouden voor de mogelijke schade.

• Als het netsnoer beschadigd is, moet het

worden vervangen door de fabrikant, de

onderhoudsmonteur van de fabrikant of door

personen met een soortgelijke kwalificatie

om gevaar te voorkomen.

• Verplaats het apparaat nooit door aan het

snoer te trekken en zorg dat het snoer niet

in de war kan raken.

• Het apparaat moet op een stabiele, vlakke

ondergrond worden geplaatst.

• De gebruiker mag het apparaat niet

onbeheerd achterlaten wanneer de stekker

zich in het stopcontact bevindt.

• Dit apparaat is uitsluitend voor huishoudelijk

gebruik en voor het doel waar het voor

bestemd is.

• Dit apparaat mag door kinderen van 8jaar

en ouder en personen met verminderde

lichamelijke, zintuiglijke of verstandelijke

capaciteiten of gebrek aan kennis worden

gebruikt, mits dit gebeurt onder toezicht of

zij de juiste instructies hebben gekregen

over het gebruik van het apparaat en de

gevaren van het gebruik begrijpen.

• Kinderen mogen niet spelen met het

apparaat.

• Het apparaat mag niet zonder toezicht

worden gereinigd of onderhouden door

kinderen.

• Kinderen van 3jaar en jonger moeten uit de

buurt van het apparaat worden gehouden,

tenzij er constant toezicht is.

• Kinderen van 3 tot 8jaar mogen het

apparaat alleen in- en uitschakelen als het

op de gewenste plek is geplaatst of

geïnstalleerd, mits dit gebeurt onder toezicht

of zij de juiste instructies hebben gekregen

over het veilige gebruik van het apparaat en

de gevaren van het gebruik begrijpen.

• Kinderen van 3 tot 8jaar mogen het

apparaat niet op een stopcontact aansluiten

of het apparaat bedienen, reinigen of

onderhouden.

• Dompel het snoer, de stekker of het

apparaat niet onder in water of andere

vloeistoffen om elektrische schokken te

voorkomen.

Gebruiksaanwijzing

• WAARSCHUWING: Sommige onderdelen

van dit product kunnen zeer heet worden en

brandwonden veroorzaken. Wees extra

voorzichtig als u het apparaat gebruikt in de

buurt van kinderen en kwetsbare personen.

• Gebruik de verwarmer niet in de directe

omgeving van een bad, douche of zwembad.

• Er dient niet in dwarsbalken, balken en

spanten te worden gesneden of gekerft om

het apparaat te installeren.

• Installeer het apparaat niet in de buurt van

gordijnen en andere brandbare materialen.

Dit kan brand veroorzaken.

• Het apparaat dient onder geen enkele

omstandigheden afgedekt te worden met

isolerend of soortgelijk materiaal.

• De verwarming dient niet direct onder een

stopcontact geplaatst te worden.

• Gebruik deze kachel niet nadat hij is

gevallen.

• WAARSCHUWING: Gebruik de heater niet

als de glazen panelen beschadigd zijn.

• Zet deze kachel op een horizontaal en

stabiel oppervlak of bevestig hem aan de

wand, voor zover van toepassing.

• WAARSCHUWING: Gebruik deze kachel

niet in kleine kamers waar zich personen

bevinden die niet in staat zijn de kamer

zelfstandig te verlaten, tenzij zij onder

voortdurend toezicht staan.

• WAARSCHUWING: Houd om de kans op

brand te verkleinen weefsels, gordijnen of

eventuele andere brandbare materialen op

een minimumafstand van 1m van de

luchtuitlaat.

• De kachel moet zodanig worden gemonteerd

dat de knoppen en andere

bedieningselementen niet vanuit het bad of

de douche bediend kunnen worden.

• WAARSCHUWING: Om oververhitting

te voorkomen, raden we u aan om het

apparaat niet te bedekken.

Dit product voldoet aan de conformiteitsvereisten van de

toepasselijke Europese regelgeving en richtlijnen.

Andere Handbücher für 350

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Princess Heizung Handbücher

Princess

Princess 01.348100.01.001 Bedienungsanleitung

Princess

Princess 341500/1 Bedienungsanleitung

Princess

Princess 01.348320.02.001 Bedienungsanleitung

Princess

Princess 347000 Bedienungsanleitung

Princess

Princess 01.348320.01.001 Bedienungsanleitung

Princess

Princess 01.348700.02.001 Bedienungsanleitung

Princess

Princess 01.348630.02.001 Bedienungsanleitung

Princess

Princess 01.341500.02.001 Bedienungsanleitung

Princess

Princess 350 Bedienungsanleitung

Princess

Princess 01.341000.02.001 Bedienungsanleitung

Beliebte Heizung Handbücher anderer Marken

oventrop

oventrop Regucor Series Bedienungsanleitung

Blaze King

Blaze King CLARITY CL2118.IPI.1 Bedienungsanleitung

ELMEKO

ELMEKO ML 150 Bedienungsanleitung

BN Thermic

BN Thermic 830T Bedienungsanleitung

KING

KING K Series Leitfaden

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Kurzanleitung

Well Straler

Well Straler RC-16B Bedienungsanleitung

EUROM

EUROM 333299 Bedienungsanleitung

Heylo

Heylo K 170 Bedienungsanleitung

Eterna

Eterna TR70W Bedienungsanleitung

Clarke

Clarke GRH15 Bedienungsanleitung

IRSAP

IRSAP The Radiator Company Ovali Bedienungsanleitung

Empire Heating Systems

Empire Heating Systems WCC65 Bedienungsanleitung

Wetekom

Wetekom 92 86 43 Bedienungsanleitung

Desa

Desa SPC170-F Bedienungsanleitung

Watlow

Watlow Watrod Electric Tubular Heaters Bedienungsanleitung

Haverland

Haverland ECO-DRY GPS Series Stücklistenhandbuch

Stelpro

Stelpro ASILVC2060 Series Bedienungsanleitung
