Pro's Kit MT-1706 Bedienungsanleitung

MT-1706

3-5/6 True-RMS Digital Multimeter

User’s Manual

1st Edition, 2018

1. General Information

This digital multimeter is designed and manufactured in compliance with

IEC-61010 safety requirements on electronic measuring instruments and

hand-held digital multi-meters. It is compliant with IEC-61010 requirements

pertaining to 600V CAT IV, 1000V CAT.Ⅲand requirements on pollution

degree 2. Please read carefully this operation manual and pay attention to

safety guidelines before operating this meter.

1.1 Safety information

1.1.1 Safety instructions

Before operating this meter, the operator must observe all standard safety

procedures in the two respects below:

A. Safety procedures against electric shock

B. Safety procedures against unintended use

To ensure your personal safety, please use the test lead that accompanies

the meter. Before operating this meter, ensure that the test lead is

flawless.

1.1.2 Safety considerations

When the meter is used in the vicinity of the equipment that produces

strong electromagnetic interferences, the reading on the meter will grow

unstable and even produce serious errors.

Don't operate the meter or pen-shaped meter whose appearance is

damaged.

The safety function of the meter will become null if the meter is not

properly operated.

The meter must be operated with great care when working in the vicinity

of an exposed conductor or bus line.

The meter is prohibited from being used in the vicinity of any explosive

gas, vapor or dust.

The measurement must be made with correct input terminals and

functions and within the allowable measuring range.

To prevent the meter from being damaged, the value to be input shall not

exceed the extremes allowed by each measuring range.

When the meter has already been connected to the line being measured,

the operator is prohibited from touching the input terminal that is not in

service.

When the voltage measured exceeds 60Vdc or 30Vac (valid value), the

operator shall be careful enough to avoid electric shock.

When making measurement with a test lead, place your fingers behind its

protective ring.

When switching to another measuring range, be sure that test lead has

already been taken off the measured circuit.

For all DC functions, to prevent potential electric shock as a result of

incorrect reading, please first useAC functions to check the absence of

any AV voltage. Then, select DC voltage measuring range equivalent to or

greater than that for AC voltage.

Before the tests on electric resistance, diode, capacitor or continuity, the

operator must cut off the power supply to the circuit to be measured, and

discharge all high-voltage capacitors within the circuit to be measured.

The electric resistance measurement or continuity test cannot be carried

out in any live electrical circuit.

Before the current measurement, the operator must first examine the

protective tube of the meter. Before connecting the meter to the circuit to

be measured, the operator must first power off the aforesaid circuit.

Before repairing TV sets or measuring power switching circuit, the

operator must be careful enough to prevent high amplitude voltage

impulse from damaging the meter.

This meter uses 4 x 1.5V AA batteries that must be correctly installed into

the battery compartment.

When appears, the batteries must be replaced immediately. The low

level of a battery will result in incorrect reading on the meter, which is

likely to bring electric shock or personal injury to the operator.

In measurement, category III voltage and category IV voltage shall not

exceed 1000V and 600V respectively.

Themetershallnot be in service ifits case(or partof itscase)is dismantled.

1.1.3 Safety symbol:

The safety symbols that appear on the meter's body and in this Operation

Manual:

Warning, an important safety symbol. The operator

must consult this Operation Manual before using the

meter. Unintended use may lead to the damage to

the device or its components.

AC (alternating current)

DC (direct current)

AC/DC

Ground

Double insulation protection

Fuse

High voltage warning

CAT.III1000V

over-voltage protection

CAT. IV 600 V

over-voltage protection

1.1.4 Maintenance practices for safety

The operator must first pull out the test lead when the meter's case is

opened or the battery cover is dismantled.

The designated replacement parts must be used at the moment of

maintenance.

The operator must cut off all relevant power supplies before opening the

meter. At the same time, the operator must avoid damage to the meter's

elements by ensure that he himself doesn't carry any static.

The meter can only be calibrated, repaired and maintained by

professionals.

When the meter's case is opened, the operator must understand the fact

that the presence of some capacitance may promise the dangerous

voltages even if the power supply to the meter is cut off.

The operator should stop using and maintain the meter immediately if any

abnormality has been observed on the meter. The operator must see to it

that the meter cannot be in service unless it is proved conforming.

When the meter is left idle for a long period, the operator shall remove the

battery and place it in a place free from high temperature and humidity.

1.2 Input protection measures

The meter can sustain the maximum input voltage of 1000V (DC) or 750V

(AC) at the moment of voltage measurement.

The meter can sustain the maximumAC voltage of 600V or equivalent

voltage (valid value) when the tests on frequency, electric resistance,

continuity and diode are carried out.

The protective tube (FF630mA/250V) is used for protection purpose when

A and mAcurrent measurements are carried out.

2. A Schematic Diagram for

the Meter

This meter is a hand-held digital

multi-meter with the function of

displaying True RMS. it is a

large-screen LCD unit with backlight

and illumination light functions so

that the user can easily recognize

reading. It is equipped with the

function of overload protection and

the indicator of battery under voltage.

Either for professionals, factories,

schools, enthusiasts or households,

it is an ideal multi-functional meter.

2.1 A Schematic Diagram for

the Meter

Physical appearance

①.Non-contact voltage detection area

②.Non-contact voltage indicator

③.LCD screen

④.hFE socket

⑤.Key

⑥.Rotary switch

⑦.Input socket

2.2 Description of the symbols on the display unit

Fig. 1 (Display panel)

Table.1 Symbols

Symbol

Description

Battery under voltage indicator/ Low Battery

To avoid electric shock or personal injury as a

result of incorrect reading, promptly replace the

battery when the battery under voltage indicator

appears.

Auto power off indicator

High voltage warning

Negative input polarity indicator

Input voltage AC

Input voltage DC

Continuity test mode

Diode test mode

Automatic range measurement mode

Data hold mode

℃，℉

Unit of temperature(℃: Celsius; ℉: Fahrenheit)

Duty ratio

NCV

Non-contact AC voltage detection mode

Live

Live line judgment mode

hFE

HFE test mode

Table.1 Symbols (Continued)

V, mV

mV：

V: the unit of volt

Millivolt，1x10-3 or 0.001 volt.

A, mA, A

mA:

A:

Ampere, the unit of current.

Milliampere, 1x10-3 or 0.001 ampere.

Microampere, 1x10-6 or 0.000001

ampere.

, k, M

:

k:

M:

Ohm, the unit of electric resistance.

Kilohm, 1000 Ohm

Megaohm, 1,000,000 ohm.

MkHz

Hz:

KHz:

MHz:

Hz, the unit of frequency

KHz, 1x103Hz.

MHz, 1x106Hz or 1000 KHz.

mF,F, nF

mF:

F:

nF:

Farad, the unit of capacitance.

Millifarad, 1x10-3 or 0.001 farad.

Microfarad, 1x10-6 or 0.000001 farad.

nF, 1x10-9 or 0.000000001 farad.

2.3 Description of functional keys

Key

Description of functions

SEL

SEL keys, e.g.

Temperature measurement position: ℃mode or ℉

mode.

Frequency measurement position: HZ measurement

mode or duty ratio (%) measurement mode

AC voltage position and AC current position: press

the key to select voltage/frequency mode or

current/frequency mode in the AC voltage

measurement mode orAC current measurement

mode.

HOLD

Press the key to hold the measured value for the

current moment Press the key again to cancel this

function.

Press the key for 2 seconds and more, the

backlight and the illumination indicator will be

on; however, with another 2-second press on

the same key, you will turn off backlight and

illumination indicator. If you don't press the key

at all, the function will automatically be

disenabled in 15 minutes.

2.4 Description of input socket

Input socket

Description

COM

All public input terminals to be measured are

connected to test leads in black or the public output

plugs of exclusive multi-function test sockets.

℃/℉

VHz%

lives

Positive input terminals (connected to a test lead in

red) for capacitor measurement, diode

measurement, beep on/off test, temperature

measurement, voltage measurement, electric

resistance, frequency, duty ratio and live/earth line

judgment.

A mA

A and mA positive input terminal (connected to a

test lead in red).

20A

20A positive input terminal (connected to a test lead

in red).

2.5 Accessories

1.Operation Manual

X 1

2. Test lead

X 1 pair

3.K-Type thermocouple

X 1

3. Operational guidelines

3.1 Normal operation

3.1.1 Hold mode

In the hold mode, the reading can be maintained on the display unit.

Changing the measurement function position or pressing the key.

Hold again to exit the hold mode

Hold mode: entry and exit

1. Press the key “H/ ” and the reading will be held and the symbol

“ ” will appear on the LCD screen.

2. Press the key “H/ ” again to restore the meter to its status for

normal measurement.

3.1.2 Backlight

The meter is equipped with the functions of backlight so that the operator

can access measurement results even if he is in a darker place. The

backlight function can be enabled or disenabled by the steps below:

1. Press the key" H/ " for over 2 seconds to enable backlight .

2. Press the key" H/ " for over 2 seconds to again to manually

disenable backlight; wait for 15 seconds until the backlight is

automatically disenabled.

3.1.3 Auto power off

If no operations are made in 15 minutes following the initialization, the meter

will sound to remind the operator to automatically cut off power supply and

enter the state of dormancy. The meter can be rebooted when the operator

presses any key in the auto power off mode.

3.2 Measurement guidelines

3.2.1 Measurement of AC voltage and DC voltage

To avoid any electric shock and/or damage to the meter, do

not attempt a voltage measurement if the voltage (valid

value) is 1,000V for DC current or 750V for AC current.

To avoid any electric shock and/or damage to the meter,

don't attempt to impose between any public terminal and

ground any voltage whose valid value is over 1,000V for DC

current or 750V for AC current.

The meter provides DC voltage measuring ranges as follows: 600.0mV,

6.000V, 60.00V, 600.0V and 1000V, and AC voltage measuring ranges:

6.000V, 60.00V, 600.0V and 750V.

Measurement of AC voltage or DC voltage

Turn the rotary switch to the position ～V or V.

Connect the test lead in black and test lead in red to COM input socket

and V input socket respectively.

Use another two ends of the test lead to measure the voltage of the

circuit to be measured. (In parallel connection with the circuit to be

measured)

Read the measured voltage value on LCD screen. When DC voltage

measurement is attempted, the display unit will show the voltage

polarity of the circuit connected to the pen-shaped meter in red.

Notes:

Within the measuring range of DC voltage of 600mV and AC voltage of

6V, even if there is no input or no connection to the test lead, the meter

will display some information. In this situation, press short circuit “V－

” and “COM” terminal to reset the meter to zero.

Within theAC voltage function, press the key "SEL" to measure the

frequency of theAC voltage source. Please refer to the relevant part for

frequency measurement.

The value of theAC voltage measured with this meter is True RMS (root

mean square). These measurements are accurate for sine wave and

other waves (without DC offset), square wave, triangular wave and step

wave.

3.2.2 Electric resistance measurement

To avoid the meter or the measured equipment from damage,

do not attempt a resistance measurement unless the operator

has already cut off all power sources for the circuit to be

measured and fully discharged all high-voltage capacitors.

Ohm is the unit of electric resistance ().

The measuring ranges of electric resistance of this meter are 600.0,

6.000k, 60.00k, 600.0k, 6.000Mand 60.00M,

Measurement of electric resistance

1. Turn the rotary switch to the appropriate position.

2. Connect the test lead in black and test lead in red to COM input

socket and V/input socket respectively.

3. Use another two ends of the test lead to measure the electric

resistance of the circuit to be measured.

4. Read the measured electric resistance value on LCD screen.

Notes:

The measured value of the electric resistance of the circuit differs a

bit from the rated value of the electric resistance.

To ensure measurement accuracy, in attempting a low resistance

measurement, first put two pen-shaped meters in short circuit and

capture the resistance reading of these short circuits. Then subtract

the aforesaid reading from the measured resistance.

At 60Mposition, you have to wait a few seconds before the reading

grow stable. This is quite normal for a high resistance

measurement.

When the meter is in open circuit, the display unit will show "OL" that

indicates the measured value is over the measuring range.

3.2.3 Diode test

To avoid the meter or the measured equipment from damage,

do not attempt a diode test unless the operator has already

cut off all power sources for the circuit to be measured and

fully discharged all high-voltage capacitors.

Diode test outside the circuit:

1. Turn the rotary switch to the position .

2. Connect the test leads in black and in red to COM input socket and

V/input socket respectively.

3. Connect the test leads in black and in red to the positive and

negative poles of the diode to be tested respectively.

4. The meter displays the forward bias value of the diode to be tested. If

Andere Pro's Kit Multimeter Handbücher

Pro's Kit

Pro's Kit MT-2017 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1220 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1236 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1820 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-2207 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1509-C Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1217 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1510 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-7602 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-2017N Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1708 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1270 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1210 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-2018 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-3109 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1707 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1509 Bedienungsanleitung

Pro's Kit

Pro's Kit mt-1232 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1630 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-5210 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-2018 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1820 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1508 Bedienungsanleitung

Pro's Kit

Pro's Kit MT-1132 Bedienungsanleitung

Beliebte Multimeter Handbücher anderer Marken

Agilent Technologies

Agilent Technologies 34420A Bedienungsanleitung

Fluke

Fluke 83 Bedienungsanleitung

Hameg

Hameg HM 8012 Bedienungsanleitung

Mastech

Mastech MY70 Bedienungsanleitung

Steren

Steren MUL-300 Bedienungsanleitung

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Bedienungsanleitung

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Bedienungsanleitung

PeakTech

PeakTech 4000 Gebrauchs- und Pflegehandbuch

YOKOGAWA

YOKOGAWA 90050B Bedienungsanleitung

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Bedienungsanleitung

Fluke

Fluke 8846A Bedienungs- und Wartungshandbuch

Tempo Communications

Tempo Communications MM200 Bedienungsanleitung

Elenco Electronics

Elenco Electronics CM-1555 Bedienungsanleitung

Mastech

Mastech MS8238C Bedienungsanleitung

SDAR

SDAR 830A, 830B, 830D, 830C Bedienungsanleitung

RS PRO

RS PRO RS-9519BT Bedienungsanleitung

BGS technic

BGS technic 8890 Bedienungsanleitung

Amprobe

Amprobe Hexagon 60 Bedienungsanleitung
