PROAIM Wave-2 Plus Bedienungsanleitung

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

10' Wave-2 Plus Telescopic Jib (P-WV-2PL)

Assembly Manua l

Wave plus jib arm Weight Bar

with Closer

Storage Bag

Camera Jib Setup

 Insert central fork of Jib arm into 100mm bowl of tripod stand, then aach boom clamp to it for

secure connecon.

NOTE: It is important to make sure that the Central Fork is seated in the bowl properly. That means

perpendicular to the tripod bowl. O axis installaon may hamper movement of the jib. Also you may need

the assistance of a grip stand to hold the camera end of the arm during installaon prevenng it from

falling as it will be front heavy at this point. You may also need the grip stand or assistance at the rear of

the jib when mounng the camera.

NOTE: Tripod Stand is Not Included.

 Unscrew the knob to extend jib arm at back and reghten the knob. Secure all the connecons.

 Insert weight rod into the jib arm. Now slide in weight to it as per your requirement and screw in

weight closer properly. (Counter weight Not Included)

 Loosen bolts of Jib bowl & remove adapter plate. Mount your uid head set-up onto bowl plate and

lock it with locking adapter. Now remove tripod plate from it.

 Aach tripod plate to your Camera and secure. Now mount your camera set-up onto uid head (Not

Included) and secure it with help of provided knob.

 LCD Mounng: Aach your LCD Mounng Arm to Jib Fork and ghten it properly to secure. Now

screw in LCD (Not Included) to arm and ghten its knob aer posioning the angle of LCD Arm.

Camera Mounng Setup

 Loosen the knobs of Jib arm to extend front telescopic post of Jib. Then extend Jib as per your

requirement and ghten all knobs to secure.

YOUR PROAIM 10’ WAVE-2 PLUS JIB ARM CRANE

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
