SKU#: 064-3155-2

Model: SP2315-IR-PHRM

23INCH LOGSET

ELECTRIC FIREPLACE HEATER

HOME OWNER’S INSTRUCTION MANUAL

SKU#: 064-3155-2

Model: SP2315-IR-PHRM

ATTENTION

FIND A LOCATION FOR THE FIREPLACE HEATER THAT IS PROTECTED FROM DIRECT

SUNLIGHT.

FAILURE TO READ ALL INSTRUCTIONS MAY RESULT IN A POSSIBLE ELECTRIC SHOCK, FIRE

HAZARD AND / OR INJURY WILL VOID THE WARRANTY

CONSUMER SAFETY INFORMATION

PLEASE READ THIS MANUAL BEFORE INSTALLING AND OPERATING THIS APPLIANCE

Warning

IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY AN ELECTRIC SHOCK

OR FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE

VICINITY OF THIS OR ANY OTHER APPLIANCE.

Thank you and congratulaons on your purchase of a Prokonian ﬁreplace. Please read

the installaon & operang instrucons before using this appliance.

Prokonian, Inc.

63 Golden Street

Meriden, CT 06450

U.S.A

Made in China

SAFETY INFORMATION

IMPORTANT INSTRUCTIONS

Please read and understand this enre manual before aempng to assemble, operate or install the product.

This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to part 15

of the FCC rules. These limits are designed to provide reasonable protecon against harmful interference in a

residenal installaon. The equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instrucons, may cause harmful interference to radio or television recepon,

which can be determined by turning the equipment oﬀ and on. The user is encouraged to try and correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separaon between the equipment and the receiver

• Connect the equipment into an outlet on a circuit diﬀerent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC rules. Operaon is subject to the following two condions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operaon.

Modiﬁcaons not approved by the party responsible for compliance could void user’s authority to operate the

equipment.

This Class B digital apparatus complies with Canadian ICES-003.

WARNING

When using electrical appliances, basic precauons should always be followed to reduce the risk of ﬁre, electric

shock and injury to persons, including the following:

• Read all instrucons before using this heater.

• To avoid injury from unexpected starng or electrical shock, DO NOT plug the power cord into a source of power

during unpacking and assembly. The cord must remain unplugged whenever you are adjusng / assembling the

item.

• If any part is missing or damaged, DO NOT aempt to use or plug in the power cord unl the missing or damaged

part is correctly replaced. To avoid electric shock, use only idencal replacement parts, and when servicing use

double-insulated tools.

• Whenever the item is le operang and unaended, extreme cauon is necessary if children or invalids are

nearby.

• Electrical outlet wiring must comply with local building codes and other applicable regulaons to

reduce the risk of ﬁre, electric shock and injury to persons.

• Disconnect power before aempng any maintenance or cleaning to reduce the risk of ﬁre, electrical shock or

personal injury.

• This appliance is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use

handles when moving this heater. Keep combusble material, such as furniture, pillows, bedding, papers, clothes

and curtains at least 3 feet from this appliance and keep them away the sides and rear.

SAFETY INFORMATION

• The appliance is not to be used by children or persons with reduced physical, sensory or mental capabilies, or

lack of experience and knowledge, unless they have been given supervision or instrucon.

• DO NOT run cord under carpeng. DO NOT cover cord with throw rugs, runners or similar coverings. DO NOT

route cord under furniture or appliances. Arrange cord away from traﬃc areas and where it will not be tripped

over.

• DO NOT insert or allow foreign objects to enter any venlaon or exhaust opening as this may cause an electric

shock or ﬁre, or damage the appliance.

• This appliance has hot and arcing or sparking parts inside. DO NOT use it in areas where gasoline, paint or

ﬂammable vapors or liquids are used or stored. This item should not be used as a drying rack for clothing.

Christmas stockings or decoraons should not be hung in the area of it.

• Use this appliance only as described in the manual. Any other use is NOT recommended by the manufacturer and

may cause ﬁre, electric shock or injury to persons.

CAUTION

• Cold climate installaon recommendaon: When installing this unit against a non-insulated exterior wall or

chase, it is mandatory the outer walls be insulated to conform to applicable insulaon codes.

• Make sure the power is turned oﬀ before proceeding with motor maintenance. Any electrical repairs or rewiring

of this unit should be carried out by a licensed electrician in accordance with naonal and local codes.

• If repairing or replacing any electrical component or wiring, the original wire roung, color coding and securing

locaons must be followed.

• DO NOT use this item if any part of it has been under water. Immediately call a qualiﬁed service technician to

inspect the item and replace any part of the electrical system.

• To prevent a possible ﬁre, DO NOT block air intakes or exhaust in any manner. DO NOT use on so surfaces, like

a bed, where openings may become blocked.

• Turn the power oﬀ when servicing this appliance. First turn the main power switch to the “OFF” posion. Then

remove the electrical plug from the wall outlet.

• If possible, ALWAYS unplug this appliance when not in use.

• DO NOT use outdoors.

• This item is not intended for use in bathrooms, laundry areas and similar indoor locaons. NEVER place heater

where it may fall into a bathtub or other water container.

• To disconnect this appliance, turn controls to the oﬀ posion, then remove plug from outlet.

• ONLY connect to properly grounded outlets.

• This appliance, when installed, must be electrically grounded in accordance with local codes, with the current

CSA C22.1 Canadian Electrical Code or follow U.S.A. Installaons, follow local codes and the Naonal Electrical

Code, ANSI/NFPA N0.70.

• There is a thermostat limiter inside the item. When the inner temperature overheats or abnormal heang

occurs, the thermostat protecve device would cut oﬀ power supply to prevent damage or risk of ﬁre.

• To prevent a possible ﬁre, DO NOT block air intakes or exhaust in any manner. DO NOT use on so surfaces, like

a bed, where opening may become blocked.

• The heaters MUST NOT be located immediately below a socket-outlet.

• Do not operate any heater with a damaged cord or plug or aer the heater malfuncons, has been dropped or

damaged in any manner. Discard heater, or return to authorized service facility for examinaon and/or repair.

• Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or relocatable power

tap (outlet/power strip).

SAFETY INFORMATION

Electrical Connecon

A 15-amp, 120-volt, 60 Hz circuit with a properly grounded outlet is

required. Preferably, the ﬁreplace will be on a dedicated circuit as other

appliances on the same circuit may cause the circuit breaker to trip or

the fuse to blow when the heater is in operaon. The unit comes

standard with 6-. three-wire cord, exing from the rear of the

ﬁreplace. DO NOT exceed the current rang of the current tap. ALWAYS

plug heaters directly into a wall outlet/receptacle. NEVER use with an

extension cord or relocatable power tap (outlet/power strip).

•

This heater is for use on 120 volts. The cord has a plug as shown

below. See illustraon for grounding instrucon. An adapter as shown

at C is available for connecng three-blade grounding type plugs to

two-slot receptacles. The green grounding lug extending from the

adapter must be connected to a permanent ground such as a properly

grounded outlet box. The adapter should not be used if a three-slot

grounded receptacle is available.

•

Voltage: 120 VAC, 60 Hz

Amps: 12.5 Amps

Was: 1500 Was

ELECTRICAL SPECIFICATIONS

Grounding Pin

Metal

Screw

Cover of

Grounding

Box

Grounding Pin

Grounding Means

Adapter

SAVE THESE INSTRUCTIONS

OPERATING INSTRUCTIONS

Power Switch

• Press this buon into the “I” posion for main power of the unit.

• Pressing the Heater buon to turn on or turn oﬀ the heater, when turn on the heater each me, heater

will be turn on at least one minute, when the ambient temperature is higher than the set temperature,

heat will turn oﬀ automacally.

Heater Buon

• To adjust the temperature to your individual requirements, turn the thermostat dial to the right

(clockwise) to increase the temperature and to the le to decrease the temperature. This thermostat

control dial can only be used while the power switch are in “I” posion and heater need turned on. When

the heater reaches the desired temperature, the heat will turn oﬀ. When the temperature dropped below

the selected temperature, heat will restart again.

Adjustable Thermal Control

• This buon controls the brightness of the ﬂame eﬀect with sengs at High, Medium and Low. When the

log set is ﬁrst turned on, the ﬂame will come on at the highest seng. Each me the Flame buon is

pressed, the brightness decreases. The only way to turn oﬀ the ﬂame eﬀect completely is to turn oﬀ the

Power switch.

Flame Buon

OPERATING INSTRUCTIONS

CARE AND MAINTENACE

• Make sure the unit is turned OFF, unplugged and the heang elements of heater are cool whenever you are

cleaning the heater.

• Clean the metal trim using a water-dampened so, clean cloth. DO NOT use brass polish or household cleaners

as these products will damage the metal trim.

• The motors used on the fan and the ﬂame generator assembly are pre-lubricated for extended bearing life and

require no further lubricaon. However, periodic cleaning/vacuuming of the fan/heater and air intake/output

vents is recommended.

• Any other servicing should be performed by an authorized service representave.

• Pressing the Heater buon to turn on or turn oﬀ the heater, when

turn on the heater each me, heater will be turn on at least one

minute, When the ambient temperature is higher than the set

temperature, heater will turn oﬀ automacally.

Heater Buon

• This buon controls the brightness of the ﬂame eﬀect with sengs

at High, Medium and Low. When the log set is ﬁrst turned on, the

ﬂame will come on at the highest seng. Each me the Flame

buon is pressed, the brightness decreases. The only way to turn oﬀ

the ﬂame eﬀect completely is to turn oﬀ the Power buon.

Flame Buon

• Press Standby buon to tuen on / turn oﬀ all funcon.

Standby Buon

Note: Remote control can

only be used while the

power switch are in “I”

posion.

Remote Control

WARNING: Make sure the power is turned oﬀ before proceeding. Any electrical repairs or rewiring of

this unit should be carried out by a licensed electrician in accordance with naonal and local codes.

If repairing or replacing and electrical component or wiring, the original wire roung, color coding and

securing locaons must be followed.

WARNING: Electrical outlet wiring must comply with local building codes and other applicable

regulaons to reduce the risk of ﬁre, electrical shock and injury to persons.

WARNING: Do not use this ﬁreplace if any part of it has been under water. Immediately call a qualiﬁed

service technician to inspect te ﬁreplace and replace any part of the electrical system.

WARNING: Disconnect power before aempng any maintenance or cleaning to reduce the risk of ﬁre,

electrical shock or personal injury.

WARNING: During any service of this appliance, the power to the unit must be turned oﬀ. First turn the

main power switch to the “OFF” posion. Then remove the electrical plug from the wall outlet.

CARE AND MAINTENACE

Replacing the Remote Control Battery

When the remote control stops operang or its range seems reduced, it is me to replace the baeries.

Note: The baeries should be removed if the product is to be le unused for a long me.

Caution: Non-rechargeable baery is not to be recharged. Exhausted baery is to be removed from the

product.

1. The baery compartment is located on the back end of the remote control.

2. Press the small tab inward as you slide the baery door open and remove the old baery.

3. Insert a new CR2025 lithium baery (not included), ensuring the polaries of the baery match the inside of

the baery compartment.

4. Re-insert the baery door.

Note: When the heater is not in use, the heater should be stored in a dry locaon, away from possible

damage. The power cord should be stored properly to avoid contact with hot or sharp objects.

Disposal of Used Battery

A baery may contain hazardous substances that could be endangering to

environment and human health.

• This symbol marked on the baery and/or packaging indicates that used baery shall

not be treated as municipal waste. Instead it shall be le at the appropriate collecon

point for recycling.

• By ensuring the used baery is disposed of correctly, you will help prevent potenal

negave consequences for the environment and human health. The recycling of

materials will help to conserve natural resources.

For more informaon about collecon and recycling of used baeries, please contact your local municipality, your

waste disposal service or the point of sale where you purchased this item.

TROUBLE SHOOTING GUIDE

PROBLEM POSSIBLE CAUSE SOLUTION

1. No power, logs

and ﬂame eﬀect do

not glow.

1. The unit does not have power. 1. Check that unit is plugged into a standard 120

volt outlet. Then make sure power is set at “ON”

posion.

2. The overheat protecon device has

been engaged.

2. Unplug unit, wait 5-10 minutes, then the

sensor will reset itself. Plug the unit back in and

turn on the heater. If the problem persists, call

customer service.

2. All funcon keys

are inacvated and

ﬂame ﬂashing.

3. Unplug unit, wait 5-10 minutes, then the

sensor will reset itself. Plug the unit back in and

turn on the heater. If the problem persists, call

customer service.

3. All funcon keys

are inacvated and

ﬂame lighted on but

do not glow.

3. The ambient temperature sensor is

broken or not working correctly.

4. Fan motor

connues to blow

aer unit is powered

oﬀ.

4. Normal operaon. 4. This is a standard feature; the blower runs for

an addional 20 seconds to ensure heat will not

be trapped inside the unit.

5. Power cord gets

warm to the touch.

5. Normal operaon. 5. This is normal for a heater appliance as it

requires more current to operate. Check the

connecons of the appliance cord and the outlet.

Make sure the plug ﬁts ghtly into the outlet.

During use, check the plug and outlet frequently

to determine if it is HOT; if so, disconnue use of

the appliance and consult with a qualiﬁed

electrician to check or change the overheang

outlet(s).

PROKONIAN ELECTRIC FIREPLACE MODEL

Prokonian Inc. (hereinaer referred to collecvely as the (“company”) warrants that your new Prokonian Electric

Fireplace is free from manufacturing and materials defects for a period of one year from date of purchase. Subject

to following condions and limitaons.

1. The electric ﬁreplace must be installed and operated at all mes in accordance with the installaon and

operang instrucon furnished with the product. Any unauthorized repair, alteraon, willful abuse, accident, or

misuse of the product shall nullify this warranty.

2. This warranty is non-transferable, and is made to the original owner, provided that the purchase was made

through an authorized supplier of the company.

3. The warranty is limited to the repair or replacement of part(s) found to be defecve in material or

workmanship, provided that such part(s) have been subjected to normal condions of use and service, aer said

defect is conﬁrmed by the company’s inspecon.

4. This warranty does not cover the LED light bar included with the Prokonian Electric Fireplace.

5. The Company may, at its discreon, fully discharge all obligaons with respect to this warranty by refunding the

wholesale price of the defecve part(s).

6. Any installaon, labor construcon, transportaon, or other related costs/expenses arising from defecve

part(s), repair, replacement, or Company assume responsibility for same.

7. The owner/user assumes all other risks. If any including the risk of any direct, indirect or consequenal loss or

damage arising out of the use. Or inability to use the product, except as provided by law.

8. All other warranes – expressed of implied – with respect to the product, its components and accessories, or

any obligaons / liabilies on the part of the Company are hereby expressly excluded.

9. The Company neither assumes, nor authorizes any third party to assume, on it behalf, any other liabilies with

respect to the sale of the Prokonian product.

10. The warranes as outlined within this document do not apply to non Prokonian accessories used in

conjuncon with the installaon of this product.

11. This warranty gives you speciﬁc legal rights, and you may also have other right which vary from state to state.

This warranty is void if:

a. The ﬁreplace is subjected to prolonged periods of dampness or condensaon.

b. Any unauthorized alteraon, willful abuse, accident, or misuse of the product.

c. You do not have the original receipt of purchase.

Contact the company, at serviceprokonian@jakeglobal.com or call +1-844-455-4621 have your warranty, your

sales receipt, locaon of purchase and the model / serial number of your Prokonian products.

Email: serviceprokonian@jakeglobal.com

Call: +1-844-455-4621

1 YEAR LIMITED WARRANTY

BASIC WARRANTY

IF WARRANTY SERVICE IS NEEDED

CUSTOMER SERVICE

Inhaltsverzeichnis

Sprachen:

Andere Prokonian Heizung Handbücher

Prokonian

Prokonian SPCT-500-P Bedienungsanleitung

Beliebte Heizung Handbücher anderer Marken

oventrop

oventrop Regucor Series Bedienungsanleitung

Blaze King

Blaze King CLARITY CL2118.IPI.1 Bedienungsanleitung

ELMEKO

ELMEKO ML 150 Bedienungsanleitung

BN Thermic

BN Thermic 830T Bedienungsanleitung

KING

KING K Series Leitfaden

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Kurzanleitung

Well Straler

Well Straler RC-16B Bedienungsanleitung

EUROM

EUROM 333299 Bedienungsanleitung

Heylo

Heylo K 170 Bedienungsanleitung

Eterna

Eterna TR70W Bedienungsanleitung

Clarke

Clarke GRH15 Bedienungsanleitung

IRSAP

IRSAP The Radiator Company Ovali Bedienungsanleitung

Empire Heating Systems

Empire Heating Systems WCC65 Bedienungsanleitung

Wetekom

Wetekom 92 86 43 Bedienungsanleitung

Desa

Desa SPC170-F Bedienungsanleitung

Watlow

Watlow Watrod Electric Tubular Heaters Bedienungsanleitung

Haverland

Haverland ECO-DRY GPS Series Stücklistenhandbuch

Stelpro

Stelpro ASILVC2060 Series Bedienungsanleitung
