PROMETHEUS PRO-1 Bedienungsanleitung
MULTI FUNCTIONAL KILN USER GUIDE
PRO-1
www.prometheushobby.com
This is the 3position switch of your kiln.
DISPLAY :only shows the temperature of your kiln.
HEATER :shows the temperature and HEATS the
kiln till reaches the target temperature.
OFF :turn offs the kiln.
PROGRAMMING KEYS
1) MODE
2) UP ARROW
3) DOWN ARROW
4) LEFT ARROW
For programming, take your switch to the Display
position.Press MODE key for 2seconds ,you’ll see
Su on the screen.Once you see Su, Press the “Left”
arrow button once;you will see adigit of the
Target Temperature start blinking.
1) 2) 3) 4)
Temperature inside the Firing Chamber
Target Temperature
You can leave it as it is or change it by pressing UP
and DOWN arrow keys.For changing the other digits
value, you can move the blinking digit by simply
pressing the LEFT arrow and adjust is as explained
before.When you have entered your target
temperature, just press MODE key for 2seconds and
your adjustment is completed.
1
This is the digital controller of you kiln.It shows you
the inner temperature of your kiln and the target
temperate.When it’s supplying energy to the
heating elements, the OUT led lights.
Now the upper line of your DC shows the current
temperature of your heating chamber. In the lower
line, it shows you the firing temperature that is set
for your kiln. Now your kiln is ready. Take the
switch to HEATER position and your kiln starts to
heat.
What is the function of the DISPLAY mode?
DISPLAY mode stops the heating of your kiln.In this
mode, you can see the current temperature inside
your firing chamber and your target temperature
and you can change your target temperature.To
start heating, you need to turn you switch to the
HEATER position.
To stop the heating process, take your switch to
the «OFF»position.The numbers on your DC will
disappear.
2
IMPORTANT INFORMATION
•If no action is taken for along time you’ll need to start
programing again by pressing to the MODE key.
•If you make amistake during any point of the programing, turn
your kiln off and on again to start over.
•Place your kiln on afire proof surface (ceramic, marble etc.)
with min.30 cm space in all sides.
•Use aheat resistant glove when loading and unloading your
kiln.
•When transporting, place your kiln back side down on the
vehicle.
