Provib Tech VS102 Bedienungsanleitung

VS102 Electronic Vibration Switch

ProvibTech Phone: +1-713-830-7601 Fax: +1-281-754-4972 pvt@provibtech.com , www.provibtech.com

VS102 Electronic Vibration Switch

User Manual

Installation, operation, maintenance

ProvibTech, Inc. 11011 Brooklet Drive, Suite 360, Houston, Texas 77099, USA

VS102-USR-A-10 COPY RIGHT PROVIBTECH 2008

VS102 Electronic Vibration Switch

ProvibTech

Table of Content

VS102 Electronic Vibration Switch - Introduction....................................................................................... 2

Specifications...................................................................................................................................... 2

Physical............................................................................................................................................... 2

System default setting......................................................................................................................... 2

VS102 System Installation ......................................................................................................................... 4

Installation - mechanical outline drawing............................................................................................ 4

Installation – hardware........................................................................................................................ 6

Installation – field-wiring diagram........................................................................................................ 7

VS102 Operation........................................................................................................................................ 8

VS102 display and status.................................................................................................................... 8

VS102 field controls............................................................................................................................ 8

VS102 zero and alarm set-point configuration................................................................................... 8

VS102 Maintenance................................................................................................................................. 10

Order Information.............................................................................................................................. 10

VS102 ZERO (4mA) calibration........................................................................................................ 12

Trouble shooting ............................................................................................................................... 14

VS102 Electronic Vibration Switch

ProvibTech

VS102 Electronic Vibration Switch - Introduction

The VS102 Electronic Vibration Switch is

designed to be the cost effective solution for

vibration switch applications. The VS102’s unique

and rugged design is suitable for harsh

environments and hazardous areas. It has a

universal mounting feature, relays or triacs, and a

4-20mA output.

Specifications

Sensor: internal piezoelectric accelerometer

Frequency Range: 2 to 1000 Hz

4-20mA Source Output: Non-linearity±1%. 600

ohms max. load resistance

Field wiring: Wire clamp type screw terminal

block. Max. wire gauge: 12-22

AWG. 500 Vrms, circuit to case

Buffered Dynamic signal:

Capable of driving 300 meters (1000

feet) of shielded cable (0.03uF max)

Alarms: Dual alarms

Dry-contact relay: 5A 230VAC/115VAC or

5A 30VDC

Triac: 5A 230VAC. Optically Isolated,

Standard NC

Temperature Limit:

-40℃to +85℃(-40℉to +185℉)

Power Supply:

95 - 250VAC@100mA, 50-60Hz, or

22 - 30VDC @ 200mA

Enclosure: Cast Aluminum (copper free)

Coating: Standard plastic coating for all cased

aluminum parts outside. Mounting

plate, mounting stud and local reset

are 304 stainless steel.

Environmental Rating: NEMA 4X, IP65

Hazard Rating: See order information

Physical

Temperature:

Operation: -40℃to +85℃(-40℉to +185℉)

Storage: -50℃to +120℃(-58℉to +248℉)

Dimensions:

See attached drawing

Weight:

1.4kg (3 lbs)

System default setting

9Channel Type: default is Acceleration

input, velocity output.

9Transducer type: internal piezoelectric

accelerometer

9Transducer location: internal

9Transducer sensitivity: default is 100mv/g

9ALERT time delay: default is 6S

9DANGER time delay: default is 6S

9System start up time delay: default is

30S*

9Full scale: default is 25mm/s

9Measurement type: default is RMS

9Measurement unit: default is mm/s

9Alarm type: (Alert; GAP). The default is

Alert

9Alarm latching**: NO local reset: default is

VS102 Electronic Vibration Switch

ProvibTech

non-latching. Local reset: default is

latching

9Alarm: dual dry contact relays; single dry

contract relays; dual TRIAC NO; dual

TRIAC NC; single TRIAC NO; single

TRIAC NC;. The default is dual dry

contact relays

9ALERT high: default is 12.5mm/s

9DANGER high: default is 18.75mm/s

9GAP high: default is 17.5V

9GAP low: default is -2V

*Output current is 3mAbefore power on delay

time.

**Latching: The alarm status of the vibration

switch does not change while the

measured variable goes below the alarm

setpoint after it has alarmed.

VS102 Electronic Vibration Switch

ProvibTech

VS102 System Installation

Installation - mechanical outline drawing

Supply

VS102 Electronic Vibration Switch

ProvibTech

Note: The default case has no local Reset.

VS102 Electronic Vibration Switch

ProvibTech

Installation – hardware

VS102 has two different mounting plates and two different mounting studs. See figuration below. Be

aware of that VS102 will sense the vibration in the vertical axis reference to the mounting plate.

VS102 Electronic Vibration Switch

ProvibTech

Installation – field-wiring diagram

Connector setting:

DANGER

BUF

J104J101

J102J105 J106 J107

OK ALERT

RESET/SET

Note: 1.Select Relay/Triac NO/Triac NC as per Alarm option

2. If single alarm is selected, Alert is valid only

Function description:

RST/BYP: Alarms reset / Bypass(When short circuit with COM, OK/TX/BYPASS LED turns red,

alarm status draws back). There are two types of bypass, hardware bypass and

software bypass. When hardware or software bypass is active, the Bypass LED

comes on. Both types of bypass do not take effect on monitoring except the alarm.

They are valid for both Alert alarm and GAP alarm. The default status is inactive.

Bypass has a higher privilege than alarm latch does.

COM: System ground

BUF: Buffered output

4-20mA: Transmitting of overall to up-level PLC/ DCS/monitor/computer

NC1: Alarm 1. Normally closed

ARM1: Alarm 1. Arm

NO1: Alarm1. Normally open

NC2: Alarm2. Normally closed

ARM2: Alarm 2. Arm

NO2: Alarm 2. Normally open

+24V: Power input (DC)

POW+/POW-:Power input(AC) Caution:

J101 for high voltage power supply and J107 for low voltage. Wrong setting will destroy the

switch!

VS102 Electronic Vibration Switch

ProvibTech

VS102 Operation

VS102 display and status

VS102 will have status indication:

9BUF: Buffered output.

9OK: green/red LED. Normally green. With not OK or no power supply, the LED is off. In bypass

mode, the LED is red.

9ALERT: yellow LED

9DANGER: red LED

VS102 field controls

9Reset: There are two ways to perform reset: 1. by pressing RESET/SET button; 2. by pressing

Local button; there is a lever on the instrument cover, whose being pressed will cause the alarm

reset. Note: It works only when the measured variable is less than the alarm set-point.

9Remote reset / Bypass: Brief short the RST/BYP pin to COM will reset the system. Continue

short the RST/BYP pin to COM will disable the alarms to realize bypass.

9Buffered output: a raw signal can be accessed by the BUF pin. There is 100 ohms output

impedance. The output can drive up to 300 meters (1000 ft) in distance between a condition

monitoring system and VS102.

9Alarms: User could select it as per category (Dual SPDT Relays Single SPDT Relay Single

SPST Triac, NO Dual SPST Triacs, NO Single SPST Triac, NC Dual SPST Triacs, NC）

9Power input: VS102 can be configured to work with either high voltage (95 to 250 VAC) or low

voltage (22 to 30 VDC).

VS102 zero and alarm set-point configuration

VS102 can be field configured with zero and alarms set-points.

9Power on

9Connect a ampere meter to the 4-20mA terminal

9Zero adjust: hold down RESET/SETET button for 10s, OK LED and Alert LED flash and the

instrument changes into 4mA calibration mode. Pressing + or – button to make the instrument

output a current of 4mA. Press RESET/SET button again, ALERT LED flash. Three seconds

later, press RESET/SET button again and DANGER LED flash. Three seconds later, press

RESET/SET button again and OK LED, ALERT LED and DANGER LED flash. At last, press

RESET/SET button to withdraw from zero calibration mode.

VS102 Electronic Vibration Switch

ProvibTech

9Adjust Alert: hold down RESET/SET button for 10s, OK LED and Alert LED flash. Press

RESET/SET button again, ALERT LED flash and it changes into Alert calibration mode. Three

seconds later, the ampere meter displays the last set alert set-point (default factory setting is

50% of full scale). Press + or – to adjust it to the desired value. Press RESET/SET button again,

DANGER LED flash. Three seconds later, press RESET/SET button and OK LED, ALERT LED

and DANGER LED flash. At last, press RESET/SET button to withdraw from Alert calibration

mode.

9Adjust Danger: hold down RESET/SET button for 10s, OK LED and Alert flash. Press

RESET/SET button again, ALERT LED flash. Three seconds later, press RESET/SET button

and DANGER LED flash and the instrument changes into Danger calibration mode. Three

seconds later, the ampere meter displays the last set DAGER set point (default factory setting is

75% of full scale). Press + or – to adjust it to desired value. Press RESET/SET button again OK

LED, ALERT LED and DANGER LED flash. At last, press RESET/SET button to withdraw from

Danger calibration mode.

FLASH LED 4mA Set Alert Set Danger Set End

OK 99

ALERT 999

DANGER 99
