Pulse Secure PSA300 Montageanleitung

PSA300 Hardware Guide

Puubblishheed Daatte September 2020

Document Revision 1.3

respective owners. All specifications are subject to change without notice.

Pulse Secure, LLC assumes no responsibility for any inaccuracies in this document. Pulse Secure, LLC reserves

the right to change, modify, transfer, or otherwise revise this publication without notice.

PSA300 Hardware Guide
© 2020 Pulse Secure, LLC. All rights reserved
3



Contents


Revision History ............................................................................................................................................................................................5
System Overview ............................................................................................................................. 6
Introduction...................................................................................................................................................................................................6
Power Button................................................................................................................................................................................................7
Reset Button..................................................................................................................................................................................................7
LED Functions...............................................................................................................................................................................................7
Air Flow Direction .........................................................................................................................................................................................8
Beeping and Alarms ...................................................................................................................................................................................8
Hardware Specifications................................................................................................................. 9
System Measurements ..............................................................................................................................................................................9
Power Rating.................................................................................................................................................................................................9
Power Consumption................................................................................................................................................................................ 10
Environmental Requirements ............................................................................................................................................................... 10
Component Specifications ..................................................................................................................................................................... 10
Regulatory Certifications ........................................................................................................................................................................ 11
Console and Initial Configuration ................................................................................................ 11
Connect Console and Network ............................................................................................................................................................ 11
Power on the PSA300 ............................................................................................................................................................................. 12
Configure Basic Settings......................................................................................................................................................................... 12
Change the Personality .......................................................................................................................................................................... 14
Access the Web Admin Interface ........................................................................................................................................................ 15
Licensing the System............................................................................................................................................................................... 16
Standard Warnings and Compliance............................................................................................. 17
About Standard Warnings ...................................................................................................................................................................... 17
Safety Certifications ................................................................................................................................................................................. 17
Electrical Safety.......................................................................................................................................................................................... 17
General Safety............................................................................................................................................................................................ 18
Installation Instructions ........................................................................................................................................................................... 22
Circuit Breaker ........................................................................................................................................................................................... 23
Power Disconnection Warning ............................................................................................................................................................. 24
Equipment Installation............................................................................................................................................................................. 26
Restricted Area .......................................................................................................................................................................................... 27
Redundant Power Supplies ................................................................................................................................................................... 29

PSA300 Hardware Guide

Backplane Voltage..................................................................................................................................................................................... 30

Comply with Local and National Electrical Codes............................................................................................................................ 31

Product Disposal ...................................................................................................................................................................................... 32

Hot Swap Fan Warning ........................................................................................................................................................................... 33

Power Cable and AC Adapter............................................................................................................................................................... 35

Certification Statements ......................................................................................................................................................................... 37

Japan .................................................................................................................................................................................................. 37

Israel .................................................................................................................................................................................................. 37

Saudi Arabia..................................................................................................................................................................................... 37

South Korea ..................................................................................................................................................................................... 37

Taiwan ............................................................................................................................................................................................... 37

Thailand............................................................................................................................................................................................. 38

PSA300 Hardware Guide

Revision History

Revision Number and Date

Description

1.3, September 2020

Updated the “Power Rating” and “Component

Specifications” sections.

1.2, September 2018

Added air flow direction details in the “Air Flow Direction”

section.

PSA300 Hardware Guide

System Overview

Introduction

The PSA300 is a compact, mini-ITX desktop embedded system.

Front view:

Power switch

Rear view:

External port

(EXT)

Internal port

(INT) Console

The front of the device includes a power on/off push-button, including an LED status light, and a reset button.

The rear has internal and external ports, console access, and a power connector.

Power connector

POWER

Reset

PSA300 Hardware Guide

Power Button

The main power button applies or removes power from the power supply to the server system. Turning off

system power with this button removes the main power but keeps standby power supplied to the system.

Therefore, you must unplug the system before servicing.

The power button features a backlit green LED that indicates power on.

Reset Button

Press the reset button for a hard reboot. It is located next to the power button.

LED Functions

Two LAN ports are located on the I/O backplane of the motherboard. Each Ethernet LAN port has two LEDs.

The yellow LED indicates activity, while the link LED may be green, amber, or off to indicate the speed of the

connections.

LED

Color

Description

Activity

Yellow (flashing)

Active

Link

Off

No connection

Amber

1 Gbps

Green

100 Mbps

PSA300 Hardware Guide

Air Flow Direction

The following table gives the air flow direction of the internal cooling fan.

Component

Air Flow Direction

Internal Cooling Fan

To the right of the unit

Beeping and Alarms

Beep Code

Description

5 short beeps + 1 long beep every 5 seconds

No memory detected in the system

Continuous beep

System overheat condition

PSA300 Hardware Guide

Hardware Specifications

This chapter describes the specifications and components of your system.

System Measurements

Category

Description

Form factor

Mini-ITX desktop

Width

7.68 inches (19.5 cm)

Height

1.75 inches (4.45 cm)

Depth

7.68 inches (19.5 cm)

Weight

2.5 lbs (1.13 kg)

Power Rating

Below is the maximum power rating for the AC to DC power brick:

Category

Description

Power type

Single-phase

Input voltage

100 - 240V

Output voltage

12 Vdc

Input current

2 Amps maximum

Output current

5 Amps

Input wattage

60W

Input frequency range

50 - 60Hz

Maximum output power

60W

PSA300 Hardware Guide

Power Consumption

This power consumption data is a worst-case scenario and is meant for reference only. The user’s system power

consumption may vary based on the workload and environment.

Device

Max

Pwr(W)

Actual

Pwr(W)

+12V

current (A)

+5V

current (A)

+3.3V

current (A)

+5VSB

current(A)

-12V

Current(A)

Server with Motherboard, Fan and

Storage drive

Total Power

37.1

Total Current

2.4

1.7

0.1

60W DC Power Adapter

Environmental Requirements

Category

Description

Operating temperature

0°C ~ 40°C (32°F ~ 104°F)

Storage temperature

(-20°C) - 60°C (-4°F –140°F)

Relative humidity (operating)

10% - 85% (non-condensing)

Relative humidity (storage)

10% - 95% (non-condensing)

Component Specifications

Category

Description

CPU

Intel Celeron J1900

Memory

8GB

Storage HDD

120GB SATA

Security module

1x TPM 1.2

Network ports

Dual port GbE LAN onboard

External I/O ports

1x console RJ-45 port

Cooling

1x fan with tachometer status monitoring

Equipped Cooling Fan

1 x FAN-0170L4

Estimated System Air Flow Rate at Cooling Fan

Full Speed Condition

3 ~ 4 CFM
