INSTALLATION INSTRUCTIONS
MODELS 600HS, 1200HS, 2000HS
PLUS “VCU WIRED REMOTE”
1200/2000HS “S”Housing
1200/2000HS “L”Housing
STEP1.
STEP2.
STEP3.
STEP4.
STEP5.
STEP6.
STEP7.
STEP8.
ASSEMBLY INSTRUCTIONS VCU
WIRED REMOTE VERSION
Unpack your unit and remove all packing from the blower and motor
assembly.
Remove both housing access doors.
VERY IMPORTANT NOTE! MAKE SURE THE BLOWER WHEEL SPINS
FREELY.
For 1200/2000 "S" version units skip to Step 8.
From the filter section, remove the wire framed pre-filter and carbon filter.
Locate the two HEPA filter holding strips that also act as a tray for the
carbon filter and pre-filter. Remove the two hex nuts and associated screws
on both holding trays and remove the trays from the housing.
Remove the hex head screws that are in the gasket material on the
BOTTOM (motor) section of your unit. The BOTTOM & TOP (filter)
sections are symmetrical, so they can be rotated 360 degrees so the
discharge can be pointed in four different directions to accommodate
any installation configuration. This allows for best directional location
for the TOP section filter access door. MAKE SURE THE DISCHARGE
DIRECTION IS CORRECT FOR YOUR APPLICATION BEFORE
ASSEMBLING. Align the sections as desired. Place the TOP section on
the BOTTOM section, align the holes and tighten the hex head screws.
Insert HEPA filter. BE CAREFUL TO NOT PUNCTURE THE HEPA MEDIA.
The gasket should be toward the motor unit. Center the gasket over the
knife-edges so that it is even on all four sides. Replace the two HEPA
holding trays.
Remove the wrapping from the carbon filter and slide the carbon filter and
pre-filter back into the trays and replace the access door.
IF YOU ARE USING YOUR SYSTEM AS A STAND ALONE, YOU MAY
SKIP TO ELECTRICAL WIRING SECTION.
Please look at the attached "typical installation" drawings. The inlet duct should be
connected to the main return air duct leading to the heating/cooling system, and the
discharge duct should be connected to the point where the return air duct enters the
heating/cooling fan area.
ALWAYS INSTALL THIS SYSTEM IN A BY-PASS CONFIGURATION.
1.)
2.)
3.)
4.)
5.)
6.)
7.)
MATERIALS NEEDED FOR COMMON HVAC INSTALLATIONS
Section of 12" (14" for 1200/2000 units) diameter sheet metal (recommended) or
flex duct. You will need 3' to 6' for most installations.
Section of 10" (14" for 1200/2000 units) diameter sheet metal (recommended) or
flex duct. You will need 6" to 24" for most installations.
12" collar (14" for 1200/2000 units) for connection to return air duct.
10" collar (14" for 1200/2000 units) for connection to fan return side of HVAC unit.
4" by 18" ( 4" by 24" for 1200/2000 units) piece of sheet metal for Air Scoop. Or a
prefabricated damper. This is recommended to be installed with every unit.
Sheet metal screws, duct tape or metal tape. 12 gauge electrical wire for power to
unit.
Thermostat wire.
INSTALLATION OF THE DUCTING
Select the proper location for the attachment of the inlet and discharge ducts. Try to
keep a minimum of 6 feet between the inlet and discharge openings. This will prevent
the Pure Air Systems’ filtration unit from recycling the same air. Cut the openings in the
existing return air duct. We recommend an air scoop be placed inside of the return air
duct so that it directs air into the inlet duct of your filtration system. You can use a
damper as an air scoop. Make sure the damper is angled to direct the air from the return
air duct into the inlet duct of your filtration system.
Use sheet metal screws, duct tape or aluminum tape to attach the duct sections to the
collars on the inlet of the unit and the air return. Make sure there are no air
leaks.Repeat this same procedure for the discharge duct. Make sure all
connections are tight and taped.
ELECTRICAL WIRING & POWER CONNECTION
***WIRING FROM 240 VOLT***
For 240 volt operation you will need to cut the "black jumper wire" that connects pin
1 to pin 2 on the 5 pin white power connector attached to the back end of the motor.
You will also need to insure the transformer is a 240V to 24V and 10VA.
FAILURE TO COMPLETE THIS WIRING CHANGE
WILL RESULT IN DAMAGE TO THE MOTOR.
NOTE: ALWAYS FOLLOW ELECTRICAL CODES FOR YOUR AREA. We recommend a
dedicated 15 amp service for all of our air filtration systems. The conduit connector is
designed for EMT conduit or Romex cable. Wire the black, white and green (ground)
wires through the conduit connector to the black, white and green wires inside the unit.
VCU CONTROLLER
The VCU digital speed controller will allow you to adjust the speed from 0 -100% in
1% increments. The LED display will show the speed in percent of air volume
capacity. If no other changes are made to the VCU controller after 20 seconds the
controller will blink with the speed shown and then switch to 0 if you are not using
the RPM feature. If you using RPM feature the LED display will blink after 20
seconds from speed to RPM. Always turn the power off at the lighted rocker on/off
switch when the unit is not in use. Turning the VCU controller to 0 will stop the
motor but will not turn off the power to the motor.
WIRED REMOTE
The VCU controller can be located in anylocation of your choosing within 150 feet of the unit.
Run low voltage, six wire, thermostat wire from the unit to where you are going to mount the
VCU controller. Then simply match up the wires to the terminal strip located in the unit with
the terminal strip located with the VCU controller
TESTING THE UNIT
To insure that the VCU controller is wired correctly, check that the controller is
illuminated. Turn on the lighted rocker switch on the unit. The VCU controller should
now be capable of adjusting the speed of the motor in the unit. If it does not, please
check that the wiring between the terminal strips is correct.
ODOR ADSORPTION MODELS
All Odor Adsorption models are identical to the regular models except there is no HEPA
filter. In-lieu of the HEPA filter there is a carbon cannister.
