Pyle PLVWR900 Bedienungsanleitung

INSTRUCTION MANUAL

PLVWR900

POWER

ON/OFF OPEN/CLOSE SEL

HD TFT LCD MONITOR

PLVWR900

9 INCH HIGHRESOLUTION TFT LCDMONITOR

WELCOME

Thank you forthe purchase ofthis monitor.Beforeoperating the unit,pleaseread this

manual thoroughly andretain it forfuture reference.

Precautions

Toprevent short-circuiting ofthe electrical systemand cause seriousdamage to the

unit or thevehicle, you areadvised to followthe instructions carefully.

Should there berequirement to replaceblown fuse,do rememberto disconnect all

power supply andswitched off theunit before replacingit with anew one.Use only

correct rating fuse toavoid damage the unit.

During operation,if there issymptom of over-heating orsystem mal-function,do switch

off the unitand consult yourdealer immediately.Pleasedo not attemptto open upthe

unit since thereis no serviceableparts inside.

To avoiddamaging the LCD paneland cause serious injuryto you or others,please

observe the followings:

Do not drop theLCD display panel ofsubject it to directimpact.

Should the LCDpanel is broken,doavoid all humancontact to thebroken glasses or

Fluid leaked outfrom the enclosure.Ifcome into contact,do flush andclean affected

areas with plentyof water.Seekmedical attention immediately.

This unit isdesigned using highquality electronic componentsand manufactured

under stringent qualitycontrol system.The systemunit will providemany hours of

quality performance ifuse correctly.Dofollow the maintenanceprocedure below:

The battery life ofthe remote control unitis about six monthslong.To ensureeffective

control,please replace thebatteries regularly.Donot use newand used batteriesat the

same time toavoid damaging the goodbattery.

Do not useany chemical solvent,cleaningagent or corrosivedetergent to cleanaway

dirt on thesurface of thescreen.By doing so,youmay cause irreversibledamage to the

surface of theTFT screen.To clean offdirt or fingerprints,we recommend theuse of a

soft damp lenscleaning cloth.

PRODUCT FEATURE

High resolution fullcolor TFT

Brand new LCDpanel

Easy installation,compact size

provides VCR/VCD/DVD/Game playersignal input

Two videoinputs

With remote control

on screen displaymenu

Auto power offif no signalfor 10 minutes

Low voltage autoalarm

FRONT PANEL

POWER

ON/OFF OPEN/CLOSE SEL

HD TFT LCDMONITOR

PLVWR900

1.neon light poweron/off

2.power indicator

3.open/close the monitor

4.negative adjustment

5.menu activate

6.positive adjustment

7.monitor power on/off

8.reset

1234567

A.The image will beshown 4 to 5seconds later

after press (7).

B.Press (1) for over4 seconds to turnthe neon off.

C.Reset to the factorydefault value by (8).

Note:Although the effectivepixels for theliquid crystal isgiven as 99.98%or more,

0.02% of pixelsmay not lightor may lightincorrectly.It isa very commonphenomenon

in active matrix displaytechnology,do notindicate fault or brokenof the unit.

REMOTE CONTROL

AV1/2 1.power on/off

2.V1/V2 switch

3.brightness -

4.brightness +

5.color -

7.color +

7.contrast -

8.contrast +

SPECIFICATION

Screen size 9inch(diagonal)

Display method TFTactive matrix system

Back light Coldcathode fluorescent lamp

System PAL& NTSC

Aspect ratio 16:9

Power source DC12V

Resolution 1024x532

Power consumption 10W

Max video input 1.0Vp-p

Input impedance 75Ohm

Dimension 24.2x15.7x3.2cm

WIRING

RED: DC 12V

BLACK:GND

YELLOW:V1 INPUT

WHITE: V2 INPUT

Pyle ,Inc

1600 63rdStreet

Brooklyn,NY11204

www.pyleaudio.com
