Pyle PRJG98 Bedienungsanleitung

PRJG98

User Manual

Portable Home Theater Projector

www.PyleUSA.com www.PyleUSA.com

• Do not try to open • Do not place

near water

• Clean with

a soft,dry cloth

• Don't cover the

lens or vents

• Place it in

horizontal position

• Place it in

ventilated places

• Don't clean

with chemical

• Disconnect

when not in use

• Don't look directly

to the light

IMPORTANT

PRJG98 Series Portable Home Theater Projector

This Guide includes all the feature operations and troubleshooting

necessary to install and operate your new PRJG98 Portable Home

Theater Projector.

Please review this manual thoroughly to ensure proper installation and

operation of this product.

Figures and illustrations in this User Manual are provided for reference

only and may differ from actual product appearance. Product design and

specifications may be changed without notice.

1 2

www.PyleUSA.com www.PyleUSA.com

PARTS

FRONT PANEL

REAR PANEL

Focus

Lens

Lens Cover

AV ( RCA )

Audio Out

USB in 1

USB in 2

HDMI

VGA

DC IN

Keystone Correction

Focus

HIGHLIGHTS

1. With this PRJG98 Portable Home theater Projector,you can

enjoy Movies,Sport,Videos,Pictures and more,like if you were

watching a 120 inches dynamic image.

2. Plug your DVD or Blu-ray in one of the two available HDMI

Digital inputs or send video from your computer via VGA port.

You can use the AV input to plug another video player.

3. You can connect your USB Memory to the projector for your

Multimedia Files.

4. The Portable home theater projector delivers clear images in low light

conditions; the audio can be played through the built in speaker, but if

you need more audio power output, you can connect an external

speaker or audio system using the 3.5mm connector.

It is very light weight and small size with respect to the home theater

projector market, it is different from other brands. LED light source

can be used above 30,000 hours life so you can carry on with the fun

everywhere.

Remote control included.

Note:

PRJG98 Projector uses long-life LED light source. It is the most suitable

for home theater market. Video playback should not be in bright light

environments. We do not recommend the projector for Word or spread-

sheet. This is not a professional education projector, video playback is the

main function.

CONTENT

Projector RCA Cable Power

Adapter Remote

Control User

Manual

3 4

www.PyleUSA.com www.PyleUSA.com

INSTRUCTIONS

CONNECTIONS

Before making any connections, turn off all the input sources

( Blu-Ray, PC, video, game console ) and the projector.

A) RCA ( AV ) Connection

use the 3.5mm cable to RCA ( included )

B) HDMI Connection

● The HDMI cable must not exceed the 10m length

HIGH PANEL

Source

Left Volume - Menu

Enter / OK

Down

Return Right Volume +

ON / OFF

5 6

www.PyleUSA.com www.PyleUSA.com

HOW TO USE

1. How to turn on the device

When turned on, the start menu will be shown

● This menu is only available for USB connection. Refer to the user

manual to know the mode of use

C) VGA ( PC ) Connection

D) USB Connection

E) Audio Connection

7 8

www.PyleUSA.com www.PyleUSA.com

3. Place the device into a stable surface and focus the image.

Turn the lens until the image is clear.

2. Selecting the Input source

Press the SOURCE button or press INPUT in the remote control and

select with the navigation keys the desired input source.

When turned on, the start menu will be shown

● Significant differences based on different versions. Different UI

have different "Input Source"

www.PyleUSA.com www.PyleUSA.com

9 10

4. Adjusting the volume using the portable projector. Some of the core product parameters will appear as icons as follows.

For different models, different parameters are expressed.

PRJG98

High Brightness Native 800x480

Physical Resolution

Short Distance

Projection 120 inch

Dynamic Image

Fully Enclosed

Smart Optical Engine

1080P/Full HD

Video Decode

Perfect PPT

Wireless Viewer

Based on the

Android OS

4Ω,3W

Stereo Speaker

Portable Small

Sizefor Home Theater

LED Light

Perfect Match

More than

30,000 Hours Life

Keystone

Correct Support

Using the remote control.

www.PyleUSA.com www.PyleUSA.com

11 12
