Pyle PADHUSB8 Bedienungsanleitung

ProAudioDigitalSpeakerTower

Surround Sound Bluetooth Speaker,

Full Range Stereo (400 Watt)

PADHUSB8

www.PyleUSA.com

WARNING!

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE THE COVER OF THIS UNIT.

THERE ARE NO USER - SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO A QUALIFIED TECHNICIAN.

The lighting ash with arrow head symbol within an equilateral triangle is

intended to alert the user to the presence of “dangerous” voltage within the

product’s enclosure that may be of sucient magnitude to constitute a risk

of Electric shock to humans. Users should exhibit extra safety when this

symbol appears in this instruction manual and follow all precautions as they

are stated.

The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance (servicing)

instructions in this manual.

SAFETY INSTRUCTION

1. Please read the user manual carefully before use and retain for future reference.

2. The power supply must match the demand of the device with reliable ground

wire.

3. All covering signal should be complied with the demand of device.

4. The device should be located far away from high temperature, moisture and

powerful electromagnetic eld.

5. Max operating temperature is 113°F.

6. No naked ame sources, such as lighted candles, shall be placed on the product.

7. Clean only with dry cloth – The appliance should be cleaned only as

recommended by the manufacturer.

8. When not in use, unplug the unit from the mains.

9. To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and

without distortion.

10. Only use suitable means of transportation if you want to move the speaker.

Note:

• Once the BLUETOOTH devices are paired, there is no need to pair them again.

• If the speaker is connected via Bluetooth device but does not play with sound,

please turn o nearby devices and only leave one device to re-connect with the

speaker.

• When inserting the USB/SD Card , make sure the direction you selected is correct.

Never insert violently to avoid damaging the USB/SD Card or the unit. If it doesn't

work, please check if the direction is correct.

• Turn oﬀ and pull out the USB/SD before turning oﬀ the speaker.

www.PyleUSA.com

CONTROL PANELS

1. LCD MP3 Player

SD port

USB port

A. Short press: Play/Pause

In USB mode, long press to track FOLDER

B. MODE: Press to switch between USB/ SD/ FM/BLUETOOTH

C. : Press to switch between RA (Repeat all)/RO(Repeat One)/RR(Repeat randomly)

D. : Short press: Switch Previous Song, Long press Voice DOWN

E. : Short press: Switch next Song, Long press Voice UP

F. : Digital Signal Processing

www.PyleUSA.com

2. DSP: Digital Signal Processing

MP3 Volume adjustment

3. Mic 1 and Mic 2 Volume control

4. 1/4 Connector for Mic 1 and Mic 2 input

5. XLR Line input

6. Line In Volume control

7. Volume control of total amplier

8. Power indicator

9. LED indicator of audio saturation

10. Volume control for Treble

11. Volume control for Bass

12. XLR Line Out to connect another active speaker

13. VOLTAGE SELECTOR for 110V and 220V

14. Power switch

15. AC input

www.PyleUSA.com

PADHUSB8

Pro Audio Digital Speaker Tower - Surround Sound Bluetooth Speaker, Full

Range Stereo (400 Watt)

Features:

• Pro Audio Surround Sound PA Speaker

• Next-Generation Digital Audio Processing

• Stage & Studio Tested Design

• Bluetooth Wireless Music Streaming

• Integrated Satellite Cylinder Speakers

• Sound System: 8’’Woofer, 2.5’’Tweeters (x4)

• Rear Panel Control Center with LCD Digital Display

• MP3 Digital Audio File Support

• USB Flash & SD Memory Card Readers

• (2) 1/4'' Microphone/Guitar Inputs

• XLR (3-Pin) Input/Output Connectors

• Connect & Stream Audio from External Devices

• Independent Channel Volume Controls

• Treble, Bass, Master Volume Conguration

• Perfect for On-Stage Performances, Crowd Control, Public Gathering Events

Bluetooth Wireless Streaming:

• Instantly Stream Music from Your Bluetooth Devices

• Works with All Your Favorite Bluetooth Devices

(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)

• Bluetooth Version: 4.0

• Bluetooth Network Name: 'PyleUSA’

• Bluetooth Wireless Range: 65'+ ft.

Technical Specs:

• Power Output: 400 Watt MAX

• Frequency Response: 50Hz-18kHz (±10dB)

• Sensitivity (1w/1m): 94dB

• Impedance: 4 Ohm

• Maximum SPL: 112Db

• Digital File Support: MP3, WMA, WAV

• Power Supply: 110/220V, Switchable

• Total Assembled Dimensions (L x W x H): 16.14” x 13.39” x 54.33” -inches

• Sold as: 1

What's in the Box:

• Speaker System

• Detachable Satellite Speakers

• Power Cable
