Please read this operating guide carefully before use and keep it for future reference.
If you have any questions, please feel free to contact our Customer Service department
IMPORTANT SAFETY INSTRUCTIONS
Please read these instructions carefully before using the Wireless TV Speaker.
• Always keep the system dry. Do not immerse in water.
• For your safety, do not attempt to open the unit or battery compartment. Attempting to open or opening the battery
compartment violates your warranty.
• The Wireless TV Speaker uses a lithium ion battery. Please observe the safety and handling instructions for the
lithium ion battery. Please dispose of the unit/used batteries properly, following any local regulations.
• Do not dispose of the unit/used batteries in the household trash. Do not incinerate.
Take the equipment to a nearby recycle center.
• Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord.
Unplug from outlet when not in use and before servicing or cleaning.
• Do not operate any device with a damaged cord or plug, or after the device malfunctions, or is dropped or damaged
in any manner. Return the device to the nearest authorized service facility for examination, repair or electrical or
mechanical adjustment.
• This device is intended for home and personal use only.
www.PyleUSA.com 3
Package Contents Features Identication
.
.
1 Wireless Receiver
(Speaker)
2 AC Adapter
1 Transmitter Base 1 Audio Cord
1 Digital Oprical Cord
* Remove plastic tip from Optical Cord plugs
1 Audio Switch Cable
Receiver
.
.
Wireless audio
transmission
mode indicator
light
ON/OFF &
volume control
Clock display
Low battery/
charging
indicator
Headset port
AC adapter jack
Audio input port
Pairing button
Reset key
Tone control
Base
AC adapter jack
Pairing
button
Optical input
Power
indicator
Audio input port
www.PyleUSA.com
4
Wireless audio transmission mode operation description
CONNECTION AND SET UP
Select an Audio Connection:
Locate the Audio Out connector on the back of your TV.
1. If your TV has an analog output connector
(see example 1), the inserted audio cable can be used
with the Wireless TV Speaker .
2. If your TV has a digital output connector
(see example 2), plug in an optical cable and it will
work with the Wireless TV Speaker.
For TV'S, with audio-output ports:
If your TV has a headphone jack, it's an analog output.
Connect the base of the Wireless TV Speaker to the TV
using the provided audio cable, as shown in the gure
below.
Note:
in most cases, the TV speaker volume will be muted
when using this type of connection.
www.PyleUSA.com 5
Wireless audio transmission mode operation description
For TVs with Audio-Out Ports (RCA Type)
If your TV has audio output RCA type ports on the back
of your TV, it is an analog output. Use the provided audio
cable and connect the base of the Wireless TV Speaker to
your TV as shown below.
PLEASE NOTE:
In most cases, TV speakers are NOT muted with this type
of connection.
For TV's with Digital Output port (optical):
If your TV has a digital optical audio output port , using
the included optical cable, connect it to the base of the
Wireless TV Speaker as showen below. In most cases,
TV speakers are NOT muted with this type of connection.
PLEASE NOTE:
Newer TV'S have the option to set digital audio output to
either DOlby or PCM. The Wireless TV Speaker only works
with PCM audio format, simply set your TV to PCM
digital output.
Contact your TV manufacturer for assistance if necessary.
www.PyleUSA.com
6
Wireless audio transmission mode operation description
Placement of Transmitter Base
For best results, place the Transmitter Base on top of
your TV stand, or on top of your TV, as shown below.
Battery Charging
Place the receiver on the base (as shown) for charging for
6+ hours before rst use. During charging, the Low
Battery/Charge indicator blinks. When it is fully charged,
the indicator light will stop blinking and stay steadily lit.
A fully charged battery will give you up to 8 hours of
listening time.
When the receiver is not in use or when the Low Battery
indicator blinks, place the receiver on the base for
recharging.
.
.
www.PyleUSA.com 7
Wireless audio transmission mode operation description
OPERATION
ON/OFF, Volume and Tone Control
1. Rotate the switch knob to turn the receiver on or off
and adjust its volume, and rotate the mode switch to
switch to 2.4G mode. At this time, the wireless audio
transmission status indicator light is on.
2. You can turn your TV speaker to Low or to Off. On some
TVs, you may need to use your remote to go into the TV's
Menu to achieve an optimal audio/speaker setting.
Please refer to your TV user manual for details.
3. To conserve battery power, the receiver will shift into
standby mode if no audio signal is received from the
base (after your TV is turned off) for a period longer
than three minutes. The volume ON/OFF indicator will
be off during this standby time. When audio signal is
received, the receiver will re-activate.
NOTE: If the receiver has hibernated too long and missed
the contacts with the base, rotate the knob, turn off the
receiver and then turn the receiver back on again to
re-sync with the base.
4. Set the Tone Control to a position that enables you to
hear and understand the dialog best.
Pairing Additional Receivers
You can add up to 50 receivers to work with your base.
Each added receiver, must be "paired" with the base as
follows:
• Make sure your new receiver is fully charged.
• Make sure your current base and receiver is working
properly and audio is playing on the receiver.
• Continue the audio playing to the base and receiver.
.
.
ON/OFF & Volume Tone Adjustment
www.PyleUSA.com
8
Wireless audio transmission mode operation description
Pairing Additional Receivers (continued)
1. Turn the new receiver ON.
2. Press and hold (about 5 seconds) the PAIRING button
on the bottom of the receiver until the ON/OFF indicator
starts blinking. Pairing period is approximately 20
seconds.
3. Press and hold (about 3 seconds) the PAIRING button
on the back of the base until the power indicator starts
blinking. It will start pairing with the new receiver.
4. As soon as pairing is successful (less than 2 seconds),
the new receiver's ON/OFF indicator will stop blinking,
and audio sounds will be played within 5 seconds.
5. Repeat these steps again if pairing is not successful.
Using Headphones
Plug your headphones into the headphone jack as shown.
No sound will be emitted from the speakers. Adjust the
headphone volume by rotating the volume knob.
Bottom of receiver
(Speaker)
Back of transmitter
(Base)
www.PyleUSA.com 9
Wireless audio transmission mode operation description
HOUR
Short press to add the number of hour slowly
Press and hold to add the number of hour rapidly
RUN: Regular working when the Key is on the "RUN" side
CLOCK: Push the Key to "CLOCK" side to make clock setting
MINUTE
Short press to add the number of minute slowly
Press and hold to add the number of minute rapidly
OFF: Don't display the time
ON: Display the time
www.PyleUSA.com
10
TROUBLESHOOTING
• No sound from the receiver
Check all connections to ensure that all the cords are
rmly connected at the back of the base and TV. Also,
conrm that the receiver is not more than 100 feet away
from the base.
• There is sound from the TV speaker, but no sound
from the receiver
Check your TV speaker setting by going into the TV Menu,
using your TV remote and ensuring the TV is sending
audio signals to the base.
• The Low Battery/Charging indicator keeps blinking
on the receiver
This indicates that the battery is low and needs to be
placed on the base for recharging. When fully charged,
the blinking will stop (in about 3 hours). If the blinking
does not stop, check to make sure the receiver is rmly
connected and properly aligned to the base.
CLEANING AND MAINTENANCE
Unplug the AC Adapter from the wall. Then, use a dry,
soft cloth to clean and dust the outside surfaces and the
charging contacts on the Base. Do not immerse the
Receiver in water.
FCC INFORMATION (FOR U.S. CUSTOMERS ONLY)
PART 15 OF FCC RULES INFORMATION
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation. This equipment has been tested and found to
comply with the limits of a Class B digital device, pursuant
to Part 15 of FCC rules. These limits are designed to provide
reasonable protection against harmful interference in
residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on, you
may try one the following methods to correct the
interference:
1. Where it can be done safely, re-orient the receiving
television or radio antenna.
2. To the extent possible, relocate the television, radio, or
other receiver, with respect to the cordless phone.
