Qazqa 44083 Bedienungsanleitung

Dark WL I PIR LED Solar

MODEL: 44083

INTRODUCTION

The Light works with a build-in PIR (Passive Infra Red) sensing device

which is connuously scanning for heat-source moving in its detec-

on scope. Once a heat-source (such as a human or a car) is detected

in that area, the light switches on immediately and automacally to

illuminate your pathways, steps, paos, porches, or anywhere you

select for safety, convenience or security. The light remains on while

heat-source moving stays in the detecng scope.

■INSTALLATION SUGGESTIONS

For best detecng eﬀect of PIR, we suggest you take the following

points into account:

● Ideally, for maximum detecon range, the Light should be moun-

ted 1.8 to 2.5 meters (6 to 8 ) above the area to be scanned

(refer to Fig.1A).

● To avoid damage to some components, please do not aim the

sensor towards the sun.

● To avoid annoying unexpected triggering, the sensor should stay

away from heat sources such as barbecues, Air-condioners, other

outside lighng, moving cars and ﬂue vents.

● To avoid annoying unexpected triggering, please keep the sensor

away from strong electromagnec disturbance source.

● Do not aim the sensor at reﬂecve surfaces such as smooth white

walls, swimming pools, etc...

● The PIR sensor’s detecon range (about 7 meters at 100°round)

may vary slightly depending on the mounng height and locaon.

The detecon range may also alter with environment temperature

change.

● Before select a place to install, please note that sensor is more

sensive to movement across the scan area than to movement

directly toward or away from the sensor (refer Fig.1B). If heat

Side View

Front View

100°

4.5 M

0.7 M 7 M

2 M

Fig 1( A )

Detection Range

153 mm

157 mm

109 mm

INSTALLATION STEPS

1．Drill two holes on wall where you want the light be mounted on

and put the plasc plugs into wall holes. Then Mount the mount

plate by screws (refer to Fig 2 A)

2．Fix the light on the wall plate and lock it by turning the key.

Remove the key and keep it for future use. (refer to Fig 2 A)

OPERATION

1. Mount the light on place where it can get max. DIRECT SUNLIGHT

in dayme. The inside baeries are charged by solar cell. The

more direct sunlight solar cell receives in dayme, the longer the

light will run. It is beer to charge the solar cell in sunlight for up

to one day before switching on it, so that the light can work with a

full charge.

2. Modes of slide switch:

AUTO: Normal work automacally

ON: Constantly light on as emergency lamp

OFF: Power oﬀ for storage and long me charging

source moves directly towards to or away from the sensor and not

across, the detecon range will be relavely reduced (refer to

Fig.1C) .

Fig 1( C )Fig 1( B )

Good Detecting Not Good Detecting

TECHNICAL DETAILS:

Baery: 3 pieces of AA 1.2V-600mAh baeries

Waage: 2×0.5 W LED, stac ≤0.64 mW

Voltage: 3.6V DC

Duraon me: 60±10 sec.

Detecon range: 100º (round) , Max. 7 meters

Weatherproof: IP44

FEATURE

1. While light is turn on for the ﬁrst me, LED light on and PIR start

warming up. Then, LEDs stay on for 40 sec., then ﬂash for 3 mes

and shi to detecon mode.

2. At night, LEDs will remain on for 60 seconds since the last move-

ment is detected. If a movement is detected during the light-on

me, duraon me will be renewed and LEDs remain ON for

another 60 seconds.

3. In daylight or bright environment, PIR’s Lux control works, move-

ment does not acvate the PIR.

Trouble shoong and user hints

Note: all PIR sensors in dry and cold environment are more sensive

than that in wet and heat environment.

PROBLEM POSSIBLE CAUSE

SUGGESTED

REMEDY

Light does not switch

on when there is

movement in the

detection area.

1. Batteries are used out

Recharge batteries

2. Nearby lighting is too bright.

Re-direct sensor or

relocate the unit

3. Sensor towards wrong direction

Re-direct the PIR

Light switches on for no

apparent reason

(false trigger)

1. Heat sources such as aircon, vents, heater flues,

barbecues, other outside lighting, moving cars are

activating the sensor.

Place it away from

these sources.

2. Animals/birds e.g. possums or domestic animals.

Redirecting light may

help.

3. Reflection from swimming pool, or reflective surface.

Re-directing light

Light switches on

during daytime

Something shadowthe Lens of PIR Sensor

Redirecting light
