LM-350 Warranty
The LM-350 has been thoroughly tested and is guaranteed for a period of 12 months from the date of
delivery. Under the terms of this guarantee all components which are proven defective within the
warranty period will be repaired or replaced free of charge. Our technical assistance service is the
sole authority in determining whether or not defects come under the coverage of the guarantee. The
guarantee excludes all responsibility on the part of the Quality Stainless Products for direct or
indirect loss or damage to persons or things deriving from incorrect operation or servicing of the
product. The guarantee is limited to defects in materials, workmanship and assembly, and excludes
all components subject to normal wear. Furthermore, the guarantee excludes return shipping of
defective part to QSP. We will however ship the replacement part by standard ground service at no
charge.
Parts Department 888-473-5378
TYPE: Tire and Wheel lift
MODEL: LM-350
_________________________________________________________________________________
OPERATION INSTRUCTIONS
Removing the Tire and Wheel Assembly from a vehicle using The LM-350
1. Attach air to LM-350
2. Position LM-350 under tire and wheel on the vehicle and raise roller carriage by operating
the raise/lower control. (Valve is variable speed. The more you move the toggle control in the
upward or downward direction the faster the carriage will move)
3. Once the rollers have made contact with the bottom of the tire, slowly release the toggle
valve.
4. Pull the top of the tire toward you and disengage wheel from the vehicle.
5. With the tire on the rollers back the lift away from the vehicle and lower.
6. Remove the tire and wheel assembly from the LM-350
Installing the Tire and Wheel Assembly on a vehicle using the LM-350
1. Position the tire and wheel assembly on the LM-350 rollers
2. Raise the tire to close to spindle height.
3. Rotate the tire and wheel to align lug studs to the wheel.
4. Slowly raise or lower to exact position and push the top of the tire and wheel assembly
forward to engage the stud and lug nut holes.
5. Install lug nuts and lower tire and wheel lift.
