QuadBoss QBRT12544 Bedienungsanleitung

44” ROUGH CUT

TRAIL CUTTER

OWNER’S

MANUAL

SWISHER MOWER, 1602 CORPORATE DRIVE, P.O. BOX 67,

WARRENSBURG, MISSOURI 64093

PHONE (660) 747-8183 FAX (660) 747-8650

Manufacturing quality lawn care equipment since 1945

Assembly

Operation

Service and Adjustment

Repair Parts

Made In The

USA

MODEL NO.

STARTING SERIAL #:

L109-243001

QBRT12544

QBRT14544

17341 Rev 09-233

Important:

Read and follow all Safety

Precautions and instructions

before operating this

equipment

In the event you have a claim under this warranty, you must return the product to an authorized

service dealer. All transportation charges, damage, or loss incurred during transportation of parts

submitted for replacement or repair under this warranty shall be borne by the purchaser. Should you

have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The

model number, serial number, date of purchase, and the name of the authorized Swisher dealer from

whom you purchased the mower will be needed before any warranty claim can be processed.

THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL

DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME

PERIODS STATED HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not

allow the limitation of consequential damages or limitations on how long an implied warranty may

last, so the above limitations or exclusions may not apply to you. This warranty gives you specific

legal rights and you may have other rights, which vary from state-to-state. This is a limited warranty

as defined by the Magnuson-Moss Act of 1975.

LIMITED WARRANTY

The manufacturer’s warranty to the original consumer purchaser is: This product is free from defects

in materials and workmanship for a period of one (1) year from the date of purchase by the original

consumer purchaser. We will repair or replace, at our discretion, parts found to be defective due to

materials or workmanship. This warranty is subject to the following limitations and exclusions:

TABLE OF CONTENTS

WARRANTY………………....….2

INTRODUCTION………………..3

SAFETY..……………………….3-4

ASSEMBLY………………..…….4

OPERATION……………………5-8

CUTTER MAINTENANCE..…….…..8

TROUBLESHOOTING………………9

DECALS…..………….………………10

PARTS BREAKDOWN……………11-18

1) Engine Warranty All engines utilized on our products have a separate warranty extended

to them by the individual engine manufacturer. Any engine service

difficulty is the responsibility of the engine manufacturer and in no

way is Swisher Mower Co., Inc. or its agents responsible for the engine

warranty. The Briggs & Stratton Engine Service Hot-Line is 1-800-

233-3723. The Tecumseh Engine Service Hot-Line is 1-800-558-5402.

The Honda Engine Service Hot-Line is 1-800-426-7701.

2) Commercial Use This product is not intended for commercial use and carries no

commercial warranty.

3) Limitation This warranty applies only to products which have been properly

assembled, adjusted, and operated in accordance with the instructions

contained within this manual. This warranty does not apply to any

product of Swisher Mower Co., Inc., that has been subject to alteration,

misuse, abuse, improper assembly or installation, shipping damage, or

to normal wear of product.

4) Exclusions Excluded from this warranty are normal wear, normal adjustments, and

normal maintenance.

SAFETY PRECAUTIONS

This Safety Alert Symbol indicates important messages in this

manual. When you see this symbol, carefully read the message that

follows and be alert to the possibility of personal injury.

Read this manual completely. This machine can amputate hands and feet, and

throw objects. Failure to observe the following safety instructions could result in

serious injury or death.

Thank you for choosing Swisher’s 44 ‘’ Trailcutter. Before operating

your cutter, please read, understand and follow all of the safety precautions

and other instructions explained in this manual . As with all power

equipment, lawn mowers,and cutters can be potentially dangerous if

improperly used.

• Read the manual. Learn to operate this machine safely.

• Always disconnect the spark plug wire and place the wire where it cannot contact the

spark plug, to prevent accidental starting the engine when setting up, transporting,

adjusting or making repairs.

• Keep all shields and guards in place.

• Understand the speed, steering and stability of this machine. Know the positions and

operations of all controls before you operate this machine. Check all of the controls in

a safe area before starting to work with this machine.

• Allow only responsible adults who are familiar with these instructions to operate this

machine. Never allow children to operate this machine.

• Clear the area of objects such as rocks, toys, wire, etc. that can be picked up and

thrown by the blade.

• Be sure the area is clear of other people before mowing. Be aware of the cutters

discharge direction and do not point at anyone. Stop the machine if anyone enters the

cutting area. Children are often attracted to the machine and the mowing activity.

Never assume that children will remain where you last saw them. Keep children

under the watchful care of another responsible adult.

•No riders!

• Do not put hands or feet near or under rotating parts.

• Do not mow in reverse. Always look down and behind before and during backing.

• Turn off the blades when not cutting. Before leaving the machine, turn off the blades

and stop the engine.

• Watch for traffic when operating near or crossing roadways.

• Do not operate the cutter if it has been dropped or damaged in any manner or if the

mower vibrates excessively. Excessive vibration is an indication of damage.

Repair cutter as necessary.

• Dress properly. Do not operate the cutter when barefoot or wearing open sandals.

Wear only solid shoes with good traction when cutting.

• Never allow operation by untrained persons.

• Do not operate the machine while under the influence of alcohol or drugs.

• Do not operate on slopes greater than 15 degrees.

• Never tamper with safety devices. Check their proper operation regularly.

• Stop and inspect the equipment if you strike an object. Repair, if necessary, before

restarting. Never make adjustments or repairs with the engine running.

• Cutter blades are sharp and can cut. Wrap the blades or wear gloves, and use extra

caution when servicing them. Do not operate at too fast a rate.

• Return lever to its vertical position to disengage blades.

• The braking system is applied when the blades become disengaged. It is designed to

bring the blades to a quick stop (approximately 7 seconds). Each Trailcutter brake

system has been tested and calibrated. For safety, the consumer should not alter the

braking system.

• Disengage spark plug wire and place where it cannot make a connection.

• Refer to Figure 2 p.11. Attach hitch assembly parts to front of mower . Insert 3/8-16 X 2 ½

through

plate and attach 3/8-16 nut to the bottom. Tighten nut tight until tube is clamped then back off ½

turn to

allow tube to pivot.

• The L hitch can be adjusted up or down to level the deck from front to back

• Check engine oil. All engines are filled with oil at the factory. Verify oil level and

add if necessary before starting engine. (See Engine Owner’s Manual)

• Verify fuel level and add if necessary before starting engine.

• Check the battery (if so equipped). If battery is put into service after the “month & year” of the

date on the battery, then it may need to be charged with a 12 volt battery charger for a minimum

of 1 hour, but no more than 2 hours at a rate of 6 to 10 amps.

• Attach battery cable(s) to battery. ( if so equipped ) Red

wire to positive (FIRST) and black wire to

negative (SECOND).

• Reconnect spark plug wire.

• (Refer to Owner’s Manual p. 5) For proper operating procedures.

ASSEMBLY

OPERATING YOUR TRAILCUTTER

The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye

damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before staring any

cutting machine and while operating such a machine.

The operation of any cutter produces sound waves that are damaging to the human ear. Ear protection is

recommended.

CAUTION! Tragic accidents can occur if the operator is not alert to the presence of children.

Children are often attracted to the machine and the mowing activity. Never assume that children will

remain where you last saw them.

INTENDED USE

The 44” Rugged Cut Trailcutter is designed to clear dense areas of grass and cut saplings up to 1-

1/2 inch thick on meadows and small estates. It is not intended to create a finish cut on

lawns.Your Trailcutter should be towed behind an ATV, golf cart, lawn tractor or other approved

vehicle. It is not recommended for speeds exceeding 5 MPH.

ATTACHING TRAILCUTTER TO TOW VEHICLE

• Back vehicle up to desired towing position.

• Offset the Trail Cutter to the side opposite the tow vehicle discharge (if any).

This prevents the tow vehicle from throwing grass into Trailcutter engine.

• Bolt swivel hitch (H10) to tow vehicle receiver. If tow vehicle has a ball

hitch, the ball must be removed before swivel hitch can be fastened.

• Attach tow hitch and the “L” hitch (10388TK & H1) to the swivel hitch.

The hitch pin (H11) should go completely through both the swivel and “L”

hitches and clipped to prevent accidental separation. Check that all hardware

is secure at both the tow vehicle and the Trailcutter.

TRANSPORTING CUTTER

• Stop Trailcutter.

• Place Trailcutter deck in its highest position.

• When transporting unattached from tow vehicle, remove spark plug wire and

place it where it cannot contact the spark plug.

STOPPING THE ENGINE

•Make sure the tow vehicle parking brake is set

•Disengage cutting Blades

•Reduce engine to idle speed and allow engine to run momentarily for cooling

•Turn the key to the off position

ENGAGING BLADES

Note: Do not attempt to start the unit with the T-handle console in the ‘’ ENGAGED ’’ position.

• Engage blades by pulling down the T-handle lever into the horizontal position.

• Return lever to the vertical position to disengage blades. See detail on page 16 figure – 8

•The braking system is applied when the blades become disengaged. It is designed to bring the blades

to a quick stop ( approximately 7 seconds. ) Each TrailCutter brake system has been tested

for safety , the consumer should not alter any part of the brake system.

BREAKING IN YOUR CUTTER

• Set the vehicle parking brake and chock the wheels to prevent accidental rolling.

• While the engine is running, slowly, engage blade control.

• In a safe environment, (i.e. no children or pets) allow blades to rotate and engine to

idle for 5 minutes, breaking in the belt for a longer life.

• Stop cutter.

FRONT TO BACK ADJUSTMENT

For best cutting results, the cutter deck should be parallel to the ground. To check parallel

adjustment, measure the distance from the bottom edge of the deck in both the front and rear of

the deck. This adjustment is best done while the tow vehicle and Trailcutter are connected.

• Remove bolt and nut from the “L” hitch (10388TK ).

• Raise or lower hitch section to obtain proper front to back adjustment.

• Connect bolt and nut in “L” hitch securely, Then rotate nut counter- clockwise ½

turn,“L” hitch should pivot freely.Bolt must go completely through nut ( but do not over

tighten). See figure – 2, page 11

CAUTION: SHUT OFF THE CUTTER ENGINE AND REMOVE SPARK

PLUG WIRE FROM SPARK PLUG BEFORE MAKING ANY

ADJUSTMENTS TO THE CUTTER.

STARTING THE ENGINE

See engine manufacturer’s recommendations for the type and amount of oil and fuel used.

• Make sure the tow vehicle parking brake is set, mower is level, and blades are

disengaged. Engine must be level to accurately check and fill oil. Do not overfill.

• Check spark plug wire, oil, and fuel.

• Check all electrical connections for build-up of debris.

• Set engine idle to “CHOKE” position.

• Turn key to the “RUN” position.

• Pull rope with a single fluid motion (for non 12V models only).

• (12V models only) Turn key to the “RUN” position, then to the “START” position.

• Set engine idle at maximum RPM for best performance.

• Allow engine to run a few moments before engaging blades.

CUTTER HEIGHT ADJUSTMENT

• There is approximately 4 inches of height adjustment.

• Rotate height adjust crank handle in a clockwise direction to lower the mower deck.

counter-clockwise direction to lift the mower deck.

• Dense areas of material should be cut twice.

• Push handle down to lock height position.

TOW HITCH OFFSET

• When offsetting the cutter do so to the side opposite the discharge of the tow

vehicle.

• Swisher recommends if the tow vehicle is equipped with a mid-mount mower to

overlap the cut approximately 6”. This may vary depending on mowing terrain,

obstacles, and/or tow vehicle. Always keep safety the first priority.

• Always keep the tow vehicle cutter raised higher than the Trailcutter

• To change the offsetting position both ball-lock pins should be removed (Figure

2). The hitches

will swivel around remaining bolts. Set hitches to desired positions and return ball-

lock pins, making

sure they go through the hitch tubing and the semi-circled hole patterned plates.

STARTING TO CUT

• Adjust the cutting height.

• Double check vehicle to cutter attachment.

• Start mower engine and set throttle to “FAST” for best cutting performance.

• Slowly engage T-handle lever. See figure-8 page 16

• Carefully mount tow vehicle and start mowing at a slow travel speed.

STOPPING THE CUTTING SESSION

• Bring tow vehicle to a complete stop, set the parking brake and disengage blades.

• Turn key switch to the “OFF” position.

• Always remember to remove keys to avoid irresponsible usage.

SUGGESTED CUTTING PRACTICES

• Operate cutter engine at full throttle to assure the best cutting performance and

maximum material discharge.

• Allow wet grass to dry. Wet grass will clump and collect under the mowing deck.

• Cutter should be started with tow vehicle in low gear and increased only as safe

mowing conditions permit. Cutting speed should not exceed 5 MPH.

• Cutting conditions and the types of grass will vary from place to place. You may

find when cutting dense areas that the pressure of the wheel tracks may cause the

grass to be pushed down and not effectively mowed. If this happens you may want

to mow the area twice. Once with the cutter raised and the second cutting at the

desired height. The second cutting should be at a right angle from the previous for

best results.

GENERAL RECOMMENDATIONS

The warranty on this cutter does not cover items that have been subjected to operator

abuse or negligence. To receive full value from the warranty, operator must maintain

unit as instructed in this manual.

Some adjustments will need to be made periodically to maintain your unit properly.

BEFORE EACH SEASON

A new spark plug and clean air filter assure proper air fuel mixture and help your engine

run better and last longer.

• Replace the spark plug.

• Clean or replace the air filter.

• Check blades and belts for wear.

BEFORE EACH USE

• Check engine oil level. (Do this twice to ensure an accurate reading.)

• Check condition of air filter and clean or replace if necessary.

• Check blade operation.

• Check for loose fasteners.

• Lubricate threads of adjustment rod P/N 4006 figure –3 page 12

DAILY MAINTENANCE

Make sure all nuts and bolts are tight and cotter pins and retainer springs are secure.

Keep blades sharp. Observe all safety precautions.

BLADE CARE AND SERVICE

For best results cutter blades must be kept sharp. The blades can be sharpened with a

few strokes of a file or grinding wheel. Do Not attempt to sharpen while on the cutter.

Important:

Replace blades that have been damaged or deeply nicked.

Important:

Check blade and spindle hardware on a regular basis to make sure

nuts are tight.

CAUTION: DO NOT HANDLE CUTTER BLADES WITH BARE HANDS.

CARELESS OR IMPROPER HANDLING MAY RESULT IN SERIOUS

INJURY.

CUTTER MAINTENANCE

• Reducing the travel speed will help cut dense growth. This allows the blades the

time necessary to make its initial cut, and regain momentum to continue cutting and

discharging debris properly. The engine may stall if you are mowing too fast!

• Do not attempt to cut areas that the tow vehicle cannot maneuver through and/or

slopes that you do not feel comfortable riding.

The unit is not cutting level.

• Level deck. Check air pressure of all tires; make sure they are equal. See

tires for maximum inflation.

• Without the engine running, make certain blades are installed identically.

The engine will not start.

• Disengage blades, turn key switch to the “OFF” position, check battery and

all other electrical connections and inspect spark plug and wire.

• Contact engine manufacturer or qualified mechanic.

Engine runs poorly.

• See engine manual.

• Check the throttle adjuster.

• Replace fuel, clean fuel filter and fuel line.

• Check spark plug and gap.

Cutter bounces excessively while towing.

• Lower tire pressure.

• Tow at a lower speed.

IF PROBLEMS PERSIST HAVE A QUALIFIED MECHANIC SERVICE

THE CUTTER. NEVER ATTEMPT TO MAKE AN ADJUSTMENT THAT

YOU ARE NOT SURE IS CORRECT. DOING SO CAN CAUSE OTHER

PROBLEMS.

GENERAL TROUBLESHOOTING

SAFETY AND OPERATIONAL DECALS

Replace decal immediately if damaged. Order by part number from

Swisher Mower and Machine Co. Inc. 1-800-222-8183,8-5 CT M-F

OD82-44 RUGGED CUT DECAL

OD29-DANGER DECAL

OD39-SWISHER FLAG DECAL

OD33-5MPH DECAL

OD36-DEFLECTOR DECAL

OD55-DANGER DECAL

OD45-WARNING DECAL

OD10-ENGAGE DECAL

OD99-OFF/RUN DECAL OD28-OFF/RUN/START DECAL

OD99161 QUADBOSS DECAL

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere QuadBoss Cutter Handbücher

QuadBoss

QuadBoss QBRT18552 Bedienungsanleitung

Beliebte Cutter Handbücher anderer Marken

Milwaukee

Milwaukee HEAVY DUTY M12 FCOT Bedienungsanleitung

Makita

Makita DCS552 Bedienungsanleitung

SignWarehouse.com

SignWarehouse.com Bobcat BA-60 Bedienungsanleitung

Makita

Makita 4112HS Bedienungsanleitung

GEISMAR STUMEC

GEISMAR STUMEC MTZ 350S Bedienungsanleitung

Hitachi

Hitachi CM 4SB2 Fehlerbehebungshandbuch

Dexter Laundry

Dexter Laundry 800ETC1-20030.1 Bedienungsanleitung

GCC Technologies

GCC Technologies AFJ-24S Bedienungsanleitung

DeWalt

DeWalt XR LI-ION DCS350N Bedienungsanleitung

Baudat

Baudat ES1 Bedienungsanleitung

Mafell

Mafell ZAF 200 Leitfaden

Makita

Makita 4100NH Bedienungsanleitung

Formax

Formax FD 574 Bedienungsanleitung

EINHELL

EINHELL TE-MA 1500 Bedienungsanleitung

Husqvarna

Husqvarna Cut-n-Break K 760 Bedienungsanleitung

CLEAN ROOM DEVICES

CLEAN ROOM DEVICES CRD130SS Bedienungsanleitung

TRI tool

TRI tool 301A Bedienungsanleitung

Roller

Roller King 1 1/4 Bedienungsanleitung
