Racal Instruments 1260-93 Bedienungsanleitung

1260 VXI

SWITCHING CARD

Model 1260-93

100MHz

MULTIPLEXER MODULE

PUBLICATION NO. 980673-026

RACAL INSTRUMENTS

Racal Instruments, Inc.

4 Goodyear St., Irvine, CA 92618-2002

Tel: (800) RACAL-ATE, (800) 722-2528, (949) 859-8999; FAX: (949) 859-7139

Racal Instruments, Ltd.

480 Bath Road, Slough, Berkshire, SL1 6BE, United Kingdom

Tel: +44 (0) 1628 604455; FAX: +44 (0) 1628 662017

Racal Systems Electronique S.A.

18 Avenue Dutartre, 78150 LeChesnay, France

Tel: +33 (1) 3923 2222; FAX: +33 (1) 3923 2225

Racal Systems Elettronica s.r.l.

Strada 2-Palazzo C4, 20090 Milanofiori Assago, Milan, Italy

Tel: +39 (0)2 5750 1796; FAX +39 (0)2 5750 1828

Racal Elektronik System GmbH.

Technologiepark Bergisch Gladbach, Friedrich-Ebert-Strasse, D-51429 Bergisch Gladbach, Germany

Tel.: +49 2204 8442 00; FAX: +49 2204 8442 19

Racal Australia Pty. Ltd.

3 Powells Road, Brookvale, NSW 2100, Australia

Tel: +612 9936 7000, FAX: +612 9936 7036

Racal Electronics Pte. Ltd.

26 Ayer Rajah Crescent, 04-06/07 Ayer Rajah Industrial Estate, Singapore 0513.

Tel: +65 7792200, FAX: +65 7785400

Racal Instruments, Ltd.

Unit 5, 25F., Mega Trade Center, No 1, Mei Wan Road, Tsuen Wan, Hong Kong, PRC

Tel: +852 2405 5500, FAX: +852 2416 4335

http://www.racalinstruments.com

PUBLICATION DATE: June 18, 2001

This book or parts thereof may not be reproduced in any form without written permission of the publisher.

WARRANTY STATEMENT

All Racal Instruments, Inc. products are designed and manufactured to exacting standards and in full

conformance to Racal’s ISO 9001 procedures.

For the specific terms of your standard warranty, or optional extended warranty or service agreement, contact

your Racal customer service advisor. Please have the following information available to facilitate service.

1. Product serial number

2. Product model number

3. Your company and contact information

You may contact your customer service advisor by:

E-Mail: Helpdesk@racalinstruments.com

Telephone: +1 800 722 3262 (USA)

+44(0) 8706 080134 (UK)

+852 2405 5500 (Hong Kong)

Fax: +1 949 859 7309 (USA)

+44(0) 1628 662017 (UK)

+852 2416 4335 (Hong Kong)

RETURN of PRODUCT

Authorization is required from Racal Instruments before you send us your product for service or calibration.

Call your nearest Racal Instruments support facility. A list is located on the last page of this manual. If you are

unsure where to call, contact Racal Instruments, Inc. Customer Support Department in Irvine, California, USA

at 1-800-722-3262 or 1-949-859-8999 or via fax at 1-949-859-7139. We can be reached at:

helpdesk@racalinstruments.com.

PROPRIETARY NOTICE

This document and the technical data herein disclosed, are proprietary to Racal Instruments, and shall not,

without express written permission of Racal Instruments, be used, in whole or in part to solicit quotations from

a competitive source or used for manufacture by anyone other than Racal Instruments. The information herein

has been developed at private expense, and may only be used for operation and maintenance reference

purposes or for purposes of engineering evaluation and incorporation into technical specifications and other

documents which specify procurement of products from Racal Instruments.

FOR YOUR SAFETY

Before undertaking any troubleshooting, maintenance or exploratory procedure, read carefully the

WARNINGS and CAUTION notices.

This equipment contains voltage hazardous to human life and safety, and is capable of inflicting

personal injury.

If this instrument is to be powered from the AC line (mains) through an autotransformer, ensure

the common connector is connected to the neutral (earth pole) of the power supply.

Before operating the unit, ensure the conductor (green wire) is connected to the ground (earth)

conductor of the power outlet. Do not use a two-conductor extension cord or a three-prong/two-

prong adapter. This will defeat the protective feature of the third conductor in the power cord.

Maintenance and calibration procedures sometimes call for operation of the unit with power

applied and protective covers removed. Read the procedures and heed warnings to avoid “live”

circuit points.

Before operating this instrument:

1. Ensure the instrument is configured to operate on the voltage at the power source. See

Installation Section.

2. Ensure the proper fuse is in place for the power source to operate.

3. Ensure all other devices connected to or in proximity to this instrument are properly grounded or

connected to the protective third-wire earth ground.

If the instrument:

- fails to operate satisfactorily

- shows visible damage

- has been stored under unfavorable conditions

- has sustained stress

Do not operate until performance is checked by qualified personnel.

This page was left intentionally blank.

User Manual 1260-93

NOTE FOR SYSTEMS WITH 1260-OPT 01T

The "Module-Specific Syntax" section of this manual shows the command syntax for the

1260-01S Smart Card. If you are using the newer 1260-01T Smart Card, the commands

will NOT work as shown.

Consult the 1260-01T Manual for a description of the commands that may be used with the

1260-01T Smart Card.

The channel numbers described in this manual are valid for the 1260-01T. The channel

numbers continue to be used for the 1260-01T.

The syntax of the commands that use channel numbers has changed for those cards

controlled by the 1260-01T.

The new syntax used to close a channel is:

CLOSE (@ <module address> (<channel>))

For example, with for a relay module whose <module address> is set to 7, closing

<channel> 0 is performed with the command:

CLOSE (@ 7 (0))

Using the older 1260-01 5, the command would be (as shown in this manual):

CLOSE 7.0

Many other command syntax differences exist. Please consult chapter 2 of the 1260-01T

manual for a description of the commands that are available for the 1260-01T.

User Manual 1260-93

2Addendum Page 6/98

Control Information for the 1260-93A

The following information describes the control-register-to-relay-channel mapping for a 1260-93A and Relay

Module. This information may be used to control a 1260-93A when using a 1260-01T in the register-based

mode of operation.

Each relay on this module is controlled by setting or clearing a single bit within a Control Register. Control

Registers on the module operate 8 channels simultaneously. There are eight control bits per Control

The table below shows the mapping from logical channels to control bits. The logical channels are used when

operating the relay module in message-based mode. The control bits within the Control Registers are used to

operate the module in register-based mode.

Each Control Register is located 2 addresses from the previous Control Register. That is, each Control

0is located at the "Base A24 Address" for the module. Consult the "Register-Based Operation" Section of

Chapter 2 of the 1260-01T manual for a description of calculating control register addresses.

Channel Control Register Control Bit

002

100

201

303

404

10 1 0

11 0 6

12 0 7

13 1 1

14 1 2

19 0 5

20 1 6

21 1 5

22 1 6

23 1 7

24 2 0

29 1 3

30 2 4

31 2 2

32 2 3

33 2 5

34 2 6

39 2 1

40 3 2

41 3 0

42 3 1

43 3 3

44 3 4

49 2 7

50 5 5

51 5 6

52 5 2

53 5 4

54 5 3

59 3 5

60 4 7

61 4 5

62 4 4

63 4 6

64 5 0

69 5 7

70 4 1

71 3 7

3Addendum Page 6/98

Channel Control Register Control Bit

72 3 6

73 4 0

74 4 2

79 5 1

80 6 3

81 6 1

82 6 0

83 6 2

84 6 4

89 4 3

90 7 1

91 6 7

92 6 6

93 7 0

94 7 2

99 6 5

100 7 6

101 7 4

102 7 5

103 7 7

104 8 0

109 7 3

110 8 4

111 8 2

112 8 3

113 8 5

114 8 6

119 8 1

120 9 2

121 9 0

122 9 1

123 9 3

124 9 4

129 8 7

130 10 0

131 9 6

132 9 7

133 10 1

134 10 2

139 9 5

140 10 6

141 10 4

142 10 5

143 10 7

144 11 0

149 10 3

150 11 4

151 11 2

152 11 3

153 11 5

154 11 6

159 11 1

User Manual 1260-93

4Addendum Page 6/98

Control Information for the 1260-93B

The following information describes the control-register-to-relay-channel mapping for a 1260-93B Relay

Module. This information may be used to control a 1260-93B when using a 1260-01T in the register-based

mode of operation.

Each relay on this module is controlled by setting or clearing a single bit within a Control Register. Control

Registers on the module operate 8 channels simultaneously. There are eight control bits per Control

The table below shows the mapping from logical channels to control bits. The logical channels are used when

operating the relay module in message-based mode. The control bits within the Control Registers are used to

operate the module in register-based mode.

Each Control Register is located 2 addresses from the previous Control Register. That is, each Control

0 is located at the "Base A24 Address" for the module. Consult the "Register-Based Operation" Section of

Chapter 2 of the 1260-01T manual for a description of calculating control register addresses.

Channel Control Register Control Bit

002

100

201

303

404

10 1 0

11 0 6

12 0 7

13 1 1

T4 1 2

19 0 5

20 1 6

21 1 5

22 1 6

23 1 7

24 2 0

29 1 3

30 2 4

31 2 2

32 2 3

33 2 5

34 2 6

39 2 1

40 3 2

41 3 0

42 3 1

43 3 3

44 3 4

49 2 7

50 5 5

51 5 6

52 5 2

53 5 4

54 5 3

59 3 5

60 4 7

61 4 5

62 4 4

63 4 6

64 5 0

69 5 7

70 4 1

71 3 7

5Addendum Page 6/98

Channel Control Register Control Bit

72 3 6

73 4 0

74 4 2

79 5 1

User Manual 1260-93

6Addendum Page 6/98

This page was left intentionally blank
