Installation Guide for RadioLabs USB Wifi Antennas/Adapters

v. 071510

2



PLEASEREADBEFOREATTEMPTINGINSTALLATION



ThankyouforpurchasingaRadioLabsUSBwirelessnetworkingproduct.Thisdocumentwillguideyou

throughthestepstoinstallthesoftwareordriversnecessaryforyourRadioLabsUSBWifiAntennaor

Adapteronyourcomputer.



Theseinstructionsarefor:



CaptiFi–HighPowerUSBWifiAntenna

WaveRv‐WirelessRvSolution(purchasedafterJune10th2009)

WaveMagnum‐HighPowerUSBWifi

O2Boost‐DirectionalUSBWifiAntenna

TheSeed–PlugandGoUSBWifiSystem

WaveRvMarine‐WirelessMarineSystem(purchasedafterMay28th2009)

O2Connect‐HighPowerDirectionalUSBPanel(purchasedafterMay28th2009)



ThisguideandtheincludedsoftwarearenotcompatiblewiththeWaveRVIILongRangeUSBAdapter.



PleasenotethatyouwillneedaUSB2.0porttoutilizeanyoftheRadioLabsUSBWifi

Adapters/Antennaslistedabove(mostnewer[post2004]PC’shaveUSB2.0portsasstandard

equipment).



InstallationInstructionsforWindowsPCs



TheWindowssoftwareincludedinthisCDor.ziparchiveiscompatiblewiththefollowingversionsof

Windows:



•Windows98SE

•WindowsMe

•Windows2000

•WindowsXP

•WindowsVista(32&64‐bit*)

•Windows7(32&64‐bit)



ThescreenshotsincludedinthisguidearefromtheWindowsXPversionofWindows.Pleasenotethat

thingsmayappearslightlydifferentonyoursystemdependingonyourversionofWindows.However,

theinstallationstepswillbesimilarregardlessofyourWindowsversion.



*ThefollowinginstructionsarenotcompatiblewithWindows64‐bitsystems.DriversareincludedwiththisCD

or.ziparchiveforWindows64‐bitsystems.However,theinstallationprogramandsoftwareutilityarenot

compatiblewith64‐bitsystems(i.e.WindowsVista64‐Bit).Instructionsforinstallationareincludedstartingon

page.10



3

Note:DonotinserttheUSBconnectorforyourRadioLabsUSBWifiAntenna/AdapterintoyourPC

untilprompted.



BeforeinstallingyourRadioLabsdevice,youwillneedtodisableordisconnectanywirelessdevices

currentlyoperatingonyourPC.Thisincludesintegratedwirelesscards,PCIadaptersorexternalUSB

adapters.



(ThisstepisnotnecessaryoncomputersrunningWindowsVista.Itis,however,recommendedtoavoid

confusionastowhichdevice’ssignalyouareviewingifusingthe“ConnecttoaNetworkfunction”to

viewandconnecttowirelessnetworks)



YourPCdoesnotneedanexistingwirelesscardorbuilt‐inwifiadaptertoutilizeanyRadioLabsUSB

WifiAntennaorAdapter.AllofRadioLabs’USBWifiAntennas/Adaptershaveabuilt‐inwirelesscard

thattakestheplaceofyourexistingwirelessnetworkconnection.



IfyourPCdoesnothaveaswitchtodisableyourinternalwirelesscardorexternalwifideviceto

disconnect,youwillneedtouse“NetworkConnections”todisabletheconnection.



WindowsXPUsers:



Click“Start”>“ControlPanel”>“NetworkConnections”



WindowsVistaUsers:



Click“Start”or“WindowsLogo”>“ControlPanel”>“NetworkAndSharingCenter”>“Manage

NetworkConnections”



OnceintheNetworkConnectionswindow,youneedtoselecttheWirelessNetworkConnection,right‐

clickandselect“Disable”.



Ifyouwishtouseyourinternalwirelesscardinthefuture,justrepeattheabovestepsandselect

“Enable”



4

Next,clickthebuttonintheRadioLabsInstallationWizardforyouroperatingsystem(WindowsXPor

Vista/Windows7).ThiswillruntheInstallShieldInstallationUtilityandinstallthe“RadioLabsUSB

WirelessLANUtilityandDriver”foryourRadioLabsUSBWifiAdapterorAntenna.



SelectyourpreferredlanguageandclickNext



SelectNexttocontinuetheinstallation.



5

ClickInstalltobegininstallingtheRadioLabsWirelessUSBUtility



Waitfortheinstallationwizardtoload…







6

ClickContinueAnywaytocontinueinstallation.

(Programmer’sNote:Thissoftwarewillnotimpairthecorrectoperationofyoursystem)



Installshieldisnowinstallingthenecessarydrivers.



SelectFinishtocompletethedriverinstallation.



Atthispoint,theRadioLabsWirelessUSBUtilityhasbeeninstalled.YoucannowinserttheUSB

connectoronyourRadioLabsUSBWifiAdapter/AntennaintoyourPC’sUSBport.

7

(IfyouhavetheWaveMagnumHighPowerUSBWifiAdapter,youwillneedtoconnecttheMini‐BUSB

endoftheincludedcabletotheWaveMagnumandthenconnectthelargerUSBconnectortoyourPC’s

USBport.)

Thismay(dependingonyouroperatingsystem)triggera“FoundNewHardware”Wizardwhichwill

promptyoutoinstalldriversspecificforyourdevice.Ifthisdoesnotappear,pleaseskiptopage9.

SelectNo,notthistimeandclickNext



SelectInstallfromalistofspecificlocation(Advanced)andclickNext



8

Makesurethat“Searchforthebestdriverintheselocations”and“Includethislocationinthesearch”

areselected,andthenclickNext



Thedriversoftwareisbeinginstalled…



ClickContinueAnywaytocontinueinstallation.



9



Thewizardiscompletingtheinstallation.



ThewizardhasfinishedinstallingyourdriversoftwareandyourRadioLabsUSBWifiAdapter/Antennais

readytouse.ClickFinishtocompletetheinstallationandclosetheFoundNewHardwarewizard.



YourRadioLabsUSBWifiAdapterorAntennaisnowinstalledandreadytouse.Pleaserefertothe

RadioLabsUSBDeviceUserManualforinstructionsonhowtousetheRadioLabsWirelessUSBUtility.



10

InstallationInstructionsforWindowsVista64‐bit

‐

Donotrunthesetup.exeinstallationprogram.Thesoftwareutilityisnotcompatiblewith64‐bit

systems.

Thisinstallationcanbedonetwoways.

1. Ifyouhaveanexistinginternetconnectiononthecomputeronwhichyouareinstallingthe

RadioLabsunit,makesureyouareconnectedtotheinternetandfollowtheinstructions

below.



a. PlugtheUSBconnectorintoanavailableUSB2.0portonyourPC(IfyouhavetheWave

Magnum,insertthesmallendoftheblackUSBcableintotheWaveMagnumandtheother

largerendintotheUSBportonthePC)

b. A“FoundNewHardware”wizardwillappearandaskifyouwantto“LocateandInstallDriver

Software”.Selectthisoption.

c. Selectthe“InstallDriverSoftwareAutomatically”andifprompted,allowtheWindowstosearch

onlinefordrivers.

d. ThewizardwillautomaticallydownloadandinstallthecorrectdriversforyourRadioLabsUSB

WifiAdapterorAntenna.

e. Oncefinished,youradapter/antennaisreadytouse.YoucanusetheWindows

“Connect/Disconnect”utility(inthesystemtray)toselectandconnecttoavailablewireless

signals.






