RaidSonic IB-864-B Bedienungsanleitung
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted. RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Makes the Computer More Sociable
Many peripherals can get in touch due to the multi-port
front panel. 60 memory cards fit and can be read. The
USB 3.0 port makes super fast data transfer possible.
That’s the future standard for multimedia.
Key features
• Fits into a standard 3.5" drive bay
• 6x card reader slot
•Supports more than 60 memory cards
• 4x USB 2.0, 2x USB 3.0 and 1x eSATA interface
• OS independent
IB-864-B
3.5" Card Reader with
multiport front panel
Technical data
Model IB-864-B
Article No. 20064
EAN code 4250078184980
Brand ICY BOX
Article text 3.5" Card Reader with
multiport front panel
Colour Black
Material Plastic
Required space 1x 3.5"
Memory card support Generic type of cards:
xD, SD, SDHC, SDXC, MMC,
RS MMC, MicroSD, CFI, CFII,
MD, MS, MS Pro, MS Pro Duo, M2
External data interface/
Front port 3x USB 2.0, 1x USB 3.0, 1x eSATA,
6x card reader slot
Operating system OS independent
Transfer rate USB 2.0 up to 480 Mbit/s
USB 3.0 up to 5 Gbit/s
eSATA up to 3 Gbit/s
Power switch No
LED Power and access
Power connector Big-4Pin Molex
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted. RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Packing content: 1x IB-864-B, 1x USB 3.0 bracket, 1x screw set, 1x manual
NOTE: For using the USB 3.0 port, an external USB 3.0
port at the mainboard or an USB 3.0 PCI-X extension card
is required.
Logistical data
Packing unit: 10 pcs./carton Dimension/Carton: 385x290x220 mm Import tax: 84733080
Total weight: 5.4 kg/carton Dimension (with packing): 198x140x74 mm
Gross weight: 0.483 kg Dimension of article: 102x24.5x119 mm
Net weight: 0.285 kg Country of Origin: China
1.
2.
3.
4.
6.
5.
Connection IB-864-B:
USB 3.0: External to the mainboard or
USB 3.0 PCI-X extension card
via USB 3.0 cable
USB 2.0 hub and
card reader: Internal to the mainboard
via USB 2.0 cable
eSATA: Internal to the mainboard
via SATA cable
Power: Internal to the system power
supply via Big-4Pin Molex
1. USB 2.0 hub (3x USB 2.0 interface)
2. 1x eSATA interface
3. 1x USB 3.0 interfacee
4. Card reader slot (6x)
5. LED Power
6. LED Access
