Raritan DOMINION KSX - Bedienungsanleitung
Remote Office Management …
KVM and Serial access in one box
The Dominion KSX difference
Dominion KSX is the first hardware-based, integrated solution to
provide remote KVM access, serial device management and power
control in a single unit. With Dominion KSX, it's as if you are
physically present at the branch office. Unlike remote control
software solutions, Dominion KSX provides:
"One consolidated view of all IT equipment deployed at branch
office locations
"A single, platform-independent solution offering centralized,
integrated and secure control
"Network-independent access via a built-in modem for emergency
access even when the network is down
"BIOS-level control of KVM equipment and console-level control
of serial devices
Secure, remote, out-of-band access and power control
of up to 16 servers and other network devices over IP
Raritan's Dominion KSX is designed specifically to make the
management of your IT infrastructure at branch locations easier,
faster, safer and more cost-effective. This innovative device combines
secure console-level access and cold-start power control of everything
in your server closets. This means from anywhere you access the Web,
you can directly access, troubleshoot and even reboot all of your remote
equipment including:
"Domain Servers "Serial IT Equipment
"Security Interfaces "File/Print Servers
"Switches "Application Servers
"Headless Servers "Routers
"Load Balancers "Network Appliances
"Firewalls "Environmental Control
Dominion KSX Series
An unprecedented combination
of remote KVM and Serial
access in one box.
Dominion KSX 440
4 Serial Ports and 4 KVM Ports
Dominion KSX 880
8 Serial Ports and 8 KVM Ports
DominionTM KSX
www.raritan.com
Simplicity
Smart engineering translates into ease of use with:
"A single consolidated view of all servers and
other IT devices from one screen — via a web
browser; no additional software is required
"A single sign-on and single interface providing
easy access to servers and other network devices
"A built-in modem for essential emergency access
in the event of a network outage
"Point and click or command-line control of
devices
"Secure, centralized monitoring and notification
"Easy ‘Plug and Play’ installation and operation
"Convenient flash upgrades
Performance
Dominion KSX includes the features you need
for superior performance:
"High performance over low bandwidth
connections including modem, wireless,
cable, DSL and fractional T/1
"A video compression algorithm and powerful
frame-grabber technology to ensure the fastest
possible transmission of high quality video
"Tight mouse synchronization that reduces
latency, the tedious wait for key strokes and mouse-
movements to catch up with your commands
"Built-in serial port buffering to provide views of
recent console history, assisting in debugging
and, ultimately, reducing downtime
Security
Dominion KSX provides bulletproof security via:
"SSL 128-bit RSA public key, 128-bit private
key encryption
"User authentication with RADIUS support
"Use of only one additional network port to
preserve strict firewall settings
"Customizable user profiles
"User event logging
"Ability to deactivate modem and/or browser access
Anytime, anywhere access and control.
Sun Server
Windows or Linux Servers
Intrusion Alarm/HVAC
Router/Switch
PBX
PSTN
TCP/IP
Headless Server,
POS Server
Power Strip Category 5, 5e or 6 UTP cables
RJ11
Coaxial cable (CCPTxx)
Secure console level management and cold start power.
ROI
Dominion KSX pays for itself quickly by:
"Reducing costly administration of on-call
labor and outsourced service providers
"Slashing expensive down time by providing
network-independent access in emergencies
"Eliminating expensive and inconvenient
travel to remote locations
"Leveraging the centralized expertise of
IT managers, regardless of their locations
"Replacing multiple software solutions with
one single hardware solution — increasing
efficiency and saving valuable IT staff time
Features
"Built-in modem
"Dedicated power control port
"‘Plug and Play’ — no software required
"Local port for rack access
"1U Rack mountable
"Multi-platform PS/2, Sun and USB servers
"64k buffering per serial port
"SSL 128-bit encryption
"KVM console ports — choose from 4 or 8
"Serial Ports — choose from 4 or 8
Raritan Computer, Inc., founded in 1985, is the leading provider of KVM (keyboard/video/mouse) and remote management solutions for access and
control of servers and other network devices. With 18 consecutive years of profitable growth and technical innovation, Raritan makes products that
are used to control millions of servers at more than 35.000 network data centers, computer test labs, and multi-workstation environments around
the world. From the small business to the enterprise, Raritan’s complete line of compatible and scalable KVM and remote connectivity products offers
IT professionals the most reliable, flexible, and secure out of band solutions to manage data center equipment, while improving operational productivity.
When you’re ready to take control,
do it with Raritan’s Dominion KSX.
Call +31-10-2844040
or visit www.raritan.com.
A single sign-on and single interface provides one consolidated view
of all servers and IT devices at each remote office:
"No additional software is required
"Simple point and click management
"Single, fail-safe solution
One Consolidated View
Specs
Dominion KSX 880
Form Factor 1U, full width, rack mountable
Dimensions 44mm (H) x 440mm (W) x 540mm (D)
Weight 11kg
Power 110/240V auto-switching; 50-60 Hz
KVM Ports 8
Serial Ports 8
Admin Port PS/2 Keyboard; VGA Video
Environmental Requirements
Operating Temperature 0°C to 40°C
Remote Connection
Network 10/100 Ethernet (RJ45)
Modem Integrated 56K V.90 (RJ11 port)
Protocols TCP/IP, UDP, RADIUS, SNMP, SNTP
DHCP, PAP, CHAP, HTTP, HTTPS
Screen Resolutions
PC text mode 720x400
PC graphic modes 640x480, 800x600, 1024x768,
1152x864, 1280x1024
Sun®video modes 1024x768, 1152x900, 1280x1024
Warranty
Standard Two Years
Dominion KSX 440
Form Factor 1U, full width, rack mountable
Dimensions 44mm (H) x 440mm (W) x 540mm (D)
Weight 11kg
Power 110/240V auto-switching; 50-60 Hz
KVM Ports 4
Serial Ports 4
Admin Port PS/2 Keyboard; VGA Video
Environmental Requirements
Operating Temperature 0°C to 40°C
Remote Connection
Network 10/100 Ethernet (RJ45)
Modem Integrated 56K V.90 (RJ11 port)
Protocols TCP/IP, UDP, RADIUS, SNMP, SNTP
DHCP, PAP, CHAP, HTTP, HTTPS
Screen Resolutions
PC text mode 720x400
PC graphic modes 640x480, 800x600, 1024x768,
1152x864, 1280x1024
Sun®video modes 1024x768, 1152x900, 1280x1024
Warranty
Standard Two Years
Raritan is a registered trademark of Raritan Computer, Inc. Dominion is a trademark of Raritan Computer, Inc. Sun is a registered trademark of Sun Microsystems, Inc.
KSX (front view)
KSX 880 (rear view)
Ethernet Access
Dedicated
Power Control
Integrated Modem
Built-In 4 or 8 Serial Ports Built-In 4 or 8 KVM Ports
Admin Port
Raritan Computer Europe B.V. The Netherlands +31-(0)10-2844040
[email protected] www.raritan.com
