As a growing small or medium-sized business, the key to your success lies in being able to

quickly and effectively react to situations that disrupt your company’s uptime. With

the expreZo EZswitch, you can access and control computers that require remote rebooting

or troubleshooting, ensuring business continuity and minimizing expensive travel costs.

EZswitch Combo KVM Series

• Easy to install and setup

• All-in-one compact design

• Video resolution support of up to 2048 x 1536

• PS/2 and USB ports (keyboard and mouse) for local access

by Raritan®

800.724.8090 / +1 732.764.8886 / Fax +1 732.764.8887 / [email protected]

How well is your business equipped for a disruption in IT operations?

by Raritan

8- and 16-port Combo KVM Switch

Features

• Connect computers via PS/2 and/or USB.

• Supports Windows, Linux, Mac OS9/OSX, Sun Microsystems.

• On-Screen-Display (OSD) & Cascade Chain functions.

• OSD with intuitive menus for quick and effective navigation.

• Daisy chain switches to control up to 4096 PCs (16-Port)

from a single console. Cascaded units do not need special

configuration.

• Hot-pluggable: all devices connected to expreZo can be added

or removed at any time without shutting down the devices.

• Easily switch between connected devices with:

- Hardware Push Button,

- Hot-Keys on PS/2 and/or USB keyboard,

- OSD menu.

• Auto Scan video for effortless monitoring.

• Supports LED display for PC and/or server status monitoring.

• Supports video resolutions up to 2048 x 1536.

• Enable/disable beeper during channel switching.

• Supports tiering with Dominion KX2 models.

• Rack mountable in 19” rack (1U).

• Firmware is upgradeable via a mini-USB port.

System Requirements

Local Console

Supports VGA, SVGA, Multisync monitor high

resolution video - 2048x1536.

PS/2 and/or USB Keyboard/Mouse.

Computer or Server

PCs must support:

- VGA, SVGA or Multisync card.

- Type A USB port or mini-DIN 6 pin PS/2

keyboard and mouse.

Cables

Custom 4-in-1 cables included

in the product package.

Specification

Models: EZ-108 (8-port) / EZ-116 (16-port)

Selection Method Push Button and Hot-Key (PS/2 / USB Keyboard)

Or On-Screen-Display (OSD)

LEDs Red for PC Selection

Green for PC On-Line ready

KVM Ports Video 8/16 x HDB-15 female

(KB/MS) (PS/2 & USB signal combined)

Console Ports Keyboard 1 x 6 pin mini-DIN female

Mouse 1 x 6 pin mini-DIN female

Video 1 x HDB-15 female

Keyboard 1 x USB – A type female

Mouse 1 x USB – A type female

Auto-Scan Interval Adjustable time setting by OSD menu driven

DDC, DDC2 monitor Max. Resolution up to 2048x1536@65Hz

Hot Swappable Yes

Operating systems supported Windows 98SE/ME/2000/XP/2003/Vista/7 Server,

Linux, Mac OS9/OSX and Sun Microsystems.

Power External power adapter, DC 5V, 2.0A

Dimensions (L X W X H) 44 x 15.7 x 4.5 cm (17.3 x 6.1 x 1.5 inch)

Unit Weight 1750g / 1900g

Housing material Metal

Operating Temperature 32~122°F (0~ 50°C)

Humidity 0%~80%RH

Firmware upgrade port Mini USB female

EZswitch series

Visit Raritan.com/products/analog-kvm/expreZo

its wholly-owned subsidiaries. All others are registered trademarks or trademarks of their respective owners.

Raritan Inc. / 400 Cottontail Lane / Somerset, NJ 08873 / USA / Raritan.com
